Cisco ASR-920-12SZ-A Manuel

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services

Router Hardware Installation Guide

First Published: 2018-07-16

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

Safety Warnings 1

CHAPTER 1

Standard Warning Statements 1

Safety Guidelines for Personal Safety and Equipment Protection 2

Safety Precautions for Module Installation and Removal 3

Safety with Electricity 3

Power Supply Considerations 6

Power Connection Guidelines 6

Guidelines for DC-Powered Systems 7

Guidelines for AC-Powered Systems 7

Prevent Power Loss 7

Preventing ESD Damage 7

Overview 9

CHAPTER 2

Power Supply 10

GNSS Module 11

Network Timing Interfaces 11

Management Interfaces 11

Alarm 11

Console 11

Auxiliary Console 11

USB Console 12

USB Memory 12

Management Port 12

Dual Rate Ports—1GE/10GE SFP+ Ports 12

LED Indicators 13

Fan Module 15

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

iii

Licensing the Router 15

Prepare for Installation 17

CHAPTER 3

Site Planning 17

General Precautions 17

Site Planning Checklist 17

Site Selection Guidelines 18

Environmental Requirements 18

Physical Characteristics 18

Airflow Guidelines 18

Floor Loading Considerations 20

Site Power Guidelines 20

Electrical Circuit Requirements 21

Site Cabling Guidelines 21

Asynchronous Terminal Connections 22

Interference Considerations 22

Rack-Mounting Guidelines 23

Precautions for Rack-Mounting 23

Rack Selection Guidelines 23

Receive the Device 23

Unpack and Verify Shipped Contents 25

Tools and Equipment 26

Install the Router 27

CHAPTER 4

Rack Compatibility 27

Rack Types 27

Set up Device on Rack or Wall 29

Rack Mount 29

Install Rack Brackets 29

Set Up Device on Rack 31

Attach the Cable Guides 36

Wall Mount 39

Install Wall Brackets 39

Wall Mount the Device 40

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

Contents

Ground the Device 42

Connect Power Cables 43

Attach AC Power Cables 43

Service AC Power Supply 44

Attach DC Power Cables 45

Activate DC Power Supply 46

Service the DC Power Supply 47

Connect Gigabit Ethernet Ports 47

Connect SFP Modules 48

Install SFP Modules 48

Remove SFP Modules 49

Connect Fiber Optic SFP Modules 49

Connect RJ-45 Connector 50

Connect Chassis to Network 50

Connecting Console Cables 50

Connecting to the USB Serial Port Using Microsoft Windows 50

Connecting to the Console Port Using Mac OS X 51

Connecting to the Console Port Using Linux 52

Installing the Cisco USB Device Driver 52

Uninstalling the Cisco USB Device Driver 53

Connecting a USB Flash Device 53

Removing a USB Flash Device 53

Install GNSS Module 54

Connecting Timing Cables 55

Connecting a Cable to the BITS Interface 56

Connecting Cables to the GPS Interface 56

Connect to EIA Console Port 57

Connect a Management Ethernet Cable 57

Configure the Device 59

CHAPTER 5

Power up the Device 59

Verify the Front Panel LEDs 59

Verify the Hardware Configuration 60

Check Hardware and Software Compatibility 60

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

Contents

Configure Device at Startup 60

Access the CLI Using the Console 61

Configure Global Parameters 61

Check the Running Configuration Settings 62

Save the Running Configuration to NVRAM 62

Safely Power Down the Device 63

Troubleshooting Aids 65

CHAPTER 6

Verify Pinout 65

BITS Port Pinouts 65

GPS Port Pinouts 66

Time-of-Day Port Pinouts 66

Alarm Port Pinouts 67

Management Ethernet Port Pinouts 67

USB Console Port Pinouts 68

USB MEM Port Pinouts 68

Check Optical Fiber Specifications 69

Check Alarm Conditions 69

Check LED Indicators 69

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

Contents

CHAPTER 1

Safety Warnings

This handout topic lists the safety warnings necessary for handling this product. Before you install or service

the chassis, review these safety warnings to avoid injuring yourself or damaging the equipment.

For a complete list of translated safety warnings, see the Regulatory Compliance and Safety Information for

the Cisco ASR 920 Series Aggregation Services Router document.

The safety warnings are grouped under the following sections:

•Standard Warning Statements, on page 1

•Safety Guidelines for Personal Safety and Equipment Protection, on page 2

•Safety Precautions for Module Installation and Removal, on page 3

•Safety with Electricity, on page 3

•Power Supply Considerations, on page 6

•Preventing ESD Damage, on page 7

Standard Warning Statements

To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to

ensure that the system remains stable. The following guidelines are provided to ensure your safety: This unit

should be mounted at the bottom of the rack if it is the only unit in the rack. When mounting this unit in a

partially filled rack, load the rack from the bottom to the top with the heaviest component at the bottom of

the rack. If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing

the unit in the rack. Statement 1006

Warning

This unit is intended for installation in restricted access areas. A restricted access area can be accessed only

through the use of a special tool, lock and key, or other means of security. Statement 1017

Warning

Ultimate disposal of this product should be handled according to all national laws and regulations. Statement

1040

Warning

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

To prevent the system from overheating, do not operate it in an area that exceeds the maximum recommended

ambient temperature of 158°F (70°C). Statement 1047

Warning

The chassis should be mounted on a rack that is permanently affixed to the building. Statement 1049

Warning

IMPORTANT SAFETY INSTRUCTIONS: This warning symbol means danger. You are in a situation that

could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical

circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided

at the end of each warning to locate its translation in the translated safety warnings that accompanied this

device. Statement 1071

Warning

This is a Class A Device and is registered for EMC requirements for industrial use. The seller or buyer should

be aware of this. If this type was sold or purchased by mistake, it should be replaced with a residential-use

type. Statement 294

Warning

This is a class A product. In a domestic environment this product may cause radio interference in which case

the user may be required to take adequate measures. Statement 340

Warning

This equipment is in compliance with the essential requirements and other relevant provisions of Directive

1999/5/EC. Statement 287

Warning

Suitable for mounting on and over a concrete or other non-combustible surface only. Statement 345

Warning

SafetyGuidelinesforPersonalSafety andEquipment Protection

The following guidelines ensure your safety and protect the equipment. This list does not include all the

potentially hazardous situations. Therefore, you must be alert.

• Before moving the system, always disconnect all power cords and interface cables.

• Never assume that power is disconnected from a circuit; always check.

• Before and after installation, keep the chassis area clean and dust free.

• Keep tools and assembly components away from walk areas where you or others could trip over them.

• Do not work alone if potentially hazardous conditions exist.

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

Safety Warnings

Safety Guidelines for Personal Safety and Equipment Protection

• Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.

• Do not wear loose clothing that may get caught in the chassis.

• When working under conditions that may be hazardous to your eyes, wear safety glasses.

Safety Precautions for Module Installation and Removal

Be sure to observe the following safety precautions when you work on the router.

Class 1 laser product. Statement 1008

Warning

Do not stare into the beam or view it directly with optical instruments. Statement 1011

Warning

Invisible laser radiation present. Statement 1016

Warning

Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams or

view directly with optical instruments. Statement 1051

Warning

Safety with Electricity

Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect

the power at the circuit breaker on DC units. Statement 12

Warning

Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces,

and watches). Metal objects will heat up when connected to power and ground and can cause serious burns

or weld the metal object to the terminals. Statement 43

Warning

Avoid using or servicing any equipment that has outdoor connections during an electrical storm.

There may be a risk of electric shock from lightning. Statement 1088

Warning

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

Safety Warnings

Safety Precautions for Module Installation and Removal

Before performing any of the following procedures, ensure that power is removed from the DC circuit.

Statement 1003

Warning

Read the installation instructions before connecting the system to the power source. Statement 1004

Warning

This product relies on the building’s installation for short-circuit (overcurrent) protection. For a DC installation,

ensure that the branch circuit breaker is rated a maximum 15A for DC systems. For AC systems, 15A for

voltages greater than 200Vac; 20A for voltages below 127Vac. Statement 1005

Warning

Take care when connecting units to the supply circuit so that wiring is not overloaded. Statement 1018

Warning

The plug-socket combination must be accessible at all times, because it serves as the main disconnecting

device. Statement 1019

Warning

To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage

(TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some LAN and

WAN ports both use RJ45 connectors. Use caution when connecting cables. Statement 1021

Warning

A readily accessible two-poled disconnect device must be incorporated in the fixed wiring. Statement 1022

Warning

To reduce the risk of fire, use only 26 AWG or larger telecommunication line cord. Statement 1023

Warning

This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence

of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician

if you are uncertain that suitable grounding is available. Statement 1024

Warning

Use copper conductors only. Statement 1025

Warning

Cisco ASR-920-12SZ-A and Cisco ASR-920-12SZ-D Aggregation Services Router Hardware Installation Guide

Safety Warnings

Safety with Electricity

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Routeur réseau

Cisco

Cisco ASR 907 Mode d’emploi

Cisco

Cisco 10000 Series Manuel utilisateur

Cisco

Cisco 8600 Manuel utilisateur

Cisco

Cisco 860 Series Manuel

Cisco

Cisco SOHO 71 Manuel utilisateur

Cisco

Cisco GRS Manuel utilisateur

Cisco

Cisco 7206VXR - VPN Bundle Router Manuel

Cisco

Cisco OSR-7609 Manuel d'installation et d'exploitation

Cisco

Cisco 7609-S Manuel utilisateur

Cisco

Cisco 6000 series Manuel technique

Cisco

Cisco 3825 - Voice Bundle Router Mode d'emploi

Cisco

Cisco Profile Series Manuel utilisateur

Cisco

Cisco 827-4V - 827-4V Router - EN Guide rapide

Cisco

Cisco 7301 Series Manuel utilisateur

Cisco

Cisco Small Business SRP520-U Manuel utilisateur

Cisco

Cisco DVB CAR100 Series Manuel utilisateur

Cisco

Cisco C1109-2PX Guide de démarrage rapide

Cisco

Cisco WRP500 Mode d’emploi

Cisco

Cisco 867W Manuel utilisateur

Cisco

Cisco 500 Series Instructions originales

Cisco

Cisco vEdge 5000 Manuel utilisateur

Cisco

Cisco 8600 Manuel

Cisco

Cisco 1605-R Mode d'emploi

Cisco

Cisco 2621XM Mode d’emploi

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

EnGenius

EnGenius ESR-9710 Manuel utilisateur

LevelOne

LevelOne FBR-1416 Manuel utilisateur

Dynacord

Dynacord Promatrix 6000 Manuel utilisateur

Lorex

Lorex F5D8230-4 Manuel utilisateur
