D-Link DCS-7517 Manuel utilisateur

This document will guide you through the

basic installation process for your new

D-Link Network Camera.

DCS-7517

Documentation also available on CD

and via the D-Link Website

Quick Installation Guide

5 Megapixel Day & Night Outdoor Network Camera

Quick Installation Guide

Installationsanleitung

Guide d’installation

Guía de instalación

Guida di Installazione

Краткое руководство по установке

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

D-Link DCS-7517 Quick Install Guide 1

ENGLISH

Quick Install Guide

This installation guide provides basic instructions for installing the Network Camera on

your network. For additional information about how to use the camera, please see the

User’s Manual which is available on the CD included in this package or from the D-Link

support website.

Installation Steps

1. Verify the package contents against the list below.

2. Hardware Overview

3. Hardware Installation

4. CongurationwithWizard

5. SD Card Installation

6. Mounting Instructions

Package Contents

�DCS-7517 5 Megapixel Day & Night Outdoor Network Camera

�Manual and Software on CD-ROM

�Quick Install Guide

�Power Adapter

�Cable Bundle

�RJ-45 Extension Connector

�Mounting Bracket and Screws

�Alignment Sticker

� WaterproofCableCover

If any of the above items are missing, please contact your reseller.

Safety Notice:

Installationandservicingshouldbedonebycertiedtechnicianssoastoconformtoall

local codes and prevent voiding your warranty.

Note:Usersareadvisedtoensurethattheweatherproofsealsaresecuredrmlyin

place.

D-Link DCS-7517 Quick Install Guide

ENGLISH

Hardware Overview

IR LEDs

Provide illumination for

low-light environments

Camera Lens

microSD Card Cover

Remove cover to insert/

remove the microSD card

Ethernet Jack

RJ-45 connector for Ethernet

which can also be used to power

the camera using Power over

Ethernet (PoE)

Power Connector

Connects to 12 V DC power

Reset Button

Resets camera to factory

default settings

BNC

Analog video output

Audio In

Connects to a microphone

DI/DO Wiring

I/O connectors for external devices

Audio Out

Connects to speakers

D-Link DCS-7517 Quick Install Guide 3

ENGLISH

Connection with a PoE Hub

If you are using a PoE hub, connect the IP camera to the hub via an Ethernet cable,

which will provide transmission of both power and data over a single cable.

General Connection Using 12 V DC Power Adapter

1. Connect the network camera to a hub via an Ethernet cable.

2. Connect the supplied power cable from the camera to a power outlet.

Hardware Installation

D-Link DCS-7517 Quick Install Guide

ENGLISH

Conguration with Wizard

Insert the DCS-7517 CD into your computer's CD-ROM drive to begin the installation. If

the Autorun function on your computer is disabled, or if the D-Link Launcher fails to start

automatically, click Start > Run. Type D:\autorun.exe, where D: represents the drive

letter of your CD-ROM drive.

The following window will open.

Click Next to continue.

Click Yes to accept the License Agreement.

Click Finish to complete the installation.

To start the installation process, click Next.

Note: The installation may take several minutes to

nish.

D-Link DCS-7517 Quick Install Guide 5

ENGLISH

Click on the D-Link Setup Wizard SE icon that was

createdinyourWindowsStartmenu.

Start > D-Link > Setup Wizard SE

TakeamomenttoconrmyoursettingsandclickRestart.

Select DHCP if your camera obtains an IP address

automatically when it boots up. Select static IP if the

camera will use the same IP address each time it is

started.

Click Next, to proceed to the next page.

EntertheAdminIDandpassword.Whenlogginginfor

thersttime,thedefaultAdminIDisadmin with the

password left blank.

Click Next, to proceed to the next page.

TheSetupWizardwillappearanddisplaytheMAC

address and IP address of your camera(s). If you have

a DHCP server on your network, a valid IP Address

will be displayed. If your network does not use a

DHCP server, the network camera's default static IP

(192.168.0.20) will be displayed.

Select your camera, then

click the Wizard button to continue.

D-Link DCS-7517 Quick Install Guide

ENGLISH

Click on the D-Link Setup Wizard SE icon that was

createdinyourWindowsStartmenu(Start > D-Link >

Setup Wizard SE).

Viewing Your Camera via a Web Browser

This section shows your camera’s live video. You

canselectyourvideoproleandvieworoperate

the camera. For additional information about web

conguration,pleaserefertotheusermanualincluded

on the CD-ROM or the D-Link website.

Enter admin as the default username and leave the

password blank.

Click OK to continue.

Select the camera and click the button labeled "Link"

toaccessthewebconguration.

TheSetupWizardwillautomaticallyopenyourweb

browser to the IP address of the camera.

D-Link DCS-7517 Quick Install Guide 7

ENGLISH

microSD Card Installation

Open the microSD Card Cover

Unscrew the microSD card cover and pull it down to open it.

Install the microSD Card

Push the microSD card into the camera with the gold contacts oriented towards the base

of the camera. To eject the microSD card, push the microSD card into the slot.

Note: Users are advised to ensure that the weatherproof seals are secured rmly

in place.

D-Link DCS-7517 Quick Install Guide

ENGLISH

Mounting Instructions

Itishighlyrecommendedthatyoucongureandtestyourcamerabeforemountingit.

Place the alignment sticker where you want to position the camera. Make sure the camera

base will be positioned so that the cable channel is on the bottom.

Use a 6 mm drill bit to make the required holes approximately 25 mm deep, then insert

the wall anchors into the holes.

If you are running the camera cables through the wall, drill a hole in the center and pull

the cables through the hole.

Use the screws provided to mount the camera to the wall.

If the cable bundle is not required, it can be detached from the camera, and the socket

sealed with a weatherproof cable cover.

If you are running the camera cables out the side of the

camera, guide the camera cables through the cable

channel on the base.

Connect the power and Ethernet cables, or just the

Ethernet cable if you are using a PoE connection.

Alignment

sticker
