Owner's Manual

ICRAFTSMAN'I

6.75 HORSEPOWER

21" REAR DISCHARGE

ROTARY LAWN MOWER

Model No.

917.388621

• Safety

• Assembly

• Operation

•Maintenance

•Espa_ol

•Repair Parts

CAUTION:

Read and followall

Safety Rulesand Instructions

before operatingthis equipment

Sears, Roebuck and Co., Hoffman Estates, IL 60179

visit ourCraftsmanwebsite: www.sears.corn/craftsman

Warranty ................................................. 2 Product Specifications.......................... 11

Safety Rules ........................................ 2-4 Service and Adjustments...................... 14

Assembly ................................................ 6 Storage ............................................ 15o16

Operation ............................................. 6-9 Troubleshooting .............................. 16-17

Maintenance Schedule ........................ 10 Repair Parts..................................... 34°39

Maintenance .................................... 10-13 Parts Ordering ........................ Back Cover

LIMITED TWO YEAR WARRANTY ON CRAFTSMAN POWER MOWER

For two years from date of purchase, when this Craftsman Lawn Mower ismaintained,

lubricated,end tuned up according to the operating and maintenance instructionsin

the owners manual, Sears will repair free of charge any defect in material or work-

manship.

If this Craftsman Lawn Mower is used for commercialor rental purposes, thiswarranty

appliesfor only 90 days from the date of purchase.

This Warranty does not cover:

• Expendable items which become worn dudng normal use, such as rotarymower

blades, blade adapters, belts, air cleaners and spark plug.

• Repairs necessary because of operator abuse or negligence, including bent

crankshafts and the failure to maintain the equipmentaccording to the instructions

contained in the owner's manual.

Warranty service is available by returning the Craftsman power mower to the nearest

Sears Service Center/Department in the United States. This warranty appliesonly

while this productis in use in the United States.

This Warranty gives you specific legal rights, and you may also have other rights

whichvary from state to state.

SEARS, ROEBUCK AND CO., D/817 WA, HOFFMAN ESTATES, ILLINOIS 60179

IMPORTANT: This cutting machine iscapable of amputating hands and feet and

throwingobjects. Failure to observe the followingsafety instructionscould result in

seriousinjury or death.

I. GENERAL OPERATION

• Read, understand, and follow all

instructionson the machine and in the

manual{s) before starting. Be thor-

oughly familiar with the controls and

the proper use of the machine before

starting.

• Do not put hands or feet near or under

rotating parts. Keep clear of the

discharge opening at all times.

• Only allow responsible individuals,

who are familiar with the instructions,to

operate the machine.

•Clear the area of objects such as

rocks, toys,wire, bones, sticks,etc.,

which could be picked up and thrown

by the blade.

•Be sure the area is clear of other

people before mowing. Stop machine if

anyone enters the area.

• Do not operate the mower when

barefoot or wearing open sandals.

Always wear substantial foot wear.

•Do not pull mower backwards unless

absolutely necessary. Always look

down and behind before and while

moving backwards.

•Do not operate the mower without

proper guards, plates, grass catcher or

other safety protective devices in place.

•See manufacturer's instructionsfor

proper operation and installationof

accessories. Only use accessories

approved by the manufacturer.

•Stop the blade(s) when crossing gravel

ddves, walks, or roads.

•Stop the engine (motor) whenever you

leave the equipment, before de_ming

the mower or unclogging the chute.

• Shut the engine (motor) off and wait

untilthe blade comes to complete stop

before removing grass catcher.

•Mow only in daylight or good artificial

light.

• Do not operate the machine while

u_der the influence of elcahoI or drugs.

•Never operate machine in wet grass.

Always be sure of your footing: keep a

firm hold on the handle and walk; never

ruO,

•Disengage the self-propelled mecha-

nism or ddve clutchon mowers so

equipped before starting the engine

(mator).

•If the equipment should start to vibrate

abnormally, stop the engine (motor)

and check immediately for the cause.

Vibration is generally a warning of

trouble.

•Always wear safety goggles or safety

glasses with side shields when

operating mower.

I1.SLOPE OPERATION

Slopes are a major factor related to slip

and fall accidents which can result in

severe iniury. All slopes require extra

caution. If you feel uneasy on a slope, do

notmow it.

DO:

• Mow across the face of slopes: never

up and down. Exercise extreme caution

when changing direction on slopes.

•Remove obstacles such as rocks,tree

limbs, etc.

• Watch for holes, ruts, or bumps. Tall

grass can hide obstacles.

DO NOT:

•Do nottrim near dropoffs, ditches or

embankments. The operator could lose

footing or balance.

• Do not trim excessively steep slopes.

•Do not mow on wet grass. Reduced

footing could cause slipping.

II1.CHILDREN

Tragic accidents can occur if the operator

is not alert to the Ixesenco of children.

Children are often attracted to the

machine and the mowing activity. Never

assume that children will remain where

you last saw them.

•Keep children out of the tdmming area

and under the watchfulcare of another

responsible adult.

•Be alert and turn machine off if children

enter the area.

•Before and while walking backwards,

leek behind and down for small

children.

•Never allow children to operate the

machine.

•Use extra care when approaching bUnd

comers, shrubs, trees, or other objects

that may obscure vision.

IV. SERVICE

•Use extra care in handling gasoline

and other fuels. They are flammable

and vapors are explosive.

-Use only an approved container.

-Never remove gas cap or add fuel

with the engine running. Allow

engine to cool before refueling. Do

not smoke.

-Never refuel the machine indoors.

-Never storethe machine or fuel

container inside where there is an

open flame, such as a water heater.

•Never run a machine inside a closed

area.

•Never make adjustments or repairs with

the engine (motor) running. Disconnect

the spark plug wire, and keep the wire

away from the plug to prevent acciden-

tal starting.

•Keep nuts and bolts, especially blade

attachment bolts, tight and keep

equipment in good condition.

•Never tamper with safety devices.

Check their proper operation rogulady.

•Keep machine free of grass, leaves, or

other debds build-up. Clean oil or fuel

spillage. Allow machine to cool before

stodng.

•Stop and inspect the equipmentif you

strike an object. Repair, If necessary,

before restarting.

•Never attempt to make wheel height

adjustments while the engine (mo'_or)is

running.

•Grass catcher components are subject

to wear, damage, and deterioration,

which could expose moving parts or

allow objects to be thrown. Frequently

check components and replace with

manufacturer's recommended parts,

when necessanJ.

•Mower blades are sharp and can cut.

Wrap the blade(s) or wear gloves, and

use extra caution when servicingthem.

•Do not change the engine governor

setting or overspeed the engine.

ALook for this symbol to pointout

importantsafety precautions. It means

CAUTION!I! BECOME ALERTlll YOUR

SAFETY IS INVOLVED.

£ CAUTION: In order to prevent

accidental starting when setting up,

transpor_ng, adjusting or making repairs,

always disconnect spark plug wire and

place wire where it cannot contact spark

plug.

£WARNING: Engine exhaust, some of its

constituents,and certain vehicle

components contain or emit chemicals

known to the State of California to cause

cancer and birth defects or other

reproductive harm.

£WARNING: Battery posts,terminalsand

related accessories contain lead and

lead compounds, chemicals known to the

State of California tocause cancer and

birth defects or other reproductive harm.

Wash hands after handling.

_CAUTION: Mufflerand other engine

parts become extremely hot dudng

operation and remain hot after engine

has stopped. To avoid severe burns on

contact,stay away _om these areas.

These accossodeswere availablewhenthislawn mowerwas prnduced.They are not

shippedwith your mower.Theyare alsoavailableat mostSearsretailou_etsandservice

centem. MostSearsstorescanalsoorderrepairpartsforyou,when youprovide_le model

numberof yourlavmnx_r. Someoftheseaccesso_s maynotapplytoyourlawnn_wer.

