CYP CH-A320RX Manuel utilisateur

Operation Manual

Audio over IP Receiver

CH-A320RX

DISCLAIMERS

The information in this manual has been carefully checked and is believed

to be accurate. Cypress Technology assumes no responsibility for any

infringements of patents or other rights of third parties which may result from

its use.

Cypress Technology assumes no responsibility for any inaccuracies that

may be contained in this document. Cypress also makes no commitment to

update or to keep current the information contained in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express written

permission and consent from Cypress Technology.

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document are trademarks of

the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply. Please keep the

following in mind as you unpack and install this equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain, moisture

or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any openings

or empty slots in the unit, as you may damage parts inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if it

is damaged.

• Do not allow anything to rest on the power cabling or allow any weight to

be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or openings

in the unit housing that provide ventilation and allow for su󰀩cient space

for air to circulate around the unit.

• Please completely disconnect the power when the unit is not in use to

avoid wasting electricity.

VERSION HISTORY

REV. DATE SUMMARY OF CHANGE

RDV1 2020/08/20 Preliminary release

CONTENTS

1. Introduction...................................................... 1

2. Applications ..................................................... 1

3. Package Contents ........................................... 1

4. System Requirements..................................... 1

5. Features............................................................ 2

6. Operation Controls and Functions ................ 3

6.1 Front Panel.................................................. 3

6.2 Rear Panel................................................... 4

6.3 RS-232 Pinout ............................................. 4

6.4 WebGUI Control .......................................... 5

6.4.1 System Tab......................................... 6

6.4.2 Network Tab ....................................... 9

6.4.3 Functions Tab ................................... 11

6.5 Telnet Control ............................................ 13

6.6 Serial and Telnet Commands .................... 13

7. Connection Diagram ..................................... 20

8. Specications ................................................ 21

8.1 Technical Specications ............................ 21

8.2 Audio Specications .................................. 22

8.2.1 Digital Audio ..................................... 22

8.2.2 Analog Audio .................................... 22

9. Acronyms ....................................................... 23

1. INTRODUCTION

The inherent routing exibility of Audio over IP (AoIP) provides great

advantages over traditional audio cabling solutions while using highly cost

e󰀨ective Cat.5e cable. This greatly reduces the cost of wiring large systems

and improves control convenience. This unit takes full advantage of the core

benets provided by AoIP and adds support for dual audio output formats,

including both analog (balanced speaker output) and digital (optical S/

PDIF). This product allows you to easily receive extended audio sources

from compatible audio transmission devices located anywhere on the local

network.

Standard control is provided by front panel controls, WebGUI, and Telnet.

Advanced control and system integration is possible using the optional IP

Master Controller.

2. APPLICATIONS

• Home Theaters

• Classrooms

• Lecture Halls

3. PACKAGE CONTENTS

• 1× Audio over IP Receiver

• 1× 5V/1.2A DC Power Adapter

• 1× 3-pin Terminal Block

• 1× 5-pin Terminal Block

• 1× Operation Manual

4. SYSTEM REQUIREMENTS

• Audio receiving equipment such as headphones, audio ampliers or

powered speakers.

• A Gigabit Ethernet switch with “IGMP snooping” enabled is required for

multicast support.

• An active network connection from a switch or router that supports PoE

(802.3af) to power the unit is highly recommended.

5. FEATURES

• Analog output: 1×Balanced stereo output

• Digital output: 1×Optical output

• Reception of extended audio and RS-232 over TCP/IP in unicast (point-to-

point) or multicast (single-to-many) modes

• Reception of extended AoIP signals can be further extended (up to 100m

per segment) by using gigabit network switches.

• Volume control for the analog audio output

• Compatible with the IP Master Controller to allow integration with existing

compatible TCP/IP video matrix networks.

• Field-upgradable rmware

• May be powered directly by Power over Ethernet (PoE) when connected

to a Gigabit Ethernet switch that provides PoE (802.3af)

• Standard control is provided by front panel controls, WebGUI, and Telnet.

Advanced control and system integration is possible using the optional IP

Master Controller.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

PWR

LINE

MIC

LINK MUTE

AUDIO

SELECT

CH - CH + MUTE

VOL.

OPT.

346

1PWR LED: This LED will illuminate to indicate the unit is on and receiving

power.

2LINK LED: While the receiver is attempting to establish a network

connection the LINK LED will ash. When the receiver has established a

stable connection the LINK LED will illuminate solidly.

3OPT/LINE/MIC LEDs: The illuminated LED indicates which source is

currently selected on the linked transmitter.

Note: Only active when linked directly to a compatible dedicated audio

transmitter.

4MUTE LED: This LED will illuminate when audio output is muted.

5CH-/CH+ Buttons: Press these buttons to increase or decrease the

streaming channel used to receive audio from the local network.

Note: If only one channel is detected, the channel number will not

change.

6MUTE Button: Press to toggle between muting and unmuting the audio

output.

7VOL -/+ & AUDIO SELECT Knob: Turn this knob to increase or

decrease the audio volume level of the analog output. Press the knob in

to sequentially switch through the available audio sources on the linked

transmitter.

Note: Input selection is only available when linked directly to a compatible

dedicated audio transmitter.

6.2 Rear Panel

OPTICALAUDIO LAN(POE)

RS-232

TX RX

DC 5V

OUT

RL G

134

1AUDIO L/R OUT 5-pin Terminal Block: Connect to powered speakers

or an amplier for analog stereo audio output.

2OPTICAL OUT Port: Connect to powered speakers or an amplier for

digital audio output using an appropriate optical cable.

3RS-232 3-pin Terminal Block: Connect to a serial controllable device

with a 3-pin adapter cable for the reception of RS-232 signals from a

compatible transmitter.

4LAN(POE) Port: Connect via a Gigabit Ethernet switch to compatible

receiver(s) to transmit data, and to a PC/laptop to control the unit via

WebGUI.

Note: This unit can be powered directly by the connected Gigabit

Ethernet switch if it provides PoE (802.3af).

5DC 5V Port: Plug the 5V DC power adapter into the unit and connect it

to an AC wall outlet for power. (Optional if powered by PoE)

6.3 RS-232 Pinout

RxD

GND

TxD

3-pin

Terminal Block

6.4 WebGUI Control

• Device Discovery

Please obtain the “Device Discovery” software from your authorized dealer

and save it in a directory where you can easily nd it.

Connect the unit and your PC/Laptop to the same active network and

execute the “Device Discovery” software. Click on “Find Devices on Internet”

and a list of devices connected to the local network will show up indicating

their current IP address.

Note: This unit defaults to Auto IP mode. The current IP address can be

veried using the Device Discovery software.

By clicking on one of the listed devices you will be presented with the

network details of that particular device.

1) IP Mode: If you choose, you can alter the static IP network settings for

the device, or switch the unit into DHCP mode to automatically obtain

proper network settings from a local DHCP server. To switch to DHCP

mode, please select DHCP from the IP mode drop-down, then click “Save”

followed by “Reboot”.

2) WebGUI Hotkey: Once you are satised with the network settings, you

may use them to connect via Telnet or WebGUI. The network information

window provides a convenient link to launch the WebGUI directly.
