Compaq P1100 Color Monitor

User’s Guide

Compaq P1100 Color Monitor

325603-001

Part Number: 144437-001 - Writer: Marianne Silvetti - Saved by: MSilvetti

Saved date: 09/16/99 12:09 PM

File Path: P:\Docs\Monitors\Mayflower

Notice

The information in this guide is subject to change without notice.

COMPAQ COMPUTER CORPORATION SHALL NOT BE

LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR

OMISSIONS CONTAINED HEREIN; NOR FOR INCIDENTAL

OR CONSEQUENTIAL DAMAGES RESULTING FROM THE

FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.

This guide contains information protected by copyright. No part of

this guide may be photocopied or reproduced in any form without

prior written consent from Compaq Computer Corporation.

1999 Compaq Computer Corporation.

Compaq and Deskpro are registered in the U. S. Patent and

Trademark Office.

Microsoft, MS-DOS, Windows, Windows NT, and other names of

Microsoft products referenced herein are trademarks or registered

trademarks of Microsoft Corporation.

ENERGY STAR is a U.S. registered mark.

Product names mentioned herein may be trademarks and/or

registered trademarks of their respective companies.

The software described in this guide is furnished under a license

agreement or nondisclosure agreement. The software may be used

or copied only in accordance with the terms of the agreement.

First Edition (July 1999)

Part Number 325603-291

CD-ROM Part Number 153303-001

Compaq Computer Corporation

User’s Guide

Compaq P1100 Color Monitor

English 1-1

ttttt

Part Number: 325603-001- Writer:Carol Benjamin Name - Saved by:

Pages: 16 Words: 2796 Saved date: 10/27/99 5:20 PM File Name: P1100

English

Product Features

The Compaq P1100 Color Monitor is a microprocessor-based, high-

resolution monitor with auto-scanning. The monitor features include the

following:

?# 21-inch (19.8-in/50.3 cm viewable) FD Trinitron®CRT

?# 1920 × 1440 resolution, plus full-screen support for lower

resolutions

?# On-Screen Display (OSD) adjustments in nine different languages:

English, Dutch, French, German, Italian, Spanish, Russian,

Swedish, and Japanese for ease of set-up and screen optimization

?# Plug and Play capability if supported by your system

?# Tilt and swivel functionality

?# Kodak Color Profile (included on CD-ROM)

?# CD-ROM includes an information file (INF), Image Color

Matching file (ICM), and product documentation

?# Automatic scanning of all horizontal frequencies between 30 and

121 kHz, and vertical frequencies between 50 and 160 Hz

?# Asset Control

?# Energy Saver feature for Energy Star®compliance

?# Macintosh-compatible timing with optional connector∗

?# USB Hub (1 upstream, 4 downstream)

?# Compliance with the following regulated specifications:

❏ Swedish MPR II 1990

❏ EPA ENERGY STAR®

❏ European Union CE Directives

❏ Swedish TCO 99 for all models

∗A Macintosh-compatible connector is not supplied with this monitor.

1-2 English

Part Number: 325603-001- Writer: Carol Benjamin Saved by: Alyce Klingler

Pages: 16 Words: 2796 Saved date: 10/27/99 5:20 PM File Name: P1100

✎Depending on the content of the screen, at times the shadows of

two small horizontal lines may appear on the screen. This is not

a defect and is normal for all aperture grille type displays. The

shadows are two damper wires that reduce the monitor's

susceptibility to vibration.

Universal Driver Manager

This monitor may require a graphics driver (and/or .INF file) that is

compatible with your computer’s graphics adapter. A CD-ROM

containing an .INF file is included with this monitor (see the section on

Information Files). Compaq has also created a Universal Driver

Manager (UDM) release that supports all graphics adapters found on

Compaq Deskpro and Compaq Workstation products. The UDM eases

graphics driver deployment across Compaq platforms ensuring cross-

compatibility and backward-compatibility. The resulting solution

enables customers to manage and control ongoing software maintenance

costs. The UDM is available on the Compaq Support Software CD for

Compaq Desktop, Portable, and Workstation Products and the Compaq

web site (www.compaq.com).

