Crestron TPS-6

Isys™5.7”TiltTouchpanel

Operations Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

Regulatory Compliance

Federal Communications Commission (FCC) Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Industry Canada (IC) Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject to the following conditions:

(1) this device may not cause harmful interference and (2) this device must accept any interference received,

including interference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance

could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy

and if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna

Increase separation between the equipment and the receiver

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

Consult the dealer or an experienced radio/TV technician for help

As of the date of manufacture, the TPS-6 has been tested and found to comply with specifications for CE

marking and standards per EMC and Radiocommunications Compliance Labelling.

All brand names, product names and trademarks are the property of their respective owners.

Crestron TPS-6 Isys™ 5.7” Tilt Touchpanel

Contents

Isys™ 5.7” Tilt Touchpanel: TPS-6 1

Introduction ...............................................................................................................................1

Features and Functions................................................................................................2

Specifications ..............................................................................................................4

Physical Description....................................................................................................7

Setup........................................................................................................................................10

Network Wiring.........................................................................................................10

Identity Code.............................................................................................................10

Configuring the Touchpanel......................................................................................11

Hardware Hookup .....................................................................................................27

Recommended Cleaning............................................................................................28

Programming Software............................................................................................................30

Earliest Version Software Requirements for the PC .................................................30

Programming with Crestron SystemBuilder..............................................................30

Programming with SIMPL Windows........................................................................31

Programming with VisionTools Pro-e.......................................................................33

Uploading and Upgrading........................................................................................................38

Establishing Communication.....................................................................................38

Programs, Projects and Firmware..............................................................................39

Program Checks ........................................................................................................39

Problem Solving ......................................................................................................................40

Troubleshooting.........................................................................................................40

Check Network Wiring..............................................................................................41

Reference Documents................................................................................................42

Further Inquiries........................................................................................................42

Future Updates ..........................................................................................................42

Software License Agreement...................................................................................................43

Return and Warranty Policies..................................................................................................45

Merchandise Returns / Repair Service ......................................................................45

CRESTRON Limited Warranty.................................................................................45

Operations Guide – DOC. 6945A Contents •i

Crestron TPS-6 Isys™ 5.7” Tilt Touchpanel

Isys™ 5.7” Tilt Touchpanel:

TPS-6

Introduction

The Crestron Isys®TPS-6 Tilt Touchpanel delivers high-end style and performance

in a striking tabletop design. Sleek and compact, the TPS-6 does away with piles of

remotes and cryptic control panels, affording true "one-touch" control over a broad

range of complex devices and systems. Featuring a bright, beautiful, high-contrast

color touchscreen, the TPS-6 offers an ideal user-interface for controlling multimedia

presentations, home automation, and a host of other uses, providing a wide open

canvas for the creation of custom control screens tailored to each unique application.

The TPS-6 is available in three different models.

Models

MODEL NUMBER COLOR

TPS-6 High Gloss Black

TPS-6-B-T Matte Black

TPS-6-W-S High Gloss White

Operations Guide – DOC. 6945A Isys™ 5.7” Tilt Touchpanel: TPS-6 •1

Isys™ 5.7” Tilt Touchpanel Crestron TPS-6

Features and Functions

• Sleek, contoured design for tabletop use

• Full-time wired touchpanel operation

• Elegant high gloss black or white, or matte black finishes

• Illuminated buttons and engravable backlit text*

• 5.7" active matrix color touchscreen display

• 16-bit Isys graphics | 640 x 480 resolution

• Dynamic graphics & text capability

• Synapse™ image rendering algorithm

• Full-motion video display

• High-speed Ethernet and Cresnet®communications

• Crestron Home®CAT5 video connectivity

• Up to 45 degree tilt adjustment

• Low-profile single-wire connection

• No-button front bezel option included

Isys™ Color Touchscreen

Its brilliant 5.7" active-matrix display and powerful Isys engine combine to produce

stunning 16-bit color graphics with extreme versatility and lightning-fast

performance. Dynamic graphics and text capability enable the display of all kinds of

useful data, from audio settings, TV channels, and lighting levels, to changing icons,

photos, and logos, to digital media playlists complete with album cover art.

Crestron®exclusive Synapse™ image rendering algorithm enables system

programmers to produce amazing graphics faster and easier, featuring advanced

antialiasing for crisper, sharper objects and text, plus 3D effects for enhanced depth

and style. Additional capabilities like animations, multimode objects, PNG

translucency, and full-motion video enhance the palette for creating GUI’s that are

both eye-catching and easy to use.

Tactile Pushbuttons

In addition to its touchscreen, the TPS-6 features illuminated tactile pushbuttons for

quick access to volume adjustment, channel selection, and on-screen menu

navigation functions. Eight additional pushbuttons, elegantly trimmed by illuminated

button dividers, flank the edges of the touchscreen to support additional

programmable functions.

