Brother GTX Manuel utilisateur

brother

UNCRATING:

Step by Step Photo

Instructions (Including

Using a Move Kit)

Step 1

2

•After cutting and removing the strapping

material.

•Remove the top cover of the crate.

Step 2

3

•Remove the side paneling cardboard from

each side of the crate.

Step 3

•Remove the front and back paneling from

the crate.

•After removing the paneling; remove any

pieces of cardboard inserts with the

exception of the three items at the front of

the printer.

•Only empty cardboard inserts are to be

removed like the ones indicated here in

the photo to the left.

KEEP THESE

DISPOSE OF THIS TYPE OF INSERT

4

Step 4

•Remove the platen box from the crate. It is

located at the front right of the printer on the

crate. Also indicated in the top photo here.

•NOTE: Do not dispose of this box it contains

the platen for the printer.

•Remove the Accessories box from the crate

located at the front left of the printer.

•Store this item for the installing technician

•NOTE: Do not dispose of this box it contains

the print heads for the printer and other

needed items for setup

5

Step 5

KEEP

DISPOSE OF

•Remove the large cardboard that has the Setup

Manual attached to it.

•Dispose of this piece of cardboard and keep the

manual.

•In total the three items in the bottom photo should

now be available for a technician at the time of setup.

Do not open or dispose of the boxes.

•If you WILL NOT be going through doorways less

than 42” wide then you may stop here. If you WILL

be going through smaller doorways and a move kit

was sent with the printer then proceed to the next

step.

6

STOP

Step 6

•Make a rubber mallet ready for the next

step. (Note: there are other ways to

remove the items in the upcoming steps

without the rubber mallet however this is a

recommended item)

20

Step 7

8

•Take the hammer and tap the two back

supports previously indicated until they come

loose from the glue holding them.

•The printer will still remain raised as it rests on

several other cardboard supports.

•You can now dispose of the two supports as

well once removed.

Step 8

9

•With the hammer take and knock down the

cardboard corner or slit with boxcutter.

•Do this for both corners at the back of the

printer as shown.

Step 9

•Ready the move kit: portable trolley and ratchet strap.

•With the move kit ready mount the trolley in the

manner shown

10
