S R X

DRIVER INFORMATION

Instrument Panel . . . . . . . . . . . . . .1

Instrument Panel Cluster . . . . . . .2

Driver Information Center . . . . . .3

COMFORT

Manual Seat Adjustments . . . . . .4

Power Seat Adjustments . . . . . . . .4

Power umbar..................5

HeatedSeats ...................5

Memory Seat and Mirrors . . . . . .5

Second-Row Seat . . . . . . . . . . . . . . .6

Third-Row Access . . . . . . . . . . . . . . .6

Power Third-Row Seat . . . . . . . . . .6

Child Restraints ( ATCH) . . . . . . . .7

Climate Control . . . . . . . . . . . . . . . . .7

Rear Air Conditioning . . . . . . . . . . .8

ENTERTAINMENT

AudioSystem...................9

XM™ Satellite Radio . . . . . . . . . . .11

Touch Screen Navigation

Entertainment System . . . . . . . .11

Rear Seat Entertainment

System ........................11

CONVENIENCE

OnStar® .......................12

Universal Home Remote . . . . . .13

Ultrasonic Rear Parking Assist

(URPA) ........................13

UltraView Sunroof . . . . . . . . . . . .13

Power Adjustable Pedals . . . . . .14

Cruise Control . . . . . . . . . . . . . . . . .14

Adaptive Remote Start . . . . . . . .14

Instrument Panel

and Courtesy ights . . . . . . . . . . .15

Rear Washer/Wiper . . . . . . . . . . .15

PERFORMANCE & MAINTENANCE

Engine Fuel . . . . . . . . . . . . . . . . . . .16

Transmission . . . . . . . . . . . . . . . . . .16

Traction and Stability . . . . . . . . . .16

OWNER PRIVI EGES™

Roadside Service . . . . . . . . . . . . . .17

Customer Assistance . . . . . . . . . .17

Cadillac Online . . . . . . . . . . . . . . . .17

TABLE OF CONTENTS

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 2

Refer to your Owner Manual for more information.

Driver

Information

Comfort Entertainment Convenience erformance &

maintenance

Owner

rivileges™

Driver Information

A. Air Outlets

B. Turn Signal/Multifunction Lever

C. Instrument anel Cluster

D. Windshield Wiper Lever

E. Audio System/Navigation System

(if equipped)

F. Driver Information Center Controls

G. Audio Steering Wheel Controls

H. Climate Control

I. Traction Control Button

J. Shift Lever

K. Hazard Warning Flashers

Button

L. Glove Box

INSTRUMENT ANEL

AB C D A

GI K

❏Reviewed with Customer (Please Check Box)

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 3

INSTRUMENT

ANEL CLUSTER

A. Engine Coolant

Temperature Gage

B. Tachometer

C. Speedometer

D. Fuel Gage

ABCD

S R X

Note: Some of the gages and indicators may differ from the illustration presented. The

instrument panel cluster is designed to let you know about many important aspects of your

vehicle’s operation.

It is important for you to read your Owner Manual and become familiar with the information

that is being relayed to you by the lights, gages and indicators, particularly the message center,

as well as what action can be taken to ensure your safety and to prevent damage.

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 4

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information. 3

Driver

Information

Comfort Entertainment Convenience erformance &

Maintenance

Owner

rivileges™

Your vehicle’s Driver Information

Center (DIC) provides vehicle

information, vehicle feature

personalization and vehicle warning

messages.The DIC messages will

be shown on your instrument

cluster display.

The following DIC buttons are

located on the left side of the

instrument panel:

(Customization): Press this

button to scroll through the

following customization settings:

• Display anguage

• Auto Door ock

• Auto Door Unlock

• Remote Door ock

• Remote Door Unlock

• Delay Door ock

• Exit ighting

• Approach ighting

• Chime Volume

• Park Tilt Mirrors

• Easy Exit Seat (if equipped)

• Memory Seat Recall

(if equipped)

• Remote Start (if equipped)

• Factory Settings

(Trip/Fuel): Press this button to

scroll through the following trip and

fuel information:

• Trip A or Trip B

• Fuel Range (until empty)

• Average Fuel Economy

• Instantaneous Fuel Economy

• Fuel Used

• Timer On/Off

• Average Speed

• Battery Voltage

(Vehicle Information): Press

this button to scroll through the

following vehicle information:

• Oil ife Remaining

• Units (English/Metric)

• Parking Assist

• Front Tires or Rear Tires

(Current tire pressures)

• Relearn Remote Key

• Speedometer

DRIVER INFORMATION CENTER (DIC)

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 5

(Set/Reset): Press this button to

reset DIC information while it is

displayed or to acknowledge a

warning message.

(Menu Up/Down): Press this

button to scroll up or down the

menu items.

Customization Settings

To customize features:

1. Place the vehicle in Park (P).

2. Press the (Customization)

button to enter the Feature

Settings menu and scroll through

the available features.

3. Press the (Set/Reset) button to

access the settings for the feature

being displayed.

