Wireless File Transmitter

WFT-E5

INSTRUCTION MANUAL

To comply with local radio wave regulations, Canon offers four region-specific versions of the

transmitter (WFT-E5A, E5B, E5C, and E5D) in various areas around the world (p.8). For

convenience, we refer to the product in this manual simply as “the transmitter,” without

reference to versions A, B, C, or D.

COPY

Thank you for purchasing a Canon product.

The Wireless File Transmitter WFT-E5 is an accessory for EOS 7D camera. It gives the camera

wireless and wired LAN functionality and adds a USB port, enabling the following operations.

It also includes a vertical-grip shutter button for convenience in vertical shooting.

Wireless and Wired LAN Functions

FTP Transfer

EOS Utility

WFT Server

Transfer images to an FTP server

Use a web browser to capture, view,

and download images remotely

Use EOS Utility to capture, view, and

download images remotely

Media Server

View images on a DLNA-compatible TV

or other devices

Linked Shooting

Wirelessly trigger shooting by slave

cameras linked to a master camera

COPY

Functions When Connected via USB

External Media

Record or backup images onto external media

Add the latitude, longitude, altitude, date and time, and

other shooting information to images

GPS

Connected by a USB cable Connected via Bluetooth

COPY

These instructions should be followed only after your wireless or wired LAN and FTP server

settings are complete. For details on configuring these settings, refer to the documentation

provided with the respective equipment.

Terms in brackets [ ] indicate button or icon names or other software elements. Brackets

also denote camera menu items.

Page numbers in parentheses indicate where you can find additional information.

Instructions on camera operations should be followed only after you have read the Camera

Instruction Manual and are familiar with operating the camera.

Sections of this manual labeled with the following symbols contain information of the

corresponding nature.

: Warnings to avoid potential problems are labeled with a caution symbol.

: Supplemental information is labeled with a note symbol.

Conventions Used in this Manual

Windows is a trademark or registered trademark of Microsoft Corporation in the United

States and other countries.

Macintosh is a registered trademark of Apple Corporation in the United States and other

countries.

Wi-Fi is a registered trademark of the Wi-Fi Alliance.

Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of the Wi-Fi

Alliance.

WPS as used on camera settings screens and in this manual signifies Wi-Fi Protected

Setup.

UPnP is a trademark of the UPnP Implementers Corporation.

Bluetooth and the Bluetooth logos are trademarks owned by Bluetooth SIG, Inc.

All other corporate and brand names in this manual are trademarks or registered

trademarks of their respective owners.

Using the transmitter for remote image transfer, capture, or viewing requires adequate knowledge of

configuring your wireless or wired LAN and FTP server.

Canon cannot provide support for configuring wireless or wired LANs or FTP servers.

Note that Canon cannot be held liable for any loss or damage to the transmitter from erroneous network

or FTP server settings. In addition, Canon cannot be held liable for any other loss or damage caused by

use of the transmitter.

COPY

Chapter List

Introduction 2

Basic Network Settings 19

Transferring Images to an FTP Server 33

Remote Capture Using EOS Utility 47

Remote Capture Using WFT Server 53

Using the Transmitter as a Media Server 65

Linked Shooting 69

Managing Settings Information 73

Using External Media 79

Using GPS Devices 91

Troubleshooting 99

Reference 117

COPY

Introduction

Conventions Used in this Manual ...................................................................................................... 4

Chapter List........................................................................................................................................ 5

Contents............................................................................................................................................. 6

Areas of Use and Restrictions ........................................................................................................... 8

Safety Warnings............................................................................................................................... 10

Nomenclature................................................................................................................................... 11

Attaching to the Camera .................................................................................................................. 13

Vertical Shooting Controls ............................................................................................................... 14

Installing and Removing the Battery ................................................................................................ 15

Using a Household Power Outlet..................................................................................................... 17

Subsequent Organization of This Manual........................................................................................ 18

1Basic Network Settings 19

Getting Ready .................................................................................................................................. 20

Displaying the Connection Wizard ................................................................................................... 21

Selecting the Communication Method and LAN Type ..................................................................... 22

Using the Wizard to Establish a Connection.................................................................................... 25

WPS Connections (PBC Mode) ....................................................................................................... 27

WPS Connections (PIN Mode) ........................................................................................................ 28

Configuring Network Settings .......................................................................................................... 29

2Transferring Images to an FTP Server 33

Configuring FTP Communication Settings....................................................................................... 34

Automatic Image Transfer After Each Shot ..................................................................................... 36

Transferring Images Individually ...................................................................................................... 38

Batch Transfer ................................................................................................................................. 40

Checking Image Transfer History .................................................................................................... 44

