DCS-5222L

Quick Install Guide

HD Pan & Tilt Day/Night Network Camera

If any of the above items are missing, please contact your reseller.

DCS-5222L HD Pan & Tilt Day/Night Network Camera

Power Adapter

Package Contents

Mounting Kit

CAT5 Ethernet Cable

Audio In/Out Cable

Minimum Requirements

Mobile Device (to use mydlink Lite app)

• iPhone, iPad, or Android smartphone or tablet

(Refer to the mobile app’s store page to see if your device is compatible)

Network Device and Service

• A wireless router (802.11ac/n/g) with Internet service

• An e-mail account (required to create a mydlink® account)

* If you use a mobile device with the mydlink Lite app, a PC is not required for

setup. Refer to Setting up Your Camera on page 4.

ENGLISH

Product Overview

Camera Lens

Microphone

Light Sensor

Power LED

PIR Sensor

WPS Status LED

Power Connector

Ethernet Port

Reset Button

WPS Button

Front

Back

IR LEDs

Speaker

I/O Connector

Audio In/Out

Antenna

microSD Card

Slot

Focus Ring

ENGLISH

Setting Up Your Camera

System Requirements: Refer to the mydlink Lite app page on Apple App Store, Google Play or Windows Phone Store.

Launch the mydlink Lite app, then create a new account or log in to your

existing account.

Download the free mydlink Lite app on your smartphone or tablet by

scanning the QR code below, or by searching for mydlink Lite in the app

store for your device.

3The app will guide you through the rest of the conguration process.

ENGLISH

Mount the Camera

Please refer to the steps below to assist you with mounting the camera.

We suggest that you congure the camera before mounting.

1. Place the arm mount where you want to position

the camera and use a pencil to mark the holes.

Make sure you allow adequate space for the

necessary cables to be routed. The camera can

be mounted to either side of the camera shoe.

2. Depending on the material of the wall or ceiling,

use a 6mm drill bit to drill two holes where you

marked. If the wall is made out of concrete, after

drilling the holes, insert the plastic anchors, and

then insert the screws.

3. The power and Ethernet cables can be concealed

behind the mounting bracket.When you run the

cables through the channel, secure them with

the built-in guides. Leave enough cable length

protruding from the top to connect the cables to

the camera.

4. Fasten the arm mount to the wall using the

screws provided. Lightly pull on the arm mount

to make sure it is fastened securely.

5. Align the camera base mounting guides with

the camera shoe and thumbscrew on the arm

mount. Tighten the thumbscrew to lock the

camera in place.

Do not overtighten the screws as this may crack the bracket.

ENGLISH

1. What is a mydlink No.? What is it used for?

Each camera has a unique eight-digit mydlink No. which will be shown on

the label on the back of your camera. This eight-digit number identies

your device, and is required to add your device to your mydlink account.

2. What can I do if my DCS-5222L is not working correctly?

• Reset the camera (see next step) and run the setup steps starting

on page 4 again.

• To make sure your hardware is installed correctly, make sure that:

- the power LED is solid green

- your Internet connection is working

- your router’s LAN & WAN connections are working

- your router supports UPnP®

- your camera is on the same network as your mobile device

- both your mobile device and camera have a working Internet connection

• If your camera is still not working, check your router and make sure it

has the latest rmware.

3. What can I do if I forget my password?

FAQs

If you forget your password, you must reset the

camera. Unfortunately, this process will change

your settings back to factory default. To reset the

camera, locate the reset button on the back of

the camera. With the camera powered on, use an

unfolded paper clip to hold the button down for

10 seconds. Run the setup procedure located on

page 4 once the camera restarts.

4. Why is there a white haze when viewing in night vision mode?

When viewing in night vision mode, the IR lights on the camera may be

reecting o a nearby surface. Try repositioning the camera in order to

avoid glare from IR LEDs.

Reset

Button

ENGLISH

Notes

ENGLISH

Technical Support

This guide is for initial conguration. Please refer to the user manual

to learn more or visit http://www.mydlink.com for more information.

Also feel free to contact us. U.S. and Canadian customers can contact

D-Link Technical Support through our website.

http://support.dlink.com

USA

http://support.dlink.ca

Canada

Version 2.2

March 24, 2015

Corporation or its subsidiaries. Other trademarks are the property of their respective owners. Maximum

wireless signal rate derived from IEEE Standard 802.11g and 802.11n specications. Actual data throughput

will vary. Network conditions and environmental factors, including volume of network trac, building

materials and construction, and network overhead, lower actual data throughput rate. Environmental

factors will adversely aect wireless signal range. Product specications, size and shape are subject to

change without notice, and actual product appearance may dier from that depicted on the packaging.

Visit dlink.com (US) or dlink.ca (Canada) for more details.
