1ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

PROFESSIONAL

SERIES

ca 1151

Owner’s Guide

IMPORTANT NOTE: The operationof the Securityand Convenience System asdescribed in this manual is

applicableto most vehicles. However,due to theconfiguration of some vehicles,some functions AND/OR

SAFETYPRECAUTIONS may notapply. Please seeyour installingdealer for more information.

Vehicle Security and Keyless Entry

System

2 ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Table of Contents

Using Your Remote Control ...............................................................3

Arming the Security System ............................................................3

Bypassing the Shock Sensor ..........................................................3

Disarming the Security System........................................................3

Two Stage Door Unlock (optional) ...................................................3

Activating Trunk Release (optional) ................................................3

Activating Optional AUX 1 (optional) ...............................................4

Using the Car Finder Feature...........................................................4

Using the Personal Protection Alarm ...............................................4

Valet Mode ........................................................................................4

Eliminating Notification Chirps ..........................................................4

Manually Overriding the Security System .......................................5

Car Jack Mode .................................................................................. 5

LED and Siren/Horn Indications ......................................................... 6

Transmitter Button Functions ........................................................... 7

Replacing Remote Control Batteries............................................... 7

Warranty Information...........................................................................8

3ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the button. The

parking lights will flash 2 times, indicating the system is armed, has locked the

doors (if equipped and connected) and activated the starter disable feature. The

LED status indicator will blink steadily, once per second.

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible arming

response from the vehicle.

Bypassing The Shock Sensor

To arm the system and ignore the shock sensor press button, then within 5

seconds press + , the system will respond with 1 long chirp.

NOTE: The system will only change the shock sensor setting for one arm cycle

and will be defaulted back to normal operation the next time the system is armed.

Disarming the Security System

To disarm the system press the button. The parking lights will flash 1 time,

indicating the system is disarmed and has unlocked the doors (if equipped and

connected).

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible disarming

response from the vehicle. If your system is set up for 2 step unlock, a third press

of unlock will activate the audible response.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more

than2seconds.

Using Your Remote Control

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will

unlock only the driver’s door. Press again within 5 seconds to unlock the

remaining doors.

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the button for 3

seconds will open the vehicle’s trunk or hatch.

4 ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Activating Optional AUX 1 (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed

for a wide range of functions like power window or sunroof automation, please

consult your installing dealer to determine the functionality of your system.

Eliminating Lock / Unlock Notification Chirps

System lock and unlock notification chirps can be toggled ON or OFF without

entering the programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

Valet Mode

When valet mode is activated the status LED will light solid, and all security

functions will be disabled. To enter or exit valet mode simply follow the 4 steps

outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection alarm.

During panic mode, the normal function of the transmitter buttons will be suspended.

The transmitter’s and buttons can be used to lock and unlock the door (if the

option is installed). To stop the alarm, press and hold the button on the transmitter

again for 3 seconds. The system will automatically stop after 30 seconds.

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will sound 5 times at low

volume, increasing in volume each time the button is pressed.

5ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Car Jack Mode

This feature must be turned on in system programming, please consult your

installing dealer.

Triggering Car Jack mode: While the ignition is ON and press and hold + for 2

seconds, the parking lights will flash 1 time and the system will act as follows;

1. 50 seconds after being triggered the siren will chirp for 15 seconds,

during this 15 seconds you will be alerted to push the valet button to

turn off Car Jack mode. If Car Jack mode is not turned off at this time it

will advance to the next step.

2. Following the 15 second chirps (total time now 65 seconds) the siren

will go into full sound and the parking lights will start flashing.

3. 90 seconds after trigger in, addition to the siren and parking lights, the

system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS

STATE UNTILTHE BATTERYISDEPLETED.

OVERRIDETHE SYSTEM TO TURNOFF CAR JACKMODE:Turn the ignitionOFF

then On and press the valet button within 10 seconds.

Manually Overriding the Security System

Your system can be disarmed without the use of the transmitter. This is

necessary, since you will need the ability to operate your vehicle if the transmitter

is lost or its battery fails. To by-pass the alarm system;

1. Open the vehicle door. The alarm will sound.

2. Turn the ignition key to the ON position.

3. Within 10 seconds, press and release the valet push button switch.

The alarm system will stop sounding and enter the (by-passed) mode. You can

now start and operate the vehicle normally.

