Craftsman 917.773762 Manuel utilisateur

Owner's Manual

CRRFTSMRN°

E T

675 Series

I E

Briggs & Stratton

Inch Cut Engine

Model No.

917.773762

•EspaSol, p. 17

LJTION'.

Read and follow all

Safety Rules and Instructions

before operating this equipment.

Sears, Roebuck and Co., Hoffman Estates, IL 60179

Visit our Craftsman website: www.sears.com/craftsman U.S.A.

Warranty ................................................... 2

Safety Rules .......................................... 2-4

Product Specifications .............................. 5

Assembly /Pre-Operation ........................ 5

Operation ............................................... 6-8

Maintenance Schedule ............................. 9

Maintenance ........................................ 9-11

Service and Adjustments ................... 12-13

Storage ................................................... 14

Troubleshooting ...................................... 15

Repair Parts ....................................... 32-41

Sears Service .......................... Back Cover

LIMITED TWO YEAR WARRANTY ON CRAFTSMAN WEEDTRIMMER

For two (2) years from date of purchase, when this Craftsman Weedtrimmer is main-

tained, lubricated, and tuned up according to the operating and maintenance instruc-

tions in the owner's manual, Sears will repair free of charge any defect in material or

workmanship.

If this Craftsman Weedtrimmer is used for commercial or rental purposes, this warranty

applies for only 90 days from the date of purchase.

This Warranty does not cover:

• Expendable items which become worn during normal use, such as rotating lines,

belts, air cleaners and spark plug.

• Repairs necessary because of operator abuse or negligence, including bent crank-

shafts and the failure to maintain the equipment according to the instructions con-

tained in the owner's manual.

Warranty service is available by returning the Craftsman Weedtrimmer to the nearest

Sears Parts & Repair Center in the United States. This warranty applies only while this

product is used in the United States.

This Warranty gives you specific legal rights, and you may also have other rights which

vary from state to state.

Sears, Roebuck and Co., Dept. 817 WA, Hoffman Estates, IL 60179

A WARNING" This trimmer is equipped with an internal combustion engine and should

not be used on or near any unimproved forest-covered, brush-covered or grass-covered

land unless the engine's exhaust system is equipped with a spark arrester meeting ap-

plicable local or state laws (if any). If a spark arrester is used, it should be maintained in

effective working order by the operator.

In the state of California the above is required by law (Section 4442 of the California

Public Resources Code). Other states may have similar laws. Federal laws apply on

federal lands. A spark arrester for the muffler is available through your nearest Sears

service center (see the REPAIR PARTS section of this manual).

SAFETYGLASSES

The operation of any trimmer can result in foreign objects thrown into

the eyes, which can result in severe eye damage. Always wear safety

glasses or eye shields while operating your trimmer or performing any

adjustments or repairs. We recommend standard safety glasses or a

wide vision safety mask worn over spectacles.

,il,Look for this symbol to point out

important safety precautions. It means

CAUTION!!! BECOME ALERT!!!

YOUR SAFETY IS INVOLVED.

A WARNING: In order to prevent ac-

cidental starting when setting up, trans-

porting, adjusting or making repairs,

always disconnect spark plug wire and

2 place wire where it cannot contact plug.

AWARNING" Engine exhaust, some

of its constituents, and certain vehicle

components contain or emit chemicals

known to the State of California to

cause cancer and birth defects or other

reproductive harm.

ACAUTION: Muffler and other engine

parts become extremely hot during

operation and remain hot after engine has

stopped. To avoid severe burns on contact,

stay away from these areas.

I. GENERAL OPERATION

• Read, understand, and follow all instruc-

tions on the machine and in the manual

before starting. Be thoroughly familiar

with the controls and the proper use of

the machine before starting.

• Do not put hands or feet near or under

rotating parts.

• Keep all parts of your body away from

muffler and spinning line. A hot muffler

can cause serious burns.

• Only allow responsible individuals, who

are familiar with the instructions, to

operate the machine.

