D-Link DSL-6740B Manuel utilisateur

Before You Begin

Make sure you have all the necessary information and equipment on hand before beginning the

installation.

Check Your Package Contents

If any of the items above are missing, please contact your reseller.

DSL-6740B Wireless ADSL Router

Ethernet Cable (Cat 5 UTP)

Telephone cable

Power Adapter

Using a powersupply

with a different voltage rating

will damage and void the

warranty for this product.

This product can be set up using any

current web browser, i.e., Internet

Explorer 6x or Netscape Navigator 7x.

DSL-6740B

Wireless 11N VDSL Router

Connecting the Router to Your Computer

A. First, connect the power adapter to the receptor at the back panel of the

DSL-6740B and then plug the other end of the power adapter to a wall outlet or

power strip. The Power LED will turn on to indicate proper operation.

B. Insert one end of the cable into any Ethernet port on the back panel of the

DSL-6740B and the other end of the cable to an Ethernet Adapter or available Ethernet

port on your computer.

C. Insert one end of the telephone cable into the ADSL port on the back panel. Connect

the other end of the cable to the telephone wall outlet or low pass filter device that is

connected to the telephone wall outlet.

Ethernet Ports

Connect to Ethernet cable

Switch

PowerInput

Connect to power

WLAN button

Connect to STA

WPS button

Connect to WPS

DSL Port

Connect to ADSL

Reset

ENGLISH

Configuring the Router

To use your Web browser to access the web pages used to set up the Router, your computer

must be configured to “Obtain an IP address automatically,”that is, you must change the IP

network settings of your computer so that it is a DHCP Client. If you are using Windows XP

and do not know how to change your network settings, skip ahead to Appendix A and read the

instructions provided. You may also read the User Manual for instructions on changing IP

settings for computers running Windows operating systems.

The logon pop-up screen will appear.

Open your Web browser and type

“http://192.168.0.1” into the URL address

box. Then press the Enter or Return



key.

The login dialog appears.

Type“

$GPLQLVWUDWRU

”for the

User Name and

“soporteETB2006” in the

Password field.

Click OK.

ENGLISH

Configuring the Router (continued)

After loginin to the DSL router, if no PVC is configured previously and no default settings

exists, the Quick Setup webpage appears, which contains some basic configuration that is

needed by VPI/VCI.

zATM Interface Configuration

Choose Advanced Setup > Layer2 Interface, and the following page appears, so you can

add or remove the ATMVPI/VCI and related configurations.

ENGLISH

zATM PVC Configuration

ENGLISH

zWAN Service

Choose Advanced Setup >WAN Service, and the following page appears, so you can

add/remove/Edit the WAN interface.

Click Add



tocreate WAN service interface configuration; Click Edit to modify WAN service.

According to the page context, choose the right item and click Next, Back step by step to

configure WAN service.

ENGLISH

When creating a WAN service, you can see the following page:

Here, you can select ATM interface which you configured before.

ENGLISH

For “EoA” type of ATM interface, you can create PPPoE/IPoE/Bridge WAN service (as below):

ENGLISH

At last, click Apply/Save to save the modification.

ENGLISH

Configuring the Router (continued)

Wireless LAN Configuration

You can enable or disable the wireless LAN interface, hide the network from active scans,

set the wireless network name (also known as SSID) and restrict the channel set based on

country requirements.

Enter the SSID for the

Wireless LAN

The channel will adjust

according to nations to adapt

to each nation's

frequency provision.

Following is a description of the different options:

zEnable Wireless: If you want to make wireless be available, you have to check this

box first. Otherwise, the Hide Access Point SSID, Country, Enable Wireless Guest

Network, and Guest SSID box will not be displayed.

zHide Access Point: Check this box if you want to hide any access point for your

router, so a station cannot obtain the SSID through passive scanning.

Click Apply / Save to save the basic wireless options and make the modification effect.

Click

Save/A

ENGLISH
