PRIME TRAIL CAMERA

INSTRUCTION MANUAL

Model# 119932C / 119932CB 08-20

IMPORTANT NOTE

Congratulations on your purchase of one of the best trail camer-

as on the market! Bushnell is very proud of this little unit and we

are sure you will be pleased with it as well. We appreciate your

business and want to earn your trust. Please refer to the notes

below and the instructions in this manual to ensure that you are

completely satisfied with this product.

If your Bushnell Prime Trail Camera does not seem to be

functioning properly or if you are having photo/video quality

issues, please check the Troubleshooting/FAQ section.

Problems are often due to something simple that was

overlooked, or require only changing one setting to solve.

If your problem continues after trying the solutions in the

Troubleshooting/FAQ section, please call Bushnell Customer

Service at (800) 423-3537. In Canada, call (800) 361-5702. For

EU owners, email: [email protected]

Bushnell recommends using 6 Energizer® Lithium AA batteries

in this Prime Trail Camera model to obtain maximum battery life.

Do not mix old and new batteries.

Do not mix battery types-use ALL lithium or ALL alkaline.

Rechargeable batteries are NOT recommended.

Bushnell recommends using SanDisk® SD and SDHC Cards (up

to 32GB capacity) in all Prime Trail Camera.

INTRODUCTION

About the Prime Trail Camera

The Bushnell Prime Trail Camera is a digital scouting camera. It can be triggered

by any movement of game in a location, detected by a highly sensitive Passive

Infra-Red (PIR) motion sensor, and then take high quality pictures (up to 24MP still

photos), or 720p HD video clips.

The Prime Trail Camera consumes very little power (less than 0.08 mA) in a stand-

by (surveillance) state. This means it can deliver up to twelve months stand-by

operation time when the device is powered by six AA alkaline batteries. Once

motion in the monitored area is detected, the digital camera unit will be triggered at

once (typically less than half a second) and then automatically take images

according to previously programmed settings. The Prime Trail Camera is equipped

with built-in infrared LEDs that function as a flash, so that it delivers clear photos or

videos (in black & white) even in the dark, and it can take color photos or videos

under sufficient daylight. The Prime Trail Camera is designed for outdoor use and

is resistant against water and snow.

Applications

The Prime Trail Camera can be used as a trail camera for hunting or scouting

game. It is also suitable for surveillance usage.

PARTS AND CONTROLS

The Prime Trail Camera provides the following connections for external devices:

USB port and SD card slot (Fig. 4).

A 3-way power switch is used to select the main operating modes: OFF, AIM, and

ON (Fig. 3).

A D-Pad interface with 5-way keys is primarily used in AIM mode to select

operational functions and parameters. As shown in Fig. 3, these keys are: UP,

DOWN, LEFT, RIGHT, OK and MENU. Three of the keys can also perform a second

function (shortcut operations in AIM mode) in addition to their main function: The

DOWN key can be used to set the camera to Photo mode (still camera icon), and

the UP key can set the camera to Video mode (movie camera icon). The RIGHT key

also serves as the manual shutter (“SHOT”) button of the camera. These second-

ary functions are indicated by icons or text above the key as shown in Fig. 3.

Fig. 1

Fig. 2

Fig. 3

Fig. 4

INSTALLING THE BATTERIES AND SD CARD

Before you begin learning how to use your Prime Trail Camera, you will first need

to install a set of batteries and insert an SD card. Although that may only take you a

minute, there are some important notes about both batteries and SD cards you

should be aware of, so please take the time to read the following directions and

cautions:

Loading Batteries

After opening the latch on the right side of the Prime Trail Camera, you will see that

the Prime Trail Camera has a battery release button. Depress this button and a

battery tray will drop out of the bottom of the camera. The battery tray will stop about

½ inch out of the device, this is a latch system to prevent the tray from dropping onto

the ground. Just apply a little pressure when pulling and the tray will release. The

battery tray has six battery slots. Install a full set of 6 batteries. Be sure to insert

each battery with correct polarity (negative or “flat” end against the long spring of

each battery slot).

Bushnell recommends using a full set of new lithium AA (Energizer® brand) or

alkaline AA batteries. NiMh Rechargeable batteries are not recommended, as the

lower voltage they produce can cause operational issues.

You can also connect an optional Solar Panel accessory (model# 119756C –please

visit www.bushnell.com for more information) to the “DC In” jack at the bottom of the

Prime Trail Camera (other external power supplies should not be used, as the

camera and/or display may not function correctly). If the solar panel is connected

and AA batteries are installed, the Prime Trail Camera will be powered by the solar

panel's rechargeable lith-ion battery, as long as it provides adequate voltage (if not,

the camera will switch to battery power). The solar panel's battery will power the

camera at night.

Inserting the SD Card

Insert the SD card (with the camera’s power switch in the OFF position) before

beginning to operate the camera. Don’t insert or remove the SD card when the

power switch is in the ON position.

