Install Cisco NCS 1004 Modules

This chapter contains procedures to install the modules of Cisco NCS 1004.

All the modular slots in the NCS 1004 chassis should always be populated with respective modules (line-cards,

controller, PSU & fan units). Empty line card slots to be populated with filler modules, which are shipped

with the chassis. The replacement or upgrade of the modules (Online Insertion or Removal, OIR) to be

performed only when the ambient temperature is below 30-degree C. The OIR of modules should be completed

within five minutes to prevent overheating of the components.

Caution

•Supported Controller Cards, on page 2

•About Line Cards, on page 3

•Install Power Supply, on page 9

•Install Fan Unit, on page 14

•Attach Fiber Management Bracket, on page 15

•Adjust Fiber Management Bracket of the 1.2T, 1.2TL, 2-QDD-C, and QXP-K9 Line Cards, on page 16

•Adjust Fiber Management Bracket of the OTN-XP Line Card, on page 17

•Install Pluggables, on page 18

•Air Filter, on page 23

Install Cisco NCS 1004 Modules

Supported Controller Cards

Table 1: Feature History

DescriptionRelease InformationFeature Name

NCS 1004 supports the NCS1K4-CNTLR-B-K9

controller card. The card supports a default of 9600

baud rate on the RS232 console port and runs on

BIOS version 5.10.

Cisco IOS XR Release

7.5.1

NCS1K4-CNTLR-B-K9

Controller Card

The Cisco NCS 1004 supports the following controller cards:

•NCS1K4-CNTLR-K9

The NCS1K4-CNTLR-K9 controller card supports a default of 115200 baud rate on the RS232 console

port and runs on BIOS version 4.20. The controller card has two USB 3.0, two 10/100/1000 Ethernet,

one RS232 console and one SFP ports. The SFP port of the controler card supports 1GE payload.

•NCS1K4-CNTLR-B-K9

The NCS1K4-CNTLR-B-K9 controller card supports a default of 9600 baud rate on the RS232 console

port and runs on BIOS version 5.10. The controller card has two USB 3.0, two 10/100/1000 Ethernet,

one RS232 console and one SFP ports. The SFP port of the controler card supports 1GE payload.

Install Controller

This task has information about installing the controller into the chassis.

Step 1 Orient the controller correctly before inserting. Check for the This Side Up label.

Step 2 Supporting the controller at the bottom with one of your hands, slide the controller into the slot, using the handle.

Install Cisco NCS 1004 Modules

Supported Controller Cards

Figure 1: Installing the Controller Unit

Step 3 Using a T15 Torx screwdriver, tighten the two M3 T15 torx screws to a torque value of 0.65 N-m.

About Line Cards

The Cisco NCS 1004 supports the following line cards:

• 1.2T DWDM Line Card

• 1.2TL DWDM Line Card

• 2-QDD-C DWDM Line Card

• OTN-XP DWDM Line Card

• NCS1K4-QXP-K9 Line Card

1.2T Line Card

1.2Tbps DWDM line card can provide up to 12 OTU4 or three 400G client ports. For more details of the 1.2T

line card, see the Cisco NCS 1004 datasheet.

Install Cisco NCS 1004 Modules

About Line Cards

The physical characteristics of the 1.2T line card are:

• Height—40.4 mm

• Breadth—191.9 mm

• Depth—277 mm without the fiber management bracket; 297.97 mm with the fiber management bracket

• Weight—3.2 kg

For the LED details of the line card, see the Line Card LEDs section.

1.2TL Line Card

1.2TL DWDM line card can provide up to 8 QSFP-28 based client ports and 2 trunk ports. For more details

of the 1.2TL line card, see the Cisco NCS 1004 datasheet.

The physical characteristics of the 1.2TL line card are same as that of the 1.2T line card. For the LED details

of the line card, see the Line Card LEDs section.

2-QDD-C Line Card

Table 2: Feature History

DescriptionRelease InformationFeature Name

NCS 1004 supports the

NCS1K4-2-QDD-C-K9 C-Band

line card. The card has eight client

ports (QSFP28 and QSFP-DD) and

two DWDM dual sub-channel

module trunk ports. Each trunk port

is capable of 200, 300, and 400

Gbps line rate.

Cisco IOS XR Release 7.3.1NCS1K4-2-QDD-C-K9 C-Band

Line Card

2-QDD-C DWDM line card can provide up to eight QSFP client ports, six of which can support QSFP-28

based client ports and remaining two can support QSFP-28, QSFP-DD, QSFP-ZR, and QSFP-ZR+ client

ports. For more details of the 2-QDD-C line card, see the Cisco NCS 1004 datasheet.

The eight client ports are divided into two sets of four slots each. The following two configurations are

supported:

• A maximum of eight QSFP-28, four for each set, configured either as 100GE or 100G OTL4.4.

• A maximum of two QSFP-DD/ZR/ZR+, configured as 400GE.

The physical characteristics of the 2-QDD-C line card are:

• Height—40.4 mm

• Breadth—191.9 mm

• Depth—277 mm without the fiber management bracket; 297.97 mm with the fiber management bracket

• Weight—3.2 kg

Install Cisco NCS 1004 Modules

1.2TL Line Card

For the LED details of the line card, see the Line Card LEDs section.

OTN-XP Line Card

The OTN-XP line card supports up to 1.6Tbps of OTN aggregation switching functionality to optimize the

available bandwidth. A single line card supports 8x100GE muxponder or 2x400 GE transponder applications.

The OTN-XP line card contains:

• Eight QSFP 28 ports

• Four QSFP-DD ports

• Two CFP2 ports

For LED details of the card, see LEDs of OTN-XP Line Card.

The OTN-XP line card supports 400GE/OTUC4, 100GE/OTU4, 10GE/OTU2/OTU2e, 16G FC, 32G FC

client rates.

The supported operating modes are:

• 2x Muxponder

• 2x Transponder

• Single-card 1.2T OTN XPonder

• Dual-card 1.6T OTN XPonder

The physical dimensions of the OTN-XP line card are:

• Height—40.4 mm

• Breadth—191.9 mm

• Depth—282 mm without fiber management bracket; 366.7 mm with fiber management bracket

• Weight—2.6 kg

When the data path device temperature of the OTN-XP card exceeds the critical threshold level of 108° Celsius,

a sensor alarm is raised and the data path is shut down. This impacts traffic. However, the card is still

operational.

Note

Install Cisco NCS 1004 Modules

OTN-XP Line Card

QXP-K9 Line Card

Table 3: Feature History

DescriptionRelease InformationFeature Name

NCS1K4-QXP-K9 line card

delivers low cost 100G and 400G

DWDM transmission with ZR+

optics on a router. This line card

can be used in both traditional

Optical Networking solution and in

Routed Optical Networking

solution. This line card has 16

pluggable ports with eight

QSFP-DD client ports and eight

QSFP-DD trunk ports.

For more information about the

NCS1K4-QXP-K9 card, see the

datasheet.

NCS1K4-QXP-K9 card supports

the following key features:

• Client rates: 400GE,

4x100GE, and 100GE

Ethernet

•Modulation formats: 16 QAM

for 400GE Txp/4x100GE Mxp

and QPSK for 100GE Txp

• Smart licensing: The license

calculation is based on the

number of trunk slices

provisioned.

For more information about the key

features, see QXP Card and smart

licensing.

Cisco IOS XR Release 7.7.1NCS1K4-QXP-K9 Line Card

The QXP-K9 line card provides up to 16 QSFP-DD ports (eight QSFP-DD client ports and eight QSFP-DD

trunk ports). The card supports 400G ETH, 4x100GE ETH, and 100G ETH without FEC client rates.

The supported operating modes are:

• 400G-TXP

• 4*100G MXP

• 100G TXP [without FEC]

The physical dimensions of the QXP-K9 line card are:

• Height—40.4 mm

Install Cisco NCS 1004 Modules

QXP-K9 Line Card

• Breadth—191.9 mm

• Depth—277 mm without the fiber management bracket; 394.7 mm with the fiber management bracket

• Weight—2.5 kg

For LED details of the line card card, see LEDs of QXP-K9 Line Card. For more details of the QXP-K9 line

card, see the data sheet.

Install Line Card

This task has details about installing a line card in to the NCS 1004 chassis. The chassis is shipped with filler

cards and/or line cards. The Cisco NCS 1004 chassis supports a maximum of four line cards.

Before you begin

It is mandatory to attach the fiber management brackets to the filler cards and line cards before installing the

chassis onto a rack. For a detailed procedure, see the Attach Fiber Management Bracket section.

The following procedure is not required if the chassis is shipped with preinstalled line cards.

Note

Step 1 Unscrew the Torx screws of the filler card using a T15 Torx screwdriver.

Step 2 Holding the fiber management bracket of the filler card with one hand and supporting it with the other, remove the filler

card from the chassis.

Step 3 Attach the fiber management bracket to the line card that needs to be installed. Follow the procedure as mentioned at the

beginning of the section.

Step 4 Orient the line card. Check for the This Side Up label.

Step 5 Use both the hands while inserting a line card. Use one hand to hold the line card using the fiber management bracket

and the other hand along the base of the card to guide it into the slot.

Install Cisco NCS 1004 Modules

Install Line Card

Figure 2: Installing the OTN-XP Line Card

Install Cisco NCS 1004 Modules

Install Line Card

Figure 3: Installing the 1.2T, 1.2TL, 2-QDD-C, and QXP-K9 Line Cards

Support the line card with your hand at the bottom, while installing (or removing) a line card.1

Use the fiber management bracket for holding the line card.2

Use the fiber management brackets only for pulling out while removing or pushing in the card while installing

line cards or filler cards. Do not use the fiber management brackets to carry the cards. Always support the line

card (or filler card) at the bottom with your hand.

Caution

Step 6 Slide the line card completely inside, into the card guide.

Step 7 Using the Torx screwdriver, tighten the two M3, T15 Torx screws of the line card, to a torque value of 0.65 N-m.

Install Power Supply

This task has information about installing the PSUs into the NCS 1004 chassis.

Step 1 Orient the PSU correctly before inserting. Check for the This Side Up label.

Step 2 Using the handle, slide the PSU into the slot (support the PSU at the bottom with your hand) and push it in until you hear

aclick sound; direction of insertion is shown in the following figure. The click sound indicates that the unit has been

latched (the locking latch needs to pressed and released only for removing the PSU).

Install Cisco NCS 1004 Modules

Install Power Supply

Figure 4: Installing a PSU

Connect DC Power to NCS 1004

NCS 1004 relies on the protective devices in the building installation to protect against short circuit, overcurrent,

and ground faults. Ensure that the protective devices comply with local and national electrical codes.

Caution

Figure 5: Rating Label for DC Power

Step 1 Verify that the correct fuse panel is installed in the top mounting space.

Step 2 Measure and cut the cables as needed to reach NCS 1004 from the fuse panel.

Install Cisco NCS 1004 Modules

Connect DC Power to NCS 1004