• Stay away from breakable objects, such

as house windows, auto glass, green-

houses, etc.

• Clear the area of objects such as rocks,

toys, wire, bones, sticks, etc., which

could be picked up and thrown by the

spinning lines.

• Be sure the area is clear of other people

before trimming, particularly small chil-

dren and pets. Stop machine if anyone

enters the area.

• Wear appropriate clothing such as a

long-sleeved shirt or jacket. Also wear

long trousers or slacks. Do not wear

shorts.

• Do not wear loose clothing which could

get caught in this equipment.

• Do not operate the machine when bare-

foot or wearing open sandals. Always

wear work gloves and sturdy footwear.

Leather work shoes or short boots work

well for most people. These will protect

the operator's ankles and shins from

small sticks, splinters, and other debris,

and improve traction. 3

• Do not pull machine backwards unless ab-

solutely necessary. Always look down and

behind before andwhile moving backwards.

• Do not operate the machine without

proper guards, plates or other safety

protective devices in place.

• See manufacturer's instructions for

proper operation and installation of

accessories. Only use accessories ap-

proved by the manufacturer.

• Neveruse blades, wire, orftailing devices.

This unit is designed for line trimmer use

only. Use of other accessories or attach-

ments will increase the risk of injury.

• Stop the rotating trimmer head when

crossing gravel drives, walks, or roads.

Wait for the cutting lines to stop rotating.

• Stop the engine (motor) whenever you

leave the equipment and allow it to cool,

before cleaning, repairing or inspecting

the unit. Be sure the trimmer head and

all moving parts have stopped.

• Operate only in daylight or good artificial

light.

• Do not operate the machine while under

the influence of alcohol or drugs.

• Never operate machine in wet grass. Al-

ways be sure of your footing: keep a firm

hold on the handle and walk; never run.

• If the equipment should start to vibrate

abnormally, stop the engine (motor) and

check immediately for the cause. Vibra-

tion is generally a warning of trouble.

• Always wear safety goggles or safety

glasses with side shields when oper-

ating machine.

Ii. SLOPE OPERATION

Slopes are a major factor related to slip and

fall accidentswhich can result in severe injury.

All slopes require extra caution. If you feel

uneasy on a slope, do not trim it.

DO:

• Trim across the face of slopes: never up

and down. Exercise extreme caution

when changing direction on slopes.

• Remove obstacles such as rocks, tree

limbs, etc.

• Watch for holes, ruts, or bumps. Tall

grass can hide obstacles.

DO NOT:

• Do not trim near drop-offs, ditches or

embankments. The operator could lose

footing or balance.

• Do not trim excessively steep slopes.

• Do not trim on wet grass. Reduced foot-

ing could cause slipping.

ill. CHILDREN

Tragic accidents can occur if the opera-

tor is not alert to the presence of chil-

dren. Children are often attracted to the

machine and the trimming activity. Never

assume that children will remain where

you last saw them.

•Keep children out of the trimming area

and under the watchful care of another

responsible adult.

• Be alert and turn machine off if children

enter the area.

• Before and while moving backwards,

look behind & down for small children.

•Never allow children to operate the

machine.

• Use extra care when approaching blind

corners, shrubs, trees, or other objects

that may obscure vision.

IV. SERVICE

• Use extra care in handling gasoline and

other fuels. They are flammable and

vapors are explosive.

Use only an approved container.

Never remove gas cap or add fuel with

with the engine running. Allow engine

to cool before refueling. Don't smoke.

Never refuel the machine indoors.

Never store the machine or fuel

container inside where there is an

open flame, such as a water heater.

Move away from fueling site before

starting engine.

• Never run trimmer inside a closed area.

•Never make adjustments or repairs with

the engine (motor) running. Disconnect

the spark plug wire, and keep the wire

away from the spark plug to prevent ac-

cidental starting.

• Keep nuts and bolts, especially trimmer

head and engine bolts, tight and keep

equipment in good condition.

•Never tamper with safety devices.

Check their proper operation regularly.

