TableofContents

TurningthePoweron ................................................................ 2

TurningthePoweroff ................................................................ 3

Paper ............................................................................................... 4

CompatiblePaper ................................................................................................ 4

PrintableAreas .................................................................................................... 7

IncompatiblePaper ............................................................................................. 8

LoadingPaper .............................................................................. 9

PaperJams(HowtoRemoveJammedPaper) .................... 12

LocatingJammedPaper ............................................................................... 12

RemovingJammedPaper ............................................................................. 12

PaperFeedArea[キュウシエリア] ....................................................................... 14

TopCoverArea[ウエカバーエリア] ...................................................................... 16

OutputArea[ハイシエリア] ..................................................................................... 20

CancelingPrinting(JobCancel)............................................... 23

CheckingOperation ................................................................. 25

TurningthePoweron

Whenyouturnthepoweron,thestatusoftheprinterandoptionaldevice(s)ischeckedbefore

printingisenabled.

Pressinthepowerbuttononthe

leftsideoftheprinter.

Whentheprinterison,thetopofthepower

buttonislevelwiththesurfaceoftheprinter.

Whentheprinteristurnedon,theoperation

panelindicatorsandthedisplaycomeson

andthestatusoftheprinterandoptional

device(s)isself-diagnosed.

Iftheresultsoftheself-diagnosisarenormal,

printing is enabled. The オンライン

indicator,the印刷可 indicatorandthe

selectedpaperfeedindicatorcomeonand

themessage [00 インサツカノウ]

appearsonthedisplay.

オンライン 排出

リセット／実行

動作モード

メッセージ ジョブ印刷可

セットアップ

ユーティリティ

ジョブキャンセル

給紙選択



ｲﾝｻﾂ



ｶﾉｳ



Thefollowinginformationappearsonthedisplay.

00ｲﾝｻﾂｶﾉｳA4



Printingenabled,no

printingdatabeing

processed

Currentlyselected

paperfeedsize

TurningthePoweroff

Whenthepoweristurnedoff,alloftheprintingdatainthememoryislost.Alwayscheckthat

theジョブindicatorisoffbeforeturningthepoweroffinordertoavoiddeletingimportant

printingdatabyaccidentordeletingprintingdatafromanothercomputerwhenconnectedtoa

network.

● Ifthepoweristurnedoffwhentheジョブindicatorison,anyprintingdata

remainingintheprinter’smemoryislost.Pressthe 排出 keywhileoff-

linetooutputanyimportantprintingdatabeforeturningoffthepower.

● Donotturnoffthepowerwhileprinting.

● Donotturnoffthepowerduringtheself-diagnosiscarriedoutimmediately

afterturningthepoweron.

Checkthattheジョブindicatoris

off.

メッセージ ジョブ印刷可



ｲﾝｻﾂ



ｶﾉｳ



Off

Pressthepowerbuttonontheleft

sideoftheprinter.

Whentheprinteristurnedoff,thepower

buttonpopsoutfromthesurfaceofthe

printer.

Powersaving(Paneloffmode)

Theprintercanbesettopaneloffmodeinordertoreducethepowerconsumed.Whenthe

printerissettopaneloffmode,alloftheindicatorsexcept印刷可indicatorgooffifno

operationsarecarriedoutandnodataissentfromthecomputerforasettime.

Thepaneloffmodeisautomaticallycanceledifdataissentfromthecomputeroranoperation

panelkeyispressed.

Thepaneloffmodeissetusingthemenufunction.

Paper

CompatiblePaper

Thisprintercanusethefollowingtypesofpaper.○indicatesthatsingle-sideprintingcanbe

performed,and×indicatesthatprintingcannotbeperformed.

■ PaperSizes

PaperSource

Papertype Papertray Papercassette 250-sheet

paperfeeder

(option)

Plainpaper(64-105g/

)

A5 ○ ○ ○

B5 ○ ○ ○

A4 ○ ○ ○

Letter ○ ○ ○

Executive ○ ○ ○

Legal ○ ○ ○

Userpaper*1

width:76.2-215.9mm ○ × ×

length:127-355.6mm

Thickpaper(106-163g/m

)

width:76.2-215.9mm ○ × ×

length:127-355.6mm

TransparenciesA4 ○ × ×

LabelsheetA4 ○ × ×

*1Whenyouareusingplainpaperoflessthan100g/m2weight,youcanonlyprintonpaper

largerthanA5-sizepaper.

● Loadthepaperlengthwise.

■ No.ofSheetsStoredinPaperSources

PaperSource

Papertype Papertray Papercassette 250-sheet

paperfeeder

(option)

Plainpaper(64g/m2) approx.100 approx.250 approx.250

Thickpaper(128g/m2) approx.50 × ×

Transparencies approx.50 × ×

Labelsheet approx.40 × ×

■ No.ofSheetsOutput

Papertype Output*2

Face-downtray Face-uptray

Plainpaper(64g/m2) approx.150 approx.50

Thickpaper(128g/m2) approx.40*3approx.30

Transparencies approx.10*31

Labelsheet approx.60*3approx.40

*2Theactualnumberofoutputsheetsvariesaccordingtotheestablishedenvironment.

