Cisco Aironet 1530 Series Manuel

2-38

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Installing Antennas

Antenna N-Type Connector Locations

The access point antenna N-type connectors are located on the top and the bottom of model

AIR-CAP1532E-x-K9. The N-type connectors support variety of the Cisco Aironet antennas. For

detailed information on these antennas, refer to Antenna Configurations, page 2-29. Figure 2-23 shows

the antenna port locations viewed from the RF cover side.

Figure 2-23 Antenna Port Locations - Model AIR-CAP1532E-x-K9

Installing a Lightning Arrestor

Overvoltage transients can be created through lightning static discharges, switch processes, direct

contact with power lines, or through earth currents. The Cisco Aironet AIR-ACC245LA-N Lightning

Arrestor limits the amplitude and duration of disturbing interference voltages and improves the over

voltage resistance of in-line equipment, systems, and components. A lightning arrestor installed

according to these mounting instructions balances the voltage potential, thus preventing inductive

interference to parallel signal lines within the protected system.

Installation Considerations

Cisco recommends that you bulkhead mount the lightning arrestor so it can be installed as a wall-feed

through on the wall of the protected space.

The importance of obtaining a good ground and bonding connection cannot be overstressed. Consider

these points when grounding the lightning arrestor:

1Antenna port 1 – Type N connector 2Antenna port 2- Type N connector

3Antenna port 3– Type N connector (with cap) 4Antenna port 4- Type N connector (with cap)

351321

2-39

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Installing Antennas

•Connect the lightning arrestor components directly to the grounding point.

•The contact points of the ground connection must be clean and free of dust and moisture.

•Tighten threaded contacts to the torque specified by the manufacturer.

Installation Notes

This lightning arrestor is designed to be installed between the antenna cable that is attached to an outdoor

antenna and the Cisco Aironet wireless device. You can install the lightning arrestor either indoors or

outdoors. It can be connected directly to a wireless device having an external N connector. It can also be

mounted inline or as a feed-through. Feed-through installations require 5/8 in. (16 mm) hole to

accommodate the lightning arrestor.

Note This lightning arrestor is part of a lightning arrestor kit. The kit contains a lightning arrestor and a

grounding lug.

Note When you install the lightning arrestor, follow the regulations or best practices applicable to lightning

protection installation in your local area.

Installing the Lightning Arrestor Outdoors

If you install the lightning arrestor outdoors, use the supplied ground lug and a heavy wire (#6 solid

copper) to connect it to a good earth ground, such as a ground rod. The connection should be as short as

possible.

Figure 2-24 Lightning Arrestor Details

1Nut 4Unprotected side (to antenna)

2Lockwasher 5Protected side (to wireless device)

3Ground lug

346382

2-40

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Grounding the Access Point

Cable for the Lightning Arrestor

Coaxial cable loses efficiency as the frequency increases, resulting in signal loss. The cable should be

kept as short as possible because cable length also determines the amount of signal loss (the longer the

run, the greater the loss).

Cisco recommends a high-quality, low-loss cable for use with the lightning arrestor.

Grounding the Access Point

The access point must be grounded before connecting power.

Warning

This equipment must be externally grounded using a customer-supplied ground wire before power is

applied. Contact the appropriate electrical inspection authority or an electrician if you are uncertain

that suitable grounding is available.

Statement 366

Warning

Installation of the equipment must comply with local and national electrical codes.

Statement 1074

In all outdoor installations and when powering the access point with AC power, you must follow these

instructions to properly ground the case:

Step 1 If using insulated 6-AWG copper ground wire, strip the insulation as required for the grounding lug.

Step 2 Use the appropriate crimping tool to crimp the bare 6-AWG copper ground wire to the supplied

grounding lug.

Note The grounding lug and hardware used must comply with local and national electrical codes.

Step 3 Open the anti-corrosion sealant (supplied), and apply a liberal amount over the metal surface where the

ground strap screw holes are located (see Figure 1-5).

Step 4 Connect the grounding lug to the access point grounding screw holes (see Figure 1-5) using the supplied

two Phillips head screws (M4 x10 mm) with lock washers. Tighten the grounding screw to

22 to 24 lb-in (2.49 to 2.71 Nm).

Step 5 If necessary, strip the other end of the ground wire and connect it to a reliable earth ground, such as a

grounding rod or an appropriate grounding point on a metal streetlight pole that is grounded (see

Figure 2-3).