• Keep machine free of grass, leaves, or

other debris buildup. Clean oil or fuel

spillage. Allow machine to cool before

cleaning or storing.

•Stop and inspect the equipment if you

strike an object. Repair, if necessary,

before restarting.

•Do not change the engine governor set-

ting or overspeed the engine.

• Clean and replace safety and instruction

decals as necessary.

Repair Protection Agreements

Congratulations on making a smart pur-

chase. Your new Craftsman@ product is

designed and manufactured for years of

dependable operation. But like all prod-

ucts, it may require repair from time to

time. That's when having a Repair Protec-

tion Agreement can save you money and

aggravation.

Purchase a Repair Protection Agreement

now and protect yourself from unexpected

hassle and expense.

Here's what's included in the Agreement:

• Expert service by our 12,000 profe-

sional repair specialists.

• Unlimited service and no charge for

parts and labor on all covered repairs.

• Product replacement if your covered

product can't be fixed.

• Discount of 10% from regular price of

service and service-related parts not

covered by the agreement; also, 10%

off regular price of preventive mainte-

nance check.

Fast help by phone - phone sup-

port from a Sears representative on

products requiring in-home repair, plus

convenient repair scheduling.

Once you purchase the Agreement, a

simple phone call is all that it takes for you

to schedule service. You can call anytime

day or night, or schedule a service ap-

pointment online.

Sears has over 12,000 professional repair

specialists, who have access to over 4.5

million quality parts and accessories.

That's the kind of professionalism you can

count on to help prolong the life of your

new purchase for years to come. Purchase

your Repair Protection Agreement today!

Some limitations and exclusions apply.

For prices and additional information

call 1=800=827=6655.

Sears Installation Service

For Sears professional installation of home

appliances, garage door openers, water

heaters, and other major home items, in

the U.S.A. call 1=800=4-MY=HOME®.

SerialNumber:

Dateof Purchase:

GasolineCapacity/Type: 1.6 Quarts (Unleaded Regular)

Oil Type (API SG-SL): SAE 30 (above 32°F); SAE 5W-30 (below 32°F)

Oil Capacity: 20 Ounces

Spark Plug (Gap: .030") Champion RJ19LM or J19LM

Trimmer Line Length: 18.75 Inches (0.155 Inch Diameter)

. The model and serial numbers will be found on a decal on the rear of the trimmer.

Record both serial number and date of purchase in the space provided above.

Read these instructions and this manual in

its entirety before you attempt to assemble

or operate your new trimmer.

IMPORTANT: This trimmer isshipped WITH-

OUT OIL OR GASOLINE in the engine.

Your new trimmer has been assembled

at the factory with the exception of those

parts left unassembled for shipping

purposes. All parts such as nuts, wash-

ers, bolts, etc., necessary to complete the

assembly have been placed in the parts

bag. To ensure safe and proper operation

of your trimmer, all parts and hardware

you assemble must be tightened securely.

Use the correct tools as necessary to

ensure proper tightness.

When right hand (RH) or left hand (LH)is

mentioned in this manual, it means when

you are in the operating position (standing

behind the handle).

Loose Parts Packed Separately

NOW TO SET UP YOUR TRIMMER

TO UNFOLD HANDLE

IMPORTANT: Unfold handle carefully so

as not to pinch or damage control cables.

1. Loosen handle knob enough to allow

upper handle to be unfolded from the

shipping position.

2. Raise upper handle section into place on

lower handle and tighten handle knob.

3. Remove handle padding holding trim-

mer head control bar to upper handle.

Your trimmer handle can be adjusted for

your trimming comfort. Refer to "ADJUST

HANDLE" in the Service and Adjustments

section of this manual.

\ \ iI \ \ ii

\ \ Ii \Ii

\\)er handle

LIFT UP

Bottle of oil Trimmer Lines (2) Sets

(0.155 diameter

× 18.75 inches long)

REMOVE TRIMMER FROM CARTON

1. Remove loose parts included with trimmer.

2. Cut down two end corners of carton

and lay end panel down flat.