The Prime Trail Camera uses a standard SD (Secure Digital) memory card to save

photos (in .jpg format) and/or videos (in .avi format). SD and SDHC (High Capacity)

cards up to a maximum 32GB capacity are supported. Before inserting the SD card

into the card slot after opening the camera’s front cover, please make sure that the

write- protect switch on the side of the card is “off” (NOT in the “Lock” position). The

following describes how to insert and remove the SD card:

• Insert the SD card into the card slot with its label side upwards (see above). A

“click” sound indicates that the card is installed successfully. If the wrong side of the

card is facing up, you will not be able to insert it without force-there is only one

correct way to insert cards. If the SD card is not installed correctly, the device will

not display an SD card icon on the LCD in SETUP mode (the SD card icon displayed

after switching to SETUP mode will have a “lock” symbol inside it in it if the card is

locked). Formatting the SD card by using the Prime Trail Camera “Format”

parameter before using it for the first time is recommended, especially when a card

has been used in other devices (see “Changing Menu Parameter Settings” for

details).

• To take out the SD card, just gently push in the card (do not try to pull it out

without pushing in first). The card is released from the slot and ready to be removed

when you hear the click. Be sure the camera’s power is switched OFF before

inserting or removing SD cards or batteries.

USING THE Prime Trail Camera

Once you’ve prepared your Prime Trail Camera by properly installing batteries and

an SD card, you could simply take it outside, strap it to a tree, switch it on and leave-

and you might get some great photos that are exactly what you wanted.

However, we highly recommend that you first spend some additional time indoors

with this manual and your camera until you know a bit more about what the 3-way

switch and direction keys do. If nothing else, you’ll probably want to at least set the

date and time so the camera will imprint them (or not-it’s your option) on your photos

as they are taken, learn how to set the camera to shoot video clips instead of still

photos if you like, and read some tips about mounting it on a tree.

THE OFF, ON, AND AIM MODES

The Prime Trail Camera has three basic operational modes:

• OFF mode: Power switch in the OFF position.

• ON mode: Power switch in the ON position (LCD screen is off.)

• AIM mode: Power switch at AIM position (LCD screen is on).

OFF MODE

The OFF mode is the “safe” mode when any actions must be taken, e.g., replacing

the SD card or batteries, or transporting the device. You will also use OFF mode if

you connect the camera to a computer’s USB port later to download your

photos/videos. And of course, when you are storing or not using the camera, you

will switch it to OFF. Please note that even in the OFF mode the Prime Trail Camera

still consumes power at a very low level. Therefore, it’s a good idea to take the

batteries out of the battery compartment if the camera will not be used for a long time.

ON MODE

Any time after the batteries and SD card have been inserted, you can switch on the

camera. When the power switch is moved to the far left position, the camera will

enter into the ON (Live) mode. The motion indicator LED (Fig.1, “Front View”) will

blink red for about 10 seconds. This interval allows time for you to close the Prime

Trail Camera’s front cover, lock it, and leave the monitored area. Once in the ON

mode, no manual controls are needed or possible (the control keys have no effect).

The Prime Trail Camera will take photos or videos automatically (according to its

current parameter settings) when it is triggered by the PIR sensor’s detection of

activity in the area it covers.

You can either move the power switch directly from OFF to ON mode, or stop at the

AIM position first to change one or more settings, then move the switch to ON after

you have finished doing so.

AIM MODE

In the AIM mode you can check and change the settings of the Prime Trail Camera

with the help of its built-in LCD. These settings, found in the SETUP Menu, let you

change the photo or video resolution, interval between photos, switch the time

imprint on, etc. Moving the power switch to the AIM position will turn on the LCD

display, and you will see an information screen that shows how many images have

been taken, the battery level, camera or video mode, etc (see Fig. 5).

NOTE: Always move the power switch from OFF to AIM mode. It is possible that the

camera could lockup if it is switched from ON to AIM mode. If this occurs, simply

move the switch to OFF and then push it up to AIM again.

AIM Mode Shortcut Keys/Functions

As mentioned earlier in “Parts & Controls”, three of the keys below the LCD have

secondary, “shortcut” functions when the camera is switched to AIM mode (but the

MENU key has not been pressed):

• Press the UP key to quickly set the camera to shoot video clips.

• Press the DOWN key to quickly set the camera to take still photos.

• Press the RIGHT key to manually trigger the shutter. This is useful for testing

the camera-make sure you are in AIM mode, press the RIGHT key, and a few

seconds later a photo or video (depending on how the camera was set) will be saved

to the SD card. The “number of images taken” counter on the bottom left of the LCD

will increase by one. If the display indicates “SD PROTECTED” when you press the

SHOT key, switch the camera OFF, remove the SD card and slide its protect switch

off.

Fig.5: SETUP Information Screen

USING THE SETUP MENU TO CHANGE SETTINGS

The main purpose of the AIM mode is to allow you to change the settings of the

camera’s parameters so your Prime Trail Camera operates exactly the way you

want it to. You will do this by entering the SETUP Menu and pressing the keys

beside the LCD display, which will show you each parameter and its setting.

Changing Parameter Settings in SETUP Mode

A wide range of options or “parameters” are provided to allow you to set the Prime

Trail Camera to your operational preferences. To change the setting of any

parameter you must first switch to the AIM mode. Once in AIM mode, pressing the

MENU button will allow you to select any parameter and change its setting. The

name of the parameter and its current setting will be shown on the LCD. Pressing

the RIGHT or LEFT key scrolls to the next or previous parameter (RIGHT key to

move on to the next parameter and LEFT key to go back to the previous parame-

ter), and pressing the UP or DOWN key lets you select a different setting for the

currently displayed parameter. Once you have selected your preferred new setting

for a parameter, press the OK button to save the new setting (actually change it).

When you are finished changing the settings of one or more parameters, press

MENU again to exit the SETUP menu. MENU can also be pressed anytime you

want to cancel changing a parameter’s setting after a new setting has been selected

(but OK has not been pressed yet). After setting the parameters to your preferences,

be sure to move the switch to ON to begin actually taking photos or videos. No

images will be captured if the switch is left in the AIM position (unless you press the

RIGHT/Shot key after exiting the menu) - in fact, the camera will power off

automatically after a few seconds with no key pressed.

To make the Parameter Settings easier, we have made the camera with 3 basic

settings (Set Clock / Mode / Interval) and an “Additional Set” which allows custom-

er to access to the full suite of settings if you turn the “Additional Set” on.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Bushnell Caméra de repérage

Bushnell

Bushnell X-8 TRAIL CAM 119327 Manuel utilisateur

Bushnell

Bushnell 119466 Manuel utilisateur

Bushnell

Bushnell Trailscout 119700 Manuel utilisateur

Bushnell

Bushnell Trophy Cam Agressor 11977 Manuel utilisateur

Bushnell

Bushnell TRAIL SENTRY 119320C Manuel utilisateur

Bushnell

Bushnell NatureView 119739 Manuel utilisateur

Bushnell

Bushnell TRAIL SENTRY 11-9200 Manuel utilisateur

Bushnell

Bushnell TROPHY CAM 119425C Manuel utilisateur

Bushnell

Bushnell Trail Scout 11-9833 Manuel utilisateur

Bushnell

Bushnell WIRELESS Trophy Cam HD Manuel utilisateur

Bushnell

Bushnell TROPHY CAM 119628C Manuel utilisateur

Bushnell

Bushnell Trophy Cam 119435 Manuel utilisateur

Bushnell

Bushnell 119437 Manuel utilisateur

Bushnell

Bushnell TROPHY CAM HD ESSENTIAL 119736C Manuel utilisateur

Bushnell

Bushnell TROPHY CAM 119437C Manuel utilisateur

Bushnell

Bushnell Trophy Cam HD Aggressor 119875 Manuel utilisateur

Bushnell

Bushnell Trail Scout 11-9501 Manuel utilisateur

Bushnell

Bushnell TROPHY CAM 119626C Manuel utilisateur

Bushnell

Bushnell CELLUCORE 20 SOLAR Manuel utilisateur

Bushnell

Bushnell TROPHY CAM HD VITAL 119726C Manuel utilisateur

Bushnell

Bushnell Trail Sentry 119302 Manuel utilisateur

Bushnell

Bushnell 119432CW Manuel utilisateur

Bushnell

Bushnell 119438 Manuel utilisateur

Bushnell

Bushnell 119600 Guide d'installation

Manuels Caméra de repérage populaires d'autres marques

Nestbox

Nestbox C13 Manuel utilisateur

Wildview

Wildview STC-TGL1 Manuel utilisateur

Stealth Cam

Stealth Cam CORE STC-Z3IRTL Manuel utilisateur

Suntek

Suntek HC-800M Manuel utilisateur

Spypoint

Spypoint G4 Manuel utilisateur

Duramaxx

Duramaxx 10029765 Manuel utilisateur

Brecom

Brecom C2400 Manuel utilisateur

BlazeVideo

BlazeVideo A280W Manuel utilisateur

Bestok

Bestok 5210GM Manuel utilisateur

GardePro

GardePro X60P Manuel utilisateur

Delta-Opti

Delta-Opti HC-SG880MK-18MHD Manuel utilisateur

PNI

PNI HUNTING 280C Manuel utilisateur

Muddy

Muddy Pro-Cam 14 Manuel utilisateur

Bresser

Bresser 3310006 Manuel utilisateur

Recon Outdoors

Recon Outdoors HS410 Manuel utilisateur

Braun

Braun 57660 Manuel utilisateur

Wildgame

Wildgame Shadow Manuel utilisateur

Spypoint

Spypoint FLEX Manuel utilisateur