*3Theface-downtraycanbesetasthestandardoutputdestinationbutbecausethiscould

causethepapertocurlorcrease,werecommendtheface-uptray.

●Thickpaper

Paperwhichis106-163g/m2canbeusedwiththisprinter.Alwaysloadpaperofthisthickness

intothepapertray.

● Whenyouwanttoprintonthickpaper,alwaysselect[給紙方法]fromthe[給

紙]sheetoftheprinterdriverandthenselect[手差し(トレイ)].

● Transparencies

Itcanbedifficulttoseparatetransparenciesfromeachother.Pickthemuponeatatimeandby

allfoursides,andthenloadthemintothepapertray.

● Whenprintingfaceupontransparencies,removethetransparenciesoneat

atimeastheycomeout.

● Whenyouwanttoprintontransparencies,alwaysselect[給紙方法]from

the[給紙]sheetoftheprinterdriverandthenselect[手差し(トレイ)].

● Labelsheet

Checkthatthelabelsheetisfaceupwhenyouloaditintothepapertray.

● Donotusethefollowingtypesoflabelsheet.Thereisariskofseverejamming

anddamagetotheinsideoftheprinter.

・ Labelsheetwithsomeadhesivesurfacesexposed

・ Labelsheetwithsomepartsofthelowersurfaceexposedontheupper

surface

・ Labelsheetwithlabelsthatpeeloffeasily

● Whenfeedinglabelsheetsideways,removeeachsheetbyhandoneata

time.Thefirstsheetsprintedoutmightcurl.

● Whenyouwanttoprintonlabelsheet,alwaysselect[給紙方法]fromthe[給

紙]sheetoftheprinterdriverandthenselect[手差し(トレイ)].

PrintableAreas

Thisprintercanprintoverareasofpaperwithinthefollowingranges.

● Plainpaper,thickpaper,transparencies,labelsheet

5mm

5mm5mm

IncompatiblePaper

Inordertoavoidpaperjamsanddamagingtheprinter,donotusethefollowingkindsofpaper.

● Paperthatjamseasily

・Paperthatistoothickortoothin

・Non-standardsizepaper

・Wetordamppaper

・Tornpaper

・Coarseorextremelysmoothpaper

・Paperwithbinderholes,serratedpaper

・Curledpaper,creasedpaper

・Speciallycoatedpaper

・Labelsheetwithlabelsthatpeeloffeasily

・Paperwhichhasalreadybeenusedforphotocopyingorlaserprinting(reversesidealso

incompatible)

・Paperwhichhasraisedsurfaces

・Wrinkledpaper

・Foldedpaper

● Heat-sensitivepaper

・Paperwithinkthatmelts,burnsorgivesofftoxicvapoursintheheatofthefixingassembly

(apporox.150｡C)

・Thermalpaper

・Colorpaperwithaprocessedsurface

・Speciallycoatedpaper

・Paperwithadhesiveonit

● Paperthatcancauseprintermalfunctionordamage

・Carbonpaper

・Paperwithstaples,clips,ribbonsortapeattached

・Paperwhichhasalreadybeenusedforphotocopyingorlaserprinting(reversesidealso

incompatible)

● Paperonwhichtonercannotfixeasily

・CoarsepapersuchaspulppaperandJapanesewritingpaper

・Paperwithroughfibers

・Speciallycoatedpaper

LoadingPaper

Youcanloadupto250sheets(64g/m2)ofplainA5-,B5-(B5-JIS),A4-,Executive-,Letter-and

Legal-sizepaperintotheprinter’spapercassette.Loadallpaperlengthwise.

Followtheprecautionsbelowinordertoavoidpaperjamming.

● Donotremovethepapercassetteduringprinting.Doingsocanleadto

paperjammingordamage.

● Donotloadpaperwhichhasraisedparts,creasesorcurlededges.

● Donotloadpaperbeyondthepaperlimitmark.Thenumberofplain(64g/m2)

sheetsthatcanbeloadedareapproximately250.

● SeePaper(→p.4)fordetailsonthekindsofpaperthatcanbeused.

Followtheinstructionsbelowwhenloadingpaperintothepapercassette.Youcanalsofollow

theseinstructionswhenloadingpaperintothepapercassetteofthe250-sheetpaperfeeder.

Pressdownthelockbuttononthe

rearofthepapersizeguideq,and

movethepapersizeguidetothe

markindicatingthesizeofthe

paperyouwanttoloadw.

Positionthepapersizeguidesothatthe

triangularmarkpointstothesizeindicator

ofthepaperthatyouwanttoload.

● IfyouwanttouseB5-sizepaper(182 ×257mm)movetheguidetothe

positionshowninthediagrambelow(sideofB5-JIS).Theguidecannotbe

usedattheB5-ISOposition.

B5-JISposition B5-ISO

position
