specifications subject to change without notice. DWL-810 10182002

If any of the above items are missing, please contact your reseller.

CD-ROM (Manual and Warranty)

Before You Begin

DWL-810 Ehternet to Wireless Bridge

Check Your Package Contents

These are the items included with your DWL-810 purchase:

Web-based Configuration will require a

current web browser, i.e., Internet

Explorer 5.x, Netscape Navigator 4.x.

DWL-810

D-Link Air™

Ethernet-to-Wireless Bridge

You must have at least the following:

An Ethernet-enabled device, such as a game console, laptop or desktop

computer, network printer or set-top box that will connect to the DWL-810

Ethernet (CAT5 UTP) Cable

5V DC 2.5A Power Adapter Using a power

supply with a

different voltage rating

will damage this

product and void its

warranty.

Connecting the DWL-810 to your

Ethernet-enabled device

A. First, connect the power adapter to the receptor at the back panel of the

DWL-810 and then plug the other end of the power adapter to a wall outlet or

power strip. The Power LED will turn ON to indicate proper operation.

B. Insert one end of the Cross-Over Ethernet cable (included) to the Ethernet port

on the back panel of the DWL-810 and connect the other end to the Ethernet

port located on the device (e.g., a Set Top Box, Gaming Console, laptop or

desktop computer, or network printer.) The LED light will blink when there is

data tranfer through the wireless connection.

C. The antenna is used by the DWL-810 to connect to other 802.11b wireless devices.

A.Receptor for

Power Adapter

C.Antenna

Used to wirelessly

connect to 802.11b

networks.

B.LAN Port

This is the connection for

Ethernet cables to your

Ethernet-enabled device.

No configuration of the DWL-810 is needed if your setup is similar to Setup #1.

Connecting the DWL-810 in

Infrastructure Mode

Setup #1

Connect a cross-over cable from the DWL-810 to your Ethernet enabled:

Desktop PC, Laptop PC, Set-Top-Box, or Gaming Console.

Connecting the DWL-810 in Ad-Hoc

Mode

Setup #2

Configuration of the DWL-810 is needed if your setup is similar to Setup #2.

Web-based Configuration

Before You Begin the Configuration

It’s best to use a computer (with an Ethernet adapter) that is connected directly to the

DWL-810 for configuration. The default IP address for the DWL-810 is 192.168.0.30 with

a Subnet Mask of 255.255.255.0. You will need to assign your computer a Static IP

address within the same range as the DWL-810’s IP address in order to configure the

DWL-810. See the Appendix in this Quick Installation Guide if you need assistance

in assigning a Static IP address.

Open your Web browser and

type “http://192.168.0.30” into

the URL address box. Then

press the Enter or Return key.

Continued...

The logon pop-up

screen will appear.

Type “admin” for the

username and leave the

password field blank.

Click OK

The configuration window will open, as shown.

Click Wireless in the

Configuration menu. This

screen will appear.

Select Ad-Hoc

The default wireless

settings are:

SSID = default

Channel = 6

You can change the SSID

and Channel settings to

match an existing Ad-Hoc

wireless network.

Changes will not take effect until you reboot the DWL-810.

To reboot, click on Admin at the top of this screen. In the

Admin window, click reboot to save the changes.

Click Apply

You have completed the Configuration of the DWL-810!

Appendix

To assign a Static IP Address to the laptop or computer that you are using to configure

the DWL-810, please do the following:

Assigning a Static IP Address in Windows

Go to Start > Double- click on

Control Panel > Double-click on

Network Connections > Right-

click on Local Area Connections

> Click Properties

Highlight Internet Protocol (TCP/IP)

Click Properties

Select Use the following IP address in

the Internet Protocol (TCP/IP) Properties

window

Input your IP address and subnet

mask. (The IP Address must be within

the same range as the DWL-810. The IP

Address of the DWL-810 is 192.168.0.30.

You can assign 192.168.0.51 for your

computer. No two computers can have

the same IP Address. Assign a subnet

mask of 255.255.255.0.)

Click OK

Note: The following screens are taken using

Windows XP. Your screens may look similar.

Notes

Technical Support

You can find the most recent software and user documentation on the D-Link website.

D-Link provides free technical support for customers within the United States for the

duration of the warranty period on this product.

U.S. customers can contact D-Link technical support through our web site or by

phone.

D-Link Technical Support over the Telephone:

(877) 453-5465

24 hours a day, seven days a week

D-Link Technical Support over the Internet:

http://support.dlink.com

email: [email protected]