3. Remove all packing materials.

4. Roll trimmer out of carton and check car-

ton thoroughly for additional loose parts.

Handle

knob

Lower

handle

KNOWYOURTRIMIVIER

READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING

YOUR TRIMMER. Compare the illustrations with your trimmer to familiarize yourself with

the location of various controls and adjustments. Save this manual for future reference.

These symbols may appear on your trimmer or in literature supplied with the product. Learn

and understand their meaning.

FAST S LOW O ILCAUTION ENGINE OFF FUEL

AVOIDSERIOUS

INJURYORDEATH

-Trimmer head control bar

Throttle control

Starter handle Engine oil cap

with dipstick

Handle knob

Gasoline cap

Air filter

Primer

Muffler

Shassis cover

Trimmer head

IMPORTANT: This trimmer is shipped Trimmer line

WITHOUT OIL OR GASOLINE in the engine.

Trimmer head control bar - must be held

down to the handle to engage trimmer

head. Release to stop the trimmer head.

Primer - pumps additional fuel from the

carburetor to the cylinder for use when

starting a cold engine. 6

Throttle control - used for starting and

stopping the engine and allows you to se-

lect either FAST or SLOW engine speed.

Starter handle - used for starting the

engine.

The operationof any trimmer can result in

foreignobjectsbeing throwninto theeyes,

which can resultin severeeye damage.

Alwayswear safetyglasses oreye shields

while operatingyourtrimmeror performing

any adjustmentsor repairs. We recom-

mendstandardsafetyglassesor awide

vision safetymaskworn over spectacles.

TOADJUST TRIMMINGHEIGHT

_,CAUTION" Stop the engineandwait for

all movingpartsto stop. Disconnectspark

plugwire fromspark plug and placewire

whereit cannotcome in contactwith plug.

The heightof cut can beset to six(6) dif-

ferent positionsrangingfrom 1-1/2 inches

to 3 inches. Recommendedcutting height

for theaverageyard is2 inches.

1. To adjusttrimmingheight,pushin the

lockingplatetab and movetrimmer

headup ordownto desired position.

2. Releasetab and be sure headis

lockedintoone of thesix (6)height

positions.

HOW TO USE YOUR TRIMMER

ENGINE SPEED

The engine speed is controlled by a throt-

tle located on the side of the upper handle.

FAST position is for starting and normal

trimming. SLOW is for light trimming and

fuel economy. STOP is for stopping the

engine.

Adj CI)

Trimmer

Head

Locking

Plate Tab

FAST

SLOW _l

TRIMMER HEAD DRIVE CONTROL

Your trimmer is equipped with a trimmer

head drive control bar which wil! require

the operator to be positioned behind the

trimmer handle to operate the trimmer.

• Trimmer head rotation is controlled by

holding the trimmer head control bar

down to the handle.

• Trimmer head rotation wi!l stop when

the control bar is released.

BEFORE STARTING ENGINE

ADD OIL

Your trimmer is shipped without oil in the

engine. For type and grade of oil to use,

see "ENGINE" in the Maintenance section

of this manual.

A CAUTION: DO NOT overfill engine with

oil, or it will smoke heavily from the muffler

on startup.

1. Be sure trimmer is level.

2. Remove oil dipstick from oil fill spout.

3. You receive a container of oil with the

unit. Slowly pour the entire container

down the oil fill spout into the engine.

4. Insert and tighten dipstick.

IMPORTANT:

• Check oil level before each use. Add oil

if needed. Fill to full line on dipstick.

• Change the oil after every 25 hours of

operation or each season. You may

need to change the oil more often under

dusty, dirty conditions.

ADD GASOLINE

• Fill fuel tankto bottomof gastank

filler neck. Do notoverfill. Usefresh,

clean, regularunleadedgasolinewith a

minimumof 87 octane. Do not mix oil

with gasoline. Purchasefuel in quanti-

tiesthat can be usedwithin30 days to

assurefuel freshness.

