Owner’s Manual

Permanently Lubricated

Tank Mounted

AIR COMPRESSOR

 

 

 

 

 

 

 

Model No.

919.152160

CAUTION: Read the Safety Guidelines

and All Instructions Carefully Before

Operating.





 Rev. 0 6/15/09

2 - ENG

TABLE OF CONTENTS

WARRANTY

WARRANTY ................................................2

SPECIFICATION CHART......................................3

 ...........................3

S........................ 3-8

 ................................................9

ACCESSORIES .............................................9

...............................................9

ASSEMBLY ...............................................10

INSTALLATION ......................................... 10-11

OPERATION............................................ 12-13

MAINTENANCE ............................................14

 ............................ 15-16

 ................................................16

 .................................... 17-19

REPAIR PARTS ......................................... 20-23

ESPAÑOL.............................................. 24-41

...........................43

 ......................back cover



If this Craftsman product fails due to a defect in material or workmanship within

one year from the date of purchase, return it to any Sears store, Sears Parts &

Repair Service Center, or other Craftsman outlet in the United States for free

replacement.

This warranty applies for only 90 days from the date of purchase if this product is

ever used for commercial or rental purposes.

This warranty gives you specific legal rights, and you may also have other rights

which vary from state to state.



3 - ENG

SPECIFICATION CHART

Model No. 919.152160

Running HP 0.8*

Bore 1.875" (47.6 mm)

Stroke 1.250" (31.8 mm)

Voltage/Hz-Single Phase 120/60

Minimum Branch Circuit Requirement 15 amps

Fuse Type Time Delay

Air Tank Capacity 6 Gallon (22.7 liters)

Approximate Cut-in Pressure 120 psig

Approximate Cut-out Pressure 150 psig

SCFM @ 40 psig 3.7 *

SCFM @ 90 psig 2.6 *

*Tested per ISO 1217

Refer to Glossary for abbreviations.



This manual contains information that is important for you to know and under-

stand. This information relates to protecting  and 

. To help you recognize this information, we use the

symbols below. Please read the manual and pay attention to these symbols.

Indicates an

imminently hazardous

situation which, if not avoided, will

result in .

Indicates a potentially

hazardous situation

which, if not avoided, may result in



Indicates a potentially

hazardous situation

which, if not avoided, could result in



Indicates a practice not



which, if not avoided, may result

in p



This product contains chemicals known to the State of

California to cause cancer, and birth defects or other

reproductive harm. Wash hands after handling.

Some dust contains chemicals known to the State of California

to cause cancer, birth defects or other reproductive harm such

as asbestos and lead in lead based paint.

Do not operate this unit until you read and

understand this instruction manual for safety,

operation and maintenance instructions.



4 - ENG



RISK OF EXPLOSION OR FIRE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Itisnormalforelectricalcontacts

within the motor and pressure

switch to spark.

• Alwaysoperatethecompressorina

well ventilated area free of combus-

tible materials, gasoline, or solvent

vapors.

• Ifelectricalsparksfromcompressor

come into contact with flammable

vapors, they may ignite, causing fire

or explosion.

• Ifsprayingflammablematerials,

locate compressor at least 20 feet

(6.1 m) away from spray area. An

additional length of air hose may be

required.

• Storeflammablematerialsina

secure location away from com-

pressor.

• Restrictinganyofthecompressor

ventilation openings will cause seri-

ous overheating and could cause

fire.

• Neverplaceobjectsagainstoron

top of compressor.

• Operatecompressorinanopen

area at least 12" (30.5 cm) away

from any wall or obstruction that

would restrict the flow of fresh air to

the ventilation openings.

• Operatecompressorinaclean,dry

well ventilated area. Do not operate

unit indoors or in any confined area.

• Unattendedoperationofthisprod-

uctcouldresultinpersonalinjury

or property damage. To reduce the

risk of fire, do not allow the com-

pressor to operate unattended.

• Alwaysremaininattendancewith

the product when it is operating.

• Alwaysturnoffandunplugunit

when not in use.





WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairdirectlyfrom

your compressor is not safe for

breathing. The air stream may

contain carbon monoxide, toxic

vapors, or solid particles from the

air tank. Breathing these contami-

nantscancauseseriousinjuryor

death.

• Airobtaineddirectlyfromthecom-

pressor should never be used to

supply air for human consumption.