Viewing Transferred Images ............................................................................................................ 45

3Remote Capture Using EOS Utility 47

Configuring EOS Utility Communication Settings ............................................................................ 48

Using EOS Utility ............................................................................................................................. 51

4Remote Capture Using WFT Server 53

Configuring WFT Server Communication Settings .......................................................................... 54

Displaying WFT Server .................................................................................................................... 56

Viewing Images................................................................................................................................ 57

Remote Capture [Camera control] ................................................................................................... 59

Remote Capture [Simple control]..................................................................................................... 62

Remote Capture............................................................................................................................... 63

5Using the Transmitter as a Media Server 65

Configuring Media Server Communication Settings ........................................................................ 66

Displaying Captured Images on a Television................................................................................... 67

Contents

COPY

Contents

6Linked Shooting 69

Setting Up Linked Shooting ............................................................................................................. 70

Arranging the Slave Cameras.......................................................................................................... 72

7Managing Settings Information 73

Checking Settings ............................................................................................................................ 74

Changing Settings............................................................................................................................ 75

Saving and Loading Settings ........................................................................................................... 77

8Using External Media 79

Connecting External Media.............................................................................................................. 80

Choosing Recording Media When Shooting .................................................................................... 83

Using Together With a CF Card....................................................................................................... 85

Backing Up on External Media......................................................................................................... 86

9Using GPS Devices 91

Connecting GPS Devices with a USB Cable ................................................................................... 92

Connecting GPS Devices via Bluetooth........................................................................................... 95

10 Troubleshooting 99

Responding to Error Messages ..................................................................................................... 100

Wireless LAN Notes....................................................................................................................... 114

Checking Network Settings............................................................................................................ 115

11 Reference 117

WFT Utility (Software).................................................................................................................... 118

Creating and Registering Captions ................................................................................................ 120

Specifications................................................................................................................................. 121

Index .............................................................................................................................................. 129

COPY

To comply with local radio wave regulations in various areas around the world, Canon offers

four region-specific versions of the transmitter (WFT-E5A, E5B, E5C, and E5D) as

described below. Please do not use your model (version) of transmitter in regions it was not

designed for.

For information on other areas where the transmitter can be used, contact Canon’s

Customer Service Center.

In France, outdoor use is prohibited.

In mainland China, outdoor use requires a permit in some areas.

IEEE 802.11a Restrictions

When IEEE 802.11a wireless networking is used, channels in gray in the following table cannot

be used. These restrictions are established by local regulations, which must be upheld.

The transmitter can be used on channels in blue. Regarding channels in yellow, some

restrictions apply. Refer to the footnotes.

Areas of Use and Restrictions

Model

(Version) Area of Use Wireless LAN Specification

and Supported Channels

WFT-E5A United States, Canada, Singapore, and Hong Kong IEEE 802.11a 36 – 64 ch

149 – 165 ch

IEEE 802.11b/g 1 – 11 ch

WFT-E5B

Japan, France, Italy, Germany, United Kingdom, Belgium,

the Netherlands, Luxembourg, Ireland, Denmark, Greece,

Spain, Portugal, Austria, Finland, Sweden, Poland, Hungary,

Romania, Bulgaria, Czech Republic, Slovakia, Slovenia,

Estonia, Latvia, Lithuania, Cyprus, Malta, Iceland, Norway,

Switzerland, Liechtenstein, Australia, New Zealand, Russia,

and Hong Kong

IEEE 802.11a 36 – 64 ch

100 – 140 ch

IEEE 802.11b/g 1 – 13 ch

WFT-E5C Mainland China and Hong Kong IEEE 802.11a 149 – 161 ch

IEEE 802.11b/g 1 – 13 ch

WFT-E5D Can be used in all areas noted above IEEE 802.11a Not supported

IEEE 802.11b/g 1 – 11 ch

Wireless LAN

Connection Method Channel

WFT-E5A

Indoors Infrastructure 36 – 48 52 – 64 149 – 165

Ad hoc 36 – 48 52 – 64 149 – 165

Outdoors Infrastructure 36 – 48 52 – 64 149 – 165

Ad hoc 36 – 48 52 – 64 149 – 165

WFT-E5B

Indoors Infrastructure 36 – 48 52 – 64 100 – 140

Ad hoc 36 – 48 52 – 64 100 – 140

Outdoors Infrastructure 36 – 48 52 – 64*J100 – 140

Ad hoc 36 – 48 52 – 64 100 – 140

WFT-E5C 149 – 161*C

*J: In Japan, outdoor use on channels 52 – 64 is prohibited.

*C: In mainland China, outdoor use requires a permit in some areas.