A CAUTION" Wipeoff any spilledoil or

fuel. Do notstore, spillor usegasoline

nearan openflame.

• I,CAUTION: Alcohol blended fuels

(called gasohol or using ethanol or

methanol) can attract moisture which

leads to separation and formation of acids

during storage. Acidic gas can damage

the fuel system of an engine while in

storage. To avoid engine problems, the

fuel system should be emptied before

storage of 30 days or longer. Empty

the gas tank, start the engine and let it

run until the fuel lines and carburetor

are empty. Use fresh fuel next season.

See Storage Instructions for additional

information. Never use engine or

carburetor cleaner products in the fuel

tank or permanent damage may occur.

Gasoline filler me

ca oil cap

Primer

TO STOP ENGINE

•To stop engine, move throttle control

lever to STOP position.

TO START ENGINE

1. To start a cold engine, push primer three

(3) times before trying to start. Use a

firm push. This step is not usually neces-

sary when starting an engine which has

already run for a few minutes.

2. Move throttle control lever to FAST

position.

3. Hold upper handle firmly and pull

starter handle quickly. Do not allow

starter rope to snap back.

NOTE: In cooler weather it may be

necessary to repeat priming steps. In

warmer weather overpriming may cause

flooding and engine wil! not start. If you

do flood engine, wait a few minutes before

attempting to start and do not repeat

priming steps.

Starter

handle

TRIMMING TIPS

• Set the throttle control in the FAST posi-

tion. If the weeds or grass are tal! and

thick, operate the trimmer at a slower

walking speed.

• Frequently clean the underside of the

trimmer to remove any grass build up.

Keep top of engine around starter clear

and clean of grass clippings and chaff.

This will help engine air flow and extend

engine life.

• For best results and longer lasting line,

use the ends of the line to do the cutting.

This is easily done by moving slowly

through very thick and heavy weeds.

• Use the left side of trimmer when trim-

ming along fences, walls, ftowerbeds

and other such objects.

• If trimmer lines become too short, it will

take longer to complete the job. If trim-

mer lines are worn to less than half their

original length, they should be replaced.

See "TO REPLACE TRIMMER LINE" in

the Maintenance section of this manual.

• Trimmer head contact with concrete, as-

phalt or other hard surfaces may cause

premature wear of the ball on bottom of

trimmer head.

MAINTENANCE

FILL IN DATES

AS YOU COMPLETE

REGULAR SERVICE

TCheck for Loose Fasteners

RClean Trimmer

i/ t/

Clean Under Engine Cover !_2

Check Drive Belt /Pulleys

RCheck /Replace Trimmer Lines 1_3

Check Engine Oil Level

Change Engine Oil t#4'1,2

Clean Air Filter If 2

Inspect Muffler I_

Clean or Replace Spark Plug

Replace Air Filter Paper Cartridge

1 - Change more often when operating under a heavy load or in high ambient temperatures.

2 - Service more often when operating in dirty or dusty conditions.

3 - Replace trimmer lines when they have worn to half their original length.

GENERAL RECOMMENDATIONS

The warranty on this trimmer does not

cover items that have been subjected to

operator abuse or negligence. To receive

full value from the warranty, operator must

maintain trimmer as instructed in this

manual.

Some adjustments will need to be made

periodically to properly maintain your unit.

At least once a season, check to see if

you should make any of the adjustments

described in the Service and Adjustments

section of this manual.

• At least once a year, replace the spark

plug and replace air filter element. A

new spark plug and clean/new air filter

element assure proper air-fuel mixture

and help your engine run better and

last longer.

,, Follow the maintenance schedule in

this manual.

BEFORE EACH USE

1. Check engine oi! level.

2. Check for loose fasteners.

3. Clean under engine cover.

LUBRICATION

To prolong the useful life of your trimmer,

change engine oil as recommended in this

section of Owner's Manual.

