Cabletron Systems MMAC-Plus 9H423-28 Manuel

9032060-01

SmartSwitch 9000

9H423-28

Local Management Appendix

Appendix

9H423-28 Module Speciﬁc

Information

Introduction

This appendix contains local management information that is speciﬁc to the

9H423-28 Ethernet Module.

The 9H423-28 Ethernet Module is a 28-port switching module with:

• 24 10Mb front panel Ethernet ports (2 RJ71 Telco)

• 4 100Mb front panel Ethernet ports (2 RJ45, 1 FEPIM, & 1 MMF SC)

• 1 Internal Network Bus (INB) backplane port

Modifying Fields and User Privileges

To modify ﬁelds on this module, you must have read-write or super-user

privileges. If you have read-only privileges, you can view information; however,

you cannot modify any ﬁelds. For more information about user privileges and

community names, see the

SmartSwitch 9000 Module Local Management User’s

Guide.

9H423-28 Module Speciﬁc Information

Module Interface Codes

The 9H423-28 Module has 33 interfaces. Table 1 lists the identifying number,

name, and description of each interface.

Table 1. 9H423-28 Module Interface Codes

Interface

Number

Interface

Name

Interface

Description

1 SMB1 1 Mbps System Management Bus

2 SMB10 10 Mbps System Management Bus

3 HOST i960 Host

4 LOCAL i960 Controller

5 INB Internal Network Bus

6 ENET1 Ethernet Front Panel Port 1

7 ENET2 Ethernet Front Panel Port 2

8 ENET3 Ethernet Front Panel Port 3

9 ENET4 Ethernet Front Panel Port 4

10 ENET5 Ethernet Front Panel Port 5

11 ENET6 Ethernet Front Panel Port 6

12 ENET7 Ethernet Front Panel Port 7

13 ENET8 Ethernet Front Panel Port 8

14 ENET9 Ethernet Front Panel Port 9

15 ENET10 Ethernet Front Panel Port 10

16 ENET11 Ethernet Front Panel Port 11

17 ENET12 Ethernet Front Panel Port 12

18 ENET13 Ethernet Front Panel Port 13

19 ENET14 Ethernet Front Panel Port 14

20 ENET15 Ethernet Front Panel Port 15

21 ENET16 Ethernet Front Panel Port 16

22 ENET17 Ethernet Front Panel Port 17

23 ENET18 Ethernet Front Panel Port 18

9H423-28 Module Speciﬁc Information

Use the numbers listed in Table 1 to conﬁgure the module’s default interface (see

the General Conﬁguration Screen).

24 ENET19 Ethernet Front Panel Port 19

25 ENET20 Ethernet Front Panel Port 20

26 ENET21 Ethernet Front Panel Port 21

27 ENET22 Ethernet Front Panel Port 22

28 ENET23 Ethernet Front Panel Port 23

29 ENET24 Ethernet Front Panel Port 24

30 ENET25 Ethernet Front Panel Port 25

31 ENET26 Ethernet Front Panel Port 26

32 ENET27 Ethernet Front Panel Port 27

33 ENET28 Ethernet Front Panel Port 28

Table 1. 9H423-28 Module Interface Codes (Continued)

Interface

Number

Interface

Name

Interface

Description

9H423-28 Module Speciﬁc Information

Port Conﬁguration Screen

The 9H423-28 Port Conﬁguration Screen (Figure 1), allows you to conﬁgure the

Desired Operational Mode and the Advertising Ability of the module.

Figure 1. 9H423-28 Port Conﬁguration Screen

SmartSwitch 9000 Local Management

Port Configuration

Module Name: 9H423-28 Firmware Revision: 01.05.02

Slot Number: 5 BOOTPROM Revision: 01.02.00

PORT #:25

Port Type RJ45

Link Status No Link

Current Operation Mode UNKNOWN

Buffer Utilization Rx [ Auto ] Tx

Desired Operation Mode [Auto-Negotiation]

Advertised Ability [10Base-T] [Enabled]

SAVE PORT #:[25] EXIT RETURN

9H423-28 Module Speciﬁc Information

Port Conﬁguration Screen Fields

The following information brieﬂy explains each Port Conﬁguration Screen ﬁeld.

Port #

Displays the port number of the current 100 Mb Ethernet port.