Powering the Access Point

Warning

Installation of the equipment must comply with local and national electrical codes.

Statement 1074

2-41

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Powering the Access Point

Warning

This equipment must be externally grounded using a customer-supplied ground wire before power is

applied. Contact the appropriate electrical inspection authority or an electrician if you are uncertain

that suitable grounding is available.

Statement 366

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity.

Statement 1001

The 1532 access point supports these power sources:

•DC power – 24- 57 VDC

•Power-over-Ethernet (PoE)

The 1532 access point can be powered via the PoE input from an in-line power injector or a suitably

powered switch port. Depending on the configuration and regulatory domain, the required power for full

operation is UPoE. For the 1532E, 802.3at power is sufficient for all regulatory domains and full 2x2

MIMO operation on both 2.4 and 5 GHz radios. Either the AIR-PWRINJ4= or the AIR-PWRINJ1500-2=

power injector can be used.

For the 1532I, UPoE powered switch port or the AIR-PWRINJ1500-2= power injector is required for

full operation of the 3x3 MIMO on the 2.4 GHz radio in the regulatory domains that allow for high 2.4

GHz transmit power (Regulatory domains -A, -D, -F, -K, -N, -Q, -T, -Z). If the 1532I is powered by a

PoE+ (802.3at power) switch port or the AIR-PWRINJ4= power injector, then the access point will

automatically disable one of the 2.4 GHz transmitters and the radio will operate in 2x3 MIMO mode.

Table 2-7 AP 1530 Power Matrix

Caution Do not place the power injector in an unprotected outdoor environment because water could get into the

power injector and cause a short circuit and possible fire.

Model Configuration

Regulatory

Domain

Switch

Power AIR-PWRINJ1500-2= AIR-PWRINJ4=

AC/ DC Power Adapter

AIR-PWRADPT-1530=

1532I 3x3:3 (2.4 GHz)

2x3:2 (5 GHz)

A, D, K, N,

Q, T, Z

UPoE Yes Yes

One Tx disabled1

2x3:2 (2.4 GHz)

2x3:2 (5 GHz)

1. Not user configurable. AP will automatically disable one of the 2.4 GHz Tx if it detects only 802.3at power input.

A, D, K, N,

Q, T, Z

802.3at

PoE+

Not Applicable Yes Not Applicable

3x3:3 (2.4 GHz)

2x3:2 (5 GHz)

C, E, F, H,

M, R, S

802.3at

PoE+

Yes Yes Yes

1532E 2x2:2 (2.4 GHz)

2x2:2 (5 GHz)

All 802.3at

PoE+

Yes Yes Yes

2-42

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Powering the Access Point

Warning

Connect the unit only to DC power source that complies with the Safety Extra-Low Voltage (SELV)

requirements in IEC 60950 based safety standards

Statement 1033

Connecting a 1530 Series Power Injector

The 1530 Series Access Points support the following power injectors:

•AIR-PWRINJ1500-2= — 100-240 VAC input, indoor use only

•AIR-PWRINJ4= — 100-240 VAC input, indoor use only

The power injector provides (AIR-PWRINJ1500-2=) 56 VDC to the access point over the Ethernet cable

and supports a total end-to-end Ethernet cable length of 100 m (328 ft) from the switch to the access

point.

When your access point is powered by an optional power injector, follow these steps to complete the

installation:

Step 1 Before applying PoE to the access point, ensure that the access point is grounded (see the “Grounding

the Access Point” section on page 2-40).

Step 2 Review Figure 2-2 to identify the components needed for the installation.

Note The 1500 power injector can only be used in an indoor environment, therefore, the cable from

the injector must travel from the protected location to the outside mounted access point.

Step 3 Connect a CAT5e or better Ethernet cable from your wired LAN network to the power injector.

Warning

To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

Statement 1023

Note The installer is responsible for ensuring that powering the access point from this type of power

injector is allowed by local and/or national safety and telecommunications equipment standards.

Tip To forward bridge traffic, add a switch between the power injector and controller. Refer to the

Cisco Wireless Mesh Access Points, Design and Deployment Guide, Release 7.0 for more

information.

Step 4 Ensure that the antennas are connected and that a ground is attached to the access point before you apply

power to the access point.

