Cisco USC 5030 Installation Guide

Cisco USC 5030 Installation Guide 2

About Your USC 5030 2

Before You Begin 2

Connect Your Cisco USC 5030 2

Verifying Your Installation 5

Safety Instructions 7

Revised: September 2, 2014,

Cisco USC 5030 Installation Guide

About Your USC 5030

The Cisco USC 5030 chassis is uniquely designed to hold either one or two Cisco USC enterprise licensed small cell modules.

Currently installation of one small cell module is supported. For a 3G enterprise solution, it is populated with the Cisco USC 5310

(Band 1 or Band 2/5).

Before You Begin

Power Considerations

Power options for the USC 5030 include:

•IEEE 802.3at POE+ 25.5 W delivered from the upstream Ethernet switch

•Cisco 3600 Series Power Injector (AIR-PWRINJ4=)

•Cisco 3600 Series local power supply (AIR-PWR-B=)

Installation Considerations

Install your USC 5030:

•in a central location, in an area where people are most likely to make calls

•away from windows, to avoid the signal leaking outside or external signals leaking in

•in an open area with airflow; not in a closed cabinet which reduces the signal strength

If you have thick internal walls, or metal, fire or rotating doors, plan to place units at either side of the obstruction at a distance shorter

than 49 feet (15 m). Install a unit across from a corner to provide coverage on both sides of the corner.

Connect Your Cisco USC 5030

Currently your Cisco USC 5030 can support the installation of up to one small cell module only (for

example, the Cisco USC 5310).

Note

Power must be disconnected before installing or removing a small cell module from the USC 5030 chassis.Note

Follow these instructions to connect your USC 5030 for use:

Procedure

Step 1 Install a USC 5310 small cell module into the USC 5030:

a) Align the module connector with the port connector on the back of the USC 5030 and click the module into place.

b) Screw down the thumb screws on the module.

Figure 1: Small Cell Installation into USC 5030

10/100 Base-T Ethernet port4Small cell module1

Power port for DC power source5Openings for module antennas2

Port connector3

If the screws are not tightened, the module will not be recognized and may not operate correctly. Make sure not

to over-tighten the screws; they should be only hand-tightened.

Note

Step 2 Mount the USC 5030, with the small cell plug-in modules installed, using the universal bracket (AIR-AP-BRACKET-2).

The USC 5030 can be mounted in several configurations, including on a suspended ceiling, on a hard ceiling or wall, on

an electrical or network box, and above a suspended ceiling.

IMPORTANT SAFETY INFORMATION!

Before use, please ensure that you read the following safety information carefully!

Refer to the USC 5030 Mounting Guide at this URL: http://www.cisco.com/c/en/us/td/docs/wireless/access_point/small_cell/

usc5030/mount/usc5030mount.html.

Step 3 Connect one end of the network cable to the USC 5030 Ethernet port and the other end to your broadband router or cable

modem.

Step 4 Connect the power adapter to the power port and to an AC power source.

Step 5 When the USC 5030 boots, it automatically recognizes the installed modules. No software configuration is required.

Verifying Your Installation

Verify Your Cisco USC 5030 Installation

The LED display is located on the top of your Cisco USC 5030 and indicates whether modules are installed and operational or not.

Figure 2: Cisco USC 5030 LED

Status LED1

Table 1: USC 5030 Module Status LED

DescriptionLED Color

No powerOff

Unit initialization in progressGreen blinking

Initialization complete and module detected, valid and drawing powerGreen

Ethernet link down or not connectedAmber

DescriptionLED Color

Module slot not detectedRed

Verify Your Small Cell Module Installation

After the USC 5310 module is installed in the USC 5030 chassis and powered up, it takes approximately ten minutes for the module

to initialize, download any necessary software and configuration information, configure the radio frequency (RF) parameters, and

come into service.

Take note of the initialization sequence by noting the color and activity of the LEDs on either side of the module. The module is

ready to use when the LEDs change to solid green.

Figure 3: Cisco USC 5310 Module

Reset button1

LED—the same LED indication displays on both sides of the module

Table 2: Cisco USC 5310 LED Indications

Small Cell State / ActionLED Indication

Unknown State or Off—Ensure power supply is connected and turned on

Off

Initialization—Wait for action to complete

Fast Blinking Green

Temporarily out of service—Wait for action to complete

Factory reset—Wait for action to complete

Small Cell State / ActionLED Indication

In service, no calls or data sessionsGreen

In service, calls or data sessions are activeSlow Blinking Green

In service, experiencing congestion and cannot accept more calls

No physical LAN connection—Verify connection with residential gateway

Red blink 1 time in 4 seconds

No connection with router—Verify residential gateway is operational

No Internet connection—Verify residential gateway is connected to Internet

Red blink 2 times in 4

seconds

RF issue, local interference or poor QoS—Verify that phones are not too close to unit

