Canon PIXMA MX522 Manuel utilisateur

<< Previous Next >>

Installing Your Multifunction to

Additional Computers on Your Network

PIXMA MX522

Windows OS

<< Previous Next >>

Installing Your Multifunction to

Additional Computers on Your Network

PIXMA MX522

Windows OS

Preparing to Connect My Multifunction to My Network 3

Network Requirements 3

Notes on Wireless Connection 4

Installing the Drivers 5

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

Wireless Connection

Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that

configuration of the computer and access point or router is complete.

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Notes on Network Connection

•The configuration, router functions, setup procedures and security settings of

the network device vary depending on your system environment. For details,

refer to your device's instruction manual or contact its manufacturer.

•In an office setup, consult your network administrator

•If you connect to a network that is not protected with security measures, there

is a risk of disclosing data such as your personal information to a third party.

•If an error message appears or if you have trouble with the network

connection, refer to the printed manual: Network Setup Troubleshooting.

•Place the machine and computer on the same network segment.

An "Ad-hoc connection," which establishes a direct

connection to the computer over a wireless connection

without using an access point, is not supported.

Software Installation

To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk.

(The installation time varies depending on the computer environment or the number of application software to be installed.)

Installing the Drivers & Software

IMPORTANT

•Log on as the administrator (or a member of the Administrators group).

•Quit all running applications before installation.

•Do not switch users during the installation process.

•Internet connection may be required during the installation. Connection fees may apply. Consult the internet service provider.

•It may be necessary to restart your computer during the installation process. Follow the on-screen instructions and do not remove the

Setup CD-ROM during restarting. The installation resumes once your computer has restarted.

•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access

the network. If such a warning message appears, set the security software to always allow access.

<< Previous Next >>

Installing the PIXMA MX522 to additional Windows computers on your

Wireless Network

If your MX522 has already been set up on your wireless network , it is only necessary to install the software on the additional

computer(s). No additional settings need to be made on the printer. Network connection will be confirmed automatically.

Simply insert the Setup CD-ROM that came with your printer into your CD-ROM drive and proceed through the easy to follow

instructions.

Installing the Drivers & Software

<< Previous Next >>

1. Insert the CD-ROM into the computer*.

*If you don’t have or cannot use your Setup CD-ROM, you can still install the printer on your computer using drivers available on our

web site. Click here for information

Installing the Drivers & Software

<< Previous Next >>

When the Software Installation List screen appears, select any software to be installed. MP Drivers is required for the printer to be able to

print and scan and cannot be de-selected. My Image Garden and Quick Menu are highly recommended to take full advantage of your

printer’s features. Click Next after selecting the software.

Continue to follow any remaining instructions

Installing the Drivers & Software

<< Previous

Installing the PIXMA MX522 on Your Wireless Network

If you can’t find or use your Setup CD-ROM, you may download the MX520 series MP Drivers , which includes a step-by-step installation, by

following the instructions below:

1. Click here to access the MX522 Drivers & Software page.

2. Select the operating system and version of your computer (see example below).

3. Expand the ‘Drivers’ section, if necessary, by clicking the red triangle.

4. Click on ‘MX520 series MP Drivers’ .

5. After reading the details and disclaimer, click ‘I Agree – Begin Download’ and save the file to your computer.

6. Once the download is complete, double-click the file from its download location to begin the installation.

In the same manner, My Image Garden and Quick Menu are available as downloads in the Software section of Drivers

& Software. These programs are recommended to take full advantage of your printer’s features. Double-click the

downloaded file(s) to start the installation.