In order to use air produced by this

compressor for breathing, suitable

filters and in-line safety equipment

must be properly installed. In-line

filters and safety equipment used

inconjunctionwiththecompres-

sor must be capable of treating air

to all applicable local and federal

codes prior to human consump-

tion.

5 - ENG

• Exposuretochemicalsindustcre-

ated by power sanding, sawing,

grinding, drilling, and other con-

struction activities may be harmful.

• Sprayedmaterialssuchaspaint,

paint solvents, paint remover, insec-

ticides, weed killers, may contain

harmful vapors and poisons.

• Workinanareawithgoodcross

ventilation. Read and follow the

safety instructions provided on the

label or safety data sheets for the

materials you are spraying. Always

use certified safety equipment:

NIOSH/OSHA respiratory protec-

tion or properly fitting face mask

designed for use with your specific

application.





OnFebruary26,2002,theU.S.ConsumerProductSafetyCommission

published Release # 02-108 concerning air compressor tank safety:

Air compressor receiver tanks do not have an infinite life. Tank life is dependent

upon several factors, some of which include operating conditions, ambient con-

ditions, proper installations, field modifications, and the level of maintenance.

The exact effect of these factors on air receiver life is difficult to predict.

If proper maintenance procedures are not followed, internal corrosion to the

inner wall of the air receiver tank can cause the air tank to unexpectedly rupture

allowingpressurizedairtosuddenlyandforcefullyescape,posingriskofinjury

to consumers.

Your compressor air tank must be removed from service by the end of the year

shown on your tank warning label.

The following conditions could lead to a weakening of the air tank, and result in

a violent air tank explosion:

WHAT CAN HAPPEN HOW TO PREVENT IT

• Failuretoproperlydraincondensed

water from air tank, causing rust

and thinning of the steel air tank.

• Drainairtankdailyoraftereach

use. If air tank develops a leak,

replace it immediately with a

new air tank or replace the entire

compressor.

• Modificationsorattemptedrepairs

to the air tank.

• Neverdrillinto,weld,ormakeany

modifications to the air tank or its

attachments. Never attempt to

repair a damaged or leaking air

tank. Replace with a new air tank.

• Unauthorizedmodificationsto

the safety valve or any other

components which control air tank

pressure.

• Theairtankisdesignedto

withstand specific operating

pressures.Nevermakeadjustments

or parts substitutions to alter the

factory set operating pressures.

6 - ENG



• Exceedingthepressureratingof

air tools, spray guns, air operated

accessories, tires, and other

inflatables can cause them to

explode or fly apart, and could

resultinseriousinjury.

• Followtheequipment

manufacturers recommendation

and never exceed the maximum

allowable pressure rating of

attachments. Never use compressor

toinflatesmalllowpressureobjects

such as children’s toys, footballs,

basketballs, etc.



• Over inflation of tires could result in

seriousinjuryandpropertydamage. • Useatirepressuregaugetocheck

the tires pressure before each use

and while inflating tires; see the tire

sidewall for the correct tire pressure.

 Air tanks, compressors and

similar equipment used to inflate tires

canfillsmalltiresveryrapidly.Adjust

pressure regulator on air supply to

no more than the rating of the tire

pressure. Add air in small increments

and frequently use the tire gauge to

prevent over inflation.



RISK OF ELECTRICAL SHOCK

WHAT CAN HAPPEN HOW TO PREVENT IT

• Your air compressor is powered by

electricity. Like any other electrically

powered device, If it is not used

properly it may cause electric

shock.

• Never operate the compressor

outdoors when it is raining or in wet

conditions.

• Never operate compressor with

protective covers removed or

damaged.

• Repairs attempted by unqualified

personnel can result in serious

injuryordeathbyelectrocution.

• Any electrical wiring or repairs

required on this product should be

performed by authorized service

center personnel in accordance with

national and local electrical codes.

• Failure to

provide adequate grounding to

this product could result in serious

injuryordeathfromelectrocution.

Refer to

paragraph in the Installation

section.

• Make certain that the electrical

circuit to which the compressor

is connected provides proper

electrical grounding, correct voltage

and adequate fuse protection.

7 - ENG





WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairstreamcan

cause soft tissue damage to

exposed skin and can propel dirt,

chips, loose particles, and small

objectsathighspeed,resultingin

propertydamageorpersonalinjury.

• Alwayswearcertifiedsafetyequip-

ment: ANSI Z87.1 eye protection

(CAN/CSA Z94.3) with side shields

when using the compressor.

• Neverpointanynozzleorsprayer

toward any part of the body or at

other people or animals.

