D-Link DCS-8620LH Manuel utilisateur

DCS-8620LH

User Manual

2K QHD Outdoor Wi-Fi Camera

Hardware: A1

Manual Version: 1.01

03/25/2022

iD-Link DCS-8620LH User Manual

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify

any person or organization of such revisions or changes. Information in this document may become obsolete as our services

and websites develop and change. Please refer to the www.mydlink.com website for the most current information.

Manual Overview

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United

States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks

of their respective companies.

D-Link Corporation, Inc.

Manual Revisions

Revision Date Description

1.01 03/25/2022 Initial release

iiD-Link DCS-8620LH User Manual

Table of Contents

Product Overview..............................................................1

Package Contents.........................................................................1

Introduction ................................................................................... 2

System Requirements.................................................................2

Hardware Overview.....................................................................3

Front .......................................................................................... 3

Bottom...................................................................................... 4

LED Behavior ..........................................................................5

Installation.........................................................................6

Safety ................................................................................................6

Before You Begin...........................................................................6

Wireless Installation Considerations...................................... 7

mydlink App Camera Setup...................................................... 8

Device Placement.......................................................................10

Mounting the Camera...............................................................11

Pole Mount............................................................................11

Wall/ Ceiling Mount ...........................................................12

Using the mydlink App....................................................14

Controlling Your Device ...........................................................14

Device Settings............................................................................15

Troubleshooting..............................................................17

Technical Specications..................................................18

Regulatory Information ..................................................20

1D-Link DCS-8620LH User Manual

Section 1 - Product Overview

Product Overview

Package Contents

If any of the above items are missing, please contact your reseller.

Note: Using a power supply with a dierent voltage rating than the one included with your product will cause damage and void

the warranty for this product.

2K QHD Outdoor Wi-Fi Camera

Mounting Screws Quick Installation Guide

Power Adapter

Cable Ties

2D-Link DCS-8620LH User Manual

Section 1 - Product Overview

Introduction

The DCS-8620LH is equipped with IP65 protection for outdoor usage and IR night vision for day and night surveillance.

Compliant with ONVIF prole S and T, the DCS-8620LH is capable of capturing images at up to 25 frames per second in

Quad HD resolution along with the support for H.264 and H.265 codecs. The AI-capable person detection noties you only

when humans appear in the camera view, signicantly reducing false detection. For ease of management, the wireless

802.11ac and Bluetooth 5.0 connectivity allow you to access the live view and congure the camera through your mobile

device. It also allows you to receive alert notications of motion, sound, vehicle, and glass break sound detection with the

mydlink app.

System Requirements

Network Requirements

• 802.11n/ac wireless network

• An Internet connection

• A router connected to your broadband modem

mydlink™ App Requirements

• iPhone®, iPad®, Android™ smartphone or tablet (please refer to the

mobile app's store page to check whether your device is compatible)

• Email account (for mydlink™ service registration)

3D-Link DCS-8620LH User Manual

Section 1 - Product Overview

Hardware Overview

Front

Status LED Refer to LED Behavior on page 5for more information.

Microphone Picks up sound near your camera.

Light Sensor The IR-Cut removable lter switches between color and infrared according to the

lighting conditions monitored by the sensor.

Camera Lens Records video of the surrounding area.

Built-In Microphone

Status LED

Light Sensor

2K QHD 1440p Resolution

Lens with 127° FOV

4D-Link DCS-8620LH User Manual

Section 1 - Product Overview

Bottom

Speaker Transmits sound for the two-way audio feature.

microSD Card Slot microSD card slot, supports up to 256 GB.

Reset Button Hold the recessed button down until the Status LED turns red to reset the camera to

factory default settings.

Speaker

microSD Card Slot Reset Button

5D-Link DCS-8620LH User Manual

Section 1 - Product Overview

LED Behavior

Status LED

Connected to Wi-Fi and mydlink.

Powering on.

Ready for conguration.

Upgrading rmware - do not power o.

Timeout for setup - please power cycle the device.

Status LED

6D-Link DCS-8620LH User Manual

Section 2 - Installation

Please read all of the safety and operating instructions before using device:

• Do not open the device or attempt to repair it.

• Do not submerge the device in liquid or attempt to clean it with liquids or solvents. To clean the device, disconnect it

from the power outlet and use a damp towel to gently wipe it down.

Before You Begin

Plan the location of your camera:

• Verify that your camera is electrically rated to operate with the power available in your location.

• Connect the camera's power adapter into an electrical outlet that is not controlled by a wall switch. This will help avoid

accidentally turning o power to the device.

• Be sure to plug the device into a properly grounded electrical outlet in order to help prevent against electrical shock.

• Make sure that the device is rmly mounted.

Installation

Safety

7D-Link DCS-8620LH User Manual

Section 2 - Installation

Wireless Installation Considerations

The DCS-8620LH 2K QHD Outdoor Wi-Fi Camera lets you view video footage from virtually anywhere within the operating

range of your wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other objects that

the wireless signals must pass through may limit the range. Typical ranges vary depending on the types of materials and

background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these

basic guidelines:

1. Keep the number of walls and ceilings between the camera and wireless access point to a minimum - each wall or ceiling

can reduce your camera’s range from 1 to 30 meters (3 to 90 feet). Position your devices so that the number of walls or

ceilings is minimized.

2. Be aware of the direct line between network devices. A wall that is 0.5 meters (1.5 feet) thick, at a 45-degree angle

appears to be almost 1 meter (3 feet) thick. At a 2-degree angle it looks over 14 meters (42 feet) thick! Position devices so

that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.

3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try

to position access points, wireless routers, and cameras so that the signal passes through drywall or open doorways.

Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and

concrete will degrade your wireless signal.

4. Keep your product away at least 1 to 2 meters (3 to 6 feet) from electrical devices or appliances that generate RF noise.
