User’s Guide

Compaq P110 Color Monitor

Second Edition (August 1997)

Part Number 284986-002

Compaq Computer Corporation

Notice

User’s Guide 1-1

Writer: M. Silvetti Saved By: Marianne Silvetti Saved Date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

book 1

ENGLISH

Introduction The Compaq P110 Color Monitor is a high-resolution, large

screen monitor intended for use with high-end graphics

controller boards from Compaq. The large screen is

recommended for advanced graphics user interfaces (GUIs),

high performance graphics and digital video applications such

as computer-aided design, computer-aided engineering,

desktop publishing, document image processing, and

Windows 95 and Windows NT applications.

1-2 English

Writer: Marianne Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

Product Features The monitor features include the following:

■ 21-inch aperture grille CRT for superior brightness and

uniformity with a 19.8-inch (50.2 cm) diagonal viewable

image size

■ Screen customizing adjustments displayed on-screen in five

different languages: English, Dutch, French, German, and

Spanish

■ Universal Serial Bus Hub interface — four Plug and Play

connectors for use with USB peripherals (mouse, etc.)

■ Plug and Play capability if supported by your system

■■ Fault Management and Asset Control

■ Multisync with screen expansion

■ Twenty-one preset display resolutions including

1600 × 1200 @ 85 Hz

■ Energy Saver feature

■ Macintosh-compatible timings with an optional connector

(the Macintosh connector is not included with this monitor)

■ Compliant with the following regulated specifications:

❏ Swedish MPR II 1990

❏ EPA Energy Star

❏ European Union CE Directives

❏ Swedish TCO 1995

User’s Guide 1-3

Writer: M. Silvetti Saved By: Marianne Silvetti Saved Date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

Setting Up the

Monitor To set up the monitor, ensure that the power is turned off to the

monitor, computer system, and other attached devices, then

follow these steps:

1. Place the monitor in a convenient, well-ventilated location

near, but not on top of, your computer.

!WARNING: This monitor weighs approximately 70 pounds and is

not intended to be placed on top of a computer. Place the monitor

directly on a desktop or other work surface. To reduce the risk of

possible injury, do not attempt to lift the monitor by yourself.

2. Remove the cover to the rear panel by grasping the thumb

tab and pulling down.

1-4 English

Writer: Marianne Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

3. Connect one end of the monitor signal cable 1to the

monitor, and the other end 2to the 15-pin connector on the

rear panel of the computer and tighten the screws.

✎Be sure the signal cable aligns with the 15-pin connector. Do not

force the cable onto the connector or you may damage the signal

cable.

4. Connect the monitor power cord 3to the rear panel of the

monitor, then plug the other end into an electrical outlet 4

that is easily accessible and close to the monitor.

!WARNING: To reduce the risk of electric shock or damage to your

equipment, do not disable the power cord grounding feature. This

equipment is designed to be connected to a grounded (earthed)

power outlet that is easily accessible to the operator. The grounding

plug is an important safety feature.

CAUTION: Be sure that the power outlet you plug your power cord

into is easily accessible and located as close to the monitor as

possible. When you need to disconnect power to the equipment, be

sure to unplug the power cord from the power outlet.

User’s Guide 1-5

Writer: M. Silvetti Saved By: Marianne Silvetti Saved Date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

Using USB Connectors

The base of the monitor has five Universal Serial Bus (USB)

connectors. Four of these connectors, 1, 3, 4, and 5, are for

connecting USB compatible Plug and Play devices such as a

keyboard, mouse, or video camera. USB connector 2is used to

connect the USB signal cable to the computer. The USB signal

cable is included with the monitor.

Using BNC Connectors

A signal cable with BNC connectors may be used in place of the

15-pin signal cable. To connect two computers to the monitor, a

BNC connector may be used together with the 15-pin signal

cable. If you have separately purchased a signal cable with BNC

connectors, use the following instructions to connect the signal

cable to the monitor.

✎Fault Management and Asset Control are not supported by the

monitor when BNC connectors are used.

1-6 English

Writer: Marianne Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

1. Connect the five BNC connectors to the monitor. Push in

and twist the connectors clockwise until they are locked

into place. The color of the wires may vary, so refer to the

manufacturer's instructions included with the BNC

connectors. Usually, the connectors are color coded from

left to right in the following order:

1Red (R) for the red video connector

2Green (G) for the green video connector

3Blue (B) for the blue video connector

4White for horizontal sync (H)

5Black for vertical sync (V)

CAUTION: When using a signal cable with BNC connectors, make

sure the BNC/D-Sub control on the monitor’s on-screen display is

set to the correct setting.

User’s Guide 1-7

Writer: M. Silvetti Saved By: Marianne Silvetti Saved Date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

2. Connect the other end of the signal cable to the 15-pin

graphics connector on the back of your computer.