• Alwaysturnthecompressoroff

and bleed pressure from the air

hose and air tank before attempt-

ing maintenance, attaching tools or

accessories.





WHAT CAN HAPPEN HOW TO PREVENT IT

• Touchingexposedmetalsuchas

the compressor head, engine head,

engine exhaust or outlet tubes, can

result in serious burns.

• Nevertouchanyexposedmetal

parts on compressor during or

immediately after operation.

Compressor will remain hot for

several minutes after operation.

• Donotreacharoundprotective

shrouds or attempt maintenance

until unit has been allowed to cool.





WHAT CAN HAPPEN HOW TO PREVENT IT

• Movingpartssuchasthepulley,fly-

wheel, and belt can cause serious

injuryiftheycomeintocontactwith

you or your clothing.

• Neveroperatethecompressorwith

guards or covers which are dam-

aged or removed.

• Keepyourhair,clothing,andgloves

away from moving parts. Loose

clothes,jewelry,orlonghaircanbe

caught in moving parts.

• Airventsmaycovermovingparts

and should be avoided as well.

• Attemptingtooperatecompressor

with damaged or missing parts or

attempting to repair compressor

with protective shrouds removed

can expose you to moving parts

andcanresultinseriousinjury.

• Anyrepairsrequiredonthisproduct

should be performed by authorized

service center personnel.

8 - ENG





WHAT CAN HAPPEN HOW TO PREVENT IT

• Unsafeoperationofyouraircom-

pressorcouldleadtoseriousinjury

or death to you or others.

• Reviewandunderstandallinstruc-

tions and warnings in this manual.

• Becomefamiliarwiththeoperation

and controls of the air compressor.

• Keepoperatingareaclearofallper-

sons, pets, and obstacles.

• Keepchildrenawayfromtheair

compressor at all times.

• Donotoperatetheproductwhen

fatigued or under the influence of

alcohol or drugs. Stay alert at all

times.

• Neverdefeatthesafetyfeaturesof

this product.

• Equipareaofoperationwithafire

extinguisher.

• Donotoperatemachinewithmiss-

ing, broken, or unauthorized parts.





WHAT CAN HAPPEN HOW TO PREVENT IT

• Aportablecompressorcanfall

from a table, workbench, or roof

causing damage to the compres-

sor and could result in serious

injuryordeathtotheoperator.

• Alwaysoperatecompressorina

stable secure position to prevent

accidental movement of the unit.

Never operate compressor on a

roof or other elevated position.

Useadditionalairhosetoreach

high locations.



RISK FROM NOISE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Undersomeconditionsanddura-

tion of use, noise from this product

may contribute to hearing loss.

• Alwayswearcertifiedsafetyequip-

ment: ANSI S12.6 (S3.19) hearing

protection.





9 - ENG



Become familiar with these terms

before operating the unit.

 Cubic feet per minute.

 Standard cubic feet per min-

ute; a unit of measure of air delivery.

 Pounds per square inch gauge;

a unit of measure of pressure.

Products that

bear one or more of the following

marks:UL®*,CUL,ETL®*, CETL, have

been evaluated by OSHA certified

independent safety laboratories and

meet the applicable Standards for

Safety.

*UL®is a registered trademark of

Underwriters Laboratories and ETL®

is a registered trademark of Electrical

Testing Laboratories.

Accessories

• InLineFilter

• TireAirChuck

• QuickConnectorSets

(various sizes)

• AirPressureRegulators

• OilFogLubricators

• AirHose:1/4",3/8"or1/2"I.D.in

various lengths

Refer to the selection chart located on

the unit to select the tools this unit is

capable of powering.









only accessories rated equal to





ACCESSORIES

This unit is capable of powering the following accessories. The accessories are

available through the current Power and Hand Tool Catalog or full-line Sears

stores.

average duty cycle be maintained;

that is, the air compressor pump

should not run more than 30-45

minutes in any given hour.

 Whilethemotoris

off, air tank pressure drops as you

continuetouseyouraccessory.When

the tank pressure drops to a certain

low level the motor will restart auto-

matically. The low pressure at which

the motor automatically restarts is

called "cut-in" pressure.

 Whenanaircom-

pressor is turned on and begins to

run, air pressure in the air tank begins

to build. It builds to a certain high

pressure before the motor automati-

cally shuts off, protecting your air tank

from pressure higher than its capacity.

The high pressure at which the motor

shuts off is called "cut-out" pressure.

Circuit carrying elec-

tricity from electrical panel to outlet.



This air compressor pump is capable

of running continuously. However, to

prolong the life of your air compressor,

it is recommended that a 50%-75%

10 - ENG

ASSEMBLY



Remove unit from carton and discard all packaging.

INSTALLATION





• Locate the air compressor in a

clean, dry and well ventilated

area.

• The air compressor should be

located at least 12" (30.5 cm)

away from the wall or other

obstructions that will interfere

with the flow of air.

• The air compressor pump and

shroud are designed to allow for

proper cooling. The ventilation

openings on the compressor are

necessary to maintain proper

operating temperature. Do not

place rags or other containers on

or near these openings.



RISK OF

ELECTRICAL

SHOCK. 











The portable air compressor is

equipped with a cord having a

grounding wire with an appropriate

grounding plug (see following

illustrations).

1. The cord set and plug with this

unit contains a grounding pin.

ThisplugMUSTbeusedwitha

grounded outlet.

The outlet being used

must be installed and grounded in

accordance with all local codes and

ordinances.

2. Make sure the outlet being used

has the same configuration as the

groundedplug.DONOTUSEAN

ADAPTER. See illustration.





Outlets



3. Inspect the plug and cord before

each use. Do not use if there are

signs of damage.

4. If these grounding instructions are

not completely understood, or if in

doubt as to whether the compres-

sor is properly grounded, have the

installation checked by a qualified

electrician.

RISK OF

ELECTRICAL

SHOCK. I



SHOCK.













trician.

Autres manuels pour 919.152160

Table des matières

Langues :

Autres manuels Craftsman Compresseur d'air

Craftsman

Craftsman 919.195411 Manuel utilisateur

Craftsman

Craftsman 919.167621 Manuel utilisateur

Craftsman

Craftsman 919.724110 Manuel utilisateur

Craftsman

Craftsman 919.167790 Operators Manuel utilisateur

Craftsman

Craftsman 919.722010 Manuel utilisateur

Craftsman

Craftsman 919.16780.CA Manuel utilisateur

Craftsman

Craftsman 921.16476 Manuel utilisateur

Craftsman

Craftsman 919.167812 Manuel utilisateur

Craftsman

Craftsman 16781 - Professional 80 Gal. Vertical Air... Manuel utilisateur

Craftsman

Craftsman 919.153090 Manuel utilisateur

Craftsman

Craftsman 919.724571 Manuel utilisateur

Craftsman

Craftsman 919.165612 Manuel utilisateur

Craftsman

Craftsman 921.166420 Manuel utilisateur

Craftsman

Craftsman 921.16475 Manuel utilisateur

Craftsman

Craftsman 919.727110 Manuel utilisateur

Craftsman

Craftsman 919.152162 Manuel utilisateur

Craftsman

Craftsman 919.166701 Manuel utilisateur

Craftsman

Craftsman 919.167341 Manuel utilisateur

Craftsman

Craftsman 919.727121 Manuel utilisateur

Craftsman

Craftsman 919.72412 Manuel utilisateur

Craftsman

Craftsman 919.167312 Manuel utilisateur

Craftsman

Craftsman 919.727570 Manuel utilisateur

Craftsman

Craftsman 919.167243 Manuel utilisateur

Craftsman

Craftsman 16953 Manuel utilisateur

Manuels Compresseur d'air populaires d'autres marques

Sparmax

Sparmax DC-25XR Manuel utilisateur

KAESER

KAESER M122 Manuel utilisateur

GMC

GMC GAC1500 Manuel utilisateur

Briggs & Stratton

Briggs & Stratton Air Compressor Manuel utilisateur

Fini

Fini F3GST2TK Manuel utilisateur

Industrial Air

Industrial Air CP1580325 Manuel de programmation

Campbell Hausfeld

Campbell Hausfeld RP3300 Guide de démarrage rapide

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Manuel utilisateur

Hitachi

Hitachi EC99S Manuel de l'opérateur

Parkside

Parkside PKO 270 A1 Manuel utilisateur

Sullair

Sullair 185 Manuel utilisateur

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Manuel utilisateur

Ferm

Ferm CRM1046 Manuel utilisateur

BE AC153 Manuel utilisateur

RIDGID

RIDGID OF25150A Manuel utilisateur

Johnson Controls

Johnson Controls QUANTUM LX Manuel

Sears

Sears Craftsman 919.167463 Manuel utilisateur

Ring Automotive

Ring Automotive RAC700 Manuel utilisateur
