Cisco ONS 15454 Mode d’emploi

Corporate Headquarters:

Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA

Unpacking and Installing the Cisco ONS 15454

Four-Shelf and Zero-Shelf Bay Assembly

Overview

The Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assemblies provide a dual-feed pre-wired

TPA-type Fuse and Alarm Panel, two vertical fiber ducts, and two 2.38-inch vertical extenders and

extender bases. The Four-Shelf Bay Assembly also provides a pre-installed, four-shelf configuration that

includes four ONS 15454 shelf assemblies with configured backplane interface connectors (BICs).

This guide describes how to unpack and install the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay

Assembly. Because it is a complete system, installation simply requires you to remove the unit from the

shipping pallet, move the unit into place, secure it, supply power and ground attachment.

This guide includes the following sections:

•Safety Recommendations

•Recommended Materials

•Unpacking Instructions

•Installation Instructions

–

Install the Four-Shelf and Zero-Shelf Bay Assembly

–

Slab Floor Plan

–

Raised Floor Plan

–

Mounting a Single Shelf Assembly

–

Mounting the Fuse and Alarm Panel

•Cabling Illustrations

•Fuse and Alarm Panel Wiring

•Install the Power and Ground

•Optional Kits

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Safety Recommendations

The following guidelines will help to ensure your safety and protect the equipment. This list does not

include every potentially hazardous situation.

•Never attempt to lift an object that might be too heavy for you to lift by yourself.

•Always disconnect the power source and unplug all power cables before installing or removing the

Bay Assembly.

•Carefully examine your work area for possible hazards such as moist floors, ungrounded power

extension cables, and missing power grounds.

•When using equipment such as a safety hand truck, pallet jack, or forklift to move the Bay Assembly

to another location, use only moving equipment that is capable of preventing the Bay Assembly from

tipping.

•Do not wear loose clothing, jewelry (including rings and chains), or other items that could get caught

in the Bay Assembly.

•Do not work alone if potentially hazardous conditions exist.

Recommended Materials

Because most of the installation is complete when you receive the system, the Bay Assembly requires

little installation material. The most significant tasks are removing the packaging from the Bay

Assembly and removing the Bay Assembly from the shipping pallet. Because the actual installation of

the Bay Assembly in each facility is done according to local site practice, your material needs may vary.

Cisco recommends that you have the following items on hand for installation:

•A pallet jack to move the packaged Bay Assembly to the unpacking/staging area

•A pair of scissors to cut the plastic banding on the shipping container

•A safety hand truck with retractable safety leg wheels and a safety strap

•Utility blankets or their equivalent to protect the Bay Assembly while on the hand truck

•Phillips screw driver or cordless drill with Phillips bit

•3/4 in. (19 mm) socket or box-end wrench for the earthquake floor bolts

•Four optional kits listed in Table 2 on page 33 that can be ordered separately

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Recommended Materials

Figure 1 Four-Shelf Bay Assembly

Note An AC outlet is provided on the front of the base if 110VAC powering is needed. Wiring for AC power

must be performed by an electrician.

Caution The AC outlet at the base of the shelf should be protected by a 20A breaker maximum.

63112

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Recommended Materials

Figure 2 Rack assembly

67462

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Unpacking Instructions

The ONS 15454 Four-Shelf and Zero-Self Bay Assembly ships in a corrugated container that covers the

unit on its shipping pallet. After removing the corrugated container, you must remove the bolts that hold

the rack to the pallet before moving the unit to the desired location. Figure 3 shows the Four-Shelf Bay

Assembly on a shipping pallet.

Caution Cisco recommends that a minimum of three people move the Bay Assembly.

Step 1 Use a pallet jack or forklift to place the shipping container as close to the installation location as

possible.

Step 2 Cut the plastic banding off of the cardboard shipping container.

Step 3 Remove the cap from the corrugated container.

Step 4 Pull the side panels away from the shipping pallet and set it aside.

Step 5 Remove the kick plate from the bottom front of the rack:

a. Remove the two screws that fasten the kick plate to the rack.

b. Pull the kick plate away.

Step 6 Remove the four bolts that hold the rack to the pallet (rack base bolts).

Step 7 Remove the extender pieces from the packaging on the rack and set aside until rack is installed.

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Unpacking Instructions

Figure 3 Four-Shelf Bay Assembly on shipping pallet

61841

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Installation Instructions

The emphasis in the following installation instructions is to remove the Bay Assembly from its shipping

pallet and position it in your facility. Perform actual installation and individual node provisioning

according to local site practice.

Install the Four-Shelf and Zero-Shelf Bay Assembly

Step 1 Line the hand truck with a utility blanket or an equivalent type of protection.

Step 2 Position the safety hand truck so that it faces the front (door side) of the Bay Assembly.

Step 3 With one person on each side of the Bay Assembly and one manning the hand truck, position the blade

of the hand truck under the edge of the rack.

Step 4 Secure the safety strap snugly around the Bay Assembly.

Do not cinch the strap too tightly. Cinching the strap too tightly can result in component damage.

Step 5 Extend the outrigger wheels from the hand truck.

Step 6 With one person on each side of the Bay Assembly, gently tilt the Bay Assembly until the outrigger

wheels on the safety hand truck are firmly on the floor.

Step 7 Move the Bay Assembly to the installation site and unload it from the safety hand truck.

To avoid injury, make sure that a sufficient number of people are present.

Step 8 Install the Bay Assembly according to local site practice.

For more information about installing or configuring individual Cisco ONS 15454s, refer to

Cisco ONS 15454 user documentation.

Step 9 After the rack is installed attach the extender bases and vertical extenders to both sides of the rack.

a. Attach the two extender bases to each side of the rack using the hardware supplied with the extender

bases.

b. Attach the two vertical extenders to each side of the rack using the hardware supplied with the

vertical extenders.

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Installation Instructions

Slab Floor Plan

Figure 4 Slab floor section for local

Figure 5 Slab base fiber routing

Rack Cutout

Power

(30.69)

61256

32X DS1 or DS3 Cables 32X DS1 or DS3 Cables

A side DC feed, 2x #2 AWG,

wrapped at floor opening.

(can require a larger gauge

wire depending on distance)

Rack ground

feed wire, #4 AWG

Fiber

openings

Fiber

openings

Rack ground

feed wire, #4 AWG

Guard rail

cover

B side DC feed, 2x #2 AWG,

wrapped at floor opening.

(can require a larger gauge

wire depending on distance)

63666

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Installation Instructions

Raised Floor Plan

Level Equipment

The raised floor is laser-leveled at the time of the floor installation, so no leveling blocks or shims should

be necessary to level the frames. This is especially important in seismic zones 2B and higher, because

leveling blocks will cause a rocking motion of the frames during an earthquake.

Cut and Drill Removable Floor Tile

Step 1 Mark the removable floor tile for the cable access to the rack using one of the following methods: the

floor cutout template included in the accessory kit (700-14208-XX) that ships with the zero-shelf bay

assembly, the diagrams in Figure 6, a floor plan drawing, or place the frame in the proper footprint and

mark the tile from the base of the frame or cabinet.

Step 2 Mark the tile for the frame anchoring holes.

Step 3 Remove the tile.

Step 4 Cut cable access holes.

Step 5 Drill the anchoring holes through the tile in an area away from the equipment to ensure the equipment

area is not contaminated with metal shavings or debris.

Note If the floor plan identifies a future frame on the same tile as the one you are adding a frame to,

you must drill and cut the tile for the future frame at this time because you cannot remove the

tile later.

Note It will be necessary to use alternate anchoring holes in the event the primary holes are obstructed

by the stringers that support the removable tile.

Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly

78-13271-05

Installation Instructions

Figure 6 Raised floor cutout for CORE and local

Framework Anchoring

To anchor framework to a raised floor, you must know in what earthquake zone the equipment is being

installed. Zones 0–2A have the frames bolted to the raised floor through a u-channel across the bottom

of the floor tile and stringers. Zones 2B–4 have 1/2-inch threaded rods extending through the raised floor

and connected to seismic anchors with coupling nuts. In all zones, standard hold-down parts are used on

top of the floor with threaded rods of varying lengths. Anchors and hold-down material must be

engineered for proper seismic zone.

Seismic Zones 0–2A

To fasten network and unequal flange duct framework to a raised floor:

Step 1 Place a 1 5/8 x 1 5/8 u-channel (with continuous slot down) under the stringers and use clips to cover

the free ends of the u-channel where the threaded rod goes through to prevent it from spreading when

compressed.

In the base of the frame, use the hold-down plate engineered for that frame, threaded rod, nut, washer,

insulating bushing, and hold-down washer.

On the bottom of the u-channel, use the clip, washer, lockwasher, and nut.

Note The u-channel should not extend more than four inches past the edge of the stringers or it will block

access under the floor.

61254