LAWN MOWER PERFORMANCE

CLIPPING DEFLECTOR

FOR REAR DISCHARGE LAWN MOWERS MULCHER KITS

GRASS CATCHERS

FOR

REAR DISCHARGE

LAWN MOWERS GRASS CATCHERS

FOR

SIDE DISCHARGE

LAWN MOWERS

STABILIZER

GAS CANS

LAWN MOWER MAINTENANCE

MUFFLERS AIR FILTERS SPARK PLUGS

BELTS BLADES BLADE ADAPTERS WHEELS ENGINE OIL

Read these instructionsand this manual

in its entirety before you attempt to

assemble or operate your now lawn

mower.

IMPORTANT: This lawn mower is

shippedWITHOUT OIL OR GASOLINE in

the engine.

Your new lawn mower has been as-

sembled at the factory with the exception

of those parts left unassembled for

shipping purposes. All partssuch as nuts,

washers, belts, etc., necessary tocom-

plete the assembly have been placed in

the parts bag. To ensure safe and proper

operation of your lawn mower, all parts

and hardware you assemble must be

tightened securely. Use the correct tools

as necessary to ensure proper tightness.

TO REMOVE LAWN MOWER FROM

CARTON

1. Remove loose parts included with

mower.

2. Cut down two end comers of carton

and lay end panel down fiat.

3. Remove all packing matedala except

padding between upper and lower

handle and padding holding operator

presence centrol bar to upper handle.

4. Roll lawn mower out of carton and

check carton thorouglyfor additional

loose parts.

HOWTO SET UPYOUR LAWN

MOWER

TO UNFOLD HANDLE

IMPORTANT: Unfold handle carefully so

as not to pinch or damage control cables.

1. Raise handles until lower handle

section looks into place in mowing

position.

2. Remove protective padding, raise

upper handle section into place on

lower handle and tighten both handle

knobs.

3. Remove handle padding holding

operator presence control bar to

upper handle.

Your lawn mower handle can be adjusted

for your mowing comfort. Refer to "AD-

JUST HANDLE" in the Service and

Adjustments section of this manual.

control bar

Upper

Liftu

position

Lower handle

Squeeze _1_--_ Handle pin

3-Positico

handle

adj

bracket

TO INSTALL ATTACHMENTS

Your lawn mower was shipped ready to

be used as a mulcher. To convert mower

to bagging, see "TO CONVERT MOWER"

in the Operation section of this manual.

KNOWYOURLAWNMOWER

READTHISOWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR

LAWN MOWER. Compare the illustrationswith your lawn mower to familiarize yourself

with the locationof various controls and adjustments. Save this manual for future

reference.

These symbols may appear on your lawn mower or In literature supplied with the

product. Learn and understand their meaning,

CAUTION ENGINE ENGINE FAST SLOW CHOKE FUEL OIL DANGER, KEEP HANDS

OR WARNING ON OFF AND FEET AWAY

presence control bar

Gasoline lifter cap

Airfilter

Grass

Engine oil cap

with d

Primer

Muffler

Housing

Wheeladjuster

IMPORTANT: This lawn mower is shipped (oneachwheel)

WITHOUT OIL OR GASOLINE in the engine.

MEETS CPSC SAFETY REQUIREMENTS

Sears rotarywalk-behind power lawn mowers conform to the safety standards of the

American National Standards Institute and the U.S. Consumer Product Safety Commis-

sion. The blade turns when the engine is running.

Operator presence control bar -must be Primer - pumps additionalfuel from the

helddown to the handle to start the carburetor to the cylinderfor use when

engine. Release to stop the engine, starting a cold engine.

Starter handle -used for startingthe

engine. 6

Theoperationofanylawn

mowercanresultinforeign

objectsthrownintothe

eyes,whichcanresultin

severeeye damage.

