CYP PUV-2010TXWP Manuel utilisateur

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

su cient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.00 XX/XX/XXXX First release

CONTENTS

UPDATE CONTENTS

1. INTRODUCTION

The PUV-2010TX Wall Plate Transmitter enables transmission of video

resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-232, PoH

(Power over HDBaseT), LAN, and USB data signals up to 100m. Utilising

the latest HDBaseT™ 2.0 technology, this solution provides advanced

signal management and dedicated audio pathways to ensure reliable

results in the most demanding of installation environments. In addition

to the full 5-Play convergence, this device also incorporates OAR (Optical

Audio Return) and ARC (Audio Return Channel) functions which enable

audio from a compatible display to be routed back from the receiver unit

to the transmitter. All audio, video, control, and power are transmitted

simultaneously over a single CAT6a/7 cable up to 100m.

This system also allows the connection of any USB host, enabling a USB

connection to 2 USB ports, giving the PU-2010RX Receiver the ability to

act like a USB hub.

This wall plate variant of the PUV-2010TX transmitter enables seamless

integration into a standard UK double-gang back box.

2. APPLICATIONS

48V PoH from Transmitter (PSE) to Receiver (PD)

Household entertainment extending and control

Lecture room display and control

Showroom display and control

Meeting room presentation and control

Classroom display and control

3. PACKAGE CONTENTS

1×HDMI/Audio over CAT5e/6/7 Transmitter

1×HDMI/Audio over CAT5e/6/7 Receiver

1×IR Blaster

×IR Extender

1×48 V/0.83 A DC Power Adaptor

1×Power Cable

1×Operation Manual

4. SYSTEM REQUIREMENTS

Input source equipment such as DVD/Blu-ray player, host PC/Laptop and

HDMI equipped output display (TV or monitor) with ampli er or active

speakers.

5. FEATURES

Supports full HDBaseT™ 2.0 speci cation signals can be received up to

a maximum distance of 100m over CAT6a/7

HDCP 2.2, HDMI and DVI compatible

HDBaseT 5-Play™ convergence: High-De nition video and audio,

100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-

Directional IR & RS-232 pass through)

Supported resolutions VGA~WUXGA, 480i~1080p, 4K

UHD@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0),

4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV

4:2:0) dependent upon the output display’s EDID settings

4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and

100m via CAT6a/7

Supports pass-through of HD audio formats: LPCM 2/5.1/7.1CH, Dolby

Digital 2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

Optical audio return (OAR)

Supports optical sampling rate up to 48kHz

Audio return channel (ARC)

Dedicated channel for analogue stereo audio transmission from the

transmitter to a compatible receiver

USB Data Serving from Transmitter (single USB) to Receiver (2x USB)

Fits in standard UK double-gang back-box

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Transmitter Front Panel

OPT. OUT OUT 1 IN 2

USB

AUDIO IN

UPDATE

ARC OUT

ON OFF

RS232 IN

POWER

LAN

LINK

HDMI IN

100M

54 6 12

1 USB: Connect from PC or Laptop for data transmit to or control from

the Receiver’s USB slots.

2 AUDIO IN L/R: Connect with audio source equipment such as PC or

CD player with 3-pin Relay cable for audio signal sending to Receiver’s

AUDIO OUT L/R.

3 ARC OUT OFF/ON SWITCH: Switch this dip switch to allows ARC

(Audio Return Channel) function to be activate or not. Switch to OFF

to disable ARC function. Switch to ON allows Receiver’s HDMI output

or Optical in audio to be routed back and output to both HDMI IN and

Optical OUT on the transmitter side.

Note: When ARC switch to ON, depending on the connected devices of

the HDMI OUT & Optical in from Receiver and the connected device of the

HDMI In & Optical Out at the Transmitter the audio format and behavior

may be varied, the ARC input/output transmission distance may be varied

too, it is suggested to use cable within 2 metres long to ensure the best

audio quality.

4 OPT. OUT: Connect to speaker for audio signal output from Receiver’s

OPTICAL IN or ARC from HDMI out.

5 IR OUT 1: Connect to the supplied IR Blaster Cable for IR signal

transmission. Place the IR Blaster in direct line-of-sight of the

equipment to be controlled.

6 IR IN 2: Connect to the supplied IR Extender cable for IR signal

reception. Ensure that remote being used is within the direct line-of-

sight of the IR Extender.

7 POWER LED: When the device is connected with power supply the

LED will illuminate.

8 LINK LED: This LED will illuminate to indicate a successful connection

between Transmitter and Receiver, when it blink irregularly it

represent the link error or when not illuminate it means no link with

Receiver.

9 LAN: Connect to internet or network service systemto this slot or

to the LAN port slot of the Receiver side for a total sharing rate of

100Mbps withing the link. The yellow LED will illuminate to represent

the link with Transmitter is steady, when it blink irregularly it represent

the link error or when not illuminate it means no link with Receiver.

The green LED will illuminate to represent the Ethernet speed is with

100Mbit/s.

10 RS-232 IN: Connect to a PC or Laptop D-Sub 9-pin female cable for

the transmission of RS-232 commands.

11 UPDATE: This is reserved for rmware update use only. Switch this

deep switch down for rmware update use, under normal operation,

leave the switch up. Update procedure may be done from the same

RS-232 port for both Transmitter and Receiver.

12 HDMI IN: Connect to HDMI source equipment such as a DVD or Blu-

ray player.

Note: When ARC switch to ON, this slot will be receiving signal from

Receiver and will not be able to send signal out to Receiver.

6.2 Transmitter Rear Panel

CAT5e/6/7 OUT

DC 48V

1 CAT5e/6/7 OUT: Connect to the Receiver unit with CAT5e/6/7 cable

for transmission of all data signals.

2 DC 48V: Plug the 48V DC power supply into the unit and connect the

adaptor to an AC outlet.
