DCS-935L

Quick Install Guide

HD Wi-Fi Camera

If any of the above items are missing, please contact your reseller.

Minimum Requirements

DCS-935L HD Wi-Fi Camera

Wall Mount Kit

Package Contents

• A wireless router (802.11ac/n/g) with Internet service

• An e-mail account (required to create a mydlink® account)

Network Device and Service

Power Adapter

• Wireless 802.11ac/n/g network

(Wireless AC network recommended for optimum performance)

Quick Install Guide

Mobile Device

• iPhone, iPad, or Android smartphone or tablet

(Refer to the mobile app’s store page to see if your device is compatible)

Quick Install Card

Product Overview

Back

Reset Button

MicroUSB Power

Connector Power LED

WPS LED

& Button

Direct LED

& Button

Front

Camera Lens

IR LEDs

Camera Stand

Microphone

Light Sensor

ENGLISH

Setting Up Your Camera

Please follow the instructions below to set up your mydlink camera.

Congratulations, your DCS-935L is now ready to use! Be sure to check the

support.dlink.com website periodically for the latest rmware updates to keep

your product up to date with the latest features.

Note: If you experience issues registering this camera with your mydlink account, or if you

purchased an open box or resold unit, perform a hard reset by pressing and holding the reset

button on the device for 10 seconds while the device is powered on. If you are returning the

device to the place of purchase, please perform the hard reset procedure to clear the

device of any personal data.

On your mobile device, download mydlink Home by going to

mydlinkhomeapp.dlink.com, or by searching for mydlink Home in the

iTunes App Store or Google Play.

3After logging in, tap the Settings icon in the top-left corner, select

Add New Device, and follow the instructions.

When you are asked to scan a QR code, use the code on the Quick Install

Card in your package, or on the label attached to your device.

Launch the mydlink Home app and create a new account or sign in to

your existing account.

iOS: If you are asked about allowing the app to

access your location, select Allow.

Android: Make sure location services are turned on

in your phone’s settings.

Mounting the Camera

Please refer to the steps below to assist you with mounting the camera.

We suggest that you congure the camera before mounting.

1. Use a pencil to mark two points on the wall or

ceiling that are 40 mm (1.6 in) apart. Use a 6 mm

drill bit to drill the holes where you marked.

The holes should be 25 mm deep (about 1 in

deep). Insert the screws into the holes. When

you tighten the screws, leave 2 mm for tting

the mounting base over the screw-heads.

2. Place the mounting base over the screws that

are inserted in the wall or ceiling. Make sure to

t the screw-heads over the big holes in the

base, and slide the mounting base downward

to lock it rmly in place. Lightly pull the base

forward to make sure that it is locked. Adjust

the angle of the camera as needed.

Note: If the wall is made out of concrete, before inserting the screws, insert

the provided plastic anchors to support the screws.

ENGLISH

1. What is a mydlink No.? What is it used for?

Each camera has a unique eight-digit mydlink No. which will be shown on the

label on the back of your camera. This eight-digit number identies your device,

and is required to add your device to your mydlink account.

2. What can I do if my camera is not working correctly?

• To make sure your hardware is installed correctly, check to see if:

- the power LED is lit solid green

- your Internet connection is working

- your router’s wireless & WAN connections are okay

- your router supports UPnP®

- your mobile device is currently on the same wireless network as your camera

- both your mobile device and camera have a working Internet connection

• If your camera is still not working, check your router and make sure it has the

latest rmware.

3. What can I do if I forget my password?

If you forget your password, you must reset the

camera. Unfortunately, this process will change

your settings back to factory default and remove

it from your account. To reset the camera, locate

the reset button on the back of the camera. With

the camera powered on, use an unfolded paper

clip to hold the button down for 10 seconds. Once

the camera restarts, follow the steps in this guide

to set up your camera again.

4. Why is there a white haze when viewing in night vision mode?

When viewing in night vision mode, the IR lights on the camera may be reecting

o a nearby surface. Try repositioning the camera in order to avoid glare from

IR LEDs.

5. Can I use my DCS-935L as a portable camera?

Yes, to use the DCS-935L as a portable camera, you can power the camera with

a portable battery that supplies 5V/2A of power.

FAQs

Reset

Button

Technical Support

This guide is only for initial conguration. Please refer to the user manual to learn

more or visit http://www.mydlink.com for more information. Also feel free to

through our website.

http://support.dlink.com

USA

Ver. 1.02(NA)_90x130

March 20, 2015

29072600935LA17

other third party marks mentioned herein may be trademarks of their respective owners. Maximum wireless signal rate

derived from IEEE Standard 802.11ac, 802.11g, and 802.11n specications. Actual data throughput will vary. Network

conditions and environmental factors, including volume of network trac, building materials and construction, and

network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal

range. Product specications, size and shape are subject to change without notice, and actual product appearance may

dier from that depicted on the packaging. This publication may not be reproduced, in whole or in part, without prior

express written permission from D-Link Systems, Inc.

Canada

http://support.dlink.ca