Step 5 Connect a shielded outdoor-rated Ethernet (CAT5e or better) cable between the power injector and the

PoE-in connector of the access point (see Figure 2-25).

Step 6 Connect the Ethernet cable to the access point PoE-In port (see “Connecting an Ethernet Cable to the

Access Point” section on page 2-43).

Step 7 Continue with What to Do Next, page 2-53.

2-43

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Powering the Access Point

Connecting an Ethernet Cable to the Access Point

You need to supply these tools and materials:

•Shielded outdoor-rated Ethernet (CAT5e or better) cable with 0.2 to 0.35 in. (0.51 to 0.89 cm)

diameter

•RJ-45 connector and installation tool

•Adjustable Wrench or 28 mm box wrench

•Large Phillips or Flat Blade screwdriver

To connect the shielded Ethernet cable to the access point, follow these steps:

Step 1 Disconnect power to the power injector, and ensure all power sources to the access point are turned off.

Warning

This unit might have more than one power supply connection. All connections must be removed to

de-energize the unit.

Statement 1028

Step 2 Ensure a 6 AWG ground wire is connected to the access point (see the “Grounding the Access Point”

section on page 2-40).

Step 3 Use a large Phillips or Flat Blade screw driver to remove the Ethernet connector plug from the access

point. Do not discard plug and rubber seal unless you are certain that the port will not have to be

re-plugged (see Figure 2-25 for the location).

Figure 2-25 Access Point PoE-In Connector- AP 1532I

Note For information on data cable entry, refer to Figure 1-1

Step 4 Loosen the Thread-Lock sealing nut of the cable gland by turning it counter clockwise, but do not

remove it (see Figure 2-26).

1LAN port (covered) 2PoE-in port (covered)

347850

2-44

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Powering the Access Point

Note Verify that the cable gland has a rubber seal and ensure that it is not damaged.

Warning

Failure to install the cable gland and rubber gasket properly will cause the cable grip to leak.

Figure 2-26 Cable Gland

Step 5 Insert the unterminated end of the Ethernet cable through the sealing nut end of the cable gland (see

Figure 2-26), and pull several inches of cable through the adapter.

Step 6 Install an RJ-45 connector on the unterminated end of the Ethernet cable using your Ethernet cable

installation tool.

Warning

To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

Statement 1023

Warning

When installing the RJ-45 connector, ensure that cable gland and the rubber gasket are present and

installed properly, to avoid water leakage into the enclosure. See Figure 2-26 and Figure 2-27.

Step 7 Carefully insert the RJ-45 cable connector into the Ethernet port opening on the access point, and

connect to the internal Ethernet connector (see Figure 2-27).

1Washer (Rubber Gasket) 2Body

3Sealing insert 4Clamping claw

5Thread-lock sealing nut

2-45

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Powering the Access Point

Figure 2-27 Inserting RJ-45 Connector into the Ethernet Port Opening in Case

Step 8 Slide the cable gland with the rubber seal towards the access point, and screw the threaded end of the

body into the access point, and hand-tighten.

Step 9 Use an adjustable wrench or a 28-mm wrench to tighten the threaded end of the body into the enclosure.

Tighten to 15 lb-in.

Step 10 Use an adjustable wrench and tighten the thread-lock seal nut to 15 lb-in.

Step 11 Ensure that the antennas are connected to the access point before you apply power to the access point.

Step 12 Route your Ethernet cable, and cut off any excess cable.

Step 13 Install an RJ-45 connector on the unterminated cable end, and insert it into the power injector. For typical

installation components, see Figure 2-2.

Step 14 Turn on power to the power injector.

Connecting a DC Power Cable to the Access Point

When powering the access point with DC power, you must ensure that DC power can be conveniently

removed from the unit. The power should not be removed by disconnecting the DC power connector on

the unit.

Warning

A readily accessible two-poled disconnect device must be incorporated in the fixed wiring.

Statement 1022

1Ethernet port opening in access point case. 2RJ-45 connector, on shielded outdoor-rated

Ethernet (CAT5e or better) cable

3Exploded view of the cable gland,on the Ethernet cable.

352056

2-46

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Powering the Access Point

Warning

Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV)

requirements in IEC 60950 based safety standards.

Statement 1033

To connect a DC power cable, you need to supply these tools and material:

•Shielded outdoor-rated DC power cable (minimum 18 AWG) with outside cable diameter of 0.20 to

0.35 inch (0.51 to 0.89 cm).