Red blink 3 times in 4

seconds

Over-temperature—Verify location of unit and that there is good air flow

Red blink 4 times in 4

seconds

Cannot create secure connection—Contact operator

Red

Internal fault—Contact operator

RF issue, cannot select an RF profile—Verify whether another small cell is located in close

proximity and if so, relocate the small cell

Provisioning failure—Contact operator

Safety Instructions

Translated versions of the following safety warnings are provided in Cisco USC 5030 Regulatory Compliance and Safety Information,

located on Cisco.com.

Statement 1071—Warning DefinitionWarning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work

on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard

practices for preventing accidents. Use the statement number provided at the end of each warning to locate

its translation in the translated safety warnings that accompanied this device.

SAVE THESE INSTRUCTIONS

Warning

IMPORTANTES INFORMATIONS DE SÉCURITÉ

Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant entraîner

des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez conscient des

dangers liés aux circuits électriques et familiarisez-vous avec les procédures couramment utilisées pour

éviter les accidents. Pour prendre connaissance des traductions des avertissements figurant dans les consignes

de sécurité traduites qui accompagnent cet appareil, référez-vous au numéro de l'instruction situé à la fin

de chaque avertissement.

CONSERVEZ CES INFORMATIONS

Attention

Statement 1004—Installation InstructionsWarning

Read the installation instructions before connecting the system to the power source.Warning

Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation.Attention

Statement 1074—Comply with Local and National Electrical CodesWarning

Installation of the equipment must comply with local and national electrical codes.Warning

L'équipement doit être installé conformément aux normes électriques nationales et locales.Attention

Statement 1005—Circuit BreakerWarning

This product relies on the buildings installation for short-circuit (overcurrent) protection. Ensure that the

protective device is rated not greater than: 10-15A, 100-240VAC

Warning

Pour ce qui est de la protection contre les courts-circuits (surtension), ce produit dépend de l'installation

électrique du local. Vérifiez que le courant nominal du dispositif de protection n'est pas supérieur à: 10-15A,

100-240VAC

Attention

Statement 332—Antenna Installation WarningWarning

In order to comply with FCC radio frequency (RF) exposure limits, antennas should be located at a minimum

of 7.9 inches (20 cm) or more from the body of all persons.

Warning

Pour se conformer aux limites d'exposition à la fréquence radio préconisées par la FCC (Federal

Communications Commission), les antennes doivent se situer à un minimum de 20 cm de toute personne.

Attention

Statement 12—Power Supply Disconnection WarningWarning

Before working on a chassis or working near power supplies, unplug the power cord on AC units; disconnect

the power at the circuit breaker on DC units.

Warning

Avant de travailler sur un châssis ou à proximité d'une alimentation électrique, débrancher le cordon

d'alimentation des unités en courant alternatif ; couper l'alimentation des unités en courant continu au

niveau du disjoncteur.

Attention

Caution The fasteners you use to mount the unit on a ceiling must be capable of maintaining a minimum pullout

force of 20 lbs (9 kg) and must use all 4 indented holes on the mounting bracket.

Caution

Les attaches que vous utilisez pour installer le châssis au plafond doivent être capables de résister à une

force d'arrachement minimale de 9 kg (20 lb) et doivent utiliser les quatre orifices de montage prévus sur

le support de montage.

Mise en garde

Caution This product and all interconnected equipment must be installed indoors within the same building, including

the associated LAN connections as defined by Environment A of the IEEE 802.af Standard.

Caution

Conformément à la définition de l'environnement A de la norme IEEE 802.af, ce produit et tout l'équipement

interconnecté, y compris les connexions LAN associées, doivent être installés à l'intérieur d'un même

bâtiment.

Mise en garde

The USC 5030 is suitable for operation in a building's environmental air space, such as above suspended

ceilings, in accordance with Section 300-22(C) of the National Electrical Code (NEC) and Sections 2-128,

12-010(3) and 12-100 of the Canadian Electrical Code, Part 1, C22.1.

Peut être utilisé dans des gaines transportant de l'air traité, conformément à la section 300-22(C) du National

Electrical Code et aux articles 2l-128, 12-010(3) et 12-100 du Code Canadien de l'électricité, Premiére

partie, CSA C22.1.

Note

Use only with listed ITE equipment.Note

If you require assistance installing or operating your small cell, contact customer support.

For warranty information, refer to: http://www.cisco-servicefinder.com/WarrantyFinder.aspx
