D-Link DCS-1201 Manuel utilisateur

This document will guide you through the

basic installation process for your new

D-Link Network Camera.

DCS-1201

Documentation also available on

CD and via the D-Link Website

Quick Installation Guide

HD Covert Network Camera

Quick Installation Guide

Installationsanleitung

Guide d’installation

Guía de instalación

Guida di Installazione

Краткое руководство по установке

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

D-Link DCS-1201 Quick Installation Guide 1

ENGLISH

Quick Installation Guide

This installation guide provides basic instructions for installing the DCS-1201 on your

network. For additional information about how to use the camera, please see the User

Manual which is available on the CD included in this package or you can download it

from the D-Link support website.

Package Contents

DCS-1201 HD Covert Network Camera (includes control box and camera)

Camera cover

Flat mounting bracket

Angled mounting bracket

Mounting Kit (with hex wrench and mounting plates for control box)

Manual and Software on CD-ROM

Quick Installation Guide

If any of the above items are missing, please contact your reseller.

Safety Notice:

Installation and servicing should be done by certied technicians so as to conform to all

local codes and prevent voiding your warranty.

D-Link DCS-1201 Quick Installation Guide

ENGLISH

Hardware Overview

1 2 3 4 5 6 7 8 9 10 11

1DC power connector 7Audio out jack

2Power connector 8Status LED

3LAN status LED 9Camera port

4LAN (PoE) port 10 DI/DO connectors

5microSD card slot 11 Reset button

6Audio in jack

12 Camera lens 15 Camera cover

13 Mounting holes 16 Flat mounting bracket

14 Camera cable 17 Angled mounting bracket

15 16 17

Back Front

Control Box

D-Link DCS-1201 Quick Installation Guide 3

ENGLISH

Connecting the Camera

Connect the camera cable to the CAM port on the control

box.

You can power the DCS-1201 three different ways:

through PoE, through the power terminal, or through a

power adapter.

Powering the camera through PoE (Class 2):

Connect an Ethernet cable to the LAN(PoE) port on the

control box. Connect the other end of the cable to your

PoE switch or PoE injector.

Powering the camera through the power terminal:

Connect your power source to the power terminal

on the control box. The specications for the power

terminal are as shown below.

Pin + : 8-28 V DC input

Pin - : Ground

Connect an Ethernet cable to the LAN(PoE) port on the

control box. Connect the other end of the cable to your

network.

Powering the camera through a power adapter

(not included):

Connect a 12 V 1.5 A power adapter to the power

connector of the control box.

Connect an Ethernet cable to the LAN(PoE) port on the

control box. Connect the other end of the cable to your

network.

D-Link DCS-1201 Quick Installation Guide

ENGLISH

Conguring the Camera

Insert the DCS-1201 CD into your computer's CD-ROM drive to begin the installation. If

the Autorun function on your computer is disabled, or if the D-Link Launcher fails to start

automatically, click the Start button and type D:\autorun.exe (where D: represents the

drive letter of your CD-ROM drive) and press Enter.

Click on the D-Link Setup Wizard SE icon that was

created in your Windows Start menu (Start > D-Link >

Setup Wizard SE).

The Setup Wizard will appear and display the MAC

address and IP address of your camera(s). If you have a

DHCP server on your network, a valid IP Address will be

displayed. If your network does not use a DHCP server,

the network camera's default static IP 192.168.0.20 will be

displayed.

Select your camera, then click the Wizard button to

continue.

Click Setup Wizard and follow the instructions to install

the Setup Wizard.

Enter the Admin ID and password. When logging in for

the rst time, the default Admin ID is admin with the

password left blank.

Click the checkboxes if you wish to change the admin ID

and password for the camera, and enter the new ID and

password you wish to use.

Click Next to continue.

Select DHCP if your camera obtains an IP address

automatically from a DHCP server such as a router.

Select Static IP if you want to manually enter the IP

settings for the camera.

Click Next to continue.

D-Link DCS-1201 Quick Installation Guide 5

ENGLISH

Viewing Your Camera via Web Browser

Click on the D-Link Setup Wizard SE icon that was

created in your Windows Start menu (Start > D-Link >

Setup Wizard SE).

Select the camera and click Link to access the web

conguration.

The Setup Wizard will automatically open your web

browser to the IP address of the camera.

This section displays your camera’s live video. You can

select your video prole and view or operate the camera.

For additional information about web conguration, please

refer to the user manual included on the CD-ROM or the

D-Link website.

Enter admin as the default username and leave the

password blank. Click OK to continue.

Take a moment to conrm your settings and click Restart.

D-Link DCS-1201 Quick Installation Guide

ENGLISH

Mounting Instructions

It is highly recommended that you congure and test your camera before mounting it.

Mounting directly on a wall/ceiling

Use the included screws to mount the camera in the desired location, then attach the

camera cover.

Covert installation

Drill a hole 9 mm in diameter in the wall/ceiling, which should be no more than 5 mm

thick. Peel off the adhesive backing on the at mounting bracket and attach it to the

inside of the wall/ceiling. Insert the camera, and use the screw and washer to secure

the camera in the mounting bracket as shown.

Mounting using the angled mounting bracket

Attach the angled mounting bracket to the wall/ceiling using the included screw. Attach

the camera to the angled mounting bracket with the included screws as shown. You can

adjust the pivot of the angled mounting bracket by using the included hex wrench.

D-Link DCS-1201 Quick Installation Guide 7

ENGLISH

Mounting the control box

Use 4 screws to attach the mounting plates to the control box, then use 2 screws to

mount the control box in the desired location.

Additional Information

Additional help and product information is available online at

http://www.dlink.com.

Warranty Information

Please visit http://warranty.dlink.com/ for warranty information for your region.

D-Link DCS-1201 Quick Installation Guide

DEUTSCH

Installationsanleitung

Diese Installationsanleitung bietet Ihnen grundlegende Anleitungen zur Installation der

DCS-1201 in Ihrem Netzwerk. Zusätzliche Informationen zur Verwendung der Kamera

nden Sie im Benutzerhandbuch auf der CD, die diesem Paket beiliegt, oder Sie

können es über die D-Link Support-Website herunterladen.

Packungsinhalt

DCS-1201 HD PoE HD Miniatur Camera (enthält Steuereinheit und Kamera)

Kameraabdeckung

Gerade Montagehalterung

Abgewinkelte Montagehalterung

Montageset (mit Sechskantschlüssel und Montageplatten für die

Steuereinheit)

CD-ROM mit Software und Handbuch

Installationsanleitung

Sollte einer der oben aufgeführten Artikel fehlen, wenden Sie sich bitte an Ihren

Fachhändler.

Sicherheitshinweis:

Installation und Wartungsarbeiten sollten nur von zertizierten Technikern

vorgenommen werden, zu jeder Zeit allen örtlich geltenden Richtlinien und

Anforderungen entsprechen und dadurch verhindern, dass Ihr Garantieanspruch

erlischt.
