Brother HL-L6300DW Manuel utilisateur

Reference Guide

Brief explanations for routine operations

HL-L6300DW

HL-L6300DWT

HL-L6400DW

HL-L6400DWT

Brother recommends keeping this guide next to your Brother machine for quick reference.

Online User's Guide

This Reference Guide contains basic instructions

and information for your Brother machine.

For more advanced instructions and information,

see the Online User's Guide at

solutions.brother.com/manuals

User's Guides and Where to Find Them

Which Guide? What's in It? Where Is It?

Product Safety Guide Read this Guide first. Please read the Safety

Instructions before you set up your machine.

See this Guide for trademarks and legal

limitations.

Printed / In the box

Quick Setup Guide Follow the instructions for setting up your

machine, and installing the drivers and

software for the operating system and

connection type you are using.

Printed / In the box

Reference Guide Learn the basic operations and basic

machine maintenance. See troubleshooting

tips.

Printed / In the box

Online User's Guide This guide includes the additional contents of

the Reference Guide.

In addition to information about the Print

operations, useful information is included

about using the machine on a network.

HTML and PDF file /

Brother Solutions

Center 1

Web Connect Guide This Guide provides useful information about

accessing Internet services from the Brother

machine, as well as downloading images and

printing data.

PDF file / Brother

Solutions Center 1

AirPrint Guide This Guide provides information for using

AirPrint to print from OS X v10.8.5 or later

and your iPhone, iPod touch, iPad, or other

iOS device to your Brother machine without

installing a printer driver.

PDF file / Brother

Solutions Center 1

Google Cloud Print Guide This Guide provides details about how to use

Google Cloud Print™ services for printing

over the Internet.

PDF file / Brother

Solutions Center 1

Mobile Print/Scan Guide

for Brother iPrint&Scan

This Guide provides useful information about

printing from your mobile device when

connected to a Wi-Fi® network.

PDF file / Brother

Solutions Center 1

1Visit solutions.brother.com/manuals.

The Online User's Guide Helps You Get the Most

Out of Your Machine

We hope that you find this guide helpful. To learn more about your machine's features, please

take a look at our Online User's Guide. It offers:

Quicker Navigation!

Search box

Navigation index in a separate panel

Comprehensive!

Every topic in one guide

Simplified Layout!

Provides step-by-step instructions

Feature summary at the top of the page

1. Search Box

2. Navigation

3. Summary

4. Step-by-Step Instructions

To View Online User's Guides

To view the Online User's Guide and other available guides, visit solutions.brother.com/manuals.

(Windows®)

You can also access your machine's guides using Brother Utilities. The Brother Utilities tool is

included in the standard installation and, when installed, you can find it either as a shortcut on

your desktop, or from the Windows® Start menu.

Questions or Problems? Please Take a Look at

our FAQs, Solutions, and Videos Online.

Go to your model's FAQs & Troubleshooting page on the Brother Solutions Center at

support.brother.com.

•Provides several ways to search!

•Displays related questions for more information

•Receives regular updates based on customer feedback

Since the Brother Solutions Center is updated regularly, this screen is subject to change without

notice.

Control Panel Overview

The control panel may vary depending on your model.

1. Touchscreen Liquid Crystal Display (LCD)

Access menus and options by pressing them on the Touchscreen.

2. Power On/Off

• Turn the machine on by pressing .

• Turn the machine off by pressing and holding down . The LCD displays [Shutting

Down] for a few seconds before going off.

3. Touchpanel

(Back)

Press to go back to the previous menu.

(Home)

• Press to return to the Home screen.

• While the machine is in Sleep Mode, the Home icon blinks.

1General Information

(Cancel)

• Press to cancel an operation (available when lit).

• Press to cancel a programmed print job and clear it from the machine’s memory. To

cancel multiple print jobs, hold down until the LCD displays [Cancel All Jobs].

Press to display the previous or next page.

4. (WiFi)

(For infrastructure mode)

When the WiFi light is on, your Brother machine is connected to a wireless access point.

When the WiFi light blinks, the wireless connection is down, or your machine is in the process

of connecting to a wireless access point.

(For Ad-Hoc mode)

The WiFi LED is always off.

1General Information

Touchscreen LCD

Overview

From the Home screen, you can access the

Wi‑Fi setup, Toner level, Settings, and

Functions screen.

The Home screen displays the machine’s

status when the machine is idle. This screen

is also called the Ready Mode screen. When

displayed, this screen indicates that your

machine is ready for the next command.

If Active Directory® Authentication or LDAP

Authentication is enabled, the machine's

control panel will be locked.

The available features vary depending on

your model.

1. (Wireless Status )

If you are using a wireless connection, a

four-level indicator in the Home screen

displays the current wireless signal

strength.

0 Max

• If you see at the top on the

screen, press it to configure wireless

settings.

2. (Toner)

Displays the remaining toner life. Press to

access the [Toner] menu.

3. [Settings]

Press to access the [Settings] menu.

Use the Settings menu to access all of

your Brother machine's settings.

If Setting Lock has been turned on, a lock

icon appears on the LCD. You must

unlock the machine to change settings.

4. [Functions]

Press to access the Functions screen.

•[Secure]

Press to access the Secure Print

option.

•[Web]

Press to connect the Brother machine

to an Internet service. For more

information, see the Web Connect

Guide. Go to your model's Manuals

page on the Brother Solutions Center at

support.brother.com to download the

guide.

Warning icon

The warning icon appears when there

is an error or maintenance message; press

to view it, and then press to

return to Ready Mode.

1General Information

Access Brother Utilities

(Windows®)

Brother Utilities is an application launcher

that offers convenient access to all Brother

applications installed on your computer.

1Do one of the following:

• (Windows® XP, Windows Vista®,

Windows® 7, Windows Server® 2003,

Windows Server® 2008 and Windows

Server® 2008 R2)

Click (Start) > All Programs >

Brother > Brother Utilities.

• (Windows® 8 and Windows Server®

2012)

Tap or click (Brother Utilities)

either on the Start screen or the

desktop.

• (Windows® 8.1 and Windows

Server® 2012 R2)

Move your mouse to the lower left

corner of the Start screen and click

(if you are using a touch-based

device, swipe up from the bottom of

the Start screen to bring up the Apps

screen).

When the Apps screen appears, tap

or click (Brother Utilities).

2Select your machine (where XXXX is

the name of your model).

3Choose the operation you want to use.

Load Paper in the

Paper Tray

Use the paper tray when printing on the

following media:

Plain paper

Thin paper

Recycled paper

Letterhead

Coloured paper

Thick paper 1

• Adjust the guides

• Fan the paper

For more information, see the Online User's

Guide: Load and Print Using the Paper Tray.

Load Paper in the Multi-

purpose Tray (MP Tray)

Use the MP tray when printing on the

following media:

Plain paper

Thin paper

Recycled paper

Bond paper

Letterhead

Coloured paper

Thick paper 2

Labels 2

Envelopes 2

• Adjust the guides

• Fan the paper

For more information, see the Online User's

Guide: Load and Print Using the

Multi

‑

purpose Tray (MP Tray).

2Load Paper

1Open the back cover (face up output tray) before printing to let the printed paper exit onto the face up output tray.

2Open the back cover (face up output tray) before printing to let the printed paper exit onto the face up output tray.

2Load Paper