PortType

Displays one of the following values:

• AUI

• BNC

• EPIM-x

• FE-xx

• MMF SMA

• MMF SC

• RJ45

• RJ71

• SMF ST

Link Status

Displays the status of the Link Integrity pulse for the twisted pair or ﬁber optic

segment. You will see one of the following:

• Link

• No Link

Current Operational Mode

Displays the operational mode that was set using the Desired Operational Mode

ﬁeld.

Buffer Utilization (Toggle)

Allows you to specify how the Receive (Rx) and Transmit (Tx) buffers will be

utilized (on a percentage basis). Valid choices are:

• Auto

• 80/20

• 60/40

• 40/60

• 20/80

9H423-28 Module Speciﬁc Information

Desired Operational Mode (Toggle)

Allows you to specify how you want the port to communicate with a device. If

you specify Auto-Negotiation, the port and the device automatically synchronize

communication. Valid modes are:

• Auto-Negotiation

• 10Base-T

• 10Base-T FD (Full Duplex)

• 100Base-TX

• 100Base-TX FD (Full Duplex)

• 100Base-T4

• 100Base-FX

• 100Base-FX FD (Full Duplex)

Advertised Ability (2Toggles)

Allows you to specify which Operational Modes the port should use (Enabled) or

not use (Disabled) in Auto-Negotiation. By

default

, operational modes are

Enabled

Disabling an Operational Mode for Auto-Negotiation

To disable an Operational Mode for Auto-Negotiation:

1. Make sure the Desired Operational Mode ﬁeld displays

Auto-Negotiation

2. Use the arrow keys to highlight the left toggle ﬁeld.

3. Press the

Space

Bar

to display an Operational Mode you want to disable.

4. Use the arrow keys to highlight the right toggle ﬁeld.

5. Press the Space Bar until

Disabled

is displayed.

The Operational Mode is disabled.

6. To disable another Operational Mode, repeat steps 2 through 5.

Changing to Another Port

To change to another port:

1. Use the arrow keys to highlight the

Port #

ﬁeld at the bottom of the screen.

2. Press the

Space

Bar

to increment (or press the

Backspace

key to decrement)

the port number.

9H423-28 Module Speciﬁc Information

Port Statistics Screen

The 9H423-28 Port Statistics Screen (Figure 2), displays information and statistics

about the module’s Ethernet ports.

Figure 2. 9H423-28 Port Statistics Screen

SmartSwitch 9000 Local Management

Port Statistics

Module Name: 9H423-28 Firmware Revision: 01.05.02

Slot Number: 5 BOOTPROM Revision: 01.02.00

PORT #: 1

OCTETS: 0 LINK STATUS: No Link

PACKETS: 0

TOTAL ERRORS: 0 PORT TYPE: RJ71

COLLISIONS: 0

CRC/ALIGNMENT ERRORS: 0 PORT STATUS: ENABLED

UNDERSIZE PACKETS: 0

OVERSIZE PACKETS: 0 APPLICATION: BRIDGING

FRAGMENTS: 0

JABBERS: 0 OPERATION MODE:

BROADCASTS: 0

MULTICASTS: 0 AUTO NEGOTIATION:

PORT #:[ 1] EXIT RETURN

9H423-28 Module Speciﬁc Information

Port Statistics Screen Fields

The following information brieﬂy explains each Port Statistics Screen ﬁeld.

PORT #

Indicates the current port for which statistics are displayed.

OCTETS

Displays the number of octets transmitted and received.

PACKETS

Displays the number of packets transmitted and received.

TOTAL ERRORS

Displays the total number of errors on this port.

COLLISIONS

Displays the total number of collisions detected on this port.

CRC/ALIGNMENT ERRORS

Displays the number of packets with bad Cyclic Redundancy Checks (CRC) that

have been received from the network. The CRC is a 4-byte ﬁeld in the data packet

that ensures that the transmitted data that is received is the same as the data that

was originally sent. Alignment errors are due to misaligned packets.

UNDERSIZE PACKETS

Displays the number of packets received whose size was less than the minimum

Ethernet frame size of 64 bytes, not including preamble.

OVERSIZE PACKETS

Displays the number of packets received whose size exceeded 1518 data bytes,

not including preamble.

FRAGMENTS

Displays the total number of packets received that were not an integral number of

octets in length or that had a bad Frame Check Sequence (FCS), and were less

than 64 octets in length (excluding framing bits but including FCS octets).

JABBERS

Displays the total number of packets received that were longer than 1518 octets

(excluding framing bits, but including Frame Check Sequence (FCS) octets), and

were not an integral number of octets in length or had a bad Frame Check

Sequence.

BROADCASTS

Displays the number of broadcasts received.