Always wear safety glasses or eye

shields while operating your lawn mower

or performing any adjustments or repairs.

We recommend awide vision safety

mask over spectacles or standard safety

glasses.

HOWTO USEYOUR LAWN MOWER

ENGINE SPEED

The engine speed was set at the factory

for optimum performance. Speed is not

adjustable.

ENGINE ZONE CONTROL

_LCAUTION: Federal regulations require

an engine controlto be installed on this

lawn mower in order to minimize the dsk

of blade contact injury.Do not under any

circumstances attempt to defeat the

function of the operator control. The blade

turns when the engine is running.

• Your lawn mower is equipped with an

operator presence control bar which

requires the operator to be positioned

behind the lawn mower handle to start

and operate the lawn mower.

TO ADJUST CU'R'ING HEIGHT

Raise wheels for low cut and lower

wheels for high cut, adjust cuttingheight

to suit your requirements. Medium

positionis best for most lawns.

To change cutting height, squeeze

adjuster lever toward wheel. Move

wheel up or down to suit your require-

ments. Be sure all wheels are in the

same setting.

NOTE: Adjuster is propedy positioned

when plate tab inserts into hole in lever.

Also, 9-positionadjusters (if so equipped)

allow lever to be positionedbetween the

plate tabs.

Lowe._rWheels_r HighCut _

RaiseWheelsfor LowCut Lever

TO CONVERT MOWER

Yourlawnrn_werwas shippedreadyto be

usedas a mulcber.Toconvert tohagging :

REAR BAGGING

•Liftreindoorof thelawnmower and placa

thegrasscatcharframe hooksonto_e

doorpivotpins.

• To convertto mulchingopera'_;_n,remove

grasscatcher and dose reardoor.

ACAUTION: Do notrun your lawnmower

without clippingdeflector or approved

grass catcher in place. Never attempt to

operate the lawn mower with the rear

door removed or propped open.

Pivot " Rear Grass

catcher

handle

TO EMPTY GRASS CATCHER

1. L_ Upon grass catcher using the

frame handle.

2, Remove grass catcher with clippings

from under lawn mower handle.

3. Empty clippingsfrom bag using both

frame handle and bag handle,

NOTE: Do not drag the bag when

emptying; it will cause unnecessary wear.

Grass

catcher

frame

handle

BEFORE STARTING ENGINE

ADD OIL

Your lawnmower is shipped without oil in

the engine. Engine holds 20 oz. of oil.

For type and grade of oil to use, see

=ENGINE" in Maintenance section of this

manual.

1. Be sure lawnmower is level and area

around oil fill is clean.

2. Remove engine oil cap and fill to the

full line on the dipstick.Pour oil slowly.

Do notover fill.

NOTE: Allow oil to settle down into engine

for accurate reading. To read proper level,

tighten engine oil cap, then remove it to

read the dipstick.

3. Reinstall engine oil cap and tighten.

• Check oil level before each use. Add

oil ifneeded. Fillto full line on dipstick.

• Change the oil after every 25 hours of

operation or each season. You may

need to change the oil more often

under dusty, dirty conditions.

ADD GASOLINE

•Fillfuel tank. Use fresh, clean, regular

unleaded gasoline with a minimum of

87 octane. Do not mix oil with gaso-

line. Purchase fuel in quantitiesthat

can be used within 30 days to assure

fuel freshness.

_.WARNING: Experience indicates that

alcohol blended fuels (called gasohol or

using ethanol or methanol) can attract

moisture which leads to separation and

formationof acids dudngstorage. Acidic

gas can damage the fuel system of an

engine while in storage. To avoid engine

problems, the fuel system should be

emptied before storage of 30 days or

longer. Drain the gas tank, start the

engine and let it run untilthe fuel lines

and carburetorare empty. Use fresh fuel

nextseason. See Storage Instructionsfor

additional information. Never use engine

or carburetor cleaner products in the fuel

tank or permanent damage may occur.

