PU-607BD-RX
HDMI over Single CAT5e/6/7 HDBaseT™ - Bi-directional
PoC Receiver (full 5Play™ & Single LAN up to 100m)
OPERATION MANUAL
3
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2019 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
4
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 11/02/2014 First release
v1.01 31/03/2014 Corrected Contents List
V1.02 22/08/2019 Update Format and Cable Distance
5
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features..................................................7
6. Operation Controls and Functions.......8
6.1 Receiver Front and Rear Panels ............ 8
6.2 IR Cable Pin Assignment ......................... 9
6.3 D-Sub 9 Pin Denitions ........................... 9
7. Connection Diagram .......................... 10
8. Specications...................................... 11
8.1 Technical Specications ........................11
8.2 Cable Specications ...............................12
9. Acronyms............................................. 13
6
1. INTRODUCTION
The PU-607BD-RX Receiver can receive uncompressed video/audio and IP
data over an single run of CAT5e/6/7 cable up to 100m/328ft at 1080p and
70m/229ft at 4K. It has the added benet of control through the built-in
RS-232 pass-through and 2-way IR control and a LAN serving connection.
Additionally, it has bi-directional Power over Cable (PoC) functionality
that allows for greater exibility in installations.
This Receiver is designed to be used with the PU-607BD-TX or PU-
607BDWP-TX Transmitters only, which enables bi-directional Power over
Cable (PoC) functionality that allows for greater exibility in installations.
2. APPLICATIONS
Household entertainment sharing and control
Lecture room display and control
Showroom display and control
Meeting room presentation and control
Classroom display and control
3. PACKAGE CONTENTS
1×PU-607BD-RX Receiver
1×IR Blaster
1×IR Receiver
Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI source equipment such as DVD/Blu-ray player and HDMI
equipped output display (TV or monitor).
7
5. FEATURES
HDMI 1.x and DVI 1.0 compliant
HDCP compliant
Supports HDMI 3D and 4K x 2K features
Supports HDCP repeater and CEC bypass
Supports distance up to 100m/328ft at 1080p and 70m/229ft at 4K
through CAT5e/6/7 cable
HDMI input resolutions up to 4K@60Hz (YUV 4:2:0, 8-bit) or 4K@30Hz
(YUV 4:4:4, 8-bit)
Supports pass-through of audio formats including LPCM 2.0/5.1/7.1,
and Bitstream over HDMI
HDBaseT™ convergence: uncompressed high-denition Video and
Audio, LAN serving, Bi-directional Power over Cable (PoC) and IR/RS-
232 Control pass-through
Installation friendly
Note:
1. This system was tested with CAT6/23AWG cables, results may vary with
cables of a dierent specication.
2. The PoC function is designed for powering compatible units only—non-
PoC units will need their own power supply.Receivers of another brand
may not be compatible.
3. For playback of 4K2K HDMI source signals, a 4K2K capable display and
High Speed HDMI cables are required.
Note: Only compatible with PU-607BD-TX & PU-607BDWP-TX Transmitters
8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Receiver Front and Rear Panels
RS-232 Out
LAN
HDMI Out
Receiver
RearFront
CAT5e/6 In
Link
IR1 Extender
IR2 Blaster
Power
DC 24V
2 31 74 8 965
1HDMI Out: Connect to a HDMI equipped TV/monitor for display of the
HDMI input source signal.
2LAN: Connect to a PC or Laptop to the Internet or network
connection.
3RS-232 Out: Connect to the device that is to be controlled (via D-Sub
9 pin female cable) by RS-232 commands.
4Power LED: This blue LED will illuminate when the device is
connected to a power supply.
5DC 24V: Plug the 24 V DC power supply into the unit and connect
the adaptor to an AC outlet. Only one side of power needs to be
connected to activate both transmitter and receiver.
6IR 2 Blaster: Connect to the supplied IR blaster cable for IR signal
transmission. Place the IR blaster in direct line of sight of the
equipment to be controlled.
7IR 1 Extender: Connect to the supplied IR receiver cables for IR signal
reception. Ensure that remote being used is within the direct line-of-
sight of the IR extender.
8Link LED: The yellow LED will illuminate when both the input and
output signals are connected.
9CAT5e/6 In: Connect to the transmitter unit with a Single CAT5e/6
cable for transmission of all data signals.
9
6.2 IR Cable Pin Assignment
3
1
2
3
2
1Power 5V
IR Blaster Signal
NC
IR Signal
Power 5V
Ground
IR Receiver
IR Blaster
6.3 D-Sub 9 Pin Denitions
Pin Dene TX / RX
1N/C
2TxD / RxD
3RxD / TxD
4N/C
5GND
6N/C
7N/C
8N/C
9N/C
10
7. CONNECTION DIAGRAM
RS-232 In
LAN
HDMI In
HDMI to CAT5e/6 with LAN/IR/RS232
Transmitter
CAT5e/6 Out
Link
IR2 Extender
IR1 Blaster
DC 24V
Power
RS-232 Out
LAN
HDMI Out
CAT5e/6 to HDMI with LAN/IR/RS232
Receiver
CAT5e/6 In
Link
IR1 Extender
IR2 Blaster
Power
DC 24V
1.5m
60°
1.5m
60°
7m3m 3m
60°
m
m
m
7m3m 3m
60°
m
m
m
TV or Monitor
RS-232 Equipped
PC or Notebook
RS-232 Equipped
HDMI Switcher
Notebook
DVD or Blu-ray Player
Internet
Modem or
Router
Power
Supply
IR
Blaster
IR
Blaster
HDMI
Output
HDMI
Input
LAN
Serving
LAN
Serving
Single
CAT5e/6/7
Cable
RS-232
IR
Extender
IR
Extender
RX
TX
RS-232
Note: Only a single unit needs to be powered and
can power the other unit via PoC. In this example the
Transmitter powers the Receiver.