Information Files

This monitor includes a CD-ROM with two information files that should

be installed onto your computer—an .INF file and an .ICM file. The

.INF file defines monitor resources and provides specifications used by

Microsoft Windows 95/98 to install support software for certain

hardware devices. The .INF file ensures monitor compatibility and

optimization with your computer’s graphics adapter.

The .ICM file provides color matching consistency from monitor screen

to printer and is activated from within the graphics programs that have

this feature. To install these files on your computer, insert the Compaq

CD-ROM into the computer's CD tray and follow the instructions from

the menu that appears on the monitor screen. The CD-ROM is located in

the Program License Agreement packet. INF file updates are

downloadable by clicking on:

www.compaq.com/products/monitors/index.html

English 1-3

Part Number: 325603-001- Writer: Shauna Allison - Saved by: Lynette

Saved date: 10/27/99 5:18 PM - File Name: Ch1Fitt.doc

Setting Up the Monitor

To set up the monitor, ensure that the power is turned off to the monitor,

computer system, and other attached devices, then follow these steps:

1. Place the monitor in a convenient, well-ventilated location near

your computer.

2. Connect the monitor signal cable 3to one of the two 15-pin

connectors 4on the rear panel of the computer and tighten the

screws.

✎Be sure the signal cable aligns with the 15-pin connector. Do

not force the cable onto the connector or you may damage the

signal cable.

3. Connect one end of the monitor power cord 1to the connector

on the back of the monitor and the other end 2to an electrical

outlet that is easily accessible and close to the monitor.

1-4 English

Part Number: 325603-001- Writer: Carol Benjamin Saved by: Alyce Klingler

Pages: 16 Words: 2796 Saved date: 10/27/99 5:20 PM File Name: P1100

!WARNING: To reduce the risk of electric shock or damage

to your equipment:

„Do not disable the power cord grounding plug. The

grounding plug is an important safety feature.

?# Plug the power cord into a grounded (earthed) electrical

outlet that is easily accessible at all times.

„#Disconnect power from the monitor by unplugging the

power cord from the electrical outlet.

„#Do not place anything on power cords or cables.

Arrange them so that no one may accidentally step on or

trip over them. Do not pull on a cord or cable. When

unplugging from the electrical outlet, grasp the cord by

the plug.

English 1-5

Part Number: 325603-001- Writer: Shauna Allison - Saved by: Lynette

Saved date: 10/27/99 5:18 PM - File Name: Ch1Fitt.doc

Using USB Connectors

The base of the monitor has five Universal Serial Bus (USB) connectors.

Four of these connectors, 1,2,3,and 4, are for connecting USB

compatible devices such as a keyboard, mouse, or joystick to the hub.

USB connector 5is used to connect the USB signal cable to the

computer. The USB signal cable is included with the monitor.

The following are required to operate the USB hub:

?# Your computer must be fitted with a USB port.

?# Your computer must have Microsoft Windows 95 OSR2.1 or

later, or Microsoft Windows 98 as the operating system.

1-6 English

Part Number: 325603-001- Writer: Carol Benjamin Saved by: Alyce Klingler

Pages: 16 Words: 2796 Saved date: 10/27/99 5:20 PM File Name: P1100

Operating the Monitor

Front Panel Controls

No./Icon Control Function

1Reset Button Pressing this button resets the following items: Contrast,

brightness, size/center, geometry, screen, zoom, and

color. OSD Position, Color Mode, Control Lock, and

Language can not be reset.

2Auto Adjust Provides automatic horizontal and vertical centering and

sizing.

312Input/Select

Switch

Selects either video input 1 or 2.

Brightness Button Down arrow decreases brightness or is used to select

menu adjustment

5Brightness Button Up arrow Increases brightness or is used to select menu

adjustment.

6Menu Button Launches on-screen menus and selects the functions. Also,

exits menus and on-screen display.

7Contrast Button Left arrow decreases contrast or is used to adjust selected

OSD adjustment item.

English 1-7

Part Number: 325603-001- Writer: Shauna Allison - Saved by: Lynette

Saved date: 10/27/99 5:18 PM - File Name: Ch1Fitt.doc

Continued

8Contrast Button Right arrow increases contrast or is used to adjust selected

OSD adjustment item

9Power Button Turns the monitor on and off.

:LED Indicates monitor mode.

1. Green LED indicates monitor is turned on.

2. Alternating Amber/Green LED indicates

Standby/Suspend.

3. Amber LED indicates Sleep Mode.

;Light Sensor Automatically adjusts the monitor contrast depending on

the ambient light levels.

1-8 English

Part Number: 325603-001- Writer: Carol Benjamin Saved by: Alyce Klingler

Pages: 16 Words: 2796 Saved date: 10/27/99 5:20 PM File Name: P1100

On-Screen Display Settings

To adjust screen settings, press the Menu button 6to launch the on-

screen display (OSD). The OSD can be viewed in nine available

languages. The following menu shows the functions at each level:

Menu Level 1 Menu Level 2

Size/Center Horizontal Centering

Vertical Centering

Horizontal Sizing

Vertical Sizing

Zoom

Geometry Rotation

Pincushion

Pin Balance

Keystone

Key Balance

Convergence Horizontal Convergence

Vertical Convergence

Vertical Convergence Top

Vertical Convergence Bottom

Screen Landing Left Top

Landing Right Top

Landing Left Bottom

Landing Right Bottom

Moire Cancel

Color Easy - 5000/6500/9300/adjustable

Expert - RGB Gain, RGB Bias

Color Return - optimizes screen brilliance as CRT ages.

Language English

Francais

Deutsche

Espanol

Italiano

Nederlands

Svenska

Ðóññêèé (Russian)

(Japanese)

Option Degauss

OSD Horizontal Position

OSD Vertical Position

Control Lock

Light Sensor

Information* Model

Serial

Manufactured

* To get this data, press the Menu button for 5 seconds while the monitor picture is stable,

Autres manuels pour P1100

Table des matières

Autres manuels Compaq Moniteur

Compaq

Compaq TFT8030 Manuel utilisateur

Compaq

Compaq P1210 Manuel utilisateur

Compaq

Compaq 8000 - Elite Convertible Minitower PC Manuel utilisateur

Compaq

Compaq ProLiant 5500 Manuel utilisateur

Compaq

Compaq TFT5000S Instructions d'utilisation

Compaq

Compaq TFT5010 Manuel utilisateur

Compaq

Compaq WF1907 - Compaq 19" LCD Monitor Comment utiliser

Compaq

Compaq 378901-008 - FP 700 - 15" LCD Monitor Instructions d'installation

Compaq

Compaq S920 Instructions d'utilisation

Compaq

Compaq V710 Manuel utilisateur

Compaq

Compaq P1100 Manuel utilisateur

Compaq

Compaq P75 Manuel utilisateur

Compaq

Compaq COMPAQ Q1859 Manuel utilisateur

Compaq

Compaq V700 Manuel utilisateur

Compaq

Compaq TFT5010R Instructions d'utilisation

Compaq

Compaq 8000 - Elite Convertible Minitower PC Manuel utilisateur

Compaq

Compaq Q2009 - Compaq - Widescreen LCD Monitor Comment utiliser

Compaq

Compaq 7020 Manuel utilisateur

Compaq

Compaq 303500-001 - V 900 - 19" CRT Display Manuel utilisateur

Compaq

Compaq P700 Manuel utilisateur

Compaq

Compaq Compaq S710 Manuel utilisateur

Compaq

Compaq V1000 Manuel utilisateur

Compaq

Compaq Compaq M720 Manuel utilisateur

Compaq

Compaq CV5500 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
