Bushnell 119904D Manuel utilisateur

CELLUCORE 20 DUAL SIM MODEL # 119904D

INSTRUCTION MANUAL

CELLUCORE 20 DUAL SIM TRAIL CAMERA

WELCOME

Welcome to your Bushnell Trail Camera! This manual has all

the instructions you need to set up your camera and your

account, plus quick answers to your questions.

If your camera does not seem to be functioning properly

or if you are having image quality issues, please check the

Troubleshooting Tips section.

If your problem continues after trying the solutions in

Troubleshooting Tips, please call Bushnell Customer Service

at (800) 423-3537. In Canada, call (800) 361-5702.

Note: This Bushnell trail camera model is not designed

or intended for operation or sale outside of the United

States.

TABLE OF CONTENTS

Camera Overview 4

Camera Status Indicator Guide 6

Quick Start Guide 6

Settings Menu 10

Mounting & Positioning 12

Frequently Asked Questions 15

Technical Speciﬁcations 17

Two-Year Limited Warranty 18

CAMERA OVERVIEW

Lens

Control Panel

Cover

DC In

Temperature

Sensor

Motion

Indicator

Antenna

LED IR Flash

Latch

Lock Hole

PIR Sensor

Temperature

Sensor

Motion

Indicator

Battery Tray

SD Card Slot

Camera Status

Indicator Lights

Power On/Off

Camera Status

Indicator Guide

Battery

Panel Door

Wake Up

Battery Life

CAMERA STATUS INDICATOR GUIDE

1. Download the free Bushnell Trail

Camera app on your smartphone from

the App Store (iPhone®) or Google

Play® (Android®).

2. Open the app, then sign in or create

a new account.

QUICK START GUIDE

Look here to identify what a green, yellow,

or red light means for your camera status

and battery life.

Cellular Signal Indicator Lights

Camera Status Indicator Light

Battery Life

3. Log in and click the Camera icon

at the bottom of the screen, then

click “+” to add a new camera. Scan

the QR code on the label inside your

camera again or manually enter its

serial # to associate this camera

with your account.

4. Install 12 AA batteries (Energizer®

lithium batteries are recommended.

Alkaline batteries may be used

but battery life will be shorter.

Rechargeable batteries are not

recommended). Be sure to position

the batteries for correct polarity

(+/-) when installing.

5. Install a new SD card, up to

32GB. High speed cards (class 10

or higher) are recommended if you

plan to record video clips.

6. Your CelluCORE 20 Dual Sim is

equipped with a dual SIM modem.

The camera will automatically

connect to the carrier with the

strongest service (ATT or Verizon)

each time the camera is powered

on. If you want to ensure you have

the strongest signal in a given

area, simply power the camera

off and power it back on. This will

ensure you have maximum signal

x12

Cellular Signal Indicator Lights

strength. (We recommend using

your camera in a location that gives

you minimally two bars of signal

strength. Lower signal strength can

cause interruptions in service and

shorten battery life.)

7. Your Cellucore 20 Dual Sim comes

equipped with a detachable solar

panel. Removing and repositioning

the panel allows you to achieve

maximum sunlight and solar

charging regardless of where

the camera lens is pointed. To

reposition your panel, remove the

thumb screw from the back of the

solar panel and mount the panel

in another location using a 1/4x20

mounting bracket (not included).

(Hint: replace the thumb screw so

that you do not misplace it.) Connect

the panel to the camera with the

included alternate power supply

cable. (This cable is only needed

when the solar panel is detached

from the camera)

8. At the location where you will

place the camera, move the power

switch to the On position. The

camera’s default settings were

chosen for typical usage as a

scouting camera for hunters: photo

mode at 2MP resolution, with a 10

second interval between photos,

and “Medium” LED ﬂash power

OFF ON

output. These settings may be easily

changed to suit your individual

preferences or application (for

example, if you would rather capture

videos, or photos at a different

resolution, spaced further apart),

using the app on your smartphone or

home computer.

9. Prior to closing the camera,

ensure the camera has acquired

cellular signal and is operating

properly by checking the camera

status indicator lights and guide.

Lower signal strength can cause

interruptions in service and shorten

battery life.

Mount the camera to a tree or post

using the provided tree strap or

1/4”-20 mounting socket.

Your wireless camera is now ready to use. You can now utilize

the mobile application or management website to review

images, change camera settings, monitor battery life and

manage your account.

Android® and Google Play® are registered trademarks of Google Inc. iPhone® is a

registered trademark of Apple, Inc.

(see pg. 6 for camera status

indicator guide)

Camera

Status

Battery

Life

Cellular Signal

(Check your app for these settings)

SETTINGS MENU

CAMERA MODE - Selects type of image ﬁles that are stored/

transmitted (note: see “Hybrid” under Video submenu).

IMAGE - Still images will be captured by the camera at

settings made in the PHOTO menu.

MOVIE - Video clips will be captured at settings made in the

VIDEO menu. NOTE: your full HD video ﬁles will be stored on

the SD card, but they cannot be transmitted wirelessly due to

the ﬁle size/cell carrier bandwidth.

HYBRID- Captures a single image followed by a video clip.

IMAGE RESOLUTION - Selects resolution (in megapixels)

for still photos. Higher resolution provides more pixels for

increased detail, but creates larger ﬁles that take up more

of the SD card capacity (ﬁlls up faster). Available settings

are: Low, medium and high. Low is the default setting, which

will deliver excellent detail while still keeping the ﬁle size per

image reasonable for most users.

CAPTURES PER TRIGGER- Selects the number of photos

captured per trigger event, with settings from 1 to 5 (default

is 1 photo per trigger).

VIDEO RESOLUTION - Selects resolution for video clips.

Choice of 1280x720 (720p), or 960x544 (544p).

VIDEO LENGTH - Selects duration of each video clip captured

per trigger. The default setting is 5S (ﬁve seconds per video).

From the 10 SEC setting up, length settings are in 5 second

increments. Maximum video length is 20 Seconds.

CAMERA NAME - Allows you to enter up to 12 characters
