Crestron TSW-730-MSMK Manuel utilisateur

Crestron TSW-730-MSMK

Multi-Surface Mount Kit for TSW-730

Installation Guide

Multi-Surface Mount Kit for TSW-730 Crestron TSW-730-MSMK

The specific patents that cover Crestron products are listed at patents.crestron.com.

Crestron and the Crestron logo are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries.

Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or

their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or

photography.

This document was written by the Technical Publications department at Crestron.

Contents Installation Guide – DOC. 7415A

Contents

Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK 1

Introduction................................................................................................................................1

Supplied Hardware ......................................................................................................2

Installation ................................................................................................................... 5

Resources................................................................................................................................. 16

Further Inquiries ........................................................................................................ 16

Future Updates ..........................................................................................................16

Return and Warranty Policies ..................................................................................................17

Merchandise Returns / Repair Service ......................................................................17

Crestron Limited Warranty........................................................................................ 17

Crestron TSW-730-MSMK Multi-Surface Mount Kit for TSW-730

Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK •1

Multi-Surface Mount Kit

for TSW-730: TSW-730-MSMK

Introduction

The TSW-730-MSMK Multi-Surface Mount Kit from Crestron®provides a very

versatile surface mounting solution for a TSW-730 Touch Screen. Using the

Multi-Surface Mount Kit, the touch screen device can be mounted directly onto

glass, granite, marble, plaster, smooth stone and masonry or virtually any other flat

surface using either the self-adhering mounting plate or screws. An optional angle

bracket is included to allow the touch screen to be mounted at a fixed tilt of 20

degrees up or down.

An adhesive backed raceway is also provided for use on smooth surfaces to conceal

wires running to the touch screen from the floor or ceiling. The raceway is paintable

and is composed of three 3 foot (0.9 meter) sections plus an assortment of elbows

and couplings.

Models

DESCRIPTION MODEL NUMBER COLOR

Multi-Surface Mount Kit

TSW-730-MSMK-B-S

Black Smooth

TSW-730-MSMK-W-S

White Smooth

For simplicity within this guide the color and texture designation are omitted and the

term “TSW-730-MSMK” is used, unless otherwise noted.

Multi-Surface Mount Kit for TSW-730 Crestron TSW-730-MSMK

2•Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A

Supplied Hardware

The TSW-730-MSMK consists of a plastic surface mount enclosure, metal mounting

plate with adhesive backing, angled mounting bracket, plastic covers to protect

cabling openings, raceway and appropriate screws and nuts for mounting.

The multi-surface mounting option provides the necessary support and accessories

for post-construction applications. The table below lists all parts included with the

TSW-730-MSMK.

Supplied Hardware for the TSW-730-MSMK

DESCRIPTION PART NUMBER COLOR QUANTITY

Assembly, Metal, Plate, Glass

Mount, Foam with Adhesive

4516855 White 1

4516856 Black 1

Plastic, Enclosure,

Surface Mount

2033441 White 1

2033442 Black 1

Plastic, Cover, Wire 2024491 White 2

2024492 Black 2

Metal Bracket,

20 Degree Mount

2033272 White 1

2033273 Black 1

Plastic, Wire Raceway Kit 2024932 White 1

Screw, #04-40 x 1/4”, Steel,

Pan, Phillips

2007161 N/A 4

Nut, #04-40, External, Hex 2004878 N/A 4

Label, Back Glass,

~ 6.5” x 4.5” x 0.01”

4517696 White 1

4517697 Black 1

Crestron TSW-730-MSMK Multi-Surface Mount Kit for TSW-730

Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK •3

The dimensions of the TSW-730-MSMK are shown below and on the next page.

Glass Mounting Plate Overall Dimensions

6.50 in

(166 mm)

4.25 in

(108 mm)

Angle Mounting Bracket Overall Dimensions

6.25 in

(159 mm)

4.04 in

(103 mm)

0.23 in

(6 mm)

1.59 in

(41 mm)

Multi-Surface Mount Kit for TSW-730 Crestron TSW-730-MSMK

4•Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A

Plastic Enclosure Overall Dimensions (Rear View)

5.75 in

(146 mm)

5.00 in

(127 mm)

3.25 in

(83 mm)

3.00 in

(77 mm)

4.74 in

(121 mm)

Plastic Enclosure Overall Dimensions (Bottom View)

8.76 in

(223 mm)

0.93 in

(24 mm) 0.63 in

(16 mm)

Crestron TSW-730-MSMK Multi-Surface Mount Kit for TSW-730

Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK •5

Installation

This section provides an installation procedure for each mounting scenario. “Glass

Mounting” starts below, “Drywall, Paneling, Concrete or Brick Mounting” starts on

page 12 and “Raceway Mounting” is on page 15. Be sure to review each procedure

before starting.