IMPORTANT: Do not oil or grease plastic

wheel bearings. Viscous lubricants will

attract dust and dirt that will shorten the

life of the self- lubricating bearings. If you

feel they must be lubricated, use only a dry,

powdered graphite type lubricant sparingly.

TRIMMER

Always observe safety rules when per-

forming any maintenance.

TIRES

. Keep tires free of gasoline, oil, or insect

control chemicals which can harm rub-

ber.

• Avoid stumps, stones, deep ruts, sharp

objects and other hazards that may

cause tire damage.

TRIMMER LINE

For best results, replace trimmer lines

when they have worn to half their original

length. Use .155 inch diameter trimmer

line. Cut new trimmer line length to 18-3/4

inches. After new line is installed on

trimmer head, check all lines so they do

not vary more then one (1) inch in length.

This is important to make sure the trim-

mer head is balanced and will not vibrate

abnormally.

AWARNING" Use only the specified

trimmer line. Do not use other materials

such as wire, string, rope, etc. Wire can

break off during trimming and become a

dangerous missile that can cause serious

injury.

TO CUT LINE TO PROPER LENGTH

NOTE: Trimmer line pre-cut to proper

length is available for this unit; see the

Repair Parts section of this manual.

If trimmer line is purchased in bulk, it must

be cut to 18-3/4 inches before using. Use

the built-in length guage as follows:

1. From front of trimmer, place the end of

spooled trimmer line at the mark on the

side of the debris shield as shown.

2. Wrap trimmer line around front of chas-

sis cover to other side and cut at the

"22" mark (your unit's width of cut).

Chassis cover

TO REPLACE TRIMMER LINE

1. Disconnect spark plug wire from spark

plug and place wire where it cannot

come in contact with spark plug.

2. Remove worn trimmer line from line

carrier plate.

3. Fold new, cut to length, trimmer line

in half and insert folded end through

carrier plate opening to back side of

retainer clip.

4. With folded end of line at back side of

retainer clip, pull line outward until line

is fully seated under the retainer clip.

5. Repeat on other side of carrier plate.

6. Check all lines to be sure they are the

same length.

7. Reconnect spark plug wire to spark

plug.

Trimmer

line

Carrier plate

opening

WRAP

LINE

AROUND

Debris New

shield End of trimmer

mark spooled line line

Retainer

clip

Table des matières

Langues :

Autres manuels Craftsman Tondeuse à gazon

Craftsman

Craftsman 247.28984 Manuel utilisateur

Craftsman

Craftsman 917.388060 Manuel utilisateur

Craftsman

Craftsman 917.25667 Manuel utilisateur

Craftsman

Craftsman 917.274641 Manuel utilisateur

Craftsman

Craftsman 917.388820 Manuel utilisateur

Craftsman

Craftsman 917.371040 Manuel utilisateur

Craftsman

Craftsman 917.378470 Manuel utilisateur

Craftsman

Craftsman 917.376151 Manuel utilisateur

Craftsman

Craftsman EZ3 917.273022 Manuel utilisateur

Craftsman

Craftsman 917.273062 Manuel utilisateur

Craftsman

Craftsman 944.364780 Manuel utilisateur

Craftsman

Craftsman 917.274953 Manuel utilisateur

Craftsman

Craftsman 917.273637 Manuel utilisateur

Craftsman

Craftsman 28925 - YT 4000 24 HP/42" Yard Tractor Manuel utilisateur

Craftsman

Craftsman 917.378460 Manuel utilisateur

Craftsman

Craftsman 944.365530 Manuel utilisateur

Craftsman

Craftsman 917.28972 Manuel utilisateur

Craftsman

Craftsman 917.374553 Manuel utilisateur

Craftsman

Craftsman 253792 Manuel du propriétaire

Craftsman

Craftsman 247.370320 Manuel utilisateur

Craftsman

Craftsman 917.273240 Manuel utilisateur

Craftsman

Craftsman 917.272074 Manuel utilisateur

Craftsman

Craftsman 917.377941 Manuel utilisateur

Craftsman

Craftsman 917.272453 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur
