Cisco Aironet Series 2800/3800 Access Point Deployment Guide

First Published: 2016-05-11

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS,

INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND,

EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH

THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY,

CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB's public domain version

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS" WITH ALL FAULTS.

CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT

LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS

HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network

topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional

and coincidental.

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: http://

www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership

relationship between Cisco and any other company. (1110R)

CONTENTS

CHAPTER 1

Overview 1

CHAPTER 2

Choosing the Right Access Point 3

Models 3

Part Numbers and Descriptions 4

Supported Code Versions Compatible with AP 2800 and AP 3800 5

Differences between the AP 2800 and AP 3800 Access Points 5

Feature Differences 8

Ports on the AP 2800 and AP 3800 9

Modularity and Smart Antenna Connector Ports 10

CHAPTER 3

Physical Hardware and Mounting Options 13

Access Point Physical Hardware and Mounting Options 13

Channel Rail Adapters 14

Mounting an AP Directly into the Tile Using Optional AIR-AP-BRACKET-3 16

Using an In-tile Mount from Oberon Wireless 18

Wall-mounting the AP 18

Changing the Color of an AP 21

Clean Rooms (Healthcare) 22

Above the Ceiling Tiles 22

CHAPTER 4

Understanding Flexible Radio Assignment (software overview) 25

Understanding Flexible Radio Assignment (Software Overview) 25

Flexible Radio Architecture (FRA) System 26

CHAPTER 5

Client Roaming in a Micro and Macro Cell 27

Understanding Macro and Micro Cells 27

Client Roaming from a Macro to Micro Cell 29

Cisco Aironet Series 2800/3800 Access Point Deployment Guide

iii

Client Roaming from a Micro to Macro Cell 29

Micro and Macro cells on “I”Series Access Points 30

RF Operations on “E/P”Series Access Points 33

CHAPTER 6

Approved Antennas for Use with Access Points 2800 and 3800 39

CHAPTER 7

AP 2800 and AP 3800 Powering Options 41

CHAPTER 8

AP 3800 and Multigigabit Ethernet (mGig) 47

CHAPTER 9

New–B Regulatory Domain for US Theater 51

CHAPTER 10

Stadium and Harsh Environments 53

CHAPTER 11

Areas with High Vibration 55

CHAPTER 12

Related References 57

Previous Deployment Guides 57

CHAPTER 13

Frequently Asked Questions (FAQ's) 59

Cisco Aironet Series 2800/3800 Access Point Deployment Guide

Contents

CHAPTER 1

Overview

This document covers the Cisco 2800/3800 Series Access Points theory of operation and installation as part

of a Cisco wireless LAN (WLAN) solution. Subjects related include:

•Choosing the right access point, part numbers and descriptions

•Supported code versions

•Differences between AP 2800 and AP 3800

•Physicals / Hardware details, mounting options, bracket choices

•Third party mounting options including hospital and cleanroom environments

•Understanding Flexible Radio Assignment (FRA) and architecture

•Understanding Macro and Microcells

•Looking at roaming between cells

•Hardware differences in FRA between I, E and P versions

•Approved antennas and new FCC regulatory –B domain

•AP 2800 and AP 3800 powering options and requirements

•AP 3800 and Multigigabit Ethernet (mGig)

Cisco Aironet Series 2800/3800 Access Point Deployment Guide

Overview

CHAPTER 2

Choosing the Right Access Point

•Models, page 3

•Part Numbers and Descriptions , page 4

•Supported Code Versions Compatible with AP 2800 and AP 3800 , page 5

•Differences between the AP 2800 and AP 3800 Access Points, page 5

•Feature Differences, page 8

•Ports on the AP 2800 and AP 3800 , page 9

•Modularity and Smart Antenna Connector Ports , page 10

Models

The Cisco 2800 and 3800 Series Access Points target customers requiring support for mission-critical and

best in class applications. The 2800/3800 embodies ClientLink 4.0, an innovative antenna technology comprising

four transmit radios and four receive radios called 4x4 in a Multiple Input Multiple Output (MIMO)

configuration and supporting three spatial streams (3SS), together referenced as 4x4:3. Using this type of

antenna system along with additional Modulation Coding Scheme (MCS) rates supporting up to 256 QAM

and up to 160 MHz channel bonding, rates of up to 5 Gbps can be supported.

Cisco Aironet Series 2800/3800 Access Point Deployment Guide

ClientLink 4.0 uses these features along with an additional antenna (N+1) to allow for beam-forming for all

802.11a/g/n/ac and now ac Wave-2 clients including those supporting 3 spatial streams.

Figure 1: Access Point Portfolio Placement

Access points are available in three models:

•Internal antennas version labeled “i”that has captured antennas (part of the housing and not removable).

The “i”series is designed for indoor Enterprise installations where office aesthetics are a primary concern.

•External antennas version labeled “e”that is more rugged and designed for industrial use in locations

such as hospitals, factories, and warehouses, anywhere a need exists for external antennas and/or extended

operating temperatures. The “e”version also supports mounting inside NEMA enclosures for use in the

most demanding environments.

•Access points for professional install are labeled “p”series and may be used in outdoor applications.

Part Numbers and Descriptions

DescriptionSKU

Single Unit; Internal Antenna ModelAIR-AP3802I-x-K9

10 pack; Internal Antenna ModelAIR-AP3802I-xK910

Single Unit; External Antenna ModelAIR-AP3802E-x-K9

10 pack; External Antenna ModelAIR-AP3802E-xK910

Single Unit; Internal Antenna Model; ConfigurableAIR-AP3802I-x-K9C

10 pack; Internal Antenna Model; ConfigurableAIR-AP3802I-xK910C

Cisco Aironet Series 2800/3800 Access Point Deployment Guide

Choosing the Right Access Point

Part Numbers and Descriptions

DescriptionSKU

Single Unit; External Antenna Model; ConfigurableAIR-AP3802E-x-K9C

10 pack; External Antenna Model; ConfigurableAIR-AP3802E-xK910C

Supported Code Versions Compatible with AP 2800 and AP 3800

The minimum versions supporting the AP 2800 and 3800 are:

•Wireless LAN Controller (WLC) AirOS release 8.2MR1

•Polaris release 16.3

•Prime release 3.1MR1

•MSE or CMX 10.2.2

•ISE 2.0

Differences between the AP 2800 and AP 3800 Access Points

The mechanical front of the AP 2800 and AP 3800 are nearly identical in physical appearance.

Figure 2: AP 2800 and AP 3800 (I and E) versions

Cisco Aironet Series 2800/3800 Access Point Deployment Guide

Choosing the Right Access Point

Supported Code Versions Compatible with AP 2800 and AP 3800

The AP 3800 is also available in a "P" version. The external antenna "E" versions permit antenna gains up to

6 dBi, "P" version up to 13 dBi.

Figure 3: AP 2800/3800

There are slight differences in the weight and thickness of the 2800 and 3800. The AP 3800 is a bit more

robust as it has support for mGig (NBASE-T) and optional module support. AP 2800 on left is smooth and

does not have heat fins.

Figure 4: AP 2800/3800 Dimensions

Cisco Aironet Series 2800/3800 Access Point Deployment Guide

Choosing the Right Access Point

Differences between the AP 2800 and AP 3800 Access Points
