EVQ71

Extractor

Installation, use and maintenance

Cod:0103085718

Contents:

3Important

4 Dimension drawing

5Important information

6 Using your extractor

7Care and maintenance

9 Troubleshooting

10 - 13 Installation

10 Installation - height

11 Installation - preparation and ducting

12 Installation - mounting theextractor

14 Mains electrical connection

17 Energy eciency information

Important

TheCDA Group Ltdcannot beheld responsible for injuries or losses

caused by incorrect use or installation of this product.Please note

that CDA reservetheright toinvalidatetheguarantee supplied with

this product following incorrect installation or misuse of theappliance

or use in acommercial environment.

This appliance is not designed tobeused by people (including

children) with reduced physical, sensorial or mental capacity,or

wholack experience or knowledgeabout it,unless they havehad

supervision or instructions on how touse theappliance by someone

whois responsible for their safety.

Under no circumstances should any external covers beremoved for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter thedetails on theappliance rating platebelow for

reference, toassist CDA Customer Care in theevent of afault with

your appliance and toregister your appliance for guarantee purposes.

Appliance Model

Serial Number

EU Declarations of Conformity:

This appliance has been manufactured tothestrictest standards and

complies with all applicable legislation, including Gas safety,Electrical

safety (LVD) and Electromagnetic interference compatibility (EMC).

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.

At theend of itsworking life, theproduct must betaken toaspecial

local authority wastecollection centre or toadealer providing

appliance recycling services.

Disposing of ahousehold appliance separately avoids possible

negativeconsequences for theenvironment and health.It also

enables theconstituent materials toberecovered, saving both energy

and resources. Asareminder of theneed todispose of household

appliances separately,theproduct is marked with acrossed-out

wheeled dustbin.

Fig.1Dimensions

Please note:

•Under no circumstances should theextractor be

connected toany gas ventilation system, ﬂue system or

hot air ducting system.

•Donot vent theextractor intoan attic or loft space.

•Only house theextractor in rooms with adequate

ventilation. Remember that theextractor is powerful and

whatever air is extracted needs tobereplaced.

•Donot tile theextractor in. It should beremovable for

service or maintenance.

•Donot use silicone sealant tosecure thehood tothewall.

•You must beable toisolatetheextractor from themains

electrical supply after installation.

•This appliance has been designed tobeused in aroom

with avolume of less than 36m³.

•Steam cleaners must not beused when cleaning this

appliance.

•Theperformance of your extractor will vary depending

on anumber of factors. These include: typeof extraction,

length of ducting,room volume, ventilation available and

cleanliness of theﬁlters.

Using your extractor

For best performance, you should switch on theextractor 15 minutes

before starting tocook and leaveit torun for approximately 15 minutes

after theend of cooking (you can use thetimer function for thelatter).

Control Panel

A- Speed 3key

B- Speed 2 key

C- Speed 1key

D- Lamp key

E- Power key

To switch the extractor on or change the speed

Touch any of thespeed keys(A,B or C).

To switch the extractor lights on and o

Touch thelamp key (D)

To switch the extractor o

Touch thepower key (E) twice.

To activate the timer function

Touch thepower key (E) once whilst theextractor is running on any

speed. This will set theextractor torun for approximately 15 minutes

before stopping automatically.

Fig.2

Care and maintenance

IMPORTANT: DO NOT PERFORM MAINTENANCE OR CLEANING

OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE

ELECTRICITY SUPPLY.

Cleaning

You should use anonabrasivecleaner. Any abrasivecleaner

(including Cif) will scratch thesurface and could erase thecontrol

panel markings.

You can clean your extractor eectively by simply using adilute

solution of water and mild detergent and drying toashine with aclean

cloth,for example amicro-ﬁbre cloth.

Cleaning the grease ﬁlter

Thegrease ﬁlter should bekept clean tominimise therisk of ﬁre.

At least once amonth you should removeand clean thegrease

ﬁlter with hot soapy water. You can also wash thegrease ﬁlter in a

dishwasher, ensuring that you place it in an upright position toprevent

damagefrom other items in thedishwasher.

Toremovethegrease ﬁlter,

push in thebutton on the

handle and then pull down on

theﬁlter at thefront as shown in

Fig.3. When you havereleased

it at thefront,then you can pull

theﬁlter out completely.

Fig.3

After rinsing and drying,reassemble thegrease ﬁlter tothehood by

reversing theremoval process.

Please note:

Cleaning thegrease ﬁlter in thedishwasher may lead to

discolouration. This is normal and does not constituteafault with the

appliance.

Changing the charcoal ﬁlter (re-circulating mode only)

Toensure best performance of your extractor, you should replace

thecharcoal ﬁlters every four tosix months, depending on use. The

charcoal ﬁlters are an optional accessory.These are available from

theCDA Sales team on 01949 862010 under code CHA33.

To attach the charcoal ﬁlters:

•Removethegrease ﬁlter as described on theprevious page.

•Aligntheslotson thecharcoal ﬁlter with thenotch on theside of the

motor. Place theﬁlter ontothemotor and turn clockwise slightly.The

ﬁlter should hold ﬁrmly in place. Repeat with theother side.

•Finally,replace thegrease ﬁlter.

Fig.4

Motor

Charcoal

Filter

LED lighting

Troubleshooting

Please note:

Your extractor is equipped witha motor protection device that will

happen duringcookingwhen most or all ofthe zones/burners are

beingused simultaneously, or ifyour extractor is installed incorrectly,

lower than the recommended height.

This is normal, and the extractor will workagain once the motor has

If your extractor is not working:

2. Checkthat the fuse in the spur has not blown.

3. Checkthat the control panel is clean and free from grease

Contact CDA Customer Care

A: Customer Care Department, The CDA GroupLtd, Harby Road,

Langar, Nottinghamshire, NG13 9HY

T: 01949 862 012F: 01949 862 003 E: customer[email protected]

W: www.cda.eu

These are not user-replaceable.In the event ofa problem withthe

lightingplease contact CDA Customer Care for assistance.Contact

details are on the rear cover ofthis manual.

Installation - height

When theextractor is tobeinstalled

aboveaCDA electric hob,theminimum

distance between thehob and extractor

must exceed 600mm.

When theextractor is tobeinstalled

aboveaCDA gas hob,theminimum

distance between thehob and extractor

must exceed 700mm.

If theinstructions provided with your

gas hob statethat therequired distance

between thehob and extractor must

begreater than 700mm, then that is

thedistance that should beobserved; this is alegal requirement and

may lead toyour hob being disconnected from thegas supply and the

installation being reported under RIDDOR.

Note: Theheight should bemeasured from thetop of theburners to

thegrease ﬁlter.

•IN THE ABSENCE OF ANY INSTRUCTIONS SUPPLIED WITH

THE GAS HOB, THE MINIMUM DISTANCE BETWEEN THE HOB

AND EXTRACTOR MUST BE AT LEAST 760mm.

•The width of any hob must not be greater than the width of the

extractor installed above it.

•Always bear servicing in mind. The extractor should always be

easily accessible or removeable after installation.

Gas: 700mm minimum

Electric: 600mm minimum

240.6

120

Fig.5
