CYP COH-TX1 Manuel utilisateur
COH-TX1 & COH-RX1
HDMI to Optical Transmitter and Receiver
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VS1 20/03/12 First Release
VR2 31/05/12 RS-232 equipped device
connection
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Transmitter Front and Rear Panels..3
6.2 Receiver Front and Rear Panels .....4
7. Support Timing Chart............................. 5
7.1 TV Timing.................................... 5
7.2 PC Timing ................................... 6
8. Connection Diagram ............................ 7
9. Specications ........................................ 8
10. Acronyms ............................................. 9
1
1. INTRODUCTION
With HDMI becoming more and more popular around the world,
many consumers have been searching for a way to transmit HDMI
signals over very long distances. The HDMI to Optical Transmitter
and Receiver set which uses ber optical cables will give you longer
transmission distances (up to 300m) while also providing you with
thinner, lighter cables for easier installation. With this system the HDMI
signal is not compressed and is fully compliant with HDMI and HDCP.
2. APPLICATIONS
• IR & RS-232 control over ber optical
• Digital signage, airport displays, advertising, video walls or special
events
• Surveillance systems
3. PACKAGE CONTENTS
• HDMI to Optical Transmitter
• Optical to HDMI Receiver
• 2 x 3.5 mm phone jack to D-Sub 9pin converter cables
• 1 x IR Extender
• 1 x IR Blaster
• 2 x 5 V DC Power Adaptors
• Operation Manual
4. SYSTEM REQUIREMENTS
Input source devices such as DVD or Blu-Ray players with HDMI cables
and output displays such as HDTV’s and monitors with HDMI ports.
2
5. FEATURES
• HDMI v1.2, HDCP and DVI compliance
• Long transmission distances - up to 300m or more
• Thinner and lighter cables for easier, more discreet installations
• Faster data transmission
• Lower power consumption
• Support the reading of EDID information
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter Front and Rear Panels
DC 5V
Optical
MainSUB
Error
HDMI
IR-Out
Optical
HDMI
Input
RS-232
13
2 54 6 7 8
1
OPTICAL LED: This blue LED will illuminate when at least one
optical cable is connected and has successfully detected and
communicated data between the Transmitter and Receiver.
Note: If the LED is not illuminated then users will need to check
the connection of the ber cable between the Transmitter and
Receiver units and then check the connection is good and that
the cable itself is correct and undamaged.
2
ERROR LED: This red LED will illuminate when there is an error in the
input signal data rate that is higher than 75/170MHz (Single/Dual).
Double Check all connections and make sure they are properly
connected.
3
HDMI LED: This blue LED will illuminate when the Transmitter unit is
receiving a HDMI signal from the source device.
4
HDMI INPUT: Connect to an HDMI input source such as a DVD or
Blu-ray player with a HDMI cable.
5
IR-OUT: Connect to the supplied IR blaster cable for IR signal
transmission. Place the IR blaster in direct line-of-sight of the
equipment to be controlled.
6
RS-232: Connect to a PC or laptop (with supplied 3.5mm phone
jack to D-Sub 9pin adaptor) for the transmission of RS-232
commands.
7
OPTICAL SUB & MAIN: Connect the Transmitter and Receiver units
with 2-way ber optical cable to transmit the data signal
Note: Connector Type: LC-LC, Fiber: Duplex Single-mode Fiber
8
DC 5V: Connect to the power adaptor included in the package
from the AC wall outlet for power supply.
4
6.2 Receiver Front and Rear Panels
DC 5V
Optical
MainSUB
Error
HDMI
HDMI
Output
Optical
IR-In RS-232
1
3
2 54 6 7 8
1
OPTICAL LED: This blue LED will illuminate when at least one
optical cable is connected and has successfully detected and
communicated data between the Transmitter and Receiver.
Note: If the LED is not illuminated then users will to need to check
the connection of the ber cable between the Transmitter and
Receiver units and then check the connection is good and that
the cable itself is correct and undamaged.
2
HDMI LED: This blue LED will illuminate when the device is
successfully communicating with the display.
3
ERROR LED: Under normal conditions, this red LED will not illuminate
but will blink for few seconds when startup of the the device.
When the LED is illuminated constantly, it means the HDMI output
is not able to output a HDMI signal. Double check the connection
and also make ensure the source is sending a compatible HDMI
signal. Check all connections and make sure they are all properly
connected.
4
HDMI OUTPUT: Connect to a HDMI Display device, such as a TV or
monitor, with a HDMI cable.
5
IR-IN: Connect to the supplied IR Extender cables for IR signal
reception. Ensure that remote being used is within the direct line-
of-sight of the IR extender.
6
RS-232: Connect to the device that is to be controlled (with the
supplied 3.5mm phone jack to D-Sub 9pin adaptor) by RS-232
commands
7
OPTICAL SUB & MAIN: Connect the Transmitter and Receiver units
with 2-way ber optical cable to transmit the data signal.
Note: Connector Type: LC-LC, Fiber: Duplex Single-mode Fiber
8
DC 5V: Connect to the power adaptor included in the package
from the AC wall outlet for power supply.
5
7. SUPPORT TIMING CHART
7.1 TV Timing
VIC Formats Field Rate Picture Aspect Ratio
1 720 × 480p 59.94 Hz/60 Hz 4:3
2 720 × 480p 59.94 Hz/60 Hz 16:9
3 1280 × 720p 59.94 Hz/60 Hz 16:9
41920 ×1080i 59.94 Hz/60 Hz 16:9
5 720 (1440) × 480i 59.94 Hz/60 Hz 4:3
6720 (1440) × 480i 59.94 Hz/60 Hz 16:9
71920 ×1 080p 59.94 Hz/60 Hz 16:9
8 720 × 576p 50 Hz 4:3
9720 × 576p 50 Hz 16:9
10 1280 × 720p 50 Hz 16:9
11 1920 × 1080i 50 Hz 16:9
12 720 (1440) × 576i 50 Hz 4:3
13 720 (1440) × 576i 50 Hz 16:9
14 1920 × 1080p 50 Hz 16:9
15 1920 × 1080p 23.97 Hz/24 Hz 16:9
16 1920 × 1080p 25 Hz 16:9
17 1920 × 1080p 29.97 Hz/30 Hz 16:9