6 ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

LED and Siren/Horn Indications

LED Display Indications

LED Function

OFF DISARMED

SLOW FLASH ARMED

FAST FLASH PASSIVEARMING

ON(SOLID) VALETMODE

2 FLASH... PAUSE ZONE2TRIGGER,HOOD/TRUNK

3 FLASH... PAUSE ZONE3TRIGGER, DOOR

4 FLASH... PAUSE ZONE4TRIGGER, SHOCK

5 FLASH... PAUSE ZONE5TRIGGER,IGNITION

Siren/Horn Indications

Chirps Function

1 DISARM

2 ARM

3 DOORAJARUPONARMING

4 DISARM/TRIGGERED

5 CARLOCATOR

Parking Light Flash Indications

Flashes Function

1 DISARM

2 ARM

3 DISARM/TRIGGERED

5 CARLOCATOR

7ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Transmitter Button Functions

Replacing Remote Control Batteries

1-Way 4 Button Remote Control:

The batteries (model CR2016) inside each remote control should last approximately

1 year under normal use. When the batteries become weak you will notice the

remote control range (the distance from the vehicle the remote control will work)

deteriorate and the small LED on the remote control will dim. To replace the remote

control batteries:

1. Remove 3 screws and disassemble the halves of the remote control.

2. Remove the old batteries, observing the +/- symbols on the batteries

and replace with new CR2016 batteries.

3. Reassemble the halves of the remote control and install the 3 screws.

4. Test operation of the remote control.

8 ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Code Systems, Inc. Limited Lifetime Warranty

Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE

vehicle security product (the “Product”), purchased from an authorized CODE dealer, that (except as

provided below) should this Product under normal use and conditions, be proven defective in

material or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGI-

NALLY INSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge for

parts directly related to repairs of the defect(s).

Switches, indicator lights, and transmitter cases are similarly warranted to the original

purchaser for a period of one (1) year from the date of purchase of the Product.

CODE accessories, sold separately, are covered by the applicable warranty accompa-

nying the accessory.

This warranty is non-transferable, non-assignable and is voided when: (1) the Product is

removed from the vehicle in which it was originally installed; or (2) the vehicle in which the Product

was originally installed is transferred to another party.

This warranty does not apply to any product damaged by accident, physical or electrical

abuse, improper installation, alteration, or use contrary to its intended function, fire, flood, or other

natural acts.

In order for the Product to be repaired or replaced under the terms of this warranty, the

defective Product must be returned to an authorized CODE dealer and accompanied by a copy of

the retail sales receipt. The date of purchase and year, make and model of the vehicle in which the

Product was originally installed must be clearly indicated on the sales receipt.

This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED

OR IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MER-

CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE

DURATION OF THIS WRITTEN WARRANTY. IN NO CASE SHALL CODE BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WAR-

RANTY, EXPRESS OR IMPLIED, WHATSOEVER.

CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT OF

CODE’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT

PROVIDED ABOVE AND, IN NO EVENT SHALL CODE’S LIABILITY EXCEED THE PURCHASE

PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT WITHOUT INSTALLATION

LABOR.

Some states do not allow the exclusion or limitation of incidental or consequential

damages, so the above limitation may not apply to you. This warranty gives you specific legal

rights and you may also have other rights which vary from state to state

9ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

10 ca1151revB.2011AudiovoxElectronicsCorporation.Allrightsreserved.

Audiovox Electronics Corporation.

Customer Service 1-800-421-3209

WWW.CODE-ALARM.COM

FCC COMPLIANCE

This device complies with Part 15 of the FCC rules and with RSS-210 of

Industry Canada. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including any interference

that may cause undesired operation.

Warning!

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Autres manuels pour ca 1151

Table des matières

Autres manuels Code Alarm Alarme de voiture

Code Alarm

Code Alarm PRO 3500 Caractéristiques techniques

Code Alarm

Code Alarm PROFESSIONAL SERIES CA 1551 Manuel utilisateur

Code Alarm

Code Alarm ca6355E Manuel utilisateur

Code Alarm

Code Alarm CA 6551 SST Manuel utilisateur

Code Alarm

Code Alarm CA-130 Manuel utilisateur

Code Alarm

Code Alarm CA-125 Manuel utilisateur

Code Alarm

Code Alarm CA 1550 Manuel utilisateur

Code Alarm

Code Alarm ca 5152 Manuel utilisateur

Code Alarm

Code Alarm CATX110 Mode d'emploi

Code Alarm

Code Alarm Vehicle Security System Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA 1050 Manuel utilisateur

Code Alarm

Code Alarm ca1555 Manuel utilisateur

Code Alarm

Code Alarm CA 680 Manuel utilisateur

Code Alarm

Code Alarm Car Alarm CA-310 Manuel utilisateur

Code Alarm

Code Alarm CSI-200 Manuel utilisateur

Code Alarm

Code Alarm CA-230 Manuel utilisateur

Code Alarm

Code Alarm CA-135 Manuel utilisateur

Code Alarm

Code Alarm 2000 Manuel utilisateur

Code Alarm

Code Alarm CA 110 Manuel utilisateur

Code Alarm

Code Alarm CA 671 Manuel utilisateur

Code Alarm

Code Alarm CATX610 Mode d'emploi

Code Alarm

Code Alarm Professional Series CA 1550 Manuel utilisateur

Code Alarm

Code Alarm SRT 5500 Manuel utilisateur

Code Alarm

Code Alarm TW-1 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur

Code Alarm ca 1151 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques
