BWI Eagle AIR-EAGLE SR PLUS Manuel

PRODUCT INFORMATION

BULLETIN

105 Bonnie Drive

Butler, PA 16002

724-283-4681

724-283-5939 (fax)

www.bwieagle.com

AIR-EAGLE®SR PLUS

2.4 GHz RF Transmitter

MODEL 36-1400-AC

DESCRIPTION

The AIR-EAGLE SRPLUS TX is an R.F. transmitter capable of sending

four independent dry contact input commands to an Air-Eagle SR

Receiver from up to 600 feet away. Any number of transmitters and

receivers can be combined to create a medium-range remote control

system that operates hazardous or hard-to-reach electrical apparatus

from safe, convenient locations. This unit has eight user-selectable

network frequencies to allow multiple systems to operate

simultaneously in the same area without interference.

APPROVALS

United States (FCC)

MCQ-XBEE3

Canada (IC)

1846A-XBEE3

Europe (CE)

ETSI

INSTALLATION

1. Mount the AIR-EAGLE SR PLUS TRANSMITTER in a convenient

location.

2. Install wiring to contact input terminal strip (Note –the terminal block

header lifts off the base for easy wiring)

3. Attach supplied antenna to connector on right side of unit.

4. Connectsupplied power input cable to your external power source.

TERMINAL STRIP WIRING

Wire as shown based on number of contact inputs

C Input 1

Input 1

C Input 2

Input 2

C Input 3

Input 3

C Input 4

Input 4

100-250 VAC (N)

Power Input

100-250 VAC (H)

Power Input

GENERAL OPERATION

A closure on any input transmits its channelcommand to activate the

corresponding relay in the remote receiver. The transmission continues as

long as the input is closed and ceases when the input opens.

Dimensions (with mounting plate) 6.3” L x 4.8” W x 2.3” H

CONTROLS & INDICATORS

TX LED

Illuminates green when power is applied.

Changes to red while any contact input is

closed and unit is transmitting.

Dry Contact Inputs

Transmits individual RF codes to the receiver

SEL1

Dip switch bank for frequency selection

SEL2

Dip switch bank for digital address selection

AIR-EAGLE®SR PLUS

2.4 GHz RF Transmitter

MODEL 36-1400-AC

FREQUENCY & DIGITAL ADDRESS SET-UP

This transmitter is factory programmed to Frequency “1”and Digital

Address “1”. These settings can be changed by the user in any

combination but must match the receiver that is set up to

communicate with this transmitter. Note –only change digital

address if using with a digitally addressable receiver. Otherwise, the

digital address must be kept at the default of Digital Address “1”.

1) Remove power from unit.

2) Remove top cover.

3) Select desired network frequency and/or digital address using table

below.

4) Reattach cover and apply power.

5) Programming is now complete.

FREQUENCY SET-UP

SEL1 (SW1-3)

SEL1

(SW1-3)

Network

Frequency

SW1

SW2

SW3

1 (default)

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

SEL1 (SW4) –Not used on this model

DIGITAL ADDRESS SET-UP

SEL2 (SW1 –4)

SEL2

(SW1-4)

Digital

Address

SW1

SW2

SW3

SW4

1 (default)

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

SEL2 (SW5-7) –Leave in OPEN position!!

SPECIFICATIONS

Power Input

100-250 VAC, 5 W, 50/60 Hz

Transmit Frequency

2.4GHz Spread Spectrum

Transmitter Inputs

Dry Contact

RF Networks

Eight Independent Frequencies

Digital Addresses

Sixteen

RF Networks

Eight Independent Frequencies

RF Output Power

60 mW

Transmit Range

Up to 600 Feet

Note: Max range figures are estimates, based on free-air terrain with limited sources of

interference. Actual range will vary based on transmitting power, orientation of

transmitter and receiver, height of transmitting antenna, height of receiving antenna,

weather conditions, interference sources in the area, and terrain between receiver and

transmitter, including, but not limited to, indoor and outdoor structures such as walls,

metal objects, trees, buildings, hills, and mountains

Antenna Connection

TNC Female

Enclosure

Polycarbonate, IP66 (NEMA 4)

Operating Temperature

-40oF to +185oF

ACCESSORIES

Standard Antenna (Included):

2.4GHz TNC “Rubber Duck” Antenna

49-1201

Mobile/Base Antennas –

Used to help achieve max range in both nonline of sight andline of

sight applications. - Contact BWI Eagle for recommendations

2.4GHz Thru-Hole Mount Mobile Antenna

49-2201

2.4GHz Magnet Mount Mobile Antenna

49-2202

2.4GHz Omni Directional Base Antenna

49-3201

2.4GHz Yagi Directional Base Antenna

49-3202

High Quality Coax Cables –

Used to connect external high gain antennas to control unit

Flex Coax Cable w/Connectors –Available in

5’,15’,25’,30’,40’,60’,80’,100’ Lengths

49-4000-XX

(XX = # of

Feet)

Bulkhead Extensions –

Used to provide an external antenna connection whenmounting

control unit inside another enclosure

TNC Male to TNCBulkhead CableAssembly -

Available in 2’, 4’, 7’ Lengths

49-5004-X-ISO

(X = # of Feet)

DOCUMENT DATE: 07/21/2021 / PRODUCT REV. 6

WARRANTY STATEMENT

BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly used and installed, will be free

from defects in material and workmanship for a period of 1 year after date of purchase. Said warranty to

include the repair or replacement of defective equipment. This warranty does not cover damage due to

external causes, including accident, problems with electrical power, usage not in accordance with product

instructions, misuse, neglect, alteration, repair, improper installation, or improper testing. This limited

warranty, and any implied warranties that may exist under state law, apply only to the original purchaser of

the equipment, and last only for as long as such purchaser continues to own the equipment. This warranty

replaces all other warranties, express or implied including, but not limited to, the implied warranties or

merchantability and fitness for a particular purpose. BWI Eagle makes no express warranties beyond

those stated here. BWI disclaims without limitation, implied warranties of merchantability and fitness for a

particular purpose. Some jurisdictions do not allow the exclusion of implied warranties so this limitation

may not apply to you. To obtain warranty service, contact BWI Eagle for a return material authorization.

When returning equipment to BWI Eagle, the customer assumes the risk of damage or loss during

shipping and is responsible for the shipping costs incurred.

SIGNAL RANGE

Max range statements are estimates based on a clear line of sight with few interferences. Actual range will

vary based on transmitting power, orientation of transmitter and receiver, height of transmitting and

receiving antennas, weather conditions, electronic interference, terrain, and physical obstacles, including

but not limited to; walls, building structures, trees (foliage), metal objects, and landscape (hills, mountains).

WIRELESS STOP, ASTOP, and E-STOP SYSTEMS

Wireless E-STOP systems should never be considered a primary life-saving device. At

least one hard-wired switch must be available in the event the wireless system is not

operational. Failure to comply may result in serious injury or death to personnel and

damage to equipment.

Wireless STOP and ASTOP transmitters are not failsafe emergency stop controls.

They are NOT to be used as a life-saving device. They are designed for wireless

control of equipment or vehicle remote operation. Failure to use as intended may result

in serious injury or death to personnel and damage to equipment.
