QUICK

INSTALLATION

GUIDE

HD OUTDOOR CLOUD CAMERA

DCS-7010L

КРАТКОЕ РУКОВОДСТВО ПО УСТАНОВКЕ

GUÍA DE INSTALACIÓN RÁPIDA

GUIA DE INSTALAÇÃO RÁPIDA

快速安裝指南

PETUNJUK PEMASANGAN CEPAT

ENGLISH

Package Contents

Minimum Requirements

Computer with:

• PC with 1.3 GHz or above and at least 128 MB RAM

• Windows® 8, Windows® 7, Vista® or XP (32-bit or 64-bit)

• Mac OS® X 10.6 or higher

Web Browser:

• Internet Explorer® 7, Firefox 12, Safari 4, or Chrome 20 and above

• Installed and enabled Java and ActiveX® controls

Network Device and Service:

• A router (A D-Link Cloud Router is recommended)

• An Internet connection

• An e-mail account (Required to register mydlink service)

CAT5 Ethernet Cable

DCS-7010L HD Outdoor Cloud Camera

CD-ROM with User Manual and Software

If any of the above items are missing, please contact your reseller.

Power Adapter

ENGLISH

From any computer, open a web browser, go to

http://www.mydlink.com and log in to your account.

Click on the device name when the new device

notication appears to add the camera to

your account.

Connect the power cable and Ethernet cable

to your cloud camera.

Connect the other end of the Ethernet cable

to your D-Link Cloud Router and connect

the camera’s power adapter to a power

outlet.

Setting up your Camera

Using a D-Link Cloud Router (Zero Conguration)

If you have a D-Link Cloud Router, you can take advantage of Zero

Conguration Setup. This feature automatically congures your camera’s

settings for you and adds it to your mydlink account automatically. If you

do not have a D-Link Cloud router, refer to the next page to install and

congure your camera.

DCS-7010L

ENGLISH

Using the Installation Wizard

If you do not have a D-Link Cloud Router, you can simply use any Windows

or Mac computer to go through the Installation Wizard from the CD, which

will guide you through the installation process from connecting your

hardware to conguring your camera.

• Windows Users - Insert the CD. Simply click Set up your Cloud

Camera to go through the Setup Wizard. If the Setup Wizard program

does not automatically start on your computer, go to Start > Run. In

the run box type D:\autorun.exe (where D: represents the drive letter

of your CD-ROM drive) and click OK.

• Mac Users - Insert the CD. On the desktop, open your CD drive,

double-click on the SetupWizard le, wait about 20-30 seconds, and

follow the instructions.

If you do not have a CD-ROM drive, or the CD is missing,

please download the Setup Wizard from

http://www.mydlink.com/support

ENGLISH

Getting Started with mydlink

mydlink is a web-based service which allows you to view and control your

mydlink-enabled devices through any computer connected to the Internet.

If you have cameras linked to your mydlink account, you will be able to see

their live views using the mydlink website. Follow the instructions below to

access your mydlink account.

• Open a web browser on any computer connected to the Internet.

• Type http://www.mydlink.com in the address bar and press Enter.

• Sign in using your mydlink account.

• From the home screen, you will be able to view all devices which have

been linked to your mydlink account.

• Ensure that your browser supports both Java and ActiveX, and that these

features have been installed and enabled.

• Windows does not have Java installed by default. You can download the latest

version from http://www.java.com.

• In Mac OS X 10.7.x, Java applets are disabled by default. To enable Java applets,

click the Finder > Applications > Utilities > Java Preferences and check the

Enable applet plug-in and Web Start applications option.

• The ActiveX® controls in IE will install automatically if needed. We suggest that

you make sure that you have enabled the related options in Tools > Internet

Options > Security > Custom Level.

ENGLISH

Mount the Camera

Please refer to the steps below to assist you with mounting the camera.

We suggest that you congure the camera before mounting.

Step 1

Position the mounting bracket

in the desired location.

Step 2

Mark the surface behind the

mounting bracket with a pencil.