4. Press the (Menu Up/Down)

button to scroll through the

available settings for each feature.

5. Press the (Set/Reset) button to

choose the setting being displayed

and move to the next feature.

Warnings and Messages

The DIC provides a variety of vehicle

warning messages (depending on

optional equipment) if a problem is

sensed in a vehicle system.

To acknowledge a message and

clear it from the display, press the

(Set/Reset) button. Some urgent

messages cannot be cleared from

the DIC display.

Check Engine or Other Warning

Lights with OnStar® (if equipped)

If your Check Engine light, or any

other warning message appears,

you can push the blue OnStar

button and speak to a live advisor.

OnStar Advisors can access certain

diagnostic information and can tell

you how serious the problem is,

what you should do about it, or can

contact a dealer or Roadside service

for you. Refer to the OnStar Owner

Guide for details.

Comfort

MANUAL SEAT ADJUSTMENTS

( assenger side only)

Use the bar at the front of the seat

to adjust seat position. Use the lever

at the side of the seat to raise or

recline the seatback.

OWER SEAT ADJUSTMENTS

The power seat controls are

located on the outboard sides

of the front seats.

S R X

Note: Your vehicle’s warning messages

provide critical information that can

prevent damage to your vehicle. Review

your Owner Manual to become familiar

with the information displayed and the

action required.

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 6

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information. 5

Driver

Information

Comfort Entertainment Convenience erformance &

Maintenance

Owner

rivileges™

ower Seat Adjustments

Use the horizontal control (A) to:

• Move the seat forward or

rearward by sliding the control

forward or rearward.

• Move the seat up or down by

moving the entire control up

or down.

• Raise or lower the front or rear

part of the seat cushion by

moving the front or rear of the

control up or down.

Seatback Adjustments

Use the vertical control (B) to:

• Recline the seatback by tilting the

top of the control rearward.

• Bring the seatback forward

by tilting the top of the

control forward.

OWER LUMBAR (If equipped)

The power lumbar switch is located

beneath the power seat switch

controls. Hold the control forward

or rearward to increase or

decrease support.

HEATED SEATS (If equipped)

The following heated seat controls

are located on the front doors:

(Heated Seatback): Press

this button to turn on the

heated seatback.

(Heated Seat and Seatback):

Press this button to turn on the

heated seat and seatback.

There are three heated seat

temperature settings (high, medium

and low). Continue to press the

desired button to decrease the

temperature setting. To turn off the

feature, press the button until all

indicator lights are off.

MEMORY SEAT AND MIRRORS

(If equipped)

The memory seat controls are

located on the front doors.

Memory Recall

Press memory button 1 or 2 to recall

the memory settings for the driver’s

seat, outside mirrors and adjustable

pedals.The memory seat setting

also can be programmed to be

recalled automatically using

the DIC.

To save memory settings:

1. Adjust the driver’s seat, outside

mirrors and adjustable pedals to

a comfortable position.

2. Press and hold button 1 or 2

until two beeps sound.

3. Repeat these steps for a

second driver.

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 7

Easy Exit Seat

With the vehicle in Park (P), press

the (Easy Exit Seat) button to

recall the exit position for the

driver’s seat. Press the button

again to move the seat back

farther. The easy exit seat also

can be programmed to move

automatically using the DIC.

SECOND-ROW SEAT

Adjusting the Seat

An adjustment lever to move the

seat forward or rearward is located

under each side of the 60/40 seat.

After adjustment, move the seat

back and forth to make sure it

locks into place.

THIRD-ROW ACCESS

The right side of the second-row

60/40 seat has an easy entry feature

to make it easier to get into and out

of the third-row seat, if equipped.

To operate the easy entry seat:

1. Pull the release lever located on

the top of the seat upward.

2. Tilt the seatback forward

by pulling the top of the

seat forward.

3. Pull upward on the release lever

located on the back of the seat

and rock forward until it stops.

OWER THIRD-ROW SEAT

(If equipped)

The third-row seat includes a

power-folding feature to provide

additional cargo space. Before the

seat can be folded, the headrests

must be removed and stored.

Removing Headrests

1. Press the button on top of the

seatback below the headrest and

pull up on the headrest.

2. Open the storage compartment

cover behind the seat and insert

the headrest posts into the slots

in the storage area.

The seatback will not fold all the

way down if the headrests are

not removed.

Folding/Unfolding Seat

Before folding or unfolding the

third-row seat, all of the following

conditions must be met:

• The vehicle must be in Park (P)

and not have a low battery.

• The liftgate or right-side rear

door must be open.

S R X

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 8

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information. 7

Driver

Information

Comfort Convenience erformance &

Maintenance

Owner

rivileges™

• The ignition must be in ON or

ACC. If not, pressing the Unlock

button on the key fob or door

three times will enable power

folding or unfolding for

two minutes.

Two buttons are located on the

right-side panel behind the second-

row seat. One button (A) folds and

raises the seat and another button

(B) changes the seatback angle.

The other button

seat is located

inside the liftgate.

