CYP CED-1M Manuel utilisateur

CED-1M

HDMI EDID Emulator

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.0 September 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

VR0 14/11/13 Preliminary Release

VR1 21/04/14 Default EDID DVI Audio Cancel

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel ........................................3

6.2 Rear Panel.........................................4

6.3 Factory Default EDID ......................5

6.4 EDID Application Installation ..........5

7. Connection Diagram .......................... 12

8. Specications ...................................... 13

9. ACRONYMS .......................................... 14

1. INTRODUCTION

The HDMI EDID Emulator is designed to manipulate the HDMI/DVI EDID

information to be provided to source device for it to know capabilities

of the connected display equipment and output the Video/Audio

signal accordingly.

Aiming to simplify the technical complications involved in Video/Audio

system integration, home theater installation, Video/Audio equipment

testing and experiment, the model provides selections of the Learning

function to Read/Write the Video/Audio EDID to the system. It also

supports EDID Emulator and Bypass modes.

2. APPLICATIONS

• HDMI/DVI EDID manipulation

• Video/Audio system integration and home theater installation

• Video/Audio equipment testing

3. PACKAGE CONTENTS

• HDMI/DVI EDID manipulation

• Mini USB to USB Type A Cable

• Operation Manual

4. SYSTEM REQUIREMENTS

Video/Audio source device, TV/display equipment with HDMI input

and output.

5. FEATURES

• Compliant with HDMI and DVI 1.0 standards

• Supports HDMI features:

■ High Video bandwidth up to 300MHz (9Gbps)

■ Resolutions up to 1080p@60Hz & 4Kx2K@24/30

■12-bit Deep Color

■ LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD

Master Audio transmission (32-192kHz sample rate)

• EDID:

■Read: Read display’s EDID

■ Write: Overwrite existing TV/display’s EDID (TV/display need to

support overwrite function)

■Emulator: The source device will read EDID from the system

■Bypass: Source device read EDID directly from TV/display

• Supports 8 sets of Default EDID

• Supports DVI source by using HDMI to DVI adaptor or cable

• CEC and EDID pass-through

• Power supported by USB or HDMI input

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

1234

Learned

Select HDMI IN

5678

Default

1 42 3

1LED indicators 1~8: Each LED indicates each EDID selection

when in Learned or Default mode. Press [Select] button to switch

between 1 to 8 memories, the LED will illuminate accordingly to the

selection. Default EDID please refer to 6.3 Factory Default EDID.

2Learned/Default:



Select Learned to save HDMI output's EDIDs up to 8 different

sets, to learn EDID please refer to 6.2 EDID Switch: Read.



Select Default to use the built-in EDID, press Select button to

choose from 1~8. Detail EDID please refer to 6.3 Factory Default

EDID.

3Select:



Press for 3 seconds to switch in between the Learned and

Default mode, the LED will illuminated accordingly.



Then press repeatedly to select in between EDID 1~8.

4HDMI IN: Connect with HDMI source equipment such as DVD/Blu-

ray or PS3 player. When the source equipment is connected with

power supply it can also trigger the device to activate.

6.2 Rear Panel

HDMI OUT USB

EDID

Wr.

Bypass

Emulator

Rd.

STATUS

SET

1 2

1 2 3 4 5

1HDMI OUT: Connect to HDMI TV/display.

2USB: Connect Mini-USB cable to an active USB device to power the

system. Or the device may also be triggered by an activate HDMI

input source.

3EDID SET: Press to execute EDID Read/Write function.

4EDID STATUS LED: Indicate EDID Read/Write status.

5EDID Switch:

√ Read:



Connect a display to HDMI output for EDID reading.



Switch to Emulator rst then to Rd. position.



Press [Select] button for 3 seconds to select Learned mode.



Press [Select] repeated to select an EDID storing number from

1~8.



Press [SET] button for 3 seconds to write HDMI output's EDID

correspondingly to the LED indicator.



When Status LED illuminate in Green that means learning

successfully, when in Red that means learning failed.

√ Write:



Connect a display to HDMI output for EDID writing.



Switch to Emulator rst then to Wr. position.



Press [Select] button to select a memory EDID from Learned/

Default 1~8 EDID.



Press [SET] button for 3 seconds to overwrite HDMI TV/display's

EDID and the LED will blink during the writing. When the STATUS

LED illuminate in Green that means writing successfully, when in

Red that means writing failed. If the STATUS LED did not blink and

illuminate in Red it means TV's EDID is not writable.

NOTE: Once overwrite is successfully done the original EDID will be

erased. Please be caution when using this function.

√ Emulator: When DIP switch selected to Emulator position, the

source device will read system’s current selected 1~8 EDID.

Change to other EDID, please follow LED indicators 1~8 steps.

√ Bypass: When DIP switch selected to Bypass position, the HDMI

input Video/Audio source device will read HDMI output TV/

display’s EDID directly.

6.3 Factory Default EDID

LED NO. Video Audio

1 DVI

21080p@60Hz, 8-bit LPCM 2CH

31080p@60Hz, 12-bit Deep Color LPCM 2CH

4 3D/1080p@60, 12-bit Deep Color LPCM 2CH

54K2K@24, 25, 30 LPCM 2CH

6 1080p@60, 8-bit LPCM 5.1CH

73D/1080p@60, 12-bit Deep Color Dolby TrueHD/DTS-HD

Master Audio

84K2K@24, 25, 30/3D Dolby TrueHD/ DTS-HD

Master Audio

6.4 EDID Application Installation

EDID Application Installation

The following section lists the procedures to follow when installing

the EDID application to HDMI EDID Emulator. Please follow the step

accordingly to launch the installation successfully.

Download/Insert the software application le and double click on the

“setup” le.