Step 3

Use a 6mm drill bit to make required holes approximately 25mm deep.

Step 4

Insert wall anchors and ax the bracket using the screws provided.

Step 5

Ensure the cable is seated in the cable channel.

Step 6

Suspend the camera from the two protruding

studs near the top of the mounting bracket.

Step 7

Insert and tighten the remaining screw into the hole on the camera base.

ENGLISH

Positioning the Camera

Step 1

Using a Torx Security screwdriver, loosen the

screw on the top of the camera housing.

Step 2

Swivel the camera along it's horizontal

axis until you achieve the desired angle.

Step 3

Using a Torx Security screwdriver, tighten the

screw on the top of the camera housing rmly.

The DCS-7010L can be adjusted to ensure optimal viewing

when mounted by following the steps outlined.

Step 4

Rotate the camera around its vertical

axis by adjusting the base.

Step 5

Rotate the camera to adjust for

positioning by rotating the barrel.

ENGLISH

Using the mydlink Lite Mobile App

The mydlink Lite app lets you conveniently manage all your mydlink-enabled

devices right from your mobile device.

You can download the free mydlink Lite app from the App Store or Google

Play. If you have a QR code scanning app, you can scan the corresponding

code below to go straight to the mydlink Lite app page.

ENGLISH

TECHNICAL SUPPORT

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: +91-832-2856000

Toll Free 1800-233-0000

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand, Indonesia,

Malaysia, Philippines, Vietnam:

Singapore - www.dlink.com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to 6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South

Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

D-Link Middle East - Dubai, U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai, U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 / 8809069

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

1, Makram Ebeid Street - City Lights Building

Nasrcity - Cairo, Egypt

Floor 6, ofce C2

Tel.: +2 02 26718375 - +2 02 26717280

Technical Support: +2 02 26738470

General Inquiries: [email protected]

Tech Support: [email protected]

Kingdom of Saudi Arabia

Ofce # 84 ,

Al Khaleej Building ( Mujamathu Al-Khaleej)

Opp. King Fahd Road, Olaya

Riyadh - Saudi Arabia

Tel: +966 1121 70008

Technical Support:

+966 1121 70009

General Inquiries: info.sa@ dlinkmea.com

Tech Support: support.sa@ dlinkmea.com

Pakistan

Islamabad Ofce:

61-A, Jinnah Avenue, Blue Area,

Suite # 11, EBC, Saudi Pak Tower,

Islamabad - Pakistan

Tel.: +92-51-2800397, 2800398

Fax: +92-51-2800399

Karachi Ofce:

D-147/1, KDA Scheme # 1,

Opposite Mudassir Park, Karsaz Road,

Karachi – Pakistan

Phone: +92-21-34548158, 34326649

Fax: +92-21-4375727

Technical Support: +92-21-34548310, 34305069

General Inquiries: [email protected]

Tech Support: [email protected]

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

ENGLISH

TECHNICAL SUPPORT

Iran

Unit 5, 5th Floor, No. 20, 17th Alley , Bokharest

St. , Argentine Sq. ,

Tehran IRAN

Postal Code : 1513833817

Tel: +98-21-88880918,19

+98-21-88706653,54

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

M.I.T.C

Route de Nouaceur angle RS et CT 1029

Bureau N° 312 ET 337

Casablanca , Maroc

Phone : +212 663 72 73 24

Email: [email protected]

Lebanon RMA center

Dbayeh/Lebanon

PO Box:901589

Tel: +961 4 54 49 71 Ext:14

Fax: +961 4 54 49 71 Ext:12

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait:

Technical Support: + 965 22453939 / +965

22453949

Türkiye Merkez İrtibat Ofisi

Ayazağa Maslak yolu

Erdebil Cevahir İş Merkezi No: 5/A Ayazağa /

Maslak İstanbul

Tel: +90 212 2895659

Ücretsiz Müşteri Destek Hattı: 0 800 211 00 65

Web:www.dlink.com.tr

Teknik Destek: [email protected]

073-796-2797