CAUTION: Fill tobottomof gas tank

filler neck. Donot overfill. Wipe off any

spilled oil or fuel. Do not store, spillor

use gasoline near an open flame.

Gasoline

fillercap

Engine

oil cap

TO START ENGINE

NOTE: Due to protective coatingson the

engine, a small amount of smoke may be

present dudng the initial use of the

product and should be considered

normal.

1. To start a cold engine, push pdmer

three (3) times before tryingto start.

Use a firm push. This step is not

usually necessary when starting an

engine which has already runfor a

few minutes.

2. Hold operator presence control bar

down to the handle and pull starter

handle quickly. Do not allow starter

rope to snap back.

TO STOP ENGINE

•To stop engine, release operator

presence control bar.

NOTE: In cooler weather it may be

necessary to repeat priming steps. In

warmer weather over pdming may cause

flooding and engine will notstart. If you

do flood engine, wait a few minutes

beforeattempting tostart and do not

repeat pdming steps.

MOWlNGTIPS

• Undercertainconditions,suchasvery

tallgrass,itmaybenecessarytoraise

theheightofcuttoreducepushing

effortandtokeepfrom ovedoading the

engine and leaving dumps of grass

clippings. It may also be necessary to

reduce ground speed and/or run the

lawn mower over the area a second

time.

•For extremely heavy cutting, reduce the

width of cot by overlapping previously

cut path and mow slowly.

•For better grass bagging and most

cutting conditions,the engine speed

should be set in the fast position.

•When using a rear discharge lawn

mower in moist, heavy grass, clumps of

cut grass may not enter the grass

catcher. Reduce ground speed

(pushingspeed) and/or nJnthe lawn

mower over the area a second time.

•If a trailof clippingsisleft onthe dght

side of a rear discharge mower, mow in

a clockwise direction with a small

ovedap to collect the clippings on the

next pass.

• Pores in cloth grass catchers can

become filled with dirt and dustwith

use and catchers will collect less grass.

To prevent this, regularly hose catcher

off with water and let dry before using.

•Keep top of engine around starter clear

and clean of grass clippingsand chaff.

This will help engine air flow and

extend engine llfe.

MULCHING MOWING TIPS

IMPORTANT: For best performance,

keep mower housingflee of built-up

grass and trash. See "CLEANING" inthe

Maintenance sectionof this manual.

•The special mulchingblade will recut

the grass clippingsmany times and

reduce them in size so that as they fall

onto the lawn they will disperse intothe

grass and not be noticed.Also, the

mulched grass will biedegrade quickly

to provide nutrientsfor the lawn.

Always mulchwith your highest engine

(blade) speed as this will provide the

best racutting action of the blades.

•Avoid cutting your lawn when it is wet.

Wet grass tends to form clumpsand

interfereswith the mulchingaction. The

besttime to mow your lawn is the eady

afternoon. At this time the grass has

dried and the cewiy cut area will not be

exposed to the direct sun.

•For best results, adjust the lawn mower

cuttingheight so that the lawn mower

cuts off only the top one-third ofthe

grass blades. If the lawn is overgrownit

will be necessary to raise the height of

cut to reduce pushing effort and to keep

from overloading the engine and

leaving dumps of mulched grass. For

extremely heavy mulching, reduce your

width of cut by overlapping previously

cut path and mow slowly.

•Certain types of grass and grass

conditionsmay require that an area be

mulched asecond time to completely

hide the clippings. When doing a

second cut, mow across or perpendicu-

lar to the first cut path.