3. Connect the power cord as previously illustrated.

!WARNING: To reduce the risk of electric shock or damage to

your equipment, do not disable the power cord grounding feature.

This equipment is designed to be connected to a grounded

(earthed) power outlet that is easily accessible to the operator. The

grounding plug is an important safety feature.

CAUTION: Be sure that the power outlet you plug your power cord

into is easily accessible and located as close to the monitor as

possible. When you need to disconnect power to the equipment, be

sure to unplug the power cord from the power outlet.

1-8 English

Writer: Marianne Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

Operating the Monitor

Front Control Panel

Icon Control Function

1Light Sensor Automatically adjusts contrast and

brightness to an appropriate level. This

function is turned On and Off using the on-

screen display.

2Contrast Dial Adjusts Contrast.

3Brightness Dial Adjusts Brightness.

4Select Button 1. Launches on-screen display.

2. Selects function adjustments.

3. Exits menus and on-screen display.

5- Minus Button Selects or adjusts the functions.

6+Plus Button Selects or adjusts the functions.

7Power Switch Turns the monitor on and off.

8Power LED 1. Green indicates monitor is turned on.

2. Yellow indicates suspend mode.

3. Amber indicates sleep mode.

User’s Guide 1-9

Writer: M. Silvetti Saved By: Marianne Silvetti Saved Date: 03/03/98 2:30 PM

Pages: 26 Words: 3913 Template: c:\msoffice\templates\normal.dot

File Name Ch1appa.doc Part Number 284986-002

On-Screen Display Settings

The adjustments for screen settings are located in the on-screen

display and can be viewed in one of five available languages.

The on-screen Main Menu displays the following nine

functions:

■ Size and Position - Adjusts the width, height, and horizontal

and vertical position of the screen.

■ Geometry - Provides adjustments to correct pincushion,

pincushion balance, trapezoid, parallelogram, and tilt.

■ Overscan - Zooms out and enlarges the screen.

■ Light Sensor - When turned on, compensates for ambient

room lighting by automatically adjusting the monitor’s

brightness and contrast settings.

■ Color - Adjusts screen color balance, beam landing, and

convergence.

■ Moire - Minimizes interference patterns that occasionally

appear on the screen.

■ Degauss - Corrects image distortion or color impurity

caused by external magnetic fields.

■ Input: DSub (BNC) - Select when using a 15-pin signal

cable and BNC connectors together. If you are using only

one of these cables/connectors, this function automatically

adjusts.

■ Language - Lists five languages available to display on-

screen menus.

■ Management - Allows On/Off selection of power saving

and display modes; displays monitor serial number, and

performs a Master Reset (Master Reset resets all display

modes to their original settings).

■ Factory Reset - Resets the operating display mode to its

factory setting.

Some functions will have up to three menu levels.

✎This monitor uses an aperture grille CRT for excellent screen

performance. At times the shadows of two small horizontal

lines may appear on the screen background. This is not a

defect. The wires are there to reduce susceptibility to

horizontal vibration.

Table des matières

Autres manuels Compaq Moniteur

Compaq

Compaq Flat Panel Monitor tft5017m Manuel utilisateur

Compaq

Compaq D-1H Manuel utilisateur

Compaq

Compaq P1100 Manuel utilisateur

Compaq

Compaq Q2009 - Compaq - Widescreen LCD Monitor Comment utiliser

Compaq

Compaq 7500 Series Manuel utilisateur

Compaq

Compaq V700 Manuel utilisateur

Compaq

Compaq Compaq S710 Manuel utilisateur

Compaq

Compaq MV7540 Manuel utilisateur

Compaq

Compaq COMPAQ Q1859 Manuel utilisateur

Compaq

Compaq 2025 Manuel utilisateur

Compaq

Compaq TFT 1501 Manuel utilisateur

Compaq

Compaq S920 Manuel utilisateur

Compaq

Compaq TFT5010R Instructions d'utilisation

Compaq

Compaq TFT5000 Manuel utilisateur

Compaq

Compaq TFT8030 Manuel utilisateur

Compaq

Compaq 8000 - Elite Convertible Minitower PC Manuel utilisateur

Compaq

Compaq TFT5010 Manuel utilisateur

Compaq

Compaq ProLiant 5500 Manuel utilisateur

Compaq

Compaq 5017 - TFT - 15" LCD Monitor Manuel utilisateur

Compaq

Compaq 307713-001 - V 75 - 17" CRT Display Manuel utilisateur

Compaq

Compaq CPQ-C1786FNSL Manuel utilisateur

Compaq

Compaq CV5500 Manuel utilisateur

Compaq

Compaq TFT1701 Manuel utilisateur

Compaq

Compaq MV 740 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