Press and hold either folding button

to fold or unfold the seat.

After the seat is folded, the panel on

the back of the seat must be flipped

forward to create a flat floor space.

Before returning the seat to its

upright position, the panel must be

returned to its folded position.

CHILD RESTRAINTS (LATCH)

Your vehicle is equipped with ATCH

anchors, and may have top tethers

for use with a ATCH compatible

child restraint. If your child restraint

is not compatible with the ATCH

system, you may still use it by

installing the child restraint with

the seat belt system.

Choose a child restraint that is

appropriate for the child’s age

and size (weight and height).

See Section 1 of your Owner

Manual for more information.

CLIMATE CONTROL

The dual-zone climate control

system can be operated manually or

can be set to automatically adjust to

the individual settings of the driver

and front seat passenger.

Automatic Operation

In the automatic mode, the system

adjusts the airflow, fan speed, air

conditioning and recirculation

functions to reach and maintain the

set temperature(s).

To set the automatic mode:

1. Turn the fan knob to the

AUTO position.

2. Turn the airflow knob to the

AUTO position.

3. Adjust the temperature to a

comfortable setting using the

temperature arrow buttons.

Entertainment

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 9

Manual Operation

Use the following controls to

operate the system manually:

(On/Off): Press this button to

turn the climate control system on

or off.

(Fan): Turn the fan knob to

increase or decrease fan speed.

(Air Conditioning): Press the fan

knob to turn the air conditioning on

or off.

Airflow Control: Turn the airflow

control knob to the following

positions to change the direction of

the airflow.

(Vent): Directs air to the

instrument panel outlets.

(Bi-Level): Directs air to

the instrument panel outlets

and floor outlets.

(Floor): Directs air to the

floor outlets.

(Defog): Directs air to the

windshield, side window outlets

and floor outlets.

(Defrost): Directs most of the

air to the windshield and some air

to the side window outlets.

(Rear Window Defogger): Press

the airflow control knob to turn the

rear window defogger on or off.

⌃/ (Temperature Control): Press

the arrow buttons next to the fan

knob to adjust the driver’s

temperature setting, and press the

arrow buttons next to the airflow

control knob to adjust the

passenger’s temperature setting.

(Recirculation): Press this

button to recirculate inside air and

keep outside air from entering the

vehicle. Recirculation will not

function in defog or defrost mode.

ASS ( assenger’s Climate Control):

Press this button to turn the front

passenger’s climate control system

on or off.

REAR AIR CONDITIONING

(If equipped)

The rear air conditioning system

provides air conditioning to the

second- and third-row occupants.

The system includes four air outlets:

two over the outboard second-row

seats and two more near the cargo

area or third-row seat (if equipped).

The system can be controlled from

the front overhead console or it can

be placed in the AUX mode to allow

rear passengers to control the

system from the second-row

overhead console.

⌃

S R X

111839_09a_SRX_GTK_042908.qxd:SRX 2007 A 4/29/08 4:38 PM Page 10

Autres manuels pour 2009 SRX

Table des matières

Autres manuels Cadillac Automobile

Cadillac

Cadillac 2008 DTS Manuel utilisateur

Cadillac

Cadillac 2014 XTS Manuel utilisateur

Cadillac

Cadillac 2003 DeVille Manuel utilisateur

Cadillac

Cadillac ESCALADE - BROCHURE 2011 Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Cadillac

Cadillac 2006 CTS-V Manuel utilisateur

Cadillac

Cadillac 2014 Cadillac SRX Manuel utilisateur

Cadillac

Cadillac 2014 ELR Manuel utilisateur

Cadillac

Cadillac CTS 2008 Guide de référence

Cadillac

Cadillac 54-6219 1954 Guide d'installation

Cadillac

Cadillac 2009 SRX Manuel utilisateur

Cadillac

Cadillac 2008 STS Manuel utilisateur

Cadillac

Cadillac ESCALADE - BROCHURE 2009 Manuel utilisateur

Cadillac

Cadillac CAR SUPERCHARGED 4.4L NORTHSTAR V8 Manuel utilisateur

Cadillac

Cadillac Escalade Two-mode Hybrid 2009 Manuel utilisateur

Cadillac

Cadillac GMC Yukon Denali 2005 Manuel utilisateur

Cadillac

Cadillac 1999 Escalade Manuel utilisateur

Cadillac

Cadillac DTS 2006 Guide de référence

Cadillac

Cadillac STS - BROCHURE 2011 Manuel utilisateur

Cadillac

Cadillac CTS SPORT WAGON - BROCHURE 2010 Manuel utilisateur

Cadillac

Cadillac 2015 Escalade Manuel utilisateur

Cadillac

Cadillac 2011 CTS-V Sports Sedan Manuel utilisateur

Cadillac

Cadillac 1998 Catera Manuel de la liste des pièces

Cadillac

Cadillac 2011 STS Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Skoda

Skoda FABIA RS - ANNEXE 118 Manuel utilisateur

Seat

Seat toledo Manuel utilisateur