•Adjustable or open-end wrench

•Small flat screw driver

•Two-pin DC power connector (Cisco supplied)

To connect the DC power cable to the access point, follow these steps:

Step 1 Before connecting DC power to the access point, ensure that the ground is connected to the access point

(see the “Grounding the Access Point” section on page 2-40).

Step 2 Turn off all power sources to the access point, including the DC power source.

Warning

This unit might have more than one power supply connection. All connections must be removed to

de-energize the unit.

Statement 1028

Caution When installing DC power to the access point, always connect the access point end of the cable FIRST.

When removing the DC power connector, always disconnect the access point end of the cable LAST.

Step 3 Use a large Phillips or Flat Blade screw driver to remove the Ethernet connector plug from the access

point. Do not discard plug and rubber seal unless you are certain that the port will not have to be

re-plugged. (see Figure 2-28 for the location of the DC power connector).

Figure 2-28 Access Point DC Power Connector and Ground Lug (Both AP 1532 Models)

1DC power port 2Ground lug location

347846

2-47

Cisco Aironet 1530 Series Outdoor Access Point Hardware Installation Guide

OL-30864-01

Chapter 2 Installing the Access Point

Powering the Access Point

Step 4 Loosen the thread-Lock sealing nut of the cable gland by turning it counter clockwise, but do not remove

(see Figure 2-29).

Note Verify that the cable gland has a rubber seal and ensure that it is not damaged.

Warning

Failure to install the Cable Gland properly will cause the cable grip to leak.

Figure 2-29 Cable Gland

Note The cable gland accepts a cable diameter of 0.20 to 0.35 in. (0.51 to 0.89 cm).

Step 5 Insert a bare end of the DC power cable into the rounded end of the cable gland (see Figure 2-29), and

pull approximately 6 inches of cable through the adapter.

Warning

When installing the DC power cable, ensure that cable gland and the rubber gasket are present and

installed properly, to avoid water leakage into the enclosure. See Figure 2-29 and Figure 2-31.

Step 6 Strip the DC cable jacket back about 1 inch to expose the wires and strip the insulation about 3/8 inch

(9.5 mm) from each wire.

Step 7 Insert each wire into the two-position terminal strip (supplied), and tighten each wire using a 0.1 inch

(0.25 cm) flat screw driver (see Figure 2-30).

1Washer (Gasket) 2Body

3Sealing insert 4Clamping claw

5Thread-lock sealing nut

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Point d'accès sans fil

Cisco

Cisco Aironet 1530 Series, 1532 Manuel utilisateur

Cisco

Cisco Aironet 1140 Series Manuel utilisateur

Cisco

Cisco Linksys WAP55AG Manuel utilisateur

Cisco

Cisco Aironet 350 Series Manuel

Cisco

Cisco USC 3330 Manuel utilisateur

Cisco

Cisco Small Business WAP551 Manuel utilisateur

Cisco

Cisco Aironet 1300 Series Manuel utilisateur

Cisco

Cisco Cisco Aironet Wireless LAN Client Manuel utilisateur

Cisco

Cisco Aironet 1250 Series Manuel utilisateur

Cisco

Cisco Small Business AP541N Manuel utilisateur

Cisco

Cisco AT&T U-VERSE VEN401 Manuel utilisateur

Cisco

Cisco WAP4410N - Small Business Wireless-N Access... Manuel utilisateur

Cisco

Cisco Aironet 1540 Series Manuel

Cisco

Cisco Catalyst Wireless 9162I Series Manuel

Cisco

Cisco Aironet 1700 Guide de référence rapide

Cisco

Cisco 1700 series Manuel

Cisco

Cisco Aironet 3700 Series Guide de référence rapide

Cisco

Cisco Linksys WAP610N Manuel utilisateur

Cisco

Cisco GR10-HW Manuel utilisateur

Cisco

Cisco WAP125 Manuel utilisateur

Cisco

Cisco Aironet 1140 Series Manuel utilisateur

Cisco

Cisco WAP371 Manuel utilisateur

Cisco

Cisco Catalyst 9120AX Series Manuel utilisateur

Cisco

Cisco MERAKI MR72 Manuel

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur

Draytek

Draytek VIGORAP 902 Manuel utilisateur
