D-Link DCS-7413 Manuel utilisateur
This document will guide you through
the basic installation process for your new
D-Link Network Camera.
DCS-7413
Quick Install Guide
Full HD Day & Night Outdoor Network Camera
D-Link DCS-7413 Quick Install Guide
2
ENGLISH
This installation guide provides basic instructions for installing the DCS-7413
Network Camera on your network. For additional information about how to
use the camera, please see the User Manual which is available on the CD
included in this package or from the D-Link website.
Package Contents
• DCS-7413 Network Camera
• Mounting Bracket and Screws
• CAT5 Ethernet Cable
• Power Adapter
• AV and Power Cables
• Extension Adapter
• Quick Install Guide
• User Manual and Software on CD-ROM
If any of the above items are missing, please contact your reseller.
Safety Notice:
Installation and servicing should be done by certied technicians so as to
conform to all local codes and prevent voiding your warranty.
Installation
D-Link DCS-7413 Quick Install Guide
3
ENGLISH
Hardware Overview
1Ethernet Jack Connect to a router or switch. Also used to power the camera
using Power over Ethernet (PoE).
2Power Connector Connects to a 12V DC power adapter.
3Audio Out Connect to external speakers.
4Audio In Connect to a microphone.
5DI/DO Connector DI/DO connector provide a physical interface to send and receive
digital signals to and from a variety of external devices.
624V Power Connector Connect to a 24V AC power source.
7Reset Button Press and hold to reset the camera to the factory default settings.
8BNC Connector
(video out) Connect to an analog video input.
12
3
4
5
6
7
8
D-Link DCS-7413 Quick Install Guide
4
ENGLISH
Insert your SD card into the camera with
the gold contacts oriented towards the
base of the camera. To eject the SD card,
push the SD card into the slot.
SD Card Installation
Loosen the two screws and lift o the
adjustable sun shield.
1
Remove the base of the camera by holding
the camera rmly and rotating the base in
a counter-clockwise direction.
2
3
Replace the base of the camera by holding
the camera rmly and rotating the base in a
clockwise direction ensuring a tight t.
Note: Ensure that the weatherproof seals are
secured rmly in place. Attach the sun shield
and tighten the two screws.
4
Note: If you fully extend the top shield, it may be visible in the camera view in the top left and right corners
of your video. It is recommended that you always check your camera’s video whenever you reposition the
camera or adjust the weather shield to ensure that your camera has the best possible view.
D-Link DCS-7413 Quick Install Guide 5
ENGLISH
Please refer to the User Manual (Section 2 - Assembly and Installation) for detailed instructions
regarding mounting of the camera using a mounting bracket.
Note: To prevent the camera’s wire connectors from being damaged by water or other
elements:
1. When connecting the camera, the unsheathed part of the wire connectors must either be
sealed or enclosed in a junction box.
2. The unsheathed part of the wire connectors should be positioned at a downward-facing
angle when they extend out of the rear of the camera, not upward.
The unsheathed part of the wire connectors must either be sealed or enclosed in a junction box.
Mounting the Camera
D-Link DCS-7413 Quick Install Guide
6
ENGLISH
Connection with a PoE Switch
If you are using a PoE switch, connect the IP camera to the switch via an Ethernet cable, which
will provide transmission of both power and data over a single cable.
General Connection Using 24V AC Power Wiring
1. Connect the network camera to a switch via an Ethernet cable.
2. Connect the supplied power cable from the camera to a power source such as your
building's emergency power.
General Connection Using 12V DC Power Adapter
1. Connect the network camera to a switch via an Ethernet cable.
2. Connect the supplied power cable from the camera to a power outlet.
D-Link DCS-7413 Quick Install Guide 7
ENGLISH
Conguration with Wizard
Click Setup Wizard to begin the installation.
Insert the DCS-7413 CD into your computer's CD-ROM drive to begin the installation. If the Autorun
function on your computer is disabled, or if the D-Link Launcher fails to start automatically, click
Start > Run. Type D:\autorun.exe, where D: represents the drive letter of your CD-ROM drive.
After clicking Setup Wizard, the following window will open.
Click Next to continue.
Click Yes to accept the License Agreement.
Click Finish to complete the installation.
To start the installation process, click Next.
Note: The installation may take several minutes to nish.
D-Link DCS-7413 Quick Install Guide
8
ENGLISH
Click on the D-Link Setup Wizard SE icon that was created
in your Windows Start menu.
Start > D-Link > Setup Wizard SE
Take a moment to conrm your settings and click Restart.
Select DHCP if your camera obtains an IP address automatically
when it boots up. Select Static IP if the camera will use the
same IP address each time it is started.
Click Next to continue.
Enter the Admin ID and password. When logging in for the
rst time, the default Admin ID is admin with the password
left blank.
Click Next to continue.
The Setup Wizard will appear and display the MAC address
and IP address of your camera(s). If you have a DHCP server
on your network, a valid IP Address will be displayed. If your
network does not use a DHCP server, the network camera's
default static IP 192.168.0.20 will be displayed.
Click the Wizard button to continue.
D-Link DCS-7413 Quick Install Guide 9
ENGLISH
Click on the D-Link Setup Wizard SE icon that was
created in your Windows Start menu.
Start > D-Link > Setup Wizard SE
Viewing Camera via Web Browser
This section shows your camera’s live video. You can select your
video prole and view or operate the camera. For additional
information about web conguration, please refer to the user
manual included on the CD-ROM or the D-Link website.
Enter admin as the default username and leave the
password blank. Click OK to continue.
Select the camera and click the button labeled "Link" to
access the web conguration.
The Setup Wizard will automatically open your web browser
to the IP address of the camera.
D-Link DCS-7413 Quick Install Guide
10
ENGLISH
Notes