COPY

Areas of Use and Restrictions

The following actions may be punishable under law. Disassembling or modifying the

transmitter, or removing the certification label on it.

Do not use the transmitter near other devices that emit radio waves, such as medical

equipment or electronic devices. The transmitter may interfere with operation of these

devices.

Use the transmitter only with a compatible EOS DIGITAL camera. Using it with incompatible

cameras may cause malfunction, accidents, and other problems not covered under

warranty.

Use the transmitter as a wireless or wired LAN device as described in this instruction

manual. If you use the transmitter for any other purpose, Canon cannot be held liable for

any loss or damage that may occur.

COPY

The following precautions are intended to prevent harm to you and others as well as damage to

equipment. Become familiar with the precautions before using the transmitter to ensure correct

and safe operation.

Be sure that you fully understand the safety precautions contained in the instruction manuals

for the battery, charger, and AC Adapter Kit before using them.

To prevent fire, excessive heat, chemical leakage, or explosion, follow these safety guidelines.

• Do not insert metallic objects between electrical contacts of the transmitter, accessories, or connecting cables.

Do not use the transmitter where there is flammable gas. There is a risk of explosion or fire.

If the transmitter is dropped and internal parts are exposed, do not touch the exposed parts. There is a risk of

electrical shock.

Do not disassemble or modify the transmitter. High-voltage internal parts may cause electrical shock.

Do not store the transmitter in dusty or humid places. There is a risk of fire or electrical shock.

Before using the transmitter on board airplanes or in hospitals, make sure use is permitted. Electromagnetic

waves emitted by the transmitter may interfere with instrumentation or medical equipment.

Do not leave the transmitter inside a vehicle in hot weather or near a heat source. The transmitter may become

hot and cause burns if touched.

Do not cover or wrap the transmitter with a cloth. This may trap heat inside, posing a risk of case deformation or

fire.

Do not use paint thinner, benzene, or other organic solvents to clean the transmitter. This poses a risk of fire and

may be hazardous to your health.

If the product malfunctions, becomes damaged, or requires repair, contact your dealer

or the nearest Canon Service Center.

The transmitter is a precision instrument. Do not drop it or subject it to shock.

The transmitter is not waterproof. Do not use it underwater.

Wipe off any moisture with a clean, dry cloth. If the transmitter has been exposed to salty air,

wipe it with a clean damp cloth after wringing it out to remove excess water.

Never leave the transmitter near any equipment that generates a strong magnetic field,

such as magnets or electric motors.

Do not leave the transmitter in excessive heat, such as in a vehicle in direct sunlight. High

temperature may damage the transmitter.

Do not wipe the transmitter using cleaners containing organic solvents. If the transmitter

becomes difficult to clean, take it to the nearest Canon Service Center.

To avoid corrosion, do not store the transmitter where there are strong chemicals, such as in

darkrooms or chemical labs.

Safety Warnings

Warning Preventing Serious Injury or Death

Caution Preventing Injury or Equipment Damage

Handling Precautions

COPY

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Émetteur

Canon

Canon Wireless File Transmitter WFT-E4 II A Manuel utilisateur

Canon

Canon WFT-E8A Manuel utilisateur

Canon

Canon WFT-E1 Manuel utilisateur

Canon

Canon WFT-E2 Manuel utilisateur

Canon

Canon WFT-E7 Ver.2 Manuel utilisateur

Canon

Canon 5743B002 Manuel utilisateur

Canon

Canon Wireless File Transmitter WFT-E7A Manuel utilisateur

Canon

Canon ST-E3-RT Manuel utilisateur

Canon

Canon Wireless File Transmitter WFT-E4 II A Manuel utilisateur

Canon

Canon WFT-E7 Manuel utilisateur

Canon

Canon WFT-R10 Instructions de montage

Canon

Canon EOS 5D - Focusing Screen Ee-A Manuel utilisateur

Canon

Canon WFT-E8 Manuel utilisateur

Canon

Canon ST-E3-RT Manuel utilisateur

Canon

Canon Wireless File Transmitter WFT-E2 II A Manuel utilisateur

Canon

Canon WFT-E1 Manuel utilisateur

Canon

Canon ST-E3-RT-V2 Manuel utilisateur

Canon

Canon WFT-E6 Manuel utilisateur

Canon

Canon Wireless File Transmitter WFT-E2 II A Manuel utilisateur

Canon

Canon WFT-E9 Instructions de montage

Canon

Canon WFT-E6 Manuel utilisateur

Canon

Canon Wireless Transmitter WFT-E6A Manuel utilisateur

Canon

Canon WFT-E6 Guide de démarrage rapide

Canon

Canon WFT-E2 Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