Glass Mounting

The touch screen can be mounted onto a flat pane of glass or similar smooth surface

(such as granite, marble, plaster, smooth stone or masonry) using the included glass

mounting plate. The back of the plate has an adhesive tape that permanently attaches

to the glass. The touch screen can be flat mounted or angle mounted to the glass

mounting plate by following the appropriate procedure below. After installation is

complete, the raceway kit may be installed on a smooth surface by following the

“Raceway Mounting” procedure on page 15.

NOTE: Ensure the glass mounting surface is cleaned with a glass cleaning product

that does not leave a film and is free of debris before mounting. Once glass mounting

plate has been attached, it cannot be easily removed.

Flat Mounting Complete the following procedure to attach the glass mounting plate. The only tools

and supplies required and not supplied are a level, tape, #2 Phillips screwdriver, 1/4”

hex driver and a glass cleaning product that does not leave a film. A T8 Torx bit is

supplied with the touch screen.

1. Thoroughly clean and dry the glass mounting surface using a glass cleaning

product that does not leave a film.

2. Using the level, carefully tape a horizontal reference line that coincides with

the lower edge of the mounting bracket.

CAUTION: Adhesive on glass mounting plate is a high strength bond.

Once adhesive meets a surface, it cannot be easily removed or adjusted.

3. Remove the adhesive backing from the glass mounting plate.

4. Holding the glass mounting plate (4516855) at a 45 degree angle to the

glass, carefully align the lower edge of the mounting plate with the level

taped line. Do not allow adhesive backing to come in contact with the glass.

5. Once aligned with the level reference line, carefully tilt the glass mounting

plate back until it is secured to the glass. Firmly press glass mounting plate

to the glass to ensure proper adhesion and that any trapped air bubbles are

removed.

6. Using a flathead screwdriver, carefully separate the back cover of the touch

screen from the front of the unit. This part is not used. Refer to the

following illustration.

Multi-Surface Mount Kit for TSW-730 Crestron TSW-730-MSMK

6•Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A

Separate Back Cover of Touch Screen

Insert screwdriver to separate back of touch screen

NOTE: If installed, the two security screws must be removed

before separating the back cover of the touch screen.

7. Insert the plastic cover (2024491 or 2024492) into top or bottom of the

plastic enclosure (20334411 or 2033442). Installation location of the plastic

cover is determined through the location of the raceway. For example, if the

raceway is to be run to the top of the plastic enclosure, install the plastic

cover in the bottom of the plastic enclosure.

8. Run the network wiring through the hole in the back of the plastic

enclosure.

9. Attach the plastic enclosure to the glass mounting plate using the 1/4” hex

driver and the four included #04-40 hex nuts (2004878). Observe the

orientation of the TOP screening to ensure proper installation of the plastic

enclosure. Refer to the following illustration.

Plastic Enclosure Mounting Using Glass Mounting Plate

Glass Mounting Plate

(4516855)

Glass

Plastic Cover

(2024491 or 2024492)

Plastic Enclosure

(2033441 or 2033442)

Nut (4) #04-40 Hex

(2004878)

Crestron TSW-730-MSMK Multi-Surface Mount Kit for TSW-730

Installation Guide – DOC. 7415A Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK •7

NOTE: When raceway is run to the bottom of the touch screen, the plastic

cover must be placed in the top of the plastic enclosure. When raceway is

run to the top of the touch screen, the plastic cover must be placed in the

bottom of the plastic enclosure.

10. Attach the RJ-45 connector of the network wiring to the touch screen and

then install the touch screen by carefully pressing it into place. While

snapping the unit into place, pull the network wiring to remove slack. Refer

to the following illustration.

NOTE: Use care when pulling plenum rated cable through the bottom of

the plastic enclosure, the rigidity of the cable causes slight resistance.

Touch Screen Mounting Using Glass Mounting Plate (Exploded View)

Glass Mounting Plate

(4516855)

Glass

Plastic Cover

(2024491 or 2024492)

Plastic Enclosure

(2033441 or 2033442)

Nut (4) #04-40 Hex

(2004878)

Touch Screen

(Sold Separately)

11. Secure the touch screen to the plastic enclosure with Phillips head screws.

Alternatively, security Torx screws can be installed using a Torx

screwdriver bit (both included with touch screen), as shown in the following

illustration.

Multi-Surface Mount Kit for TSW-730 Crestron TSW-730-MSMK

8•Multi-Surface Mount Kit for TSW-730: TSW-730-MSMK Installation Guide – DOC. 7415A

Secure Touch Screen with Screws (Mounting Surface Not Shown)

12. For a neat appearance, apply the peel-and-stick label that came with the

TSW-730-MSMK (4517696 or 4517697) to the opposite side of the glass.

Refer to the following illustration.
