Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu

www.cda.eu

3S10BL &

3S10WH

Extractors

Installation, Use and Maintenance

Important

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance

or use in a commercial environment.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by someone

who is responsible for their safety.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity:

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Gas safety, Electrical

safety (LVD) and Electromagnetic Interference Compatibility (EMC).

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both energy

and resources. As a reminder of the need to dispose of household

appliances separately, the product is marked with a crossed-out

wheeled dustbin .

Please note:

•This appliance is designed to recirculate air only, under no

circumstances should it be connected to any ductwork or

external venting system.

•Do not use silicone sealant to secure the extractor to the ceiling.

•You must be able to isolate the extractor from the mains electrical

supply after installation.

•Steam cleaners must not be used when cleaning this appliance.

•The performance of your extractor will vary depending on a number

of factors, such as supply voltage and cleanliness of the ﬁlters.

Note:

For best performance, you should switch on the extractor 15 minutes

before starting to cook and leave it to run for approximately 15

minutes after the end of cooking.

Using Your Extractor

Remote Control

A - LED lights

B - “Plus” button

C - “Light” button

D - “Power” button

E - “Clock” button

F - “Minus” button

E D

Fig. 1

To switch the extractor on or o:

• Press the “Power” button “D” once. After switching on the motor

will automatically start at the lowest speed setting.

Setting the extractor speed when it is running:

The extractor may run at a choice of 4 speeds, indicated by the LED

lights on the remote control.

• To increase the speed press the “Plus” button “B”. The speed will

increase by one increment for each push of this button.

• To decrease the speed press the “Minus” button “F”. The speed

will decrease by one increment for each push of this button until it

reaches speed 2.

• To switch from a higher speed to the lowest one it is necessary to

press the “Power” button “D” twice (once to switch the motor o

then second time to restart it at the lowest speed).

To switch the light on or o:

• Press the “Light” button “C”.

The timer function:

The timer function sets the extractor to switch itself o after ten

minutes have passed. This is ideal when you leave the kitchen after

cooking as the extractor can be left to clear the air then switch o to

save power, without you disturbing your meal to switch it o.

• To set this function, press the “Timer” button “E”; the right hand

LED on the remote control will start to ﬂash slowly (once every ﬁve

seconds).

• To cancel this function, press either the “Plus” or “Minus” button “B”

or “F” on the remote control.

Care and Maintenance

IMPORTANT : DO NOT PERFORM

MAINTENANCE OR CLEANING OF

THE EXTRACTOR WITHOUT FIRST

SWITCHING OFF THE ELECTRICITY

SUPPLY.

Cleaning

You should use a nonabrasive cleaner.

Any abrasive cleaner (including Cif) will

scratch the surface.

You can clean your extractor eectively

by simply using a dilute solution of

water and mild detergent and drying to

a shine with a clean cloth, for example

the CDA E-Cloth.

Cleaning the grease ﬁlters

The grease ﬁlters should be kept clean to minimise the risk of ﬁre.

The grease ﬁlters may be removed then cleaned with hot soapy

water. You can also wash the grease ﬁlters in a dishwasher, ensuring

that you place them in an upright position to prevent damage from

other items in the dishwasher.

Please note:

Cleaning the grease ﬁlters in the dishwasher may lead to

discolouration. This is normal and does not constitute a fault with the

appliance.

Fig. 3

Fig. 2



ϭϭ

To remove the aluminium grease ﬁlters for cleaning

• While supporting the weight of the lower half of the globe, use the

special tool supplied with the appliance to unscrew the metal ring

that secures it (Fig. 2).

• Place the lower half of the globe, chrome lower cover and locking

ring aside safely.

• Slacken one of the retaining screws (“A” in Fig. 3) by a maximum of

one turn.

• Swing the retaining tab (“B” in Fig. 3) aside to release the carbon

ﬁlter and aluminium grease ﬁlter.

• Pull the carbon ﬁlter and aluminium grease ﬁlter downward from

their housing.

• Repeat this to remove the second set of carbon ﬁlter and aluminium

grease ﬁlter.

To re-ﬁt the aluminium grease ﬁlters after cleaning

• Slide one carbon ﬁlter and one aluminium grease ﬁlter back into

the housing on one side of the motor, ensuring that the aluminium

grease ﬁlter is located furthest from the motor itself.

• Swing the retaining tab (“B” in Fig. 3) into position to hold the ﬁlters

in place.

• Tighten the retaining screw (“A” in Fig. 3) to secure the retaining tab

in position.

• Fit the other carbon ﬁlter and aluminium grease ﬁlter in a similar way.

• Relocate the lower half of the globe and chrome lower cover to the

extractor body, then secure them using the locking ring, removed

earlier. Tighten this hand-tight using the special tool supplied with

the appliance.

Changing the charcoal ﬁlter

To ensure best performance of your extractor, you should replace the

charcoal ﬁlter every four to six months, depending on use.

To replace the charcoal ﬁlters:

• The charcoal ﬁlters are removed as part of the grease ﬁlter cleaning

process described on the previous page. Refer to this for charcoal

ﬁlter replacement.

IMPORTANT: Steam cleaners must not be used to clean this

appliance.

If your extractor is not working:

1. Check that the mains supply has not been switched o.

2. Check that the fuse in the spur has not blown.

3. There is a hidden on/o switch inside the body of the

globe. Ensure that this has not been accidentally switched

o during installation or maintenance. This switch is shown

as “C” in Fig. 3.

The LED and Neon Lamps

The LED lamps (3S10BL) and neon light tubes (3S10WH) are long-life

items that are not designed to be replaced by the user. In the unlikely

event of a lamp failure, contact CDA Customer Care for assistance.

Mains Electricity Connection

THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY

BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE

POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A

3A FUSE.

We recommend that the appliance is

connected by a qualiﬁed electrician,

who is a member of the N.I.C.E.I.C. and

who will comply with the I.E.T. and local

regulations.

The wires in the mains lead of this

appliance are coloured in accordance

with the following code:

Green & Yellow = Earth

Blue = Neutral

Brown = Live

As the colours of the wires in the mains lead for the appliance may

not correspond with the coloured markings identifying the terminals

connecting to the fused spur, proceed as follows:

DOUBLE POLE

SWITCHED

FUSED SPUR OUTLET

USE A 3 AMP FUSE

Fig. 4
