Cisco WAP121 Mode d’emploi

5(9,(:'5$)79HUVLRQ{&,6&2&21),'(17,$//

&LVFR6PDOO%XVLQHVV

:$3

:$3

$'0,1,675$7,21

*8,'(

Wireless-N Access Point with Power over Ethernet

Wireless-N Selectable -Band Access Point with 

Power over Ethernet

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 2

REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

&RQWHQWV

&KDSWHU*HWWLQJ6WDUWHG 

Starting the Web-based AP Configuration Utility 7

Launching the Utility 8

Logging In 8

Logging Out 8

Using the Access Point Setup Wizard 9

Getting Started 10

Window Navigation 11

Application Header 11

Navigation Window 11

Management Buttons 12

&KDSWHU9LHZLQJ6WDWLVWLFV 

System Summary 14

Network Interfaces 15

Traffic Statistics 16

WorkGroup Bridge Transmit/Receive 17

Associated Clients 18

TSPEC Client Associations 19

Rogue AP Detection 21

TSPEC Status and Statistics 25

TSPEC AP Statistics 26

RADIO Statistics 27

Email Alert Status 28

Log 29

&KDSWHU/$16HWWLQJV 

Port Settings 30

LAN 31

Time Settings 33

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 3

REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

&RQWHQWV

&KDSWHU:LUHOHVV6HWWLQJV 

Radio 36

Networks 43

SSID Naming Conventions 43

VLAN IDs 44

Configuring VAPs 44

Configuring Security Settings 47

None (Plain-text) 47

Static WEP 47

Dynamic WEP 50

WPA Personal 51

WPA Enterprise 53

Scheduler 55

Adding Scheduler Profiles 56

Configuring Scheduler Rules 57

Scheduler Association 58

Bandwidth Utilization 58

MAC Filtering 59

Configuring a MAC Filter List Locally on the AP 59

Configuring MAC Authentication on the RADIUS Server 60

WDS Bridge 60

Work Group Bridge 62

QoS 65

WPS Setup 67

WPS Overview 68

Usage Scenarios 68

WPS Roles 69

Enabling and disabling WPS on a VAP 69

External and Internal Registration 70

Client Enrollment 70

Optional Use of Internal Registrar 71

Lockdown Capability 71

VAP Configuration Changes 72

External Registration 72

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 4

REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

&RQWHQWV

Exclusive Operation of WPS Transactions 72

Backward Compatibility with WPS Version 1.0 73

Configuring WPS Settings 73

WPS Process 74

Enrolling a Client Using the PIN Method 74

Enrolling a Client Using the Push Button Method 75

Viewing Instance Summary Information 76

&KDSWHU6103Y 

SNMP Overview 77

General SNMP Settings 78

SNMP Views 80

SNMP Groups 81

SNMP Users 83

SNMP Targets 84

&KDSWHU$GPLQLVWUDWLRQ 

System Settings 86

User Accounts 87

Adding a User 87

Changing a User Password 88

Firmware Upgrade 89

TFTP Upgrade 89

HTTP Upgrade 90

Packet Capture 90

Packet Capture Configuration 91

Local Packet Capture 92

Remote Packet Capture 93

Packet Capture File Download 96

Log Settings 97

Configuring the Persistent Log 97

Remote Log Server 98

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 5

REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

&RQWHQWV

Email Alert 99

Discovery—Bonjour 101

HTTP/HTTPS Service 102

Configuring HTTP and HTTPS Services 102

Managing SSL Certificates 103

Telnet/SSH Service 104

Management Access Control 104

Download/Backup Configuration File 105

Backing Up a Configuration File 106

Downloading a Configuration File 107

Configuration Files Properties 107

Copying and Saving the Configuration 108

Rebooting 109

&KDSWHU6\VWHP6HFXULW\ 

RADIUS Server 110

802.1X Supplicant 112

Password Complexity 113

WPA-PSK Complexity 114

&KDSWHU&DSWLYH3RUWDO 

Configuring Global Captive Portal Settings 117

Configuring Instances 118

Configuring VAPs 120

Uploading Binary Files 121

Customizing the Captive Portal Web Pages 122

Web Customization Preview 124

Local Groups 125

Local Users 125

Local User/Group Associations 127

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 6

REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

&RQWHQWV

Authenticated Clients 127

Failed Authentication Clients 128

&KDSWHU&OLHQW4XDOLW\RI6HUYLFH 

ACLs 130

IPv4 and IPv6 ACLs 130

MAC ACLs 131

Configuring ACLs 131

Class Map 137

Adding a Class Map 138

Defining a Class Map 138

Policy Map 142

Client QoS Association 144

Client QoS Status 145

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 7

REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

*HWWLQJ6WDUWHG

This chapter provides an introduction to the web-based access point (AP)

configuration utility, and includes the following topics:

•6WDUWLQJWKH:HEEDVHG$3&RQILJXUDWLRQ8WLOLW\

•8VLQJWKH$FFHVV3RLQW6HWXS:L]DUG

•*HWWLQJ6WDUWHG

•:LQGRZ1DYLJDWLRQ

6WDUWLQJWKH:HEEDVHG$3&RQILJXUDWLRQ8WLOLW\

This section describes how to navigate the AP configuration utility.

