Catalyst 2960-S Switch Hardware Installation Guide

OL-19732-01

APPENDIX

Technical Specifications

Table A-1 Environmental Specifications for All Catalyst 2960-S Switches

Environmental Ranges

Operating temperature 0 to 113°F (–5 to 45°C) up to 5,000 ft (1500 m)

23 to 104°F (–5 to 40°C) up to 10,000 ft (3000 m)

Storage temperature –13 to 158°F (–25 to 70°C)

Relative humidity 10 to 85% (noncondensing)

Storage altitude Up to 15,000 ft (4573 m)

A-2

Catalyst 2960-S Switch Hardware Installation Guide

OL-19732-01

Appendix A Technical Specifications

Table A-2 Catalyst 2960S-48FPD-L, 2960S-48LPD-L, 2960S-24PD-L, 2960S-48FPS-L,

2960S-48LPS-L, and 2960S-24PS-L Switch Specifications

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

9 to 4 A, 50 to 60 Hz (Catalyst 2960S-48FPD-L)

5 to 2 A, 50 to 60 Hz (Catalyst 2960S-48LPD-L)

5 to 2 A, 50 to 60 Hz (Catalyst 2960S-24PD-L)

9 to 4 A, 50 to 60 Hz (Catalyst 2960S-48FPS-L)

5 to 2 A, 50 to 60 Hz (Catalyst 2960S-48LPS-L)

5 to 2 A, 50 to 60 Hz (Catalyst 2960S-24PS-L)

DC input voltage for

RPS 2300

+12 V @ 4 A, –52 V @ 15A (Catalyst 2960S-48FPD-L)

+12 V @ 4 A, –52 V @ 8 A (Catalyst 2960S-48LPD-L)

+12 V @ 3 A, –52 V @ 8 A (Catalyst 2960S-24PD-L)

+12 V @ 4 A, –52 V @ 15 A (Catalyst 2960S-48FPS-L)

+12 V @ 4 A, –52 V @ 8 A (Catalyst 2960S-48LPS-L)

+12 V @ 3 A, –52 V @ 8 A (Catalyst 2960S-24PS-L)

Power consumption1

1. Power consumption values for the power consumed internally by the switch at 120 VAC 60 Hz.

129 W, 440 BTUs per hour (Catalyst 2960S-48FPD-L)

100 W, 341 BTUs per hour (Catalyst 2960S-48LPD-L)

84 W, 286 BTUs per hour (Catalyst 2960S-24PD-L)

131 W, 447 BTUs per hour (Catalyst 2960S-48FPS-L)

100 W, 341 BTUs per hour (Catalyst 2960S-48LPS-L)

84 W, 286 BTUs per hour (Catalyst 2960S-24PS-L)

Power rating2

2. Power rating values for the switch input power.

0.89 KVA (Catalyst 2960S-48FPD-L)

0.48 KVA (Catalyst 2960S-48LPD-L)

0.46 KVA (Catalyst 2960S-24PD-L)

0.89 KVA (Catalyst 2960S-48FPS-L)

0.48 KVA (Catalyst 2960S-48LPS-L)

0.46 KVA (Catalyst 2960S-24PS-L)

PoE+

15.4 W-per-port maximum, 740-W switch maximum

(Catalyst 2960S-48FPD-L and 2960S-48FPS-L switches)

15.4-W-per-port maximum, 370-W switch maximum

(Catalyst 2960S-48LPD-L, 2960S-24PD-L, 2960S-48LPS-L, and 2960S-24PS-L switches)

Physical Dimensions

Weight 13 lb (5.89 kg) (Catalyst 2960S-48FPD-L)

12.5 lb (5.66 kg) (Catalyst 2960S-48LPD-L)

12.5 lb (5.66 kg) (Catalyst 2960S-24PD-L)

13 lb (5.89 kg) (Catalyst 2960S-48FPS-L)

12.5 lb (5.66 kg) (Catalyst 2960S-48LPS-L)

12.5 lb (5.66 kg) (Catalyst 2960S-24PS-L)

Dimensions (H x D x W) 1.75 x 15.19 x 17.5 in. (4.45 x 38.6 x 44.5 cm). Applies to all PoE

switches.

A-3

Catalyst 2960-S Switch Hardware Installation Guide

OL-19732-01

Appendix A Technical Specifications

Table A-3 Catalyst 2960S-48TD-L, 2960S-24TD-L, 2960S-48TS-L, 2960S-24TS-L, 2960S-48TS-S,

and 2960S-24TS-S Switch Specifications

Power Requirements

AC input voltage 100 to 240 VAC (autoranging)

1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-48TD-L)

1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-24TD-L)

1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-48TS-L)

1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-24TS-L)

1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-48TS-S)

1 to 0.5 A, 50 to 60 Hz (Catalyst 2960S-24TS-S)

DC input voltage for

RPS 2300

+12 V @ 4 A, (Catalyst 2960S-48TD-L)

+12 V @ 3 A, (Catalyst 2960S-24TD-L)

+12 V @ 4 A, (Catalyst 2960S-48TS-L)

+12 V @ 4 A, (Catalyst 2960S-24TS-L)

+12 V @ 4 A, (Catalyst 2960S-48TS-S)

+12 V @ 3 A, (Catalyst 2960S-24TS-S)

Power consumption1

1. Power consumption values for the power consumed internally by the switch at 120 VAC 60 Hz.

55 W, 188 BTUs per hour (Catalyst 2960S-48TD-L)

40 W, 136 BTUs per hour (Catalyst 2960S-24TD-L)

52 W, 177 BTUs per hour (Catalyst 2960S-48TS-L)

40 W, 136 BTUs per hour (Catalyst 2960S-24TS-L)

53 W, 181 BTUs per hour (Catalyst 2960S-48TS-S)

36 W, 123 BTUs per hour (Catalyst 2960S-24TS-S)

Power rating2

2. Power rating values for the switch input power.

0.09 KVA (Catalyst 2960S-48TD-L)

0.09 KVA (Catalyst 2960S-24TD-L)

0.13 KVA (Catalyst 2960S-48TS-L)

0.09 KVA (Catalyst 2960S-24TS-L)

0.10 KVA (Catalyst 2960S-48TS-S)

0.08 KVA (Catalyst 2960S-24TS-S)

Physical Dimensions

Weight

Dimensions (H x D x W)

9.5 lb (4.30 kg) (Catalyst 2960S-48TD-L,

Catalyst 2960S-24TD-L, and 2960S-48TS-S)

10.5 lb (4.76 kg) (Catalyst 2960S-48TS-L)

10 lb (4.53 kg) (Catalyst 2960S-24TS-L and

2960S-24TS-S)

1.75 x 11.77 x 17.50 in. (4.45 x 29.9 x 44.5 cm). All non-PoE

switches.

A-4

Catalyst 2960-S Switch Hardware Installation Guide

OL-19732-01

Appendix A Technical Specifications
