Cisco CTE 1400 Series Manuel utilisateur
2
1Introduction
The Cisco Content Transformation Engine (CTE) 1400 Series handles requests for applications from
devices with microbrowser screens and uses transformation instructions to convert applications into
appropriate formats. Transformation instructions are created in the companion PC-based application,
Design Studio.
This document provides instructions for installing the CTE and performing the initial configuration
procedure.
2Install the Cisco CTE 1400 Series Hardware
This section describes how to install the CTE hardware in your network environment.
Requirements
To set up the CTE, you need the following hardware in addition to the items delivered with the CTE:
•Power cable
•Null-modem cable (9-pin female connector at both ends)
•A computer capable of hosting terminal console communication through a serial port
•One or two network cables to connect the CTE to a LAN
Procedure
The following steps summarize the hardware installation procedure described in the Cisco CTE 1400
Series Hardware Installation Guide:
Step 1 Install the CTE in a rack (if rack-mounted).
Step 2 Use network cables to connect the CTE NIC 1 (e0) port to your network (such as to a server
load balancer). For information on using the NIC 2 (e1) port, refer to the Cisco CTE
Configuration Note.
Step 3 Connect a null-modem cable to the 9-pin serial port on the CTE and connect the cable to a
computer that is capable of running terminal emulation software.
Step 4 On the computer, start a terminal emulation application. For example, start HyperTerminal.
3
Step 5 Set the serial connection to 9600 bits per second, 8 data bits, no parity, 1 stop bit; set the
Backspace key to issue a Delete character.
Hardware flow control is optional.
Step 6 Power up the CTE.
After about five minutes, the CTE serial console appears on the computer terminal.
Next
You are now ready to configure the CTE with your network. If you are upgrading the CTE, go to
section 3. Otherwise, skip to section 4.
4
3Upgrade the Cisco CTE 1400 Series Software
If you are installing a new device, rather than an upgrade, skip this section.
Requirements
To upgrade to Release 2.7, you need the Release 2.7 Restore CD-ROM.
Note Be aware that an upgrade is a complete new installation, and it will overwrite any previous
CTE settings.
Upgrade Procedure
To upgrade your CTE, perform these steps:
Step 1 Make sure that a PC capable of hosting terminal emulation software is connected to the CTE;
power on both systems.
Step 2 Insert the CTE Release 2.7 Restore CD into the CD-ROM drive of the CTE.
Step 3 Power down the CTE.
Step 4 Wait 10 seconds.
Step 5 Power on the CTE.
Step 6 When the installation has completed, the serial console displays the message “Installation
successful.”
Step 7 When the upgrade is complete, eject the Restore CD and reboot the CTE.
Step 8 When the CTE restarts, the CTE serial console opens.
Next
You are now ready to configure the CTE with your network.
5
4Configure the CTE for the First Time
This section describes the minimum configuration required to establish and test a connection between
your CTE and another device such as a server load balancer, switch, or web server.
Procedure
To configure the CTE, perform these general steps:
Step 1 In the CTE serial console, set the root password when prompted.
a. Enter a password of 8 or more characters.
b. Verify the password when prompted.
Step 2 Enter the IP address and netmask for Interface 0 when prompted:
IP address [x.x.x.x] (Enter 0 to clear):
ipAddress
Netmask [x.x.x.x] (Enter 0 to clear):
netmask
Step 3 Enter the IP address of the gateway device when prompted.
Gateway [x.x.x.x]:
gateway ipAddress
Step 4 The first DNS server is automatically set. If you want to change it, you can enter a different
IP address when prompted. Otherwise, press Enter to leave this setting unchanged.
DNS server[0] [x.x.x.x] (Enter 0 to clear):
Step 5 You can define two other DNS servers when prompted if you wish. To leave these values unset,
press Enter at each prompt.
Step 6 Enter the name, if any, that you want to use as your default domain name, such as
www.fox.com.
Domain Name [ ] (Enter 0 to clear):
Step 7 Type 1and then 6to ping the connected device.
If the ping command is successful, you have completed the initial configuration. If you are
unable to ping the connected device, refer to the Cisco CTE Configuration Note for
troubleshooting information.
For detailed information on other configuration settings, see the Cisco CTE Configuration Note.
6
Next
Continue configuring the CTE from the Administration interface. Perform these steps:
Step 1 From a web browser, enter:
https://ipAddress:9001
Where:
– ipAddress is the IP address of your CTE
–9001 is the administration port
Step 2 Click the Network tab.
