CH-514RXWPL
HDMI over CAT5e/6/7 Wall Plate Receiver
Operation Manual
Operation Manual
DRAFT
DRAFT
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.0 September 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
DRAFT
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 20/06/13 Preliminary Release
DRAFT
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 IR Cable Pin Assignment..................4
7. Connection Diagram ............................ 5
8. Specications ........................................ 6
8.1 CAT5e/6/7 Cable Specication .....7
9. Acronyms ............................................... 7
DRAFT
1
1. INTRODUCTION
The HDMI over CAT5e/6/7 Wall plate Receiver make your home or
ofce more efcient. This Receiver can receive uncompressed Video/
Audio and Bi-directional IR over 60 meters from Transmitter. It is freely
to connect with compatible Transmitter through CAT5e/6/7 for data
transmission.
2. APPLICATIONS
• Household entertainment sharing and control
• Showroom/Meeting room/Classroom display and control
3. PACKAGE CONTENTS
• HDMI over Cat5e/6/7 Receiver
• IR Blaster x 1
• IR Receiver x 1
• 5V DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI over CAT5e/6/7 Transmitter and output with HDMI TV/
display
DRAFT
2
5. FEATURES
• HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant
• Supports data rate from 250Mbps up to 3Gbps
• Supports wide range of PC resolutions from VGA to WUXGA
and HDTV resolutions up to 4Kx2K (3840x2160@30Hz and
4096x2160@24Hz)
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
• Master Audio transmission (32-192kHz sample rate)
• Supports distance up to 60 meters through HDMI to CAT5e/6/7
Transmitter
• Supports Bi-directional IR control
• Wall plate design and installation friendly
Note:
1. This system was tested with CAT6/23AWG cables, results may vary
withcablesofadifferentspecication.
2. Displaying HDMI 4Kx2K resolution require the standard 4Kx2K HDMI
cable and display in order for proper image displaying.
DRAFT
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
HDMI OUT
POWER
LINK
IR 1
Digital Eye
IR 2
Emitter
DC 5V
1 3 4
2 4 6
1IR 1 EXTENDER: Connect to the supplied IR Extender cable for IR
signal reception. Ensure that remote controller being used is within
the direct line-of-sight of the IR Extender.
2IR2 BLASTER: Connect to the supplied IR Blaster cable for IR signal
transmission. Place the IR Blaster in direct line-of sight of the
equipment to be controlled.
3DC 5V: Plug the 5V DC power supply into the unit and connect the
adaptor to an AC outlet.
4HDMI OUT: Connect to HDMI TV/display for instant image display or
cascade with another family type Transmitter.
5LINK LED: This LED will illuminate when both CAT5e/6/7 input and
output signal is connected.
6POWER LED: This LED will illuminate when the device is connected
to a power supply.
DRAFT
4
6.2 Rear Panel
1
1CAT5e/6/7: Connect this port to HDMI to CAT5e/6/7 Transmitter
(without PoE function) with CAT5e/6/7 cable to extend the signal
up to 60 meters.
6.3 IR Cable Pin Assignment
3
1
3
1
2
2
Power 5 V
IR Blaster Signal
NC
IR Signal
Power 5 V
Grounding
IR Extender
IR Blaster
DRAFT
5
7. CONNECTION DIAGRAM
7m
3m 3m
60°
m
7m
3m 3m
60°
m
1.5m
60°
1.5m
60°
CONTROL
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUTCAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
1
2
3
4
V+
GND
GND GND
V+
HDMI OUT
POWER
LINK
IR 1
Digital Eye
IR 2
Emitter
DC 5V
IR2 Receiver
IR1 Blaster IR2 Blaster
IR1 Receiver
HD Monitor or TV
or Projector
HDMI Cable HDMI Cable
DC DC
Blu-ray
CAT5e/6/7(60M)
TV/HD Monitor's
Remote
Blu-ray's
Remote
