February 2008

Silicon Errata for the nvPSoC CY8CNP101, CY8CNP102 Product Family

CY8CNP101, CY8CNP102

Cypress Semiconductor Corporation •198 Champion Court •San Jose, CA 95134 •408.943.2600

Document Number: 001-44873 Rev. ** Revised April 17, 2008

This document describes the errata for the nvPSoC, CY8CNP101, CY8CNP102. Details include errata trigger con-

ditions, scope of impact, available workarounds, and silicon revision applicability. Compare this document to the

device’s data sheet for a complete functional description.

Contact your local Cypress Sales Representative if you have questions.

Part Numbers Affected

nvPSoC Qualification Status

Engineer Sampling

nvPSoC Errata Summary

Thefollowingtabledefinestheerrataapplicabilitytoavailable nvPSoC family devices. An "X" indicatesthattheerrata

pertains to the selected device.

Note Errata items, in the table below, are hyperlinked. Click on any item entry to jump to its description.

Part Number Device Characteristics

CY8CNP101 All Packages

CY8CNP102 All Packages

Items CY8CNP101,

CY8CNP102 Fix Status

[1]. Standby Current XAddressed before the product family enters full production.

[2]. VCAP XAddressed before the product family enters full production.

[3]. Test at Room Temperature XAddressed before the product family enters full production.

[+] Feedback

CY8CNP101, CY8CNP102

Errata Document

Document Number: 001-44873 Rev. ** Revised April 17, 2008

1. Standby Current

• PROBLEM DEFINITION

Engineering samples of the nvPSoC CY8CNP101, CY8CNP102 product family do not meet the data sheet

standby current specifications of 3 mA. The standby current will be a maximum of 15 mA.

• TRIGGER CONDITION(S)

• SCOPE OF IMPACT

• WORKAROUND

• FIX STATUS

This issue will be addressed before the nvPSoC CY8CNP101, CY8CNP102 product family enters full produc-

tion.

2. VCAP

• PROBLEM DEFINITION

Engineering samples of the nvPSoC CY8CNP101, CY8CNP102 product family do not meet the data sheet

specifications. VCap: 68 μF (maximum). The required Vcap is 200 μF (minimum) to 400 μF (maximum).

• TRIGGER CONDITION(S)

• SCOPE OF IMPACT

Capacitor value needs to change.

• WORKAROUND

• FIX STATUS

This issue will be addressed before the nvPSoC CY8CNP101, CY8CNP102 product family enters full produc-

tion.

3. Test at Room Temperature

• PROBLEM DEFINITION

The data sheet specifications (AC/DC Electrical Specifications) for the nvPSoC CY8CNP101, CY8CNP102

product family are tested and guaranteed only at room temperature.

• TRIGGER CONDITION(S)

• SCOPE OF IMPACT

• WORKAROUND

• FIX STATUS

This issue will be addressed before the nvPSoC CY8CNP101, CY8CNP102 product family enters full produc-

tion.

[+] Feedback

CY8CNP101, CY8CNP102

Errata Document

Document Number: 001-44873 Rev. ** Page 3 of 3

of any circuitry other than circuitry embodied in a Cypress product. Nor does it convey or imply any license under patent or other rights. Cypress products are not warranted nor intended to be

used for medical, life support, life saving, critical control or safety applications, unless pursuant to an express written agreement with Cypress. Furthermore, Cypress does not authorize its

products for use as critical components in life-support systems where a malfunction or failure may reasonably be expected to result in significant injury to the user. The inclusion of Cypress

products in life-support systems application implies that the manufacturer assumes all risk of such use and in doing so indemnifies Cypress against all charges.

Any Source Code (software and/or firmware) is owned by Cypress Semiconductor Corporation (Cypress) and is protected by and subject to worldwide patent protection (United States and

foreign), United States copyright laws and international treaty provisions. Cypress hereby grants to licensee a personal, non-exclusive, non-transferable license to copy, use, modify, create

derivative works of, and compile the Cypress Source Code and derivative works for the sole purpose of creating custom software and or firmware in support of licensee product to be used only

in conjunction with a Cypress integrated circuit as specified in the applicable agreement. Any reproduction, modification, translation, compilation, or representation of this Source Code except

as specified above is prohibited without the express written permission of Cypress.

Disclaimer: CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WAR-

RANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Cypress reserves the right to make changes without further notice to the materials described herein.

Cypress does not assume any liability arising out of the application or use of any product or circuit described herein. Cypress does not authorize its products for use as critical components in

life-support systems where a malfunction or failure may reasonably be expected to result in significant injury to the user. The inclusion of Cypress’ product in a life-support systems application

implies that the manufacturer assumes all risk of such use and in doing so indemnifies Cypress against all charges.

Use may be limited by and subject to the applicable Cypress software license agreement.

Document History Page

Document Title: Silicon Errata for the nvPSoC CY8CNP101, CY8CNP102 Product Family

Document Number: 001-44873

Rev. ECN No. Issue Date Orig. of

Change Description of Change

** 2397787 04/17/2008 GVCH/HMT New spec.
