CAS SC Series Manuel utilisateur
SC Series
Precision Counting Scale
OWNER’S MANUAL
CONTENTS
PRECAUTIONS 4
PREFACE 6
NAMES AND FUNCTIONS 6
OPERATIONS 8
1. When You Know the Unit Weight of a Sample 8
2. When You Know the Quantity of the Samples 9
3. Storing Unit Weight to Memory 10
4. Counting with Stored Unit Weight 11
5. Add-up Samples 12
6. How to Set the Limit of Samples 13
7. How to Use Tare 14
8. Printer 15
SPECIFICATIONS 16
SPECIFICATIONS FOR CE MARKED PRODUCT 17
4
PRECAUTIONS
Do not subject the scale to sudden
temperature changes.
Place the scale on a flat and stable
surface.
Do not subject the platter to sudden
shocks. This scale must be installed in a dry
and liquid free environment.
Make sure that you plug your scale into the proper power outlet.
Plug into a power outlet 10 minutes before operations.
5
Keep the scale away from strong EMI noises may cause incorrect weight
readings.
If the scale is not properly
level, please adjust the 4 legs
at the bottom of the scale
(turn legs clockwise or
counterclockwise) so as to
center the bubble of the
leveling gauge inside the
indicated circle.
Leveling gauge
6
PREFACE
NAMES AND FUNCTIONS
Thank you for purchasing our CAS SC Series.
These series have been designed with CAS reliability, under rigid quality control
and with outstanding performance. Your specialty departments can enjoy these
high quality reliable CAS products.
We believe that your needs will be satisfied and you will have proper reliability.
This manual will help you with proper operation and care of the SC Series.
Please keep it handy for future reference.
OVERALL VIEW
PLATTER
DISPLAY
ADJUSTING
BOLT
LEVELING
GAUGE
KEYBOARD
KEYBOARD
ZERO TARE g/lb MODE SET PRINT
ENTRY CALL STORE TOTALM+
SAMPLE
1
6 7 8 9 0
2 3 4 5
C
UNIT WEIGHT COUNT
~
09
C
SET
ZERO
TARE
g/lb
MODE
PRINT
KEYS FUNCTIONS
Numeric keys used to enter numerical data.
Decimal key.
Clear key used to clear recorded unit weight or recorded quantity.
Used to set the Zero Point.
Used to clear Tare entries and enter Tare weight.
Toggle between metric and non-metric mode.
This key is used for change mode.
WEIGHING MODE COMPARATOR MODE UNIT WEIGHT STORE MODE
When you turn on the power, the default is WEIGHING mode.
Used to set mode to enter the data.
Toggle between auto print and manual print.
7
DISPLAYS
ZERO
TARE
CAPACITY
:
5x0.001kg, 10x0.002lb
COUNTING SCALE
ZERO
TARE
LACKED
SAMPLE
LACKED
U.W.
WEIGHT UNIT WEIGHT
COUNT
SC 05P
pcs
g
lb
KEY FUNCTIONS
8
OPERATIONS
1. When You Know the Unit Weight of a Sample
When you know the unit weight of a sample, you can count samples.
For example) unit weight - 1.25g
1 2 5
Place the samples on the platter. Enter the unit weight.
ENTRY
SAMPLE
CALL
STORE
M+
TOTAL
Used to enter the unit weight of a sample.
Used to enter quantity of samples.
Used to call the unit weight from memory.
Used to save each data in the unit weight mode.
(This key does not work in weighing mode)
Used to add-up samples.
Used to call total number of samples.
KEYS FUNCTIONS
LAMP DESCRIPTIONS
The symbol represents the lamps on the displays.
ZERO Lamp: If the ZERO lamp is on, it means that weight is zero.
TARE Lamp: If the TARE lamp is on, it means that tare is entered.
Lack of Sample: This lamp blink when samples are lacked.
Lack of U/W: This lamp blink when the unit weight is smaller than set
value.
9
ENTRY
C
5 0
SAMPLE
C
MODE SET
1 0
STORE
1 2 3 4 5
STORE
Press the ENTRY key, then you will see
the quantity of samples.
Remove the samples and press the C key.
NOTE: You have to enter the unit weight more than recommendation below.
(Refer to TABLE 1.)
TABLE 1.
MODEL SC-0.5P SC-10P SC-25P
LACK OF UNIT WEIGHT(g) Below 0.5g Below 1g Below 2.5g
LACK OF UNIT WEIGHT(lb) Below 0.001lb Below 0.0025lb Below 0.005lb
2. When You Know the Quantity of the Samples
When you know the quantity of the samples, you will know the unit weight of a
sample.
Make sure that ZERO lamp is on.
5 0
Place the samples on the platter. Enter the quantity of samples
(for example, 50 samples)
10
3. Storing Unit Weight to Memory
NOTE: You have to place more samples than “Lack of sample” weight to know
the exact unit weight of a sample(Refer to TABLE 2.)
TABLE 2.
WARNING SC-0.5P SC-10P SC-25P
LACK OF SAMPLE(g) 25g 50g 125g
LACK OF SAMPLE(lb) 0.05lb 0.125lb 0.25lb
SAMPLE
C
MODE SET
Press the MODE key twice. Press the SET key.
1 0
STORE
Enter address of a unit weight to store.
(Address : 10)
Press the STORE key.
SAMPLE
C
MODE SET
1 0
STORE
1 2 3 4 5
STORE
2 0
STORE
Press the SAMPLE key, then you will see the
unit weight of a sample on the unit weight
display.
Remove the samples and press the C key.
11
1 2 3 4 5
STORE
2
0
0
STORE
STORE
Enter a unit weight. (1.2345g) Press the STORE key.
2 0
STORE
Enter tare weight. (20g)
(If you don’t use tare, go to step 8.)
0
STORE
Press the STORE key.
Enter “0” or “1”.
“0” indicates g and “1” indicates lb.
Press the STORE key. To finish storing unit
weight, press the MODE key then the display
shows “End” and go to normal mode.
(To continue storing another unit weight, press
the SET key. Then you will go to step 2.)
4. Counting by Stored Unit Weight
1 0
CALL
Enter the address to call up a unit weight.
(Address : 10)
Press the CALL key.
