Canon Pixma G2430 Manuel utilisateur



. )(     

Спершу прочитайте документ Інформація щодо

безпеки й важливі відомості )додаток(.

Посібник для початку

роботи

В первую очередь прочтите документ Информация

о безопасности и важные сведения )приложение(.

Руководство по началу

работы

Commencez par lire Sécurité et informations

importantes )addendum(.

Démarrage

Leia Informações Importantes e Sobre

Segurança )adendo( primeiro.

Para Começar

Lea primero Información de seguridad

e información importante )apéndice(.

Guía de inicio

Getting Started

Read Safety and Important Information

)addendum( rst.

1.......................................................................................................................................



6......................................................................................................................  

Установлення принтера........................................................................................................стор. 1

Як тримати принтер

Підключення до комп’ютера..............................................................................................стор. 6

Установка принтера....................................................................................................................стр. 1

Удерживание принтера

Подключение к компьютеру................................................................................................стр. 6

Installation de l'imprimante..................................................................................................page 1

Manipulation de l'imprimante

Connexion à un ordinateur...................................................................................................page 6

Instalando a impressora......................................................................................................página 1

Segurando a impressora

Conectando a um Computador ....................................................................................página 6

Instalación de la impresora ...............................................................................................página 1

Cómo sujetar la impresora

Conectar al ordenador.........................................................................................................página 6

Installing the Printer...................................................................................................................page 1

Holding the Printer

Connecting to a Computer...................................................................................................page 6

ENGLISH

Setting Up the Printer

1. Box Contents

• Print Heads

• Ink Bottles

• Power Cord

• Setup CD-ROM

• Safety and Important Information

• Getting Started (this manual)

2. Turning on the Printer

1 Connect the power cord.

Back

2 Press the ON button.

• The ON lamp lights.

Lit

Setting Up the Printer

Computer

Easy Setup Using Computer

Simple, easy-to-follow instructions are displayed on your computer.

1 Visit the URL below to start setup.

https://ij.start.canon/G2430

2 Follow the instructions to complete setup and print.

1 2

Easy Setup Using Computer Setup Using this Manual

Getting Started

ENGLISH

4. Installing the Print Heads

1 Open the scanning unit / cover.

Caution

Do not touch the print head holder until it stops moving.

2 Open the print head locking cover.

3 Take out each print head from the package and

remove the label.

4 Remove the orange tape.

5 Insert the C )color( print head on the left and the

B )black( print head on the right.

6 Close the print head locking cover and press

down until it clicks.

Setting Up the Printer

5. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are lled with ink. If ink gets on your clothes or

belongings, it may not come o.

1 Open the tank cap on the left of the printer.

2 Hold the ink bottle upright and gently twist the

bottle cap to remove.

Check!

PGBK

3 Align the nozzle of the ink bottle with the inlet.

4 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

5 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

6 Replace the tank cap securely.

ENGLISH

7 Repeat steps 1 through 6 to pour all ink into the

corresponding ink tanks on the right.

Check!

CM Y

8 Close the scanning unit / cover.

• If you lift the scanning unit / cover slightly and release

it, it will close by itself.

9 Press the OK button.

• The ON lamp ashes and the ink system preparation

starts. It takes about 6 minutes to complete.

Flashing

Count the number of ashes.

• 4 times

Print heads are not installed correctly.

"4. Installing the Print Heads" on page 3

• 5 times

Print heads cannot be recognized.

"4. Installing the Print Heads" on page 3

For all other cases, refer to the Online Manual.

If the Alarm lamp ashes or lights

Setting Up the Printer

6. Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website directly. No need to search.

https://ij.start.canon/connect

2 Enter your printer's model name and click Go.

3 Follow the on-screen instructions.

Using the Setup CD-ROM

1. Double click EasySetup.exe on the screen that appears.

2. If the printer selection screen appears, select G2430.

If the installation screen appears, click Next.

3. Follow the on-screen instructions.

If nothing appears, start Explorer and then run EasySetup.exe in the CD-ROM.

ENGLISH

1 Open the paper support.

2 Slide the right-hand side paper guide to the far

right.

3 Load several sheets of paper with the print side

facing up and slide the side paper guide against

the edge of the paper stack.

4 Press the Paper Select button, select a paper

size, and then press the OK button.

5 Extend the paper output tray.

Transporting Your Printer

When relocating the printer, check the following. Refer to the Online Manual for details.

Check if the tank caps are completely closed.

If the print head holder is in the center of the printer,

check that the cover is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using sucient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains at

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

Loading Paper