Browsers have the following restrictions:

•If you are using Internet Explorer 6, you cannot directly use an IPv6 address

to access the AP. You can, however, use the DNS (Domain Name System)

server to create a domain name that contains the IPv6 address, and then

use that domain name in the address bar in place of the IPv6 address.

•To use Internet Explorer 8, open a browser window and configure the

following settings:

Click 7RROV!,QWHUQHW2SWLRQV and then select the 6HFXULW\ tab. Select

/RFDO,QWUDQHW and click 6LWHV. Click $GYDQFHG and then click $GG. Add the

intranet address of the AP (http://<ip-address>) to the local intranet zone.

The IP address can also be specified as the subnet IP address, so that all

addresses in the subnet are added to the local intranet zone.

•If you have multiple IPv6 interfaces on your management station, use the

IPv6 global address instead of IPv6 link local address to access the AP from

your browser.

*HWWLQJ6WDUWHG

Starting the Web-based AP Configuration Utility

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 8



REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

/DXQFKLQJWKH8WLOLW\

To open the web-based AP configuration utility:

67(3  Open a Web browser.

67(3  Enter the IP address of the AP you are configuring in the address bar on the

browser, and then press Enter. The Login page opens.

/RJJLQJ,Q

To log in to the web-based AP configuration utility:

67(3  Enter the user name and password. The factory default user name is FLVFR and the

default password is FLVFR.

67(3  If this is the first time that you logged on with the default user name (FLVFR) and the

default password (FLVFR) or your password has expired, the Change Admin

Password page opens. Enter the new password and confirm it, click $SSO\, and

then click &ORVH. The new password is saved.

Then, enter the user name FLVFR and the new password on the Login page.

67(3  Click /RJLQ.

When the login attempt is successful, the Access Point Startup Wizard page

opens.

If you entered an incorrect user name or password, an error message is displayed

and the Login page remains displayed on the screen.

See 8VLQJWKH$FFHVV3RLQW6HWXS:L]DUGSDJH for instructions on using the

wizard.

/RJJLQJ2XW

By default, the application logs out after five minutes of inactivity. See +773

+77366HUYLFH for instructions on changing the default timeout period.

To logout, click /RJRXW in the top right corner of any page.

*HWWLQJ6WDUWHG

Using the Access Point Setup Wizard

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 9



REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

8VLQJWKH$FFHVV3RLQW6HWXS:L]DUG

The first time you log into the AP (or after it has been reset to the factory default

settings), the Access Point Startup Wizard displays to help you perform initial

configuration. Follow these steps to complete the wizard:

127( If you click Cancel to bypass the Wizard, the Change Password page displays. You

can then change the default password for logging in. For all other settings, the

factory default configuration will apply.

67(3  Click 1H[W. The Wizard displays the first of several Configuration windows, the

Access Point Setup Wizard—IP Address window.

67(3  Configure the system to receive its IP information from a DHCP server, or specify

this information manually. For a description of these fields, see /$1SDJH.

67(3  Click 1H[W. The Access Point Setup Wizard—Time Settings window displays.

67(3  Select your time zone, and then configure the system time manually or set the AP

to get its time from an NTP server. For a description of these options, see 7LPH

6HWWLQJVSDJH.

67(3  Click 1H[W. The Wizard displays the first of four security windows, the Access

Point Setup Wizard—Device Password window.

67(3  Enter a 1HZ3DVVZRUG and enter it again in the &RQILUP3DVVZRUG text box. For

more information about passwords, see 8VHU$FFRXQWVSDJH.

67(3  Click 1H[W. The Wizard displays the second of four security windows, the Access

Point Setup Wizard—Network Name window.

67(3  Enter a 1HWZRUN1DPH. This name serves as the SSID for the default wireless

network.

67(3  Click 1H[W. The Wizard displays the third of four security windows, the Access

Point Setup Wizard—Wireless Security window.

67(3 Choose a security type. For a description of these options, see 6\VWHP6HFXULW\

SDJH .

67(3 Click 1H[W. The Wizard displays the Access Point Setup Wizard—Summary

window.

67(3 Review the settings you configured. If they are correct, click 6XEPLW. Or, click %DFN

to reconfigure one or more settings. If you click &DQFHO, all settings are returned to

the previous values.

*HWWLQJ6WDUWHG

Getting Started

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 10



REVIEW DRAFT Version 2—CISCO CONFIDENTIAL

If you click 1H[W, the Wizard displays the Access Point Setup Wizard—Finish

window.

67(3 Click )LQLVK. The Getting Started window displays.

*HWWLQJ6WDUWHG

To simplify device configuration through quick navigation, the Getting Started

page provides links for performing common tasks.

/LQNVRQWKH*HWWLQJ6WDUWHG3DJH

&DWHJRU\ /LQN1DPHRQWKH3DJH /LQNHG3DJH

Initial Setup Run Setup Wizard Access Point Startup

Wizard

Configure Radio Settings Radio

Configure Wireless Network Settings Networks

Configure LAN Settings LAN

Run WPS WPS Setup

Device

Status System Summary System Summary

Wireless Client Associations Network Interfaces

Quick

Access Change Account Password User Accounts

Upgrade Device Firmware Upgrade Firmware

Backup/Restore Configuration Download/Backup

Configuration File

Other

Resources Support Cisco AP support site

Forums Cisco Support

Community site