High-quality backlit laser-engraving lends a crisp, legible appearance to button text

in both darkened and fully lit rooms*. The pushbuttons come pre-engraved with

labeling suited to a typical home theater or multimedia presentation application. If

needed, customized engraving can be attained simply using Crestron Engraver

software. A no-button front bezel is also included with the TPS-6, which may be

installed in place of the button bezel for a very clean appearance with no front panel

pushbuttons.

Two additional “trigger” style buttons are positioned on top of the TPS-6 for easy

control of the display brightness and other programmable functions.

* Text engraving on the TPS-6-W-S white model is not backlit.

2 •Isys™ 5.7” Tilt Touchpanel: TPS-6 Operations Guide – DOC. 6945A

Crestron TPS-6 Isys™ 5.7” Tilt Touchpanel

Full Motion Video

The TPS-6 displays full-motion video, providing the ability to monitor a security

camera, or preview a DVD or television channel, right on the touchscreen display.

The video image is fully scalable for viewing in any size window or full screen. The

choice of balanced or unbalanced composite inputs allows compatibility with both

conventional coaxial and Crestron Home®Balanced AV distribution systems.

TableTop Tilt Base

With its sleek and innovative tilting base, the TPS-6 functions as a stylish tabletop

tilt touchpanel, providing full-time wired communications and video capability. Both

high-speed Ethernet and Cresnet connectivity are available. The screen tilt can be

freely adjusted or locked down at up to a 45 degree angle for optimal viewing and

operation. A single cable exits the rear of the base, extending to a wall or surface

mounted TPS-6X-IMCW Interface Module (included). The cable can also be

repositioned to exit from the bottom for a very clean, cordless appearance. A swivel

mount kit is also available for fixed-mount applications that require the ability to

rotate the touchpanel during use.

Operations Guide – DOC. 6945A Isys™ 5.7” Tilt Touchpanel: TPS-6 •3

Isys™ 5.7” Tilt Touchpanel Crestron TPS-6

Specifications

Specifications for the TPS-6 are listed in the following table.

TPS-6 Specifications

SPECIFICATION DETAILS

Touchscreen Display

Display Type TFT Active matrix color LCD

Size 5.7 inch (145 mm) diagonal

Aspect Ratio 4:3 VGA

Resolution 640 x 480 pixels

Brightness 350 nits

Contrast 400:1

Color Depth 18-bit, 256 k colors

Illumination Backlit fluorescent

Viewing Angle ±80º horizontal, +80º/-70º vertical

Touchscreen Resistive membrane

Processor

CPU 32-bit Freescale ColdFire®Microprocessor

Memory

SDRAM 32 MB

Flash 32 MB

Maximum Project Size 28 MB

Graphic Engine Isys engine; 16-bit non-palette graphics;

65,536 colors; Synapse image rendering

algorithm; multi-mode objects, dynamic

graphics, PNG translucency, full-motion (60

fps) animation, color key video windowing

Ethernet 10BASE-T/100BASE-TX, auto-switching,

auto-negotiating, auto-discovery, full/half

duplex, TCP/IP, UDP/IP, CIP, DHCP, IEEE

802.3U compliant

Video

Signal Types Composite

Formats NTSC 480i or PAL 576i

Color Depth 18-bit, 262,144 colors

Windowing Single window, deinterlaced and scalable up

to full screen

Audio Internal transducer for key click sound

Power Requirements1

24 VDC Power Consumption 0.75 Amps @ 24 Volts DC including

interface module

Power connection is via TPS-6X-IMCW

interface module2

Cresnet Power Usage 16 Watts (0.67 Amps @ 24 Volts DC)

including interface module

Power connection is via TPS-6X-IMCW

interface module2

(Continued on following page)

4 •Isys™ 5.7” Tilt Touchpanel: TPS-6 Operations Guide – DOC. 6945A

Crestron TPS-6 Isys™ 5.7” Tilt Touchpanel

TPS-6 Specifications (Continued)

SPECIFICATION DETAILS

Default Net ID 03

Minimum 2-Series Control

System Update File3, 4 Version 3.155.1240 or later

Environmental

Temperature 32º to 112ºF (0º to 45ºC)

50º to 104ºF (10º to 40ºC) while charging

Humidity 10% to 90% RH (non-condensing)

Heat Dissipation 30 BTU/Hr

Enclosure

Construction Plastic, 45° to 90° adjustable friction clutch

tilt mechanism, low-profile base, integral

cable assembly, swivel mount kit available

separately

Front Bezels Button and no-button bezels included; button

bezel includes white translucent illuminated

Up/Down and Thumbpad buttons and eight

hardkey buttons with illuminated dividers and

default backlit5text engraving, optional

custom backlit5text engraving sold

separately

Dimensions

Height 6.21 in (158 mm) maximum

Width 8.08 in (206 mm)

Depth 7.02 in (179 mm), 6.53 in (166 mm) without

grommet

Weight 2.9 lbs (1.3 kg)

Available Models

TPS-6 Isys 5.7” Tilt Touchpanel, High Gloss Black

TPS-6-B-T Isys 5.7” Tilt Touchpanel, Matte Black

TPs-6-W-S Isys 5.7” Tilt Touchpanel, High Gloss White

Included Accessories

Power Pack 24 Volt Power Pack

TPS-6X-FP Button Bezel with Default Engraving

(specify color)

TPS-6X-FP-NB No Button Bezel (specify color)

TPS-6X-IMCW Interface Module

Available Accessories

SMK-6X Swivel Mount Kit

TPS-6X-FP Button Bezel w/Custom Engraving

(specify color)

1. May be powered by 24 Volts DC or Cresnet network power but not both.

2. Item is included with the TPS-6; refer to individual product specifications for additional information.

3. The latest software versions can be obtained from the Crestron®website. Refer to the NOTE

following these footnotes.

4. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product

Catalog for a complete list of 2-Series control systems.

5. Text engraving on the TPS-6-W-S white model is not backlit.

Operations Guide – DOC. 6945A Isys™ 5.7” Tilt Touchpanel: TPS-6 •5

Isys™ 5.7” Tilt Touchpanel Crestron TPS-6

NOTE: Crestron software and any files on the website are for authorized Crestron

dealers and Crestron Authorized Independent Programmers (CAIP) only. New users

may be required to register to obtain access to certain areas of the site (including the

FTP site).

6 •Isys™ 5.7” Tilt Touchpanel: TPS-6 Operations Guide – DOC. 6945A

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Crestron Écran tactile

Crestron

Crestron Isys TPS-12 Manuel utilisateur

Crestron

Crestron TPMC-3X Series Manuel utilisateur

Crestron

Crestron STX-1600C Manuel utilisateur

Crestron

Crestron TPS-6X Series Manuel utilisateur

Crestron

Crestron SmarTouch ST-1700C Manuel utilisateur

Crestron

Crestron TSW-770R Series Manuel utilisateur

Crestron

Crestron TPMC-V12 & TPMC-V15 Manuel utilisateur

Crestron

Crestron QM-FTCC Comment utiliser

Crestron

Crestron Wallmount Touchpanel Manuel utilisateur

Crestron

Crestron CT-1600 Guide de démarrage rapide

Crestron

Crestron TSW-770-GV Manuel utilisateur

Crestron

Crestron TPS-4500IMC Manuel utilisateur

Crestron

Crestron TSW-570PR Series Manuel utilisateur

Crestron

Crestron TPS-FPAR6000L Manuel utilisateur

Crestron

Crestron DualTouch DTT-17 Manuel utilisateur

Crestron

Crestron TSS-752 Manuel utilisateur

Crestron

Crestron CT-3500 Manuel utilisateur

Crestron

Crestron MTX-3 Manuel utilisateur

Crestron

Crestron TSD-2220 Dessin dimensionnel

Crestron

Crestron TPS-4500IMW Manuel utilisateur

Crestron

Crestron Isys TPS-5000L Manuel utilisateur

Crestron

Crestron TSW-570 Manuel utilisateur

Crestron

Crestron C2N-FT-TPS4 Manuel utilisateur

Crestron

Crestron TSW-730 Manuel utilisateur

Manuels Écran tactile populaires d'autres marques

FlowLine

FlowLine Data loop Manuel utilisateur

ALPEX

ALPEX AEx-8 P Series Manuel utilisateur

Ltech

Ltech E5S Manuel utilisateur

Harman

Harman AMX MODERO S MSD-701-L2 Manuel utilisateur

Acnodes

Acnodes PC 1150 Manuel utilisateur

AIS

AIS IP10IA99 series Manuel utilisateur

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manuel utilisateur

YASKAWA

YASKAWA TP 610C Manuel utilisateur

B&R

B&R Power Panel C Series Manuel utilisateur

Beijer Electronics

Beijer Electronics X2 control Manuel utilisateur

AXIOMTEK

AXIOMTEK GOT321W-521 Manuel utilisateur

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manuel utilisateur

Qomo

Qomo QIT1386 Manuel utilisateur

DFI

DFI KS104-CD Manuel utilisateur

AMX

AMX AXP-PPC Mode d’emploi

Sartorius

Sartorius X3 PR 5410 Manuel utilisateur

AMX

AMX Modero X Series Manuel utilisateur

Advantech

Advantech TPC-30 Series Manuel utilisateur