Step 3 Click Yes in the Security Alert dialog box.
Step 4 Log in as root, and enter the root password that you defined in the CTE serial console.
Step 5 On the Interfaces screen of the Network tab, define the Masquerade Host for Interface 0. The
masquerade host is an IP address that can be used for Network Address Translation (NAT).
Step 6 Click Submit to save your changes. Although a Restart Server button appears, you do not need
to restart the server yet.
Step 7 On the Ports screen of the Network tab, select from the Listen on Interface drop-down menu
the IP address that you have configured for Interface 0.
Step 8 Click Submit to save your changes and then click Restart Server.
Step 9 After the server restarts, click the Administration tab.
Step 10 Click Yes in the Security Information dialog box.
Step 11 On the Users screen of the Administration tab, specify a username and password for each
Design Studio user. Enter a username of at least 6 characters and a password of at least 8
characters. Click the Add User button.
From your web browser, check network connectivity by entering
http://ipAddress:httpPort.
For example, if the IP address of your CTE is 192.168.10.0 and its HTTP port is 80, enter
http://192.168.10.0:80.
If the ScreenTop Menu appears, the CTE is properly configured. If the ScreenTop Menu does
not appear, check the settings.
Next
Continue to the next section to install Design Studio.
7
5Install Design Studio
Design Studio is the application that creates transformation rules. You also use Design Studio to
customize the default ScreenTop Menu that serves as a portal for devices connecting to the CTE.
Requirements
Design Studio requires the following:
•Windows 95, Windows 98/ME, Windows 2000, or Windows NT 4.0 with Service Pack 6.
•At least 25 MB of disk space.
•At least 128 MB of RAM; 256 MB is recommended.
•Internet Explorer version 5.0 or higher, or Netscape Navigator version 4.01 or higher.
•A VGA color monitor with a graphics card capable of showing 16-bit color or higher. A minimum
screen resolution of 640 x 480. Recommended resolution is 1280 x 1024.
•Network connection to the CTE.
The network connection can be through a proxy server, which you specify when you log in to
Design Studio.
Procedure
To install Design Studio, perform these steps:
Step 1 Insert the Design Studio CD-ROM into your CD-ROM drive.
If auto-start is enabled on your computer, the installer starts.
If auto-start is not enabled on your computer, double-click the drive icon for your CD-ROM,
and then double-click CiscoCTEDesignStudio.exe.
Step 2 Follow the instructions in the installer.
You may be asked to restart your PC during the installation. After you restart your PC, the
Design Studio installation wizard continues the installation.
By default, Design Studio is installed in C:\Program Files\Cisco\CTE\Design Studio.
Next
Continue to the next section to start Design Studio.
8
6Start Design Studio
See the Design Studio Getting Started Guide for detailed information on installing and starting Design
Studio, as well as an overview of the product and a tutorial. For detailed information on using Design
Studio to create, preview, and publish transformation rules, see the Design Studio User Guide. That
information is also available from the Design Studio Help menu.
Requirements
To start Design Studio, you need the following login information from the administrator who sets up
the CTE:
•Your Design Studio username and password
•The IP address of the CTE
•The server upload port number
•HTTP and HTTPS proxy hosts and ports, if Design Studio and the CTE are connected through a
proxy server
Procedure
To start Design Studio, perform these steps:
Step 1 From the Windows Start menu, choose Program Files > Cisco > CTE > Design Studio.
The login dialog box appears.
Step 2 Enter your username and password.
Step 3 Enter the IP address of the CTE.
Step 4 If necessary, change the upload port number.
The default upload port number is 9001. You might need to change the port number if your
firewall redirects ports. Contact your CTE administrator if you do not know which port to
use.
9
Step 5 If the computer on which Design Studio is installed is connected to the CTE through a proxy
server, click Use Proxy and enter the host and port for HTTP and HTTPS connections.
Step 6 Click OK.
If you cannot connect to the CTE, verify that your computer has a network connection to a
running CTE. Contact your CTE administrator for help.
For More Information
All of the Design Studio and CTE documentation is available on the Design Studio CD-ROM. You can
also obtain the documentation from the Cisco home page (http://www.cisco.com) or order a printed
copy by calling Cisco corporate headquarters (California, USA) at 408 526-7208 or, elsewhere in
North America, by calling 800 553-NETS (6387).
