D-Link DKVM-4K - KVM Switch Manuel utilisateur

4-Port PS2 KVM Switch

DKVM-4K

This product works with

all Windows Operating

Systems

Check Your Package Contents

These are the items included with your purchase:

Before You Begin

You must have at least the following:

• PS/2 Keyboard

• PS/2 Mouse

• VGA or Higher Monitor

respective holders. Software and specications subject to change without notice.

•DKVM-4K KVM Switch

•2 sets 3-in-1 KVM Cable in 6 ft

If any of the above items are missing, please contact your reseller.

Installing the DKVM-4K

Attach your 6-pin PS/2 mouse

connector to the console mouse

port of DKVM-4K.

Attach your monitor’s HDDB 15

VGA connector to the console port

of the DKVM-4K.

Attach your 6-pin PS/2 keyboard

connector to the console

keyboard port of DKVM-4K.

Make sure that all your computers are turned OFF before installing

the DKVM-4K to avoid mouse and keyboard errors when booting up

your computers.

Installing the DKVM-4K

Attach the KVM cable (VGA

Connector) to the VGA port

located on the DKVM-4K.

Attach the KVM cable(Keyboard

Connector) to the PS/2 keyboard

port located on the DKVM-4K.

Attach the KVM cable(Mouse

Connector) to the PS/2 mouse

port located on the DKVM-4K.

The following steps apply to the four computers that you are using with your

DKVM-4K.

Installing the DKVM-4K

Attach the KVM cable (VGA

Connector) to the VGA port

located on the back of your

computer case.

Attach the KVM cable(Mouse

Connector) to the PS/2 mouse

port located on the back of your

computer case.

Attach the KVM cable(Keyboard

Connector) to the PS/2 keyboard

port located on the back of your

computer case.

Note: Repeat the above steps for the remainder of the PCs

Type A

Power ON all your attached computers after you have

completed the DKVM-4K installation.

Switching with the DKVM-4K

The DKVM-4K features a Select Button located on the upper case and keyboard Hot

Keys to switch quickly and easily.

Select

Button

You can also conveniently command KVM to switch ports through simple key sequences.

Press the Scroll Lock key twice with-in 2 seconds to enter Hot Key switching

mode. A beep conrms that the Hot Key mode is activated.

Switching with the DKVM-4K

Hot Key Menu

Scroll Lock + Scroll Lock + : Switches Previous Channel.

Scroll Lock + Scroll Lock + : Switches Next Channel.

Scroll Lock + Scroll Lock + 1 : Switches to PC 1.

Scroll Lock + Scroll Lock + 2 : Switches to PC 2.

Scroll Lock + Scroll Lock + 3 : Switches to PC 3.

Scroll Lock + Scroll Lock + 4 : Switches to PC 4.

Scroll Lock + Scroll Lock + S : Activates Auto Scan Mode. Each

computer will be scanned every 10 seconds.

Scroll Lock + Scroll Lock + B : Beeper ON /OFF

To get out of Auto Scan Mode, Press any key or SPACE bar.

Troubleshooting Tips

Keyboard

If your keyboard is not functional, not detected, or there is a keyboard error on boot-

up, check the following:

• Make sure that the keyboard is properly connected to the

computer and to the DKVM-4K. Check that the keyboard is plugged into the

correct PS/2 keyboard port and not the PS/2 mouse port.

• Verify that the keyboard works when plugged into the computer directly. You

will have to shut down your computer rst to do this.

• Read your motherboard documentation and make sure that the PS/2

keyboard’s IRQ is enabled. This can be set for most computers in the

BIOS setup.

• Try using a different keyboard.

Mouse

If your mouse is not functional, not detected, or there is a mouse error on boot-up,

check the following:

• Make sure that the mouse is properly connected to the

computer and to the DKVM-4K. Check that mouse is plugged into the

correct PS/2 mouse port and not the PS/2 keyboard port.

• Verify that the mouse works when plugged into the computer directly. You

will have to shut down your computer rst to do this.

• Read your motherboard documentation and make sure that the PS/2

mouse’s IRQ is enabled. This can be set for most computers in the

BIOS setup.

• Try using a different mouse.

• If mouse movement is random when switching between computers, try

shutting down your computer and rebooting.

• Verify that your computers do not have more than one mouse driver installed

(check your cong.sys and autoexec.bat les for Windows) and that you are

using the latest mouse driver.

• If a special mouse is used such as a cordless or scrolling mouse, make sure

you use generic PS/2 mouse drivers. A non-standard PS/2 mouse may have

extensions on the PS/2 protocol that are not supported by the DKVM-4K.

• Do not move the mouse or press any mouse buttons when switching from one

PC to another.

• Try resetting the mouse by unplugging it from the DKVM-4K for about 3

seconds and reconnecting.

Video

If the image on your monitor is not clear, check the following:

• Verify that all video monitor cables are inserted properly.

• Try lowering the resolution and refresh rate of your monitor.

• Try using a shorter video cable.

Technical Support

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Australia:

Tel: 1300-766-868

Monday to Friday 8:00am to 8:00pm EST

Saturday 9:00am to 1:00pm EST

http://www.dlink.com.au

e-mail: [email protected]

India:

Tel: 1800-222-002

Monday to Friday 9:30AM to 7:00PM

http://www.dlink.co.in/support/productsupport.aspx

Indonesia, Malaysia, Singapore and Thailand:

Tel: +62-21-5731610 (Indonesia)

Tel: 1800-882-880 (Malaysia)

Tel: +65 66229355 (Singapore)

Tel: +66-2-719-8978/9 (Thailand)

Monday to Friday 9:00am to 6:00pm

http://www.dlink.com.sg/support/

e-mail: [email protected]

Korea:

Tel: +82-2-890-5496

Monday to Friday 9:00am to 6:00pm

http://www.d-link.co.kr

e-mail: [email protected]

New Zealand:

Tel: 0800-900-900

Monday to Friday 8:30am to 8:30pm

Saturday 9:00am to 5:00pm

http://www.dlink.co.nz

e-mail: [email protected]

Technical Support

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Egypt:

Tel: +202-2919035 or +202-2919047

Sunday to Thursday 9:00am to 5:00pm

http://support.dlink-me.com

e-mail: [email protected]

Iran:

Tel: +98-21-88822613

Sunday to Thursday 9:00am to 6:00pm

http://support.dlink-me.com

e-mail: [email protected]

Israel:

Tel: +972-9-9715701

Sunday to Thursday 9:00am to 5:00pm

http://www.dlink.co.il/support/

e-mail: [email protected]

Pakistan:

Tel: +92-21-4548158 or +92-21-4548310

Sunday to Thursday 9:00am to 6:00pm

http://support.dlink-me.com

e-mail: [email protected]

South Africa and Sub Sahara Region:

Tel: +27-12-665-2165

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South Africa Time

http://www.d-link.co.za

Turkey:

Tel: +90-212-2895659

Monday to Friday 9:00am to 6:00pm

http://www.dlink.com.tr

e-mail: [email protected]

U.A.E and North Africa:

Tel: +971-4-391-6480 (U.A.E)

Sunday to Wednesday 9:00am to 6:00pm GMT+4

Thursday 9:00am to 1:00pm GMT+4

http://support.dlink-me.com

e-mail: [email protected]