•Change your cuttingpattern from week

to week. Mow northto south one week

then change to east to west the next

week. This will help prevent matting

and graining of the lawn.

eEOOLS V,O0

Check lor Loose Fasteners V' I_

Clean/Inspect Grass Catcher

IfEquipped) I/ _f/'

MClean Lawn MoWer I_ Vs

O Clean Under DriVe Cover

(Power*Propelled Mowers! it/

Check ddve belt/ ulleys

IE_ower'ProP etl_PMowers) I,/

Check/Sharpen/Replace Blade I_ I

Lubdcation Ch_rt _ i

Clean BaitePj/RechaLme

Electdc Stad Mowers'_ _ it/4

ECheck Engine Oil Level lt_

N Chan_e EnQine Oil I_t_

GClean Air Filter I_ 2

I Insl_ Muffler IV/

N Clean or Replace Spark Plug I_

EReplace Air FIRerPaper Cartridge IS'=

1.Change more often when operalmg urlder a _ _ad Of in high amb;e_t tert_t m'_

2*Se_ mJ0_eoldenwhe_ opmating indidy of duety condit=ons

3*Replace b_s more o_en when mo_ng in s_r_y _c,d

4. Charge 4_ houn_at end _ m

GENERAL RECOMMENDATIONS

The warranty on this lawn mower does

notcover items that have been subjected

to operator abuse or negligence. To

receive full value from the warranty,

operator must maintain mower as

instructedin this manual.

Some adjustments will need to be made

periodically to properly maintain your

unit.

All adjustments in the Service and

Adjustmentssection of this manual

should be checked at least once each

season.

• Once a year, replace the spark plug,

clean or replace air filter element and

check blade for wear. A new spark

plug and clean/new air filter element

assure proper air-fuel mixture and help

your engine run better and last longer.

•Follow the maintenance schedule in

this manual.

BEFORE EACH USE

1, Check engine oil level,

2. Check for loose fasteners.

LUBRICATION

Keep unit well lubdcated (See "LUBRI-

CATION CHART'),

LUBRICATION CHART

(

I/Brake

I\spring

bracket

ne oil

Rear

(_) Handle bracket mounting pins door hJnge

(_ Spray lubricant

_) Bee "ENGINE" In Maintenance section.

IMPORTANT: Do not oil or grease

plastic wheel bearings, viscous

lubricantswill attractdust and dirt that

will shorten the life of the self-lubricat-

ing beadngs. If youfeel they must be

lubdcated, use only a dry, powdered "

graphite type lubricant sparingly.

Table des matières

Autres manuels Craftsman Tondeuse à gazon

Craftsman

Craftsman 917.376592 Manuel utilisateur

Craftsman

Craftsman 944.364220 Manuel utilisateur

Craftsman

Craftsman 27725 Manuel utilisateur

Craftsman

Craftsman 247.203694 Manuel utilisateur

Craftsman

Craftsman 138.37097 Manuel utilisateur

Craftsman

Craftsman 917.271065 Manuel utilisateur

Craftsman

Craftsman 917.388522 Manuel utilisateur

Craftsman

Craftsman 917.28872 Manuel utilisateur

Craftsman

Craftsman 247.772460 Manuel utilisateur

Craftsman

Craftsman 917.376802 Manuel utilisateur

Craftsman

Craftsman 917.270430 Manuel utilisateur

Craftsman

Craftsman 917.9994B Manuel utilisateur

Craftsman

Craftsman 247.203690 Manuel utilisateur

Craftsman

Craftsman 917.376460 Manuel utilisateur

Craftsman

Craftsman 917.9997A Manuel utilisateur

Craftsman

Craftsman 3One 917.383242 Manuel utilisateur

Craftsman

Craftsman 917.387611 Manuel utilisateur

Craftsman

Craftsman 917.272442 Manuel utilisateur

Craftsman

Craftsman 28813 - 46 in. Lawn Tractor Manuel utilisateur

Craftsman

Craftsman 917.28948 Manuel utilisateur

Craftsman

Craftsman 917.28749 Manuel utilisateur

Craftsman

Craftsman 917.378350 Manuel utilisateur

Craftsman

Craftsman 138.37671 Manuel utilisateur

Craftsman

Craftsman 247.37683 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur
