Cisco NCS 4016 Mode d’emploi

Unpacking the Chassis

This chapter describes how to unpack the Cisco NCS 4016 chassis.

Use the complete Cisco Systems packaging for shipment of product or components. Failure to properly use

Cisco packaging may result in damage or loss of the product.

Caution

•Unpacking the Chassis, on page 1

Unpacking the Chassis

The chassis is shipped on a pallet by itself and is enclosed in a corrugated box, held in place by plastic bands.

Prerequisites

Before performing this task, be sure to have sufficient room around the chassis pallet for unpacking.

Required Tools and Equipment

• Cutters to cut strapping (plastic bands)

Steps

To unpack the Cisco NCS 4016 chassis, follow these steps:

SUMMARY STEPS

1. Carefully move the pallet containing the Cisco NCS 4016 chassis to the staging area where you plan on

unpacking it.

2. Cut the plastic bands holding the chassis shipping box in place.

3. Remove the six plastic clips on the outer sleeve using a flat head screw driver.

4. Remove the accessories, corrugated accessory tray and the top foam cap.

5. Leave the chassis on the pallet until you are ready to move and install the chassis in a rack.

DETAILED STEPS

Step 1 Carefully move the pallet containing the Cisco NCS 4016 chassis to the staging area where you plan on unpacking it.

Unpacking the Chassis

The Cisco NCS 4016 chassis with pallet should be handled carefully to eliminate the risk of tipping over the

package.

Caution

Step 2 Cut the plastic bands holding the chassis shipping box in place.

Figure 1: Chassis Shipping Box

Step 3 Remove the six plastic clips on the outer sleeve using a flat head screw driver.

Unpacking the Chassis

Figure 2: Chassis in Original Packaging

Unpacking the Chassis

Step 4 Remove the accessories, corrugated accessory tray and the top foam cap.

Step 5 Leave the chassis on the pallet until you are ready to move and install the chassis in a rack.

Be sure to save the packaging in case you need to return any of the components.

Tip

What to do next

What to Do Next

After performing this task, go to the Removing the Chassis from the Pallet, on page 4.

Removing the Chassis from the Pallet

This procedure describes how to remove the support brackets that secure the chassis to the pallet.

Figure 3: Hardware Locations for Support Brackets

8 bolts with washers (4 on each side)228 M4 screws (14 on each side)1

Required Tools and Equipment

• Number 1 and number 2 Phillips screwdrivers

• 3/8-in. socket wrench or 3/8-in. drive ratchet wrench

Steps

To remove the chassis from the pallet and then transfer the chassis to a moving device, follow these steps:

Unpacking the Chassis

Removing the Chassis from the Pallet

SUMMARY STEPS

1. Using the Phillips #2 screwdriver, remove the fourteen M4 screws that connect the right support bracket

to the chassis.

2. Using the 3/8-in. socket wrench, remove the 4 hex cap bolts that connect the right support bracket to the

pallet.

3. Set the support bracket aside carefully.

4. Repeat Step 1 through Step 3 for the left support bracket.

DETAILED STEPS

Step 1 Using the Phillips #2 screwdriver, remove the fourteen M4 screws that connect the right support bracket to the chassis.

Unpacking the Chassis

Removing the Chassis from the Pallet

Figure 4: Removing the Chassis Support Brackets

Step 2 Using the 3/8-in. socket wrench, remove the 4 hex cap bolts that connect the right support bracket to the pallet.

Unpacking the Chassis

Removing the Chassis from the Pallet

Step 3 Set the support bracket aside carefully.

Step 4 Repeat Step 1 through Step 3 for the left support bracket.

What to do next

What to Do Next

After you have removed the support brackets that secure the chassis to the pallet, go to the Transferring the

Chassis to a Mechanical Lifting Device.

Unpacking the Chassis

Removing the Chassis from the Pallet

Unpacking the Chassis

Removing the Chassis from the Pallet
