D-Link Securicam Network DCS-2000 Manuel utilisateur

Check Your Package Contents

These are the items included with your purchase:

If any of the below items are missing, please contact your reseller.

BeforeYou Begin

You must have at least the following:

•Windows XP/2000/Me/98SE

• EthernetAdapter

•CD-ROMDrive

DCS-2000

This product can be set up

using Internet Explorer 5.x

or above Home Security

Internet Camera

respective holders. Software and specifications subject to change without notice. DCS-2000.04262004

Using a power supply

with a different voltage

rating will damage this

productandvoidthewarranty.

DCS-2000 InternetCamera

Camera Stand and Bracket

AC PowerAdapter

Category5EthernetCable

InstallationCD(containingDrivers,

Software,QuickInstallationGuide

andManual)

Hardware Installation

System Requirements

• Internet Explorer 5.x or above

• CPU:PentiumIII,800MHzorabove(RequiredforusewithIPSurveillancesoftware)

• MemorySize:128MB(256MBrecommended)

• VGAcard resolution: 800x600 or above

Connect the Ethernet Cable

Connect an Ethernet cable to the Ethernet connector

locatedon theInternet Camera’sback panel and attach

it to the network.

Attach the External Power Supply

Attach the external power supply to the DC power input

connector located on the Internet Camera’s back panel

(labeled DC 12V) and connect it to anAC power outlet.

When you have a proper connection, the LED (Light Emitting Diode) will turn from red to

green. The light may blink on and off and your computer may show an intermittant loss of

connectivityifitis connecteddirectlytothecamera.Thisisnormaluntilyouhaveconfigured

yourcamera.

Ifyou connectthis cameradirectly to

a PC, you will need a cross-over

Ethernet cable. If you plug the camera into a

huborrouter,you willbeableto use thecable

includedwith yourcamera.

Powersourceis confirmedwhen

the LED Power Indicator on the

InternetCamerais illuminated.

Configuring your camera with IP

Installer

This is the first screen that will appear.

Insertthe DCS-2000 CDintothe

CD-ROMdrive.

Click on Install Software

If the IP installer does not display any

devices, lightly insert a paper clip into the

reset opening on the unit’s rear panel until

the light starts to cycle (a series of blinks)

twice, then let go.

Click on IP Installer

Configuring your camera with IP

Installer (continued)

Highlightthe MACaddress 4

The IP Installer will now show a MAC

address of the DCS-2000 and an IP

Address (which may or may not be

correct depending on what you have

your DCS-2000 connected to.) If you

havea DHCP* serveron yournetwork,

avalidIPAddresswillbedisplayedhere.

*ADHCPserverisadevicethat

supplies IP Addresses to its

clients that are on the same network.

Configuring your camera with IP

Installer (continued)

This page will now show the IP Address

assigned to the MAC address of the

DCS-2000.

After you click on the Link but-

ton, IP Installer will automati-

callyopenyourInternetbrowser

to the IP Address of the DCS-

2000,inthisexampleitis:http:/

/192.168.0.100.YourDCS-2000

mayhaveadifferentIPAddress.

HighlightedMACaddress

Click Link

UPnPisshortforUniversalPlugandPlay,whichisanetworkingarchitecturethat provides

compatibilityamongnetworkingequipment, software,andperipherals.The DCS-2000 is

aUPnP enabledinternet camera. If your operatingsystem isUPnP enabled, the device

will be easier to configure. If you do not want to use the UPnP functionality, it can be

disabledbyunselecting “Enabled”on theDDNS/UPnPsettings pageunder “Advanced”

in the configuration menu. Use the following steps to enable UPnP (Universal Plug and

Play) settings only if you are running Windows XP/Me. If you are running Windows 98/

2000,UPnP isnot available.

Enabling UPnP for Windows XP/Me

Click Add or Remove

Programs

Go to Start > Settings

Click Control Panel

Enabling UPnP for Windows XP/Me

(continued)

Select Universal

Plug and Play

Click Ok

Thefollowingscreenwillappear:

Click Details

Click Add/Remove

Windows Components

Select Networking Services

(CommunicationsinWindowsMe)

Enabling UPnP for Windows XP/Me

(continued)

Click Finish

Please wait while Setup

configures the components.

Click Next

(Note: Screen shots are taken in Windows XP, similar screens will appear in Windows Me.)

Enabling UPnP for Windows XP/Me

(continued)

ClickDCS-2000-100

The last three digits (100),

representthe fourthoctetofyour

Internet Camera’s IP address

(inthisexample,198.168.0.100).

AfteryouclickontheDCS-2000-

100 icon, your Internet browser

will automatically be opened to

theIPAddressofthe DCS-2000,

in this example it is: http://

192.168.0.100.YourDCS-2000

mayhaveadifferentIPAddress.

Click My Network Places

Toview yourDCS-2000 Internet

Camera in an Internet browser,

goto yourDesktop andclick My

Network Places.

Setting a Password

Clickon the Configuration

buttonon the Homepage:

There are five tabs across the top of the Configuration screen. Each tab displays

different configuration elements of the DCS-2000. The Advanced tab is the default

screen in Configuration and Network is the default selection under Advanced.

ClickConfiguration

Anychangesmadetothesesettingswill

requirethesystemtorestart tovalidate.

Makesure everyfield iscorrectly typed

beforeclicking on Apply.

Uncheck the option

Reset IP address at

nextboot.
